Engine Mechanical - 4.4l (1 of 5) Cadillac XLR I

Scheme 1

Supercharger Belt Replacement

Scheme 2

Water Pump and Generator Belt Replacement

Scheme 3

Air Conditioning Compressor and Power Steering Pump Belt Replacement

Scheme 4

Drive Belt Tensioner Replacement - Supercharger

Scheme 5

Water Pump and Generator Drive Belt Tensioner Replacement

Scheme 6

Air Conditioning Compressor Belt Tensioner Replacement

Scheme 7

Supercharger Belt Idler Pulley Replacement

Scheme 8

Water Pump and Generator Belt Idler Pulley Replacement

Tools Required

J 28467-81 Engine Support Fixture Kit. See Special Tools .

Installation Procedure

1. Remove the hood. Refer to «Hood Replacement»(/cadillac/xlr/i-2003-2009/remont/exterior-body-panels/#body-front-end) .
2. Remove the engine cover. Refer to «Intake Manifold Sight Shield Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
3. Disconnect the negative battery cable from the battery. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/xlr/i-2003-2009/remont/charging-system/#battery-charging-system-and-starting-system) .
4. Remove the battery negative cable bolt (3) from the RH rear of cylinder head. Position the battery negative cable (1) and ground junction (2) aside.
5. Remove the camshaft cover ground strap from the camshaft cover. Position the ground strap aside.
6. Remove the plastic wire harness protector from the frame rail pinch weld to provide clearance for the engine lift hook.
7. Install the J 28467-87 Right Engine Lift Bracket to the right cylinder head.
8. Remove the bolt securing the wiring harness to the left cylinder head.
9. Install the J 28467-86 Left Engine Lift Bracket to the left cylinder head.
10. Assemble a J 28467-83 Rear Crossbar Support (2) to each end of the J 28467-3 Rear Crossbar (1). Secure the assembly with the lock pin (3).
11. Position the rear crossbar assembly (1-3) over the hood hinge brackets with the support located over each hood safety catch bracket.
12. Assemble a J 28467-82 Front Crossbar Legs to each end of the J 28467-85 Front Crossbar (1).
13. Install the 0.5 in X 2.5 in J 28467-10 Quick Release Pins (4).
14. Place the front crossbar assembly with supporting legs on the right and left frame rails. Each leg should rest in the shock absorber upper mount on the frame rail.
15. Install the right and left side bars (3-4) over the front and rear crossbars.
16. Install the J 28467-1A assembly and hand tighten.
17. Repeat steps 12 and 13 for the remaining three corners of the support fixture assembly.
18. Install the J 28467-7A lift hook through the J 28467-6A lift hook bracket.
19. Install the 1/2 inch lift hook washer and the J 28467-34 lift hook wing nut onto the J 28467-7A lift hook.
20. Install the J 28467-6A assembled lift hook (1) over the J 28467-84 left side bar (2).
21. Adjust the J 28467-6A assembled lift hook bracket (1) in order to align the hook with the J 28467-86 left engine lift hook bracket.
22. Repeat step 18 for the right lift hook (3).
23. Install each J 28467-7A lift hook (5,6) through each engine lift hook bracket. Ensure that the hooks do not damage the surrounding components.
24. Hand-tighten the lift hook wing nuts securely to remove all slack from the engine support fixture assembly.

Removal Procedure

1. Loosen and remove the J 28467-7A lift hooks (5,6)
2. Remove the J 28467-81 Engine Support Fixture Kit (1-4). See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
3. Remove the J 28467-86 Left Engine Lift Bracket from the left cylinder head.
4. Install the bolt securing the wiring harness to the left cylinder head. Tighten: Tighten the wiring harness bolt to 35 N.m (26 lb ft).
5. Remove the J 28467-87 Right Engine Lift Bracket from the right cylinder head.
6. Install the plastic wire harness protector to the frame rail pinch weld.
7. Install the camshaft cover ground strap to the camshaft cover. Tighten: Tighten the camshaft cover bolt to 10 N.m (89 lb in).
8. Install the battery negative cable and ground junction to the RH rear of cylinder head. Tighten: Tighten the negative battery cable bolt to 35 N.m (26 lb ft).
9. Connect the negative battery cable to the battery. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/xlr/i-2003-2009/remont/charging-system/#battery-charging-system-and-starting-system) .
10. Install the engine cover. Refer to «Intake Manifold Sight Shield Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
11. Install the hood. Refer to «Hood Replacement»(/cadillac/xlr/i-2003-2009/remont/exterior-body-panels/#body-front-end) .

Engine Mount Inspection

Note. Broken or deteriorated mounts can cause misalignment and destruction of certain drive train components. When a single mount breaks, the remaining mounts are subjected to abnormally high stresses.

Note. When raising or supporting the engine for any reason, do not use a jack under the oil pan, any sheet metal, or the crankshaft pulley. Due to the small clearance between the oil pan and the oil pump screen, jacking against the oil pan may cause the pan to be bent against the pump screen. This will result in a damaged oil pickup unit.

1. Measure the engine movement at the engine mount in order to check for damage to the rubber portions of the mount. Apply the park brake. Start the engine. Firmly apply and hold the primary brakes. Have an assistant stand to the side of the vehicle in order to observe for engine movement. Slightly load the engine shifting from drive to reverse a few times. If the engine moves more than 24 mm (0.945 in) from the at rest position, in either direction, check for loose engine mount or engine mount bracket attachments.
2. If the engine mount and engine mount bracket bolt torque is at specifications, check the condition of the engine mount.
3. Replace the engine mount if any of the following conditions exist: Heat check cracks cover the rubber cushion surface. The rubber cushion is separated from the metal plate of the mount. There is a split through the rubber cushion.

1. Remove the front suspension crossmember. Refer to «Front Suspension Crossmember Replacement»(/cadillac/xlr/i-2003-2009/remont/frames-subframes-crossmembers/#frame-and-underbody) .
2. Remove the engine mount-to-engine mount bracket nut.
3. Remove the engine mount from the engine mount bracket.
4. Remove the engine mount heat shield from the engine mount.

1. Install the engine mount heat shield to the engine mount.
2. Position the engine mount to the engine mount bracket.
3. Install the engine mount-to-engine mount bracket nut. Tighten: Tighten the nut to 58 N.m (43 lb ft).
4. Install the front suspension crossmember. Refer to «Front Suspension Crossmember Replacement»(/cadillac/xlr/i-2003-2009/remont/frames-subframes-crossmembers/#frame-and-underbody) .

1. Remove the front suspension crossmember. Refer to «Front Suspension Crossmember Replacement»(/cadillac/xlr/i-2003-2009/remont/frames-subframes-crossmembers/#frame-and-underbody) .
2. Remove the engine mount-to-engine mount bracket nut.
3. Remove the engine mount from the engine mount bracket.
4. Remove the engine mount heat shield from the engine mount.

1. Install the engine mount heat shield to the engine mount.
2. Position the engine mount to the engine mount bracket.
3. Install the engine mount-to-engine mount bracket nut. Tighten: Tighten the nut to 58 N.m (43 lb ft).
4. Install the front suspension crossmember. Refer to «Front Suspension Crossmember Replacement»(/cadillac/xlr/i-2003-2009/remont/frames-subframes-crossmembers/#frame-and-underbody) .

