Entertainment Schematic Icons Icon Icon Definition CAUTION: This vehicle is equipped with a Supplemental Inflatable Restraint (SIR) System. Failure to follow the correct procedure could cause the following conditions: Air bag deployment Personal injury Unnecessary SIR system repairs In order to avoid the above conditions, observe the following guidelines: Refer to SIR Component Views in order to determine if you are performing service on or near the SIR components or the SIR wiring. If you are performing service on or near the SIR components or the SIR wiring, disable the SIR system. Refer to Disabling the SIR System in SIR. IMPORTANT: Twisted-pair wires provide an effective "shield" that helps protect sensitive electronic components from electrical interference. If the wires were covered with shielding, install new shielding. In order to prevent electrical interference from degrading the performance of the connected components, you must maintain the proper specification when making any repairs to the twisted-pair wires shown : The wires must be twisted a minimum of 9 turns per 31 cm (12 in) as measured anywhere along the length of the wires. The outside diameter of the twisted wires must not exceed 6.0 mm (0.2 in)
Scheme 1
Scheme 1: Entertainment Schematic Icons
Scheme 2
Scheme 2: Radio/Audio System Schematics
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 6: Steering Wheel Controls Schematics
Scheme 7
Scheme 7: Entertainment Component Views
| Callout | Component Name |
|---|
| 1 | Headlamp Switch |
| 2 | Instrument Panel Cluster (IPC) |
| 3 | Radio |
| 4 | Inflatable Restraint I/P Module |
| 5 | Auxiliary Power Outlet Front #2 |
| 6 | Cigar Lighter |
| 7 | HVAC Control Module |
| 8 | Auxiliary Power Outlet Front #1 |
| 9 | Noise Compensation Microphone |
| 10 | Ignition Switch |
Scheme 8
| Callout | Component Name |
|---|
| 1 | Outside Rearview Mirror Switch |
| 2 | Speaker - LF Door Midrange |
| 3 | S501 |
| 4 | C500 |
| 5 | C501 |
| 6 | S500 |
| 7 | Outside Rearview Mirror - Driver |
| 8 | Speaker - LF Door |
| 9 | S502 |
| 10 | Window Motor - Driver |
| 11 | Inflatable Restraint Side Impact Sensor (SIS) - Left |
| 12 | Door Latch Assembly - Driver |
Scheme 9
| Callout | Component Name |
|---|
| 1 | Speaker - RF Door Midrange |
| 2 | Door Latch Assembly - Passenger |
| 3 | Passenger Door |
| 4 | Inflatable Restraint Side Impact Sensor (SIS) - Right |
| 5 | Window Motor - Passenger |
| 6 | S602 |
| 7 | Speaker - RF Door |
| 8 | Outside Rearview Mirror - Passenger |
| 9 | S600 |
| 10 | C601 |
| 11 | C600 |
| 12 | S601 |
Scheme 10
| Callout | Component Name |
|---|
| 1 | Speaker - RR |
| 2 | Speaker - LR |
| 3 | Audio Amplifier |
| 4 | Body Harness |
| 5 | Steering Wheel Controls - Left |
| 6 | Steering Wheel Controls Assembly |
| 7 | Steering Wheel Controls - Right |
Test Description
The numbers below refer to the step numbers on the diagnostic table.
- 2: Lack of communication may be due to a partial malfunction of the class 2 serial data circuit or due to a total malfunction of the class 2 serial data circuit. The specified procedure will determine the particular condition.
- 5: The presence of DTCs which begin with "U" indicate some other module is not communicating. The specified procedure will compile all the available information before tests are performed.
| Step | Action | Yes | No |
|---|
| 1 | Install a scan tool. Turn ON the ignition, with the engine OFF. Does the scan tool power up? | Go to Step 2 | Go to Scan Tool Does Not Power Up in Data Link Communications |
| 2 | Attempt to establish communication with the following: Radio Amplifier Body control module (BCM) Does the scan tool communicate with the radio, amplifier, and BCM? | Go to Step 3 | Go to Scan Tool Does Not Communicate with Class 2 Device in Data Link Communications |
| 3 | IMPORTANT: The engine may start during the following step. Turn OFF the engine as soon as you have observed the Crank power mode. Access the Class 2 Power Mode in the Diagnostic Circuit Check on the scan tool. Rotate the ignition switch through all positions while observing the ignition switch power mode parameter. Does the ignition switch parameter reading match the ignition switch position for all switch positions? | Go to Step 4 | Go to Power Mode Mismatch in Body Control System |
| 4 | Select the following display DTCs function on the scan tool: Radio Amplifier Body control module (BCM) Does the scan tool display any DTCs? | Go to Step 5 | Go to Symptoms - Entertainment |
| 5 | Does the scan tool display any DTCs which begin with a "U"? | Go to Scan Tool Does Not Communicate with Class 2 Device in Data Link Communications | Go to Step 6 |
| 6 | Does the scan tool display DTC B1000? | Go to Diagnostic Trouble Code (DTC) List in Body Control System | Go to Step 7 |
| 7 | Does the scan tool display DTC B1327? | Go to Diagnostic Trouble Code (DTC) List in Engine Electrical | Go to Diagnostic Trouble Code (DTC) List |
| IMPORTANT |
|---|
| The engine may start during the following step. Turn OFF the engine as soon as you have observed the Crank power mode. |
Diagnostic System Check - Entertainment System
The number below refers to the step number on the diagnostic table.
