Torque Converter End Play Check
- Inspect torque converter for hub scoring, cracks or weld area cracks before checking end play. Install End Play Checking Tool (J-35138) on torque converter. (Scheme 591)
- Note end play of torque converter. End play must be within specification. See «TORQUE CONVERTER END PLAY SPECIFICATIONS»(ref-156199-S21404744672003071000000) table. Replace torque converter if end play is not within specification or damage to hub area exists.
| Converter Diameter - In. (mm) | End Play - In. (mm) |
|---|
| 9.650 (245) | 0-.015 (0-.38) |
| 10.157 (258) | .004-.020 (.10-.50) |
| 11.732 (298) | 0-.019 (0-.48) |
| 11.811 (300) | .004-.020 (.10-.50) |
TORQUE CONVERTER END PLAY SPECIFICATIONS
Scheme 591
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Converter Housing Bolt (Except Corvette) | 55 (75) |
| Detent Spring-To-Valve Body Bolt | 20 (27) |
| Extension Housing Bolt | 35 (48) |
| Manual Shaft-To-Detent Lever Nut | 25 (34) |
| Oil Cooler Pipe Connector | 30 (41) |
| Oil Cooler Pipe Fitting | 30 (41) |
| Oil Pan Drain Plug |
| Corvette | 24 (32) |
| Except Corvette | 30 (40) |
| Oil Pump Cover-To-Body Bolt | 20 (27) |
| Oil Pump-To-Case Bolt | 24 (32) |
| Park Bracket-To-Case Bolt | 25 (34) |
| Torque Converter-To-Flexplate Bolt | 44 (60) |
| Transmission Case Extension Bolt (Corvette) | 16 (22) |
| INCH Lbs. (N.m) |
| Accumulator Cover-To-Case Bolt | 124 (14) |
| Forward Accumulator Cover-To-Valve Body Bolt | 124 (14) |
| Line Pressure Plug | 124 (14) |
| Oil Pan-To-Case Bolt | 124 (14) |
| Oil Passage Cover Bolt | 124 (14) |
| PC Solenoid Bracket-To-Valve Body Bolt | 124 (14) |
| Speed Sensor Bolt | 124 (14) |
| TCC Solenoid Assembly-To-Case Bolt | 124 (14) |
| TFP Manual Valve Position Switch-To-Valve Body Bolt | 124 (14) |
| Valve Body-To-Case Bolt (1) | 124 (14) |
| (1) Tighten valve body bolts in a spiral pattern starting in center of valve body. |
| (1) | Tighten valve body bolts in a spiral pattern starting in center of valve body. |
TRANSMISSION SPECIFICATIONS
| Application | In. (mm) |
|---|
| Clearance |
| Forward Clutch (1) |
| W/9.650" (245 mm) Converter | .030-.069 (.76-1.75) |
| W/11.732" (298 mm) Converter | .034-.074 (.86-1.88) |
| W/11.811" (300 mm) Converter | .034-.074 (.86-1.88) |
| Reverse Input Clutch | .040-.076 (1.02-1.93) |
| 3-4 Clutch | .035-.083 (.89-2.11) |
| End Play |
| Reaction & Input Planetary Pinion Gear | .008-.024 (.20-.61) |
| Torque Converter |
| 9.650" (245 mm) | 0-.015 (0-.38) |
| 10.157" (258 mm) | .004-.020 (.10-.50) |
| 11.732" (298 mm) | 0-.019 (0-.48) |
| 11.811" (300 mm) | .004-.020 (.10-.50) |
| Transmission | .005-.036 (.13-.91) |
| Height (Low-Reverse Clutch) | 1.15-1.18 (29.2-29.9) |
| (1) Forward clutch clearance specification for transmissions equipped with 258 mm torque converter is not available from manufacturer. |
| (1) | Forward clutch clearance specification for transmissions equipped with 258 mm torque converter is not available from manufacturer. |