1. Remove the left engine mount. Refer to «Engine Mount Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
2. Remove the engine mount bracket bolts.
3. Remove the engine mount bracket.

1. Install the engine mount bracket. NOTE: Refer to «Fastener Notice»(/cadillac/xlr/i-2003-2009/remont/oem-general-information/#cautions-and-notices__fastener-notice) .
2. Install the engine mount bracket bolts. Tighten: Tighten the engine mount bracket bolts to 58 N.m (43 lb ft).
3. Install the left engine mount. Refer to «Engine Mount Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

1. Remove the right engine mount. Refer to «Engine Mount Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
2. Remove the engine mount bracket bolts.
3. Remove the engine mount bracket.

1. Install the engine mount bracket.
2. Install the engine mount bracket bolts. Tighten: Tighten the engine mount bracket bolts to 58 N.m (43 lb ft).
3. Install the right engine mount. Refer to «Engine Mount Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

Scheme 9

Intake Manifold Sight Shield Replacement

1. Release the lock tab (1) when disconnecting the positive crankcase ventilation (PCV) tube connections.
2. Disconnect the fresh air PCV tube (1) from the fitting on the underside of the supercharger inlet duct, during the removal procedure of the front section of the supercharger inlet duct assembly. Refer to «Supercharger Inlet Duct Assembly Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
3. Disconnect the PCV fresh air tube (1) from the left camshaft cover.
4. Disconnect the PCV foul air tube (1) from the PCV orifice fitting on the right camshaft cover.
5. Remove the supercharger assembly. Refer to «Supercharger Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
6. Remove the PCV foul air tube from the fitting on the underside of the supercharger assembly.

1. Connect the PCV foul air tube to the fitting on the underside of the supercharger assembly.
2. Install the supercharger assembly. Refer to «Supercharger Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
3. Connect the PCV foul air tube (1) to the PCV orifice fitting on the right camshaft cover.
4. Connect the PCV fresh air tube (1) to the left camshaft cover.
5. Connect the fresh air PCV tube (1) to the fitting on the underside of the supercharger inlet duct, during the installation procedure of the front section of the supercharger inlet duct assembly. Refer to «Supercharger Inlet Duct Assembly Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .

Scheme 10

Charge Air Cooler Coolant Filler Cap Replacement

1. Remove the hood. Refer to «Hood Replacement»(/cadillac/xlr/i-2003-2009/remont/exterior-body-panels/#body-front-end) .
2. Remove the engine sight shield. Refer to «Intake Manifold Sight Shield Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
3. Remove the front supercharger inlet duct assembly. Refer to «Supercharger Inlet Duct Assembly Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
4. Drain the charge air cooling system. Refer to «Charge Air Cooling System Draining and Filling (Static Fill)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) or «Charge Air Cooling System Draining and Filling (GE 47716)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) .
5. Remove the charge air cooler hoses from the front section of the charge air cooler front manifold.
6. Remove the bolts (1) and remove the front portion of the supercharger front manifold (2). Discard the manifold O-ring seals.
7. Remove the supercharger bypass regulator solenoid valve and bracket. Refer to «Supercharger Bypass Regulator Solenoid Valve Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
8. Remove the charge air cooler front manifold bolts.
9. Remove the charge air cooler front manifold.
10. Remove and discard the charge air cooler front manifold gasket.
11. Remove and discard the charge air cooler cooling tube front O-rings.
12. Remove the charge air cooler cooling tube front spacers if required.
13. Remove the charge air cooler rear manifold bolts.
14. Remove the charge air cooler rear manifold.
15. Remove and discard the charge air cooler rear manifold gaskets.
16. Remove and discard the charge air cooler cooling tube rear O-rings.
17. Remove the charge air cooler cooling tube rear spacers, if required.
18. Remove the inboard and outboard charge air cooling tubes, if required. Refer to «Charge Air Cooler Cooling Tube Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
19. Clean and inspect the charge air cooler manifolds and cooling tubes. Refer to «Supercharger Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-4-of-5__supercharger-cleaning-and-inspection-off) .

1. Install the charge air cooling tubes, if previously removed. Refer to «Charge Air Cooler Cooling Tube Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
2. Install the charge air cooler cooling tube rear spacers, if previously removed.
3. Install the NEW charge air cooler cooling tube rear O-rings.
4. Install the NEW charge air cooler rear manifold gaskets.
5. Install the charge air cooler rear manifold.
6. Install the charge air cooler rear manifold bolts. Tighten: Tighten the charge air cooler rear manifold bolts to 10 N.m (89 lb in).
7. Install the charge air cooler cooling tube front spacers, if previously removed.
8. Install the NEW charge air cooler cooling tube front O-rings.
9. Install the NEW charge air cooler front manifold gasket.
10. Install the charge air cooler front manifold.
11. Install the charge air cooler front manifold bolts. Tighten: Tighten the charge air cooler front manifold bolts to 10 N.m (89 lb in).
12. Install the supercharger bypass regulator solenoid valve and bracket. Refer to «Supercharger Bypass Regulator Solenoid Valve Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
13. Using NEW O-ring seals, install the front portion of the charge air cooler front manifold (2).
14. Install the manifold bolts (1). Tighten: Tighten the charge air cooler front manifold bolts to 10 N.m (89 lb in).
15. Install the charge air cooler hoses to the front section of the charge air cooler front manifold.
16. Fill the charge air cooling system. Refer to «Charge Air Cooling System Draining and Filling (Static Fill)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) or «Charge Air Cooling System Draining and Filling (GE 47716)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) .
17. Install the front supercharger inlet duct assembly. Refer to «Supercharger Inlet Duct Assembly Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
18. Install the engine sight shield. Refer to «Intake Manifold Sight Shield Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
19. Install the hood. Refer to «Hood Replacement»(/cadillac/xlr/i-2003-2009/remont/exterior-body-panels/#body-front-end) .

1. Remove the hood. Refer to «Hood Replacement»(/cadillac/xlr/i-2003-2009/remont/exterior-body-panels/#body-front-end) .
2. Remove the engine sight shield. Refer to «Intake Manifold Sight Shield Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
3. Remove the front supercharger inlet duct assembly. Refer to «Supercharger Inlet Duct Assembly Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
4. Drain the charge air cooling system. Refer to «Charge Air Cooling System Draining and Filling (Static Fill)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) or «Charge Air Cooling System Draining and Filling (GE 47716)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) .
5. Remove the charge air cooler hoses from the front section of the charge air cooler front manifold.
6. Remove the bolts (1) and remove the front portion of the supercharger front manifold (2). Discard the manifold O-ring seals.
7. Remove the supercharger bypass regulator solenoid valve and bracket. Refer to «Supercharger Bypass Regulator Solenoid Valve Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
8. Remove the charge air cooler front manifold bolts.
9. Remove the charge air cooler front manifold.
10. Remove and discard the charge air cooler front manifold gasket.
11. Remove and discard the charge air cooler cooling tube front O-rings.
12. Remove the charge air cooler cooling tube front spacers if required.
13. Remove the charge air cooler rear manifold bolts.
14. Remove the charge air cooler rear manifold.
15. Remove and discard the charge air cooler rear manifold gaskets.
16. Remove and discard the charge air cooler cooling tube rear O-rings.
17. Remove the charge air cooler cooling tube rear spacers, if required.
18. Remove the inboard and outboard charge air cooling tubes, if required. Refer to «Charge Air Cooler Cooling Tube Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
19. Clean and inspect the charge air cooler manifolds and cooling tubes. Refer to «Supercharger Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-4-of-5__supercharger-cleaning-and-inspection-off) .