- 3: Tests for the proper operation of the circuit in the low voltage range.
| Step | Action | Value(s) | Yes | No |
|---|
| Schematic Reference: Radio/Audio System Schematics Connector End View Reference: Entertainment Connector End Views |
| 1 | Did you perform the Entertainment Diagnostic System Check? | | Go to Step 2 | Go to Diagnostic System Check - Entertainment System |
| 2 | Install a scan tool. Turn ON the ignition, with the engine OFF. With a scan tool, observe the SWC Switch Voltage parameter in the Body Control Module data list. Does the scan tool indicate that the SWC Switch Voltage parameter is near the specified value? | 0 V | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems | Go to Step 3 |
| 3 | CAUTION: Refer to SIR Caution in Cautions and Notices. Disable the SIR system. Refer to SIR Disabling and Enabling Zone 1 and SIR Disabling and Enabling Zone 3 in SIR. Turn OFF the ignition. Disconnect the left steering wheel controls. Turn ON the ignition, with the engine OFF. With a scan tool, observe the SWC Switch Voltage parameter. Does the scan tool indicate that the SWC Switch Voltage parameter is near the specified value? | 0 V | Go to Step 6 | Go to Step 4 |
| 4 | Turn OFF the ignition. Disconnect the right steering wheel controls. Turn ON the ignition, with the engine OFF. With a scan tool, observe the SWC Switch Voltage parameter. Does the scan tool indicate that the SWC Switch Voltage parameter is near the specified value? | 0 V | Go to Step 7 | Go to Step 5 |
| 5 | Test the remote radio control signal circuit for a short to voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | | Go to Step 12 | Go to Step 8 |
| 6 | Inspect for poor connections at the harness connector of the left steering wheel control switch. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | | Go to Step 12 | Go to Step 9 |
| 7 | Inspect for poor connections at the harness connector of the right steering wheel control switch. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | | Go to Step 12 | Go to Step 10 |
| 8 | Inspect for poor connections at the harness connector of the body control module (BCM). Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | | Go to Step 12 | Go to Step 11 |
| 9 | Replace the left steering wheel control switch. Refer to Steering Wheel Control Switch Assembly Replacement in Steering Wheel and Column. Did you complete the replacement? | | Go to Step 12 | |
| 10 | Replace the right steering wheel control switch. Refer to Steering Wheel Control Switch Assembly Replacement in Steering Wheel and Column. Did you complete the replacement? | | Go to Step 12 | |
| 11 | IMPORTANT: Perform the set up procedure for the BCM. Replace BCM. Refer to Body Control Module Replacement in Body Control System.Did you complete the replacement? | | Go to Step 12 | |
| 12 | Enable the SIR system. Refer to SIR Disabling and Enabling Zone 1 and SIR Disabling and Enabling Zone 3 in SIR. Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | | Go to Step 2 | System OK |
| CAUTION |
|---|
| Refer to SIR Caution in Cautions and Notices. |
| IMPORTANT |
|---|
| Perform the set up procedure for the BCM. |
Symptoms - Entertainment
| IMPORTANT | The following steps must be completed before using the symptom tables. Perform the Diagnostic System Check - Entertainment System before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control module can communicate via the serial data link. Review the system operation in order to familiarize yourself with the system functions. Refer to Radio/Audio System Description and Operation . |
Radio/Audio System Description and Operation
The entertainment system on this vehicle is configured with a radio, antenna, and speakers.
The following list shows the radios available for this vehicle
- Base Radio (UB0) - AM/FM with CD
- Uplevel Radio (UC6) - AM/FM, Integral Multi Disc CD Changer
| Controls | UB0 | UC6 |
|---|
| Power | Push PWR/VOL knob to turn the radio on. |
| Volume | The volume is adjusted by rotating the PWR/VOL knob. |
| Automatic Volume Control | Press the AUTOVOL Button |
| Tune | Turn the TUNE knob |
| Seek | Momentarily press SEEK/PSCAN button | Momentarily press SEEK/SCAN button |
| Scan | N/A | Hold SEEK/SCAN button at least 2 seconds |
| Preset Scan | Hold SEEK/PSCAN button at least 2 seconds | N/A |
| Presets | Six AM, Six FM1 and Six FM2 |
| Preset Saving | Press and hold desired button until an audible beep is heard |
| Set Clock | Press and hold the HR or MN button until an audible beep indicates the time set mode has been entered. Once the beep is heard, the time can be set by tapping each button to incrementally adjust the time. Holding down each button will rapidly change the time. |
| Recall | Push the TUNE knob |
| Fade or Balance | Press the AUDIO knob to select and turn to adjust. |
| Bass, Treble or Midrange | Press the AUDIO knob to select and turn to adjust. |
| Automatic Tone | Press AUTO TONE button | Press AUTO EQ button |
| Controls | UB0 Radio | UC6 Radio |
|---|
| Eject | Press the EJT button | Press the eject button |
| Fast Forward | Press the preset 4 button. | Press the FWD button. |
| Reverse | Press the preset 3 button. | Press the REV button. |
| Disc | Press the preset 5 button. | N/A |
| Previous | Press the preset 1 button. | Press the left SEEK/SCAN arrow. |
| Next | Press the preset 2 button. | Press the right SEEK/SCAN arrow. |
| Random | Press the preset 6 button. | Press the RDM button. |
Each item in the list below represents topics covered in detail below.
- AM/FM Reception
- Audio Amplifier
- Theft Deterrent
- Integral Multi Disc CD Changer (IMDX)
- Radio Data System (RDS)
- Tape/CD Player Error Messages
- Voice Recorder
