Removal Procedure
- Position the mirror face outward on a angle with the mirror housing.
- Remove the mirror face as follows: Position the hand in the center of the mirror face. Apply light pressure. Push upward releasing the motor retainers from the mirror back. Holding the mirror face, disconnect the electrical connectors from the back of the mirror.
Installation Procedure
- Position the mirror face on a angle to the mirror housing.
- Install the mirror face as follows: Holding the mirror face, connect the electrical connectors to the back of the mirror. Position the mirror face to the motor retainer tabs. Position the hand in the center of the mirror face. Apply light pressure to the face. Push downward and inward to lock in place. Inspect the mirror face for proper operation.
Scheme 12
| Callout | Component Name |
|---|---|
| 1 | Rearview Mirror Support Cover |
| 2 | Rearview Mirror Support Wire Cover Procedure: Disconnect the wiring harness from the rearview mirror. |
| 3 | Rearview Mirror Procedure: With both hands on the mirror, rock it from side to side while sliding upward, this will assist in the releasing of the mirror from the mounting tab. |
Inside Rearview Mirror Replacement