1. Install the charge air cooling tubes, if previously removed. Refer to «Charge Air Cooler Cooling Tube Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
2. Install the charge air cooler cooling tube rear spacers, if previously removed.
3. Install the NEW charge air cooler cooling tube rear O-rings.
4. Install the NEW charge air cooler rear manifold gaskets.
5. Install the charge air cooler rear manifold.
6. Install the charge air cooler rear manifold bolts. Tighten: Tighten the charge air cooler rear manifold bolts to 10 N.m (89 lb in).
7. Install the charge air cooler cooling tube front spacers, if previously removed.
8. Install the NEW charge air cooler cooling tube front O-rings.
9. Install the NEW charge air cooler front manifold gasket.
10. Install the charge air cooler front manifold.
11. Install the charge air cooler front manifold bolts. Tighten: Tighten the charge air cooler front manifold bolts to 10 N.m (89 lb in).
12. Install the supercharger bypass regulator solenoid valve and bracket. Refer to «Supercharger Bypass Regulator Solenoid Valve Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
13. Using NEW O-ring seals, install the front portion of the charge air cooler front manifold (2).
14. Install the manifold bolts (1). Tighten: Tighten the charge air cooler front manifold bolts to 10 N.m (89 lb in).
15. Install the charge air cooler hoses to the front section of the charge air cooler front manifold.
16. Fill the charge air cooling system. Refer to «Charge Air Cooling System Draining and Filling (Static Fill)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) or «Charge Air Cooling System Draining and Filling (GE 47716)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) .
17. Install the front supercharger inlet duct assembly. Refer to «Supercharger Inlet Duct Assembly Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
18. Install the engine sight shield. Refer to «Intake Manifold Sight Shield Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
19. Install the hood. Refer to «Hood Replacement»(/cadillac/xlr/i-2003-2009/remont/exterior-body-panels/#body-front-end) .

1. Drain the charge air cooling system. Refer to «Charge Air Cooling System Draining and Filling (Static Fill)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) or «Charge Air Cooling System Draining and Filling (GE 47716)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) .
2. Remove the front section of the supercharger inlet duct assembly. Refer to «Supercharger Inlet Duct Assembly Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
3. Place a shop rag under the front portion of the supercharger to collect any remaining coolant that may drain from the charge air cooling system.
4. Remove the charge air cooler front manifold, gasket, O-rings, and spacers. Refer to «Charge Air Cooler Front Manifold Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
5. Remove the charge air cooler rear manifold, gaskets, O-rings, and spacers. Refer to «Charge Air Cooler Coolant Rear Manifold Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
6. Carefully remove the outboard charge air cooler cooling tubes.
7. The charge air cooler cooling tubes are fragile and must be placed in a protected area.
8. Carefully remove the inboard charge air cooler cooling tubes.
9. The charge air cooler cooling tubes are fragile and must be placed in a protected area.
10. Inspect the charge air cooler cooling tubes for the following: Damaged, clogged, bent or missing fins (1) Damage, corrosion or restrictions to the cooling passages (2) Damage, corrosion, restrictions or missing diversion end plate (3)
11. Inspect the charge air cooler cooling tubes for the following: Damaged, clogged, bent or missing fins (1) Damage, corrosion or restrictions to the cooling passages (2) Damage, corrosion or restrictions to the intake end (3)
12. Replace any damaged, corroded or restricted charge air cooler cooling tubes as a set.

1. Carefully install the inboard charge air cooler cooling tubes.
2. The charge air cooler cooling inboard tubes are installed with the restrictor plates (1) to the front of the supercharger, towards the drive belt pulley.
3. Align the wide notch at a 45 degree angle up from horizontal and outboard as shown.
4. Carefully install the outboard charge air cooler cooling tubes.
5. The charge air cooler cooling outboard tubes are installed with the restrictor plates (1) to the rear of the supercharger. The open end of the cooling tube will be to the front of the supercharger, towards the drive belt pulley.
6. Align the wide notch at a 45 degree angle up from horizontal and outboard as shown.
7. Install the charge air cooler cooling tube rear spacers.
8. Install the NEW charge air cooler cooling tube rear O-rings.
9. Install the NEW charge air cooler rear manifold gaskets.
10. Install the charge air cooler rear manifold.
11. Install the charge air cooler rear manifold bolts. Tighten: Tighten the charge air cooler rear manifold bolt to 10 N.m (89 lb in).
12. Install the charge air cooler cooling tube front spacers.
13. Install the NEW charge air cooler cooling tube front O-rings.
14. Install the NEW charge air cooler front manifold gasket.
15. Install the charge air cooler front manifold.
16. Install the charge air cooler front manifold bolts. Tighten: Tighten the charge air cooler front manifold bolt to 10 N.m (89 lb in).
17. Install the remaining portion of the charge air cooler front manifold. Refer to «Charge Air Cooler Front Manifold Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
18. Install the front section of the supercharger inlet duct assembly. Refer to «Supercharger Inlet Duct Assembly Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
19. Fill the charge air cooling system. Refer to «Charge Air Cooling System Draining and Filling (Static Fill)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) or «Charge Air Cooling System Draining and Filling (GE 47716)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) .

Disassemble Procedure

1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2__fuel-pressure-relief) .
2. Remove the fuel rail. Refer to «Fuel Injector and Fuel Rail Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
3. Drain the charge air cooling system. Refer to «Charge Air Cooling System Draining and Filling (Static Fill)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) or «Charge Air Cooling System Draining and Filling (GE 47716)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) .
4. Place a shop rag under the front portion of the supercharger to catch any remaining coolant.
5. Remove the charge air cooler front manifold. Refer to «Charge Air Cooler Front Manifold Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
6. Remove the charge air cooler rear manifold. Refer to «Charge Air Cooler Coolant Rear Manifold Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
7. Remove the charge air cooler cooling tubes, if necessary. Refer to «Charge Air Cooler Cooling Tube Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
8. Remove the long charge air cooler bolts.
9. Remove the short charge air cooler perimeter bolts.
10. Remove the charge air cooler housing.
11. Remove and discard the charge air cooler housing perimeter gasket.
12. Remove and discard the charge air cooler housing interior O-ring gaskets.

1. Install the NEW charge air cooler housing interior O-ring gaskets.
2. Install the NEW charge air cooler housing perimeter gasket.
3. Install the charge air cooler housing.
4. Install the long charge air cooler bolts. Tighten: Tighten the long charge air cooler bolt to 10 N.m (89 lb in).
5. Install the short charge air cooler perimeter bolts. Tighten: Tighten the short charge air cooler bolt to 10 N.m (89 lb in).
6. Install the charge air cooler cooling tubes, if necessary. Refer to «Charge Air Cooler Cooling Tube Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
7. Install the charge air cooler rear manifold. Refer to «Charge Air Cooler Coolant Rear Manifold Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
8. Install the charge air cooler front manifold. Refer to «Charge Air Cooler Front Manifold Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
9. Fill the charge air cooling system. Refer to «Charge Air Cooling System Draining and Filling (Static Fill)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) or «Charge Air Cooling System Draining and Filling (GE 47716)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) .
10. Install the fuel rail. Refer to «Fuel Injector and Fuel Rail Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
11. Install the fuel fill cap.
12. Check the charge air cooling system for leaks.
13. Check the fuel system for leaks.

