Installation - Right: Removal & Installation Chrysler Crossfire I

Note. The arrows on the engine mounts must be located in the retaining slots on the engine bracket.

1. Position the engine mount (3) on the crossmember.
2. Install the engine mount lower bolt (4). Tighten the bolt to 35 N.m (26 ft. lbs.). NOTE: The recesses of the heat shield must be located in the anti twist slots of the engine bracket.
3. Lower the engine onto the engine mount. Install the heat shield (2) and the engine mount upper bolt (1).
4. Tighten the engine mount upper bolt (1) to 55 N.m (41 ft. lbs.).
5. Install the lower splash shield and screws (1). Tighten to 7 N.m (5 ft. lbs.).
6. Lower the vehicle.
7. Remove the engine support frame from the engine.
8. Install the air cleaner housing. «(Refer to ENGINE/AIR INTAKE SYSTEM/AIR CLEANER HOUSING - INSTALLATION)»(ref-250615-S14278514492007031500000) .
9. Connect the negative battery cable.

Scheme 83

1. Raise and support the vehicle.
2. Support the transmission with a transmission jack.
3. Remove the rear mount lower bolts (3).
4. Raise the transmission slightly off of the rear crossmember.
5. Remove the rear mount upper bolts (1).
6. Remove the rear mount.

1. Position the rear mount on the transmission.
2. Install the rear mount upper bolts (1). Tighten the bolts to 40 N.m (30 ft. lbs.).
3. Lower the transmission on to the rear crossmember.
4. Install the rear mount lower bolts (3). Tighten the bolts to 40 N.m (30 ft. lbs.).
5. Remove the transmission jack.
6. Lower the vehicle.
