STARTER SPECIFICATIONS
| Application | Specification | ||
|---|---|---|---|
| Brush Length | |||
| Metro & Firefly (Canadian) | .47-.69" (12-18 mm) | ||
| Prizm | .39-.61" (10-15 mm) | ||
| Brush Spring Tension | |||
| Metro & Firefly (Canadian) | 25-74 ozs. (.7-2.1 kg) | ||
| Prizm | 85-112 ozs. (2.4-3.2 kg) | ||
| Commutator Insulation Depth | |||
| Minimum Depth | .008" (.2 mm) | ||
| Standard Depth | |||
| Metro & Firefly (Canadian) | .020-.031" (.5-.8 mm) | ||
| Prizm | .008-.024" (.2-.6 mm) | ||
| Commutator Outside Diameter | |||
| Metro & Firefly (Canadian) | 1.134-1.157" (28.8-29.4 mm) | ||
| Prizm | 1.14-1.18" (28.9-30.0 mm) | ||
| Commutator Runout | .002-.016" (.05-.41 mm) | ||
| Starter Current Draw | |||
| Metro & Firefly (Canadian) | |||
| No-Load | 50-75 Amps At 11.0 Volts | ||
| Load (80.5 INCH Lbs. Torque) | 300 Amps At 7.7 Volts | ||
| Locked Rotor (13.7 Ft. Lbs. Torque) | 780 Amps At 4.0 Volts | ||
| Prizm | |||
| No-Load | 60-90 Amps At 11.0 Volts | ||
STARTER SPECIFICATIONS
TORQUE SPECIFICATIONS
| Model | Ft. Lbs. (N.m) | |
|---|---|---|
| Starter Mounting Bolts | ||
| Metro & Firefly (Canadian) | 17 (23) | |
| Prizm | 27 (37) | |
| INCH Lbs. (N.m) | ||
| Battery-To-Starter Terminal Nut (Prizm) | 80 (9) | |
| Commutator End Cover Bolts (Metro & Firefly (Canadian)) | 71 (8) | |
| Solenoid Field Coil Lead Wire Nut | ||
| Metro & Firefly (Canadian) | 89 (10) | |
| Prizm | 53 (6) | |
| Solenoid Mounting Nuts (Metro & Firefly (Canadian)) | 62 (7) | |
| Starter Assembly Bolts (Prizm) | 53 (6) | |
TORQUE SPECIFICATIONS