1. EN 46109 Guide Pins. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
2. EN-47748 Supercharger Lift Bracket. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
3. EN-47833 Supercharger Service Holding Fixture. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .

1. Remove the hood. Refer to «Hood Replacement»(/cadillac/xlr/i-2003-2009/remont/exterior-body-panels/#body-front-end) .
2. Remove the engine sight shield. Refer to «Intake Manifold Sight Shield Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
3. Remove the front supercharger inlet duct assembly. Refer to «Supercharger Inlet Duct Assembly Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
4. Drain the charge air cooling system. Refer to «Charge Air Cooling System Draining and Filling (Static Fill)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) or «Charge Air Cooling System Draining and Filling (GE 47716)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) .
5. Remove the front portion of the supercharger front manifold (2). It is not necessary to remove the hoses from the manifold. Discard the manifold O-ring seals. Position the hoses with manifold aside. Refer to «Charge Air Cooler Front Manifold Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
6. Remove the fuel injector rail assembly (1). Refer to «Fuel Injector and Fuel Rail Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
7. Disconnect the throttle body electrical connector (5).
8. Disconnect the evaporative emission (EVAP) canister purge solenoid valve hose (3) from the EVAP valve. Refer to «Plastic Collar Quick Connect Fitting Service»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) . Position the hose aside.
9. Disconnect the EVAP canister purge solenoid valve electrical connector (4).
10. Disconnect the brake booster vacuum hose (2) from the fitting on the supercharger. Position the hose aside.
11. Disconnect the supercharger bypass regulator solenoid valve electrical connector (3).
12. Disconnect the manifold absolute pressure (MAP) sensor vacuum line (2) from the supercharger.
13. Disconnect the supercharger intake air temperature (IAT) sensor electrical connector.
14. Disconnect the supercharger inlet absolute pressure (SIAP) sensor vacuum line fitting (1) from the rear of the supercharger. Position the sensors, vacuum lines, and wire harness aside.
15. Disconnect the positive crankcase ventilation (PCV) tube fitting (1) from the right camshaft cover.
16. Remove the supercharger drive belt. Refer to «Supercharger Belt Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
17. Install the EN-47748 (1-5) to the supercharger. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
18. Install an engine hoist to the EN-47748 . See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
19. Remove and discard the supercharger bolts.
20. Remove the supercharger.
21. Install the EN-47833 to the supercharger while the supercharger is suspended by the engine hoist. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
22. Place the supercharger on a workbench and remove the engine hoist.
23. If replacing the supercharger, transfer the necessary parts.
24. Remove the supercharger gaskets from the engine.
25. Clean and inspect the supercharger. Refer to «Supercharger Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-4-of-5__supercharger-cleaning-and-inspection-off) .
26. Clean and inspect the supercharger mating surface on the engine.

1. Install the new supercharger gaskets to the engine.
2. Install two of the appropriate size guide pins from the EN 46109 alignment pin set to the engine in the front two bolt hole locations. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
3. If previously removed, install the EN-47748 to the supercharger. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
4. Install an engine hoist to the EN-47748 and raise the supercharger off the workbench. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
5. Remove the EN-47833 from the supercharger. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
6. Inspect the gasket surface on the supercharger and clean as necessary.
7. Ensure that all wiring and vacuum lines are positioned aside and install the supercharger to the engine.
8. Remove the engine hoist and the EN-47748 . See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
9. Remove the EN 46109 alignment pins. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
10. Loosely install the NEW supercharger bolts.
11. Tighten the supercharger bolts in sequence as shown. Tighten: Tighten the supercharger bolts to 40 N.m (30 lb ft).
12. Install the supercharger drive belt. Refer to «Supercharger Belt Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
13. Connect the PCV tube fitting (1) to the right side camshaft cover.
14. Connect the SIAP sensor vacuum line fitting (1) to the rear of the supercharger.
15. Connect the supercharger IAT sensor electrical connector.
16. Connect the MAP sensor vacuum line fitting (2) to the supercharger.
17. Connect the supercharger bypass regulator solenoid valve electrical connector (3).
18. Connect the brake booster vacuum hose (2) to the fitting on the supercharger.
19. Connect the EVAP canister purge solenoid valve electrical connector (4).
20. Connect the EVAP canister purge solenoid valve hose (3) to the EVAP valve. Refer to «Plastic Collar Quick Connect Fitting Service»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
21. Connect the throttle body electrical connector (5).
22. Install the fuel injector rail assembly (1). Refer to «Fuel Injector and Fuel Rail Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
23. Using NEW O-rings, install the front portion of the supercharger front manifold (2). Refer to «Charge Air Cooler Front Manifold Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
24. Install the front section of the supercharger inlet duct assembly. Refer to «Supercharger Inlet Duct Assembly Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
25. Install the engine sight shield. Refer to «Intake Manifold Sight Shield Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
26. Install the hood. Refer to «Hood Replacement»(/cadillac/xlr/i-2003-2009/remont/exterior-body-panels/#body-front-end) .
27. Fill the charge air cooling system with coolant and check for leaks. Refer to «Charge Air Cooling System Draining and Filling (Static Fill)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) or «Charge Air Cooling System Draining and Filling (GE 47716)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) .

1. Remove the oil level indicator.
2. Remove the oil level indicator tube bolt.
3. Disconnect the coolant surge tank fluid level indicator electrical connector.
4. Remove the surge tank nuts and reposition the surge tank away from the brake master cylinder.
5. Disconnect the master cylinder fluid level sensor electrical connector (1).
6. Remove the master cylinder mounting nuts and reposition the master cylinder away from the brake booster.
7. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/xlr/i-2003-2009/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) .
8. Pull the oil level indicator tube from the crankcase while rotating it counterclockwise.

1. Replace the oil level indicator tube O-ring and lubricate with engine oil.
2. With the aid of an assistant, install the oil level indicator tube into the crankcase.
3. Lower the vehicle.
4. Install the oil level indictor tube bolt into the left cylinder head. Tighten: Tighten the oil level indicator tube bolt to 50 N.m (37 lb in).
5. Install the oil level indicator.
6. Reposition the brake master cylinder to the brake booster.
7. Install the master cylinder mounting nuts. Tighten: Tighten the master cylinder mounting nuts to 29 N.m (21 lb ft).
8. Connect the electrical connector (1) for the master cylinder fluid level sensor.
9. Install the coolant surge tank. Refer to «Radiator Surge Tank Replacement»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) .

1. Remove the left engine mount bracket. Refer to «Engine Mount Bracket Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
2. Disconnect the engine oil cooler lines from the adapter.
3. Disconnect the electrical connector from the engine oil pressure switch.
4. Place a suitable drain pan under the vehicle.
5. Remove the oil filter.
6. Remove the oil filter adapter mounting bolts.
7. Remove the oil filter adapter and discard the gasket.
8. Disassemble the oil filter adapter as necessary. Refer to «Oil Filter Adapter Disassemble»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-3-of-5__oil-filter-adapter-disassemble-off) .
9. Clean and inspect the oil filter adapter. Refer to «Oil Filter Adapter Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-3-of-5) .

