Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Inside Rearview Mirror | 1.8 N.m | 16 lb in |
| Outside Mirror Motor Screw | 2 N.m | 18 lb in |
| Outside Power Mirror Nuts | 9 N.m | 80 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Inside Rearview Mirror Schematics
Scheme 2
Scheme 2: Outside Rearview Mirror Schematics
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 6: Mirror Component Views
| Callout | Component Name |
|---|
| 1 | Radiator Core Support |
| 2 | Ambient Air Temperature Sensor (DF5) |
| 3 | Ambient Air Temperature Sensor - HVAC (CJ2) |
Scheme 7
| Callout | Component Name |
|---|
| 1 | Exterior Illumination Lamp - Left |
| 2 | Exterior Illumination Lamp - Right |
| 3 | Outside Rear View Mirror (OSRVM) - Driver |
| 4 | Outside Rear View Mirror (OSRVM) - Passenger |
Scheme 8
| Callout | Component Name |
|---|
| 1 | Inside Air Temperature Sensor - Front (CJ2) |
| 2 | Cellular Microphone (UE1/U3U/UVB) |
| 3 | Courtesy/Reading Lamps - Rear (Extended Cab/Crew Cab) |
| 4 | Sunroof Switch (CF5) |
| 5 | Sunshade - Right (DH6) |
| 6 | Garage Door Opener (UG1) |
| 7 | Onstar Button Assembly |
| 8 | Inside Rearview Mirror (ISRVM) |
| 9 | Courtesy/Reading Lamps - Front |
| 10 | Windshield |
| 11 | Sunshade - Left (DH6) |
Scheme 9
Scheme 9: Ambient Air Temperature Sensor (DF5)
| Connector Part Information OEM: 13543521 Service: See Catalog Description: 2-Way F Metri-Pack 150 Series Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
Ambient Air Temperature Sensor (DF5) Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | 0.5 D-GN/WH | 636 | Ambient Air Temperature Sensor Signal |
| B | 0.5 YE | 61 | Low Reference |
Ambient Air Temperature Sensor (DF5) Connector Terminal Identification
Scheme 10
Scheme 10: Inside Rearview Mirror (ISRVM)
| Connector Part Information OEM: 15441350 Service: 15306351 Description: 16-Way F Micro 100A Series (BK) |
|---|
| Terminal Part Information Pins: 5-9, 11-16 Terminal/Tray: 15445905/23 Core/Insulation Crimp: J/J Release Tool/Test Probe: 12180559/J-35616-6 (BN) |
Inside Rearview Mirror (ISRVM) Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1-4 | | | Not Used |
| 5 | 0.35 GY | 1690 | Automatic Day/Night Mirror Signal (DF5 +DL3/DR4) |
| 6 | 0.35 D-GN/WH | 636 | Ambient Air Temperature Sensor Signal (DF5) |
| 7 | 0.35 YE | 61 | Low Reference (DF5) |
| 8 | 0.5 BK | 1050 | Ground (DF5/UE1) |
| 9 | 0.35 D-BU | 38 | Backup Lamp Relay Control (DF5) |
| 10 | | | Not Used |
| 11 | 0.35 D-GN/WH | 2514 | Keypad Signal (UE1) |
| 12 | 0.35 L-GN/BK | 2515 | Keypad Supply Voltage (UE1) |
| 13 | 0.35 PK | 1639 | Ignition 1 Voltage (DF5) |
| 14 | 0.35 YE/BK | 2516 | Keypad Green LED Signal (UE1) |
| 15 | 0.35 BN/WH | 2517 | Keypad Red LED Signal (UE1) |
| 16 | 0.35 PK | 1691 | Low Reference (DF5 +DL3/DR4) |
Inside Rearview Mirror (ISRVM) Connector Terminal Identification
Scheme 11
Scheme 11: Outside Rearview Mirror - Driver (-AN3/DL3)
| Connector Part Information OEM: 13548147 Service: See Catalog Description: 10-Way M (BK) |
|---|
| Terminal Part Information Pins: 1-7, 10 Terminal/Tray: SAITW-A03T-064/20 Core/Insulation Crimp: J/J Release Tool/Test Probe: J-38125-215A/J-35616-65B (L-BU) |
Outside Rearview Mirror - Driver (-AN3/DL3) Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 0.5 L-GN | 89 | Driver Mirror Motor Down Control (DL8/DPN) |
| 2 | 0.5 WH | 81 | Driver Mirror Motor Right Control (DL8/DPN) |
| 3 | 0.5 BK | 1850 | Ground (DL8/DPN) |
| 4 | | | Not Used |
| 5 | 0.5 L-BU/WH | 1314 | Left Front Turn Signal Lamp Supply Voltage (DPN) |
| 6 | 0.5 TN | 329 | Driver Mirror Motor Supply Voltage (DL8/DPN) |
| 7 | 0.5 OG | 2267 | Mirror Heating Element Supply Voltage (DL8/DPN) |
| 8-9 | | | Not Used |
| 10 | 0.5 BK | 1850 | Ground (DPN) |
Outside Rearview Mirror - Driver (-AN3/DL3) Connector Terminal Identification
