Door System, Mirror System & Window System: Specifications

Door System, Mirror System & Window System: Specifications Chevrolet SSR I

Fastener Tightening Specifications

Application	Specification
Application	Metric	English
Door Check Link Retaining Bolts	15 N.m	11 lb ft
Door Check Link Retaining Nuts	15 N.m	11 lb ft
Door Hinge to Door Bolts	25 N.m	18 lb ft
Door Hinge to Hinge Pillar Bolts	25 N.m	18 lb ft
Door Striker Screws	24 N.m	18 lb ft
Front Door Sealing Strip Fastener	2 N.m	18 lb in
Inside Handle Screw	5 N.m	44 lb in
Lock Screws	10 N.m	89 lb in
Power Mirror Nuts	10 N.m	89 lb in
Window Regulator Bolts	25 N.m	18 lb ft
Window Motor Bolts	5 N.m	44 lb in
Window Regulator Window Clamp Nuts	10 N.m	89 lb in

Fastener Tightening Specifications

Scheme 1: Power Window Schematics

Scheme 3: Door Lock/Indicator Schematics

Scheme 5: Outside Mirror Schematics

Scheme 7: Power Door Systems Component Views

Callout	Component Name
1	Outside Rearview Mirror Switch
2	Speaker - LF Door Midrange
3	S501
4	C500
5	C501
6	S500
7	Outside Rearview Mirror - Driver
8	Speaker - LF Door
9	S502
10	Window Motor - Driver
11	Inflatable Restraint Side Impact Sensor (SIS) - Left
12	Door Latch Assembly - Driver

Callout	Component Name
1	Speaker - RF Door Midrange
2	Door Latch Assembly - Passenger
3	Passenger Door
4	Inflatable Restraint Side Impact Sensor (SIS) - Right
5	Window Motor - Passenger
6	S602
7	Speaker - RF Door
8	Outside Rearview Mirror - Passenger
9	S600
10	C601
11	C600
12	S601

Callout	Component Name
1	Passenger Window Switch
2	Door Lock/Unlock Switch
3	Folding Top Switch
4	Center Console Switch Assembly
5	Traction ON/OFF Switch
6	Driver Window Switch

Callout	Component Name
1	Outside Rearview Mirror Switch
2	Outside Rearview Mirror - Driver
3	Outside Rearview Mirror - Passenger
4	Passenger Door
5	Speaker - RF Door
6	Speaker - RF Door Midrange
7	Speaker - LF Door Midrange
8	Speaker - RF Door
9	Driver Door