1. Assemble the oil filter adapter as necessary. Refer to «Oil Filter Adapter Assemble»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-3-of-5__oil-filter-adapter-assemble-off) .
2. Install a new gasket to the oil filter adapter.
3. Apply 10 drops of high-strength, high-temperature threadlocker to the engine oil filter adapter pipe fittings. Refer to «Sealers, Adhesives, and Lubricants»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__sealers-adhesives-and-lubricants) .
4. Install the oil filter adapter to the engine block.
5. Install the oil filter adapter bolts. Tighten: Tighten the oil filter adapter bolts to 25 N.m (18 lb ft).
6. Lightly oil the oil filter gasket with clean oil.
7. Install the oil filter. Refer to «Engine Oil and Oil Filter Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-2-of-5) .
8. Connect the electrical connector to the engine oil pressure switch.
9. Connect the engine oil cooler lines to the adapter.
10. Install the left engine mount bracket. Refer to «Engine Mount Bracket Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
11. Lower the vehicle.
12. Adjust the engine oil level to the full mark.
13. Inspect for oil leaks after engine start up.

Crankshaft Balancer Replacement

Tools Required

1. J 45059 Angle Meter. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
2. J 41816 Crankshaft Balancer Remover. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
3. J 41998-B Crankshaft Balancer Installer. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
4. EN 46326 Flywheel Holding Tool. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .

1. Remove the water pump and generator drive belt. Refer to «Water Pump and Generator Belt Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
2. Remove the supercharger drive belt. Refer to «Supercharger Belt Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
3. Remove the air conditioning and power steering drive belt. Refer to «Air Conditioning Compressor and Power Steering Pump Belt Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
4. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/xlr/i-2003-2009/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) .
5. Remove the power steering gear. Refer to «Steering Gear Replacement»(/cadillac/xlr/i-2003-2009/remont/manual-power-steering/#power-steering-system) .
6. Remove the starter motor. Refer to «Starter Motor Replacement (LC3)»(/cadillac/xlr/i-2003-2009/remont/charging-system/#battery-charging-system-and-starting-system) .
7. Install the EN 46326 . See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
8. Remove the crankshaft balancer bolt.
9. Place the remover pilot into the end of the crankshaft.
10. Install the J 41816 on the crankshaft balancer. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
11. Remove the crankshaft balancer using the J 41816 . See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
12. Ensure that you do not lose the oil pump drive to crankshaft balancer friction washer. The friction washer may come off with the balancer.
13. Clean and inspect the crankshaft balancer. Refer to «Crankshaft Balancer Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-3-of-5) .

1. Ensure that the oil pump drive to crankshaft balancer friction washer is installed.
2. Position the crankshaft balancer on the nose of the crankshaft.
3. Press the crankshaft balancer in place using the J 41998-B . See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
4. Clean the crankshaft balancer bolt threads.
5. Apply engine oil to the crankshaft balancer bolt threads.
6. Install the crankshaft balancer bolt. First Pass Tighten: Tighten the crankshaft balancer bolt to 50 N.m (37 lb ft). Final Pass Tighten: Tighten the crankshaft balancer bolt an additional 120 degrees using the J 45059 . See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
7. Install the steering gear. Refer to «Steering Gear Replacement»(/cadillac/xlr/i-2003-2009/remont/manual-power-steering/#power-steering-system) .
8. Lower the vehicle.
9. Remove the EN 46326 . See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
10. Install the starter motor. Refer to «Starter Motor Replacement (LC3)»(/cadillac/xlr/i-2003-2009/remont/charging-system/#battery-charging-system-and-starting-system) .
11. Install the air conditioning and power steering drive belt. Refer to «Air Conditioning Compressor and Power Steering Pump Belt Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
12. Install the supercharger drive belt. Refer to «Supercharger Belt Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
13. Install the water pump and generator drive belt. Refer to «Water Pump and Generator Belt Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

1. Drain the cooling system. Refer to «Cooling System Draining and Filling (Static Fill)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system__cooling-system-draining-and-filling-static) or «Cooling System Draining and Filling (GE 47716)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system__cooling-system-draining-and-filling-ge) .
2. Remove the air cleaner assembly. Refer to «Air Cleaner Assembly Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
3. Remove the accessory drive belts. Refer to «Supercharger Belt Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) , «Water Pump and Generator Belt Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) and «Air Conditioning Compressor and Power Steering Pump Belt Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
4. Remove the accessory drive belt tensioners. Refer to «Drive Belt Tensioner Replacement - Supercharger»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) , «Water Pump and Generator Drive Belt Tensioner Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) and «Air Conditioning Compressor Belt Tensioner Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
5. Remove the accessory drive belt idler pulleys. Refer to «Supercharger Belt Idler Pulley Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) and «Water Pump and Generator Belt Idler Pulley Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
6. Remove the water pump pulley. Refer to «Water Pump Replacement (LC3)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) .
7. Remove the water outlet housing. Refer to «Water Outlet Housing Replacement (LC3)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) .
8. Remove the radiator hose and the heater hose from the thermostat housing. position the hoses aside.
9. Remove the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__crankshaft-balancer-replacement) .
10. Remove the engine front cover bolts.
11. Remove the engine front cover.
12. Remove and discard the engine front cover gasket.
13. Remove the oil pump drive to crankshaft balancer friction washer.
14. Clean and inspect the engine front cover. Refer to «Engine Front Cover Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-4-of-5) .

1. Install the oil pump drive to crankshaft balancer friction washer.
2. Place a small amount of sealant at the split line of the upper and lower crankcases (1). Refer to «Sealers, Adhesives, and Lubricants»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__sealers-adhesives-and-lubricants) for the correct part number.
3. Place the NEW engine front cover gasket over the crankcase dowel pins.
4. Place a small amount of sealant at the engine front cover gasket pad area located on top of the split line of the upper and lower crankcases (1). Refer to «Sealers, Adhesives, and Lubricants»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__sealers-adhesives-and-lubricants) for the correct part number.
5. Place the engine front cover in position on the crankcase.
6. Apply the thread locking compound to the threads of the engine front cover bolts. Refer to «Sealers, Adhesives, and Lubricants»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__sealers-adhesives-and-lubricants) for the correct part number.
7. Install the engine front cover retaining bolts.
8. Tighten the engine front cover bolts in the sequence shown. Tighten: Tighten the engine front cover bolts in proper sequence to 15 N.m (11 lb ft).
9. Install the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__crankshaft-balancer-replacement) .
10. Install the radiator hose and the heater hose to the thermostat housing.
11. Install the water outlet housing. Refer to «Water Outlet Housing Replacement (LC3)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) .
12. Install the water pump pulley. Refer to «Water Pump Replacement (LC3)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system) .
13. Install the accessory drive belt idler pulleys. Refer to «Supercharger Belt Idler Pulley Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) and «Water Pump and Generator Belt Idler Pulley Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
14. Install the accessory drive belt tensioners. Refer to «Drive Belt Tensioner Replacement - Supercharger»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) , «Water Pump and Generator Drive Belt Tensioner Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) and «Air Conditioning Compressor Belt Tensioner Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
15. Install the accessory drive belts. Refer to «Supercharger Belt Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) , «Water Pump and Generator Belt Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) and «Air Conditioning Compressor and Power Steering Pump Belt Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
16. Install the air cleaner assembly. Refer to «Air Cleaner Assembly Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
17. Fill the cooling system. Refer to «Cooling System Draining and Filling (Static Fill)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system__cooling-system-draining-and-filling-static) or «Cooling System Draining and Filling (GE 47716)»(/cadillac/xlr/i-2003-2009/remont/cooling-system-mechanical/#engine-cooling-system__cooling-system-draining-and-filling-ge) .

1. EN-48036 Oil Pump Alignment Tool. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
2. J 45059 Angle Meter. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .

1. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
2. Remove the oil pump drive to crankshaft balancer friction washer.
3. Remove the 3 oil pump assembly retaining bolts (1, 2, 3) identified by the larger head size.
4. Slide the oil pump assembly off the nose of the crankshaft with the drive collar in place.
5. Remove the crankshaft sprocket to oil pump drive friction washer.
6. Disassemble the oil pump as necessary. Refer to «Oil Pump Disassemble»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-3-of-5__oil-pump-disassemble-off-vehicle) .
7. Clean and inspect the oil pump. Refer to «Oil Pump Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-3-of-5) .
8. Assemble the oil pump if necessary. Refer to «Oil Pump Assemble»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-3-of-5__oil-pump-assemble-off-vehicle) .

1. Install the crankshaft sprocket to oil pump drive friction washer.
2. Install the oil pump drive spacer (1) into the oil pump (2) so that the drive flat engages the pump rotor.
3. Install the oil pump.
4. Install the EN-48036 over the crankshaft nose and up to the oil pump. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
5. Loosely install the oil pump bolts.
6. Apply force by hand to the EN-48036 against the oil pump in order to align the pump to the oil pump drive. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
7. Install the retaining bolts.
8. While keeping force on the EN-48036 tighten the oil pump bolts in sequence (1, 2, 3) as shown. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) . Tighten: First Pass Tighten the oil pump mounting bolts in sequence to 10 N.m (89 lb in). Final Pass Tighten the oil pump mounting bolts in sequence an additional 35 degrees using the J 45059 . See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
9. Remove the EN-48036 . See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
10. Install the oil pump drive to crankshaft balancer friction washer.
11. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/cadillac/xlr/i-2003-2009/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) .
2. Disconnect the electrical connector from the engine oil pressure switch.
3. Remove the engine oil pressure switch from the oil filter adapter using a snap-on S 6152 Oil Pressure Sender Switch Crowfoot Wrench™ (1 1/16") or equivalent.

1. Install a new O-ring on the oil pressure switch.
2. Install the engine oil pressure switch to the oil filter adapter using a Snap-On™ S 6152 Oil Pressure Sender Switch Crowfoot Wrench (1 1/16") or equivalent. Tighten: Tighten the engine oil pressure switch to 16 N.m (12 lb ft).
3. Connect the electrical connector to the engine oil pressure switch.
4. Lower the vehicle.
5. Adjust the engine oil level to the full mark.
6. Inspect for oil leaks after engine start up.

1. Drain the engine oil. Refer to «Engine Oil and Oil Filter Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-2-of-5) .
2. Disconnect the electrical connector (1) from the engine oil level sensor (2).
3. Remove the engine oil level sensor (2) from the oil pan.

1. Install the engine oil level sensor (2) into the oil pan. Tighten: Tighten the engine oil level sensor to 20 N.m (15 lb ft).
2. Connect the electrical connector (1) to the engine oil level sensor (2).
3. Fill the engine oil. Refer to «Engine Oil and Oil Filter Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-2-of-5) .
4. Inspect for oil leaks after engine start up.

1. Remove the engine oil pan. Refer to «Oil Pan Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-2-of-5) .
2. Remove the oil pump pipe support bracket nut.
3. Remove the oil pump pipe bolt.
4. Remove the oil pump pipe and screen assembly.
5. Remove and discard the oil pump pipe and screen assembly gasket.

1. Install a NEW gasket to the oil pump pipe and screen assembly.
2. Install the oil pump pipe and screen assembly.
3. Install the oil pump pipe and screen assembly retaining bolt and nut. Tighten: Tighten the oil pump pick-up tube nut to 24 N.m (18 lb ft). Tighten the oil pump pick-up tube bolt to 10 N.m (89 lb in).
4. Install the oil pan. Refer to «Oil Pan Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-2-of-5) .

J 39946 Crankshaft Socket. See Special Tools .

1. Remove the oil pump. Refer to «Oil Pump Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
2. Remove the crankshaft sprocket to oil pump drive friction washer.
3. Align the primary timing marks (1) using the J 39946 . See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
4. Remove the secondary camshaft drive chains. Refer to «Secondary Camshaft Drive Chain Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-replacement) and «Secondary Camshaft Drive Chain Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-replacement) .
5. Remove the primary drive chain tensioner. Refer to «Primary Camshaft Drive Chain Tensioner Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
6. Remove the oil outlet tube bolts (1-5).
7. Remove the oil outlet tube.
8. Remove and discard the oil outlet tube O-ring.
9. Clean and inspect the oil outlet tube. Refer to «Oil Pump Outlet Tube Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-3-of-5) .

1. Install a NEW O-ring on the oil outlet tube.
2. Apply lubricant to the O-ring.
3. Install the oil outlet tube and bolts (1-5). Tighten: Tighten the oil outlet tube bolts to 10 N.m (89 lb in).
4. Ensure the primary timing marks (1) are aligned vertically using the J 39946 . See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
5. Install the primary drive chain tensioner. Refer to «Primary Camshaft Drive Chain Tensioner Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
6. Install the secondary camshaft drive chains. Refer to «Secondary Camshaft Drive Chain Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-replacement) and «Secondary Camshaft Drive Chain Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-replacement) .
7. Install the crankshaft sprocket to oil pump drive friction washer. The crankshaft sprocket to oil pump drive friction washer outer diameter is 62.0 mm (2.4410 in) and the inner diameter is 45.25 mm (1.7815 in).
8. Install the oil pump. Refer to «Oil Pump Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

1. Remove the engine sight shield. Refer to «Intake Manifold Sight Shield Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
2. Disconnect the vacuum hose from the brake booster. Position the hose aside.
3. Remove the air cleaner assembly. Refer to «Air Cleaner Assembly Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
4. Remove the front section of the supercharger inlet duct assembly. Refer to «Supercharger Inlet Duct Assembly Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
5. Disconnect the positive crankcase ventilation (PCV) fresh air tube from the left camshaft cover.
6. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2__fuel-pressure-relief) .
7. Disconnect the fuel line from the fuel rail. Position the fuel line aside. Refer to «Fuel Hose/Pipes Replacement - Engine Compartment»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
8. Disengage the wire harness retainers from the camshaft cover.
9. Remove the left bank ignition coils as an assembly. Refer to «Ignition Coil Replacement - Bank 2»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
10. Remove the bolt connecting the ground strap to the left rear corner of the camshaft cover.
11. Remove the bolt securing the oil level indicator tube to the left cylinder head and reposition the tube away from the camshaft cover.
12. Remove the camshaft cover bolts.
13. Lift the camshaft drive end of the camshaft cover up.
14. Remove the camshaft cover.
15. Discard the camshaft cover gasket and spark plug port seals if there is any evidence of damage or if the seal comes out of the groove in the cover during removal.
16. Clean and inspect the camshaft cover. Refer to «Camshaft Cover Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-4-of-5) .

1. Work the camshaft cover into position by pivoting the cover down and aligning the bolt holes.
2. Install the camshaft cover bolts installing the ground strap to the camshaft cover. Tighten: Tighten the camshaft cover bolts to 10 N.m (89 lb in).
3. Rotate the oil level indicator tube back into its original position and install the bolt securing the tube to the cylinder head. Tighten: Tighten the oil level indicator tube bolt to 10 N.m (89 lb in).
4. Install the left bank ignition coil assembly. Refer to «Ignition Coil Replacement - Bank 2»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
5. Attach the wire harness retainers to the camshaft cover.
6. Connect the fuel line to the fuel rail. Refer to «Fuel Hose/Pipes Replacement - Engine Compartment»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
7. Install the PCV fresh air tube to the left camshaft cover.
8. Install the front section of the supercharger inlet duct assembly. Refer to «Supercharger Inlet Duct Assembly Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
9. Install the air cleaner assembly. Refer to «Air Cleaner Assembly Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
10. Connect the vacuum hose to the brake booster.
11. Install the engine sight shield. Refer to «Intake Manifold Sight Shield Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

1. Remove the engine sight shield. Refer to «Intake Manifold Sight Shield Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
2. Remove the front section of the supercharger inlet duct assembly. Refer to «Supercharger Inlet Duct Assembly Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
3. Disconnect the PCV dirty air tube from the right side camshaft cover.
4. Remove the right bank ignition coils as an assembly. Refer to «Ignition Coil Replacement - Bank 1»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
5. Disconnect the wire harness clips from the camshaft cover and position the wire harness aside.
6. Remove the bolt connecting the ground strap to the right rear of the camshaft cover.
7. Remove the camshaft cover bolts.
8. Remove the camshaft cover.
9. Discard the camshaft cover gasket and spark plug port seals if there is any evidence of damage or if the seal comes out of the groove in the cover during removal.
10. Clean and inspect the camshaft cover. Refer to «Camshaft Cover Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-4-of-5) .

1. Install the camshaft cover gasket as required. IMPORTANT: Be careful to prevent the exposed section of the camshaft cover seal from being damaged by the edge of the cylinder head casting.
2. Install the camshaft cover.
3. Install the camshaft cover bolts installing the ground strap to the camshaft cover. Tighten: Tighten the camshaft cover bolts to 10 N.m (89 lb in).
4. Connect the wire harness clips to the camshaft cover.
5. Install the right bank ignition coil assembly. Refer to «Ignition Coil Replacement - Bank 1»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
6. Connect the PCV dirty air tube to the right side camshaft cover.
7. Install the front section of the supercharger inlet duct assembly. Refer to «Supercharger Inlet Duct Assembly Replacement»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
8. Install the engine sight shield. Refer to «Intake Manifold Sight Shield Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

1. Remove the left exhaust camshaft sensor. Refer to «Camshaft Position Sensor Replacement - Bank 2 (Left Side) Exhaust»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
2. Remove the left intake camshaft sensor. Refer to «Camshaft Position Sensor Replacement - Bank 2 (Left Side) Intake»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
3. Remove the left camshaft cover. Refer to «Camshaft Cover Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
4. Remove the water pump and generator drive belt tensioner. Refer to «Water Pump and Generator Drive Belt Tensioner Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
5. Remove the left intake camshaft position actuator magnet bolts.
6. Remove the left intake camshaft position actuator magnet.
7. Remove the left intake camshaft position actuator magnet alignment plug and discard.
8. Remove the left exhaust camshaft position actuator magnet bolts.
9. Remove the left exhaust camshaft position actuator magnet.
10. Remove the left exhaust camshaft position actuator magnet alignment plug and discard.
11. Remove the wire harness retainers from the actuator housing studs.
12. Remove the left camshaft position actuator housing bolts.
13. Remove the left camshaft position actuator housing.

1. Install a NEW gasket to the camshaft position actuator housing.
2. Install the left camshaft position actuator housing to the left cylinder head.
3. Install the actuator housing bolts and studs. Tighten: Tighten the actuator housing bolts and studs to 10 N.m (89 lb in).
4. To allow for camshaft position actuator solenoid to camshaft position actuator oil control valve alignment, DO NOT install NEW camshaft position actuator solenoid alignment plugs at this time.
5. Use the following procedure for the camshaft position actuator solenoid alignment: Make an alignment pin from drill rod 15/64 inch diameter and at least 50 mm (1.97 in) long. Verify that the alignment pin will pass through the camshaft position actuator solenoid alignment hole. Verify that the alignment pin will fit into the alignment hole in the camshaft position actuator oil control valve. Apply a 2 mm (0.079 in) bead of RTV around the flange of the camshaft position actuator solenoid. Refer to «Sealers, Adhesives, and Lubricants»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__sealers-adhesives-and-lubricants) for the correct part number. Install the camshaft position actuator solenoid over the oil control valve. Install the alignment pin through the solenoid alignment hole and into the oil control valve alignment hole. With the alignment pin in place, install the camshaft position actuator solenoid bolts. Tighten: Tighten the camshaft position actuator solenoid bolts to 8 N.m (71 lb in). Remove the alignment pin. Install a NEW camshaft position actuator solenoid plug. Repeat this alignment procedure for the exhaust camshaft position actuator solenoid.
6. Install the wire harness retainers to the actuator housing studs.
7. Install the left camshaft cover. Refer to «Camshaft Cover Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
8. Install the left intake camshaft sensor. Refer to «Camshaft Position Sensor Replacement - Bank 2 (Left Side) Intake»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
9. Install the left exhaust camshaft sensor. Refer to «Camshaft Position Sensor Replacement - Bank 2 (Left Side) Exhaust»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
10. Install the water pump and generator drive belt tensioner. Refer to «Water Pump and Generator Drive Belt Tensioner Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

1. Remove the right exhaust camshaft sensor. Refer to «Camshaft Position Sensor Replacement - Bank 1 (Right Side) Exhaust»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
2. Remove the right intake camshaft sensor. Refer to «Camshaft Position Sensor Replacement - Bank 1 (Right Side) Intake»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
3. Remove the wire harness retainers from the actuator housing studs. Position the wire harness aside.
4. Remove the right camshaft cover. Refer to «Camshaft Cover Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
5. Remove the supercharger drive belt tensioner. Refer to «Drive Belt Tensioner Replacement - Supercharger»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
6. Remove the power steering reservoir. Refer to «Remote Power Steering Fluid Reservoir Replacement»(/cadillac/xlr/i-2003-2009/remont/manual-power-steering/#power-steering-system) .
7. Remove the right intake camshaft position actuator magnet bolts.
8. Remove the right intake camshaft position actuator magnet.
9. Remove the right intake camshaft position actuator magnet alignment plug and discard.
10. Remove the right exhaust camshaft position actuator magnet bolts.
11. Remove the right exhaust camshaft position actuator magnet.
12. Remove the right exhaust camshaft position actuator magnet alignment plug and discard.
13. Remove the right camshaft position actuator housing bolts.
14. Remove the right camshaft position actuator housing.

1. Install a NEW gasket to the camshaft position actuator housing.
2. Install the right camshaft position actuator housing to the right cylinder head.
3. Install the actuator housing bolts and studs. Tighten: Tighten the actuator housing bolts and studs to 10 N.m (89 lb in).
4. To allow for camshaft position actuator solenoid to camshaft position actuator oil control valve alignment, DO NOT install NEW camshaft position actuator solenoid alignment plugs at this time.
5. Use the following procedure for the camshaft position actuator solenoid alignment: Make an alignment pin from drill rod 15/64 inch diameter and at least 50 mm (1.97 in) long. Verify that the alignment pin will pass through the camshaft position actuator solenoid alignment hole. Verify that the alignment pin will fit into the alignment hole in the camshaft position actuator oil control valve. Apply a 2 mm (0.079 in) bead of RTV around the flange of the camshaft position actuator solenoid. Refer to «Sealers, Adhesives, and Lubricants»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__sealers-adhesives-and-lubricants) for the correct part number. Install the camshaft position actuator solenoid over the oil control valve. Install the alignment pin through the solenoid alignment hole and into the oil control valve alignment hole. With the alignment pin in place, install the camshaft position actuator solenoid bolts. Tighten: Tighten the camshaft position actuator solenoid bolts to 8 N.m (71 lb in). Remove the alignment pin. Install a NEW camshaft position actuator solenoid plug. Repeat this alignment procedure for the exhaust camshaft position actuator solenoid.
6. Install the right camshaft cover. Refer to «Camshaft Cover Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
7. Install the wire harness retainers to the actuator housing studs.
8. Install the right intake camshaft sensor. Refer to «Camshaft Position Sensor Replacement - Bank 1 (Right Side) Intake»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
9. Install the right exhaust camshaft sensor. Refer to «Camshaft Position Sensor Replacement - Bank 1 (Right Side) Exhaust»(/cadillac/xlr/i-2003-2009/remont/testing-diagnostics/#engine-controls-44l-introduction-2-of-2) .
10. Install the supercharger drive belt tensioner. Refer to «Drive Belt Tensioner Replacement - Supercharger»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
11. Install the power steering reservoir. Refer to «Remote Power Steering Fluid Reservoir Replacement»(/cadillac/xlr/i-2003-2009/remont/manual-power-steering/#power-steering-system) .

Secondary Camshaft Drive Chain Replacement - Left Side

Tools Required

1. J 39946 Crankshaft Socket. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
2. EN 46328 Camshaft Holding Tool. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .

1. Remove the right secondary timing chain. Refer to «Secondary Camshaft Drive Chain Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-replacement) .
2. Using the J 39946 , rotate the crankshaft until the primary timing gear alignment marks (1) are adjacent to each other as shown. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
3. Remove the left camshaft position actuator housing. DO NOT remove the actuator solenoids from the housing. Refer to «Camshaft Position Actuator Housing Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
4. Install the EN 46328 (1) on the bank 2 (left) camshafts (2). See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
5. Loosen and remove the left secondary timing chain tensioner bolts and tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-tensioner-replacement) .
6. Use an open-end wrench on the hex cast into the camshaft in order to prevent the camshaft from rotating when removing the camshaft oil control valve.
7. Loosen and remove the bank 2 (left) exhaust camshaft position oil control valve.
8. Slide the left exhaust camshaft position actuator off of the camshaft and remove the secondary timing chain from the camshaft actuator teeth.
9. Use an open-end wrench on the hex cast into the camshaft in order to prevent the camshaft from rotating when removing the camshaft oil control valve.
10. Loosen and remove the bank 2 (left) intake camshaft position oil control valve.
11. Slide the left intake camshaft position actuator off of the camshaft and remove the secondary timing chain from the camshaft actuator teeth.
12. Remove the left secondary timing chain from the engine.
13. Clean and inspect the camshaft timing drive components. Refer to «Camshaft Timing Drive Components Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-3-of-5) .

1. The secondary timing chain (2) has 3 black links that aid in timing the camshaft position actuators to the intermediate sprocket.
2. The black link (4) is aligned with the bank 2 exhaust actuator timing mark. The black link (3) is aligned with the bank 2 intake actuator timing mark.
3. The black link (1) is aligned with the intermediate sprocket.
4. The intermediate sprocket left bank timing mark is labeled left bank (LB) as shown.
5. Assemble the secondary timing chain to the intermediate sprocket aligning the sprocket LB timing mark to the timing chain black link.
6. Align the timing mark (5) of the LB intake camshaft position actuator with the timing chain black link (3) and install the actuator on the camshaft with the actuator timing mark perpendicular (90 degrees) to the cylinder head deck surface at the top of its rotation.
7. Loosely install the oil control valve (10) to secure the intake actuator.
8. Use an open-end wrench on the hex cast into the camshaft in order to prevent the camshaft from rotating when tightening the oil control valve. Tighten: Tighten the oil control valve to 120 N.m (89 lb ft).
9. Align the timing mark (7) of the LB exhaust camshaft position actuator with the timing chain black link (4) and install the actuator on the camshaft with the actuator timing mark perpendicular (90 degrees) to the cylinder head deck surface at the top of its rotation.
10. Loosely install the oil control valve (8) to secure the exhaust actuator.
11. Use an open-end wrench on the hex cast into the camshaft in order to prevent the camshaft from rotating when tightening the oil control valve. Tighten: Tighten the oil control valve to 120 N.m (89 lb ft).
12. Install the left secondary timing chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-tensioner-replacement) .
13. Install the right secondary timing chain. Refer to «Secondary Camshaft Drive Chain Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-replacement) .
14. Remove the EN 46328 . See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
15. Install the left camshaft position actuator housing. Refer to «Camshaft Position Actuator Housing Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

Secondary Camshaft Drive Chain Replacement - Right Side

Tools Required

1. EN 46328 Camshaft Holding Tool. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
2. J 39946 Crankshaft Socket. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .

1. Remove the oil pump. Refer to «Oil Pump Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
2. Using the J 39946 , rotate the crankshaft until the primary timing gear marks (1) are adjacent to each other as shown. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
3. Remove the right camshaft position actuator housing. DO NOT remove the actuator solenoids from the housing. Refer to «Camshaft Position Actuator Housing Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
4. Install the EN 46328 (1) on the bank 1 (right) camshafts (2). See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
5. Loosen and remove the right secondary timing chain tensioner bolts and tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-tensioner-replacement) .
6. Use an open-end wrench on the hex cast into the camshaft in order to prevent the camshaft from rotating when removing the camshaft oil control valve.
7. Loosen and remove the bank 1 (right) exhaust camshaft position oil control valve.
8. Slide the right exhaust camshaft position actuator off of the camshaft and remove the secondary timing chain from the camshaft actuator teeth.
9. Use an open-end wrench on the hex cast into the camshaft in order to prevent the camshaft from rotating when removing the camshaft oil control valve.
10. Loosen and remove the bank 1 (right) intake camshaft position oil control valve.
11. Slide the right intake camshaft position actuator off of the camshaft and remove the secondary timing chain from the camshaft actuator teeth.
12. Remove the right secondary timing chain from the engine.
13. Clean and inspect the camshaft timing drive components. Refer to «Camshaft Timing Drive Components Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-3-of-5) .

1. The secondary timing chain has 3 black links that aid in timing the camshaft position actuators to the intermediate sprocket.
2. The black link (2) is aligned with the bank 1 exhaust actuator timing mark. The black link (3) is aligned with the bank 1 intake actuator timing mark.
3. The black link (1) is aligned with the intermediate sprocket.
4. The intermediate sprocket right bank timing mark is labeled right bank (RB) as shown.
5. Assemble the secondary timing chain to the intermediate sprocket aligning the sprocket RB timing mark to the timing chain black link.
6. Align the timing mark (5) of the RB intake camshaft position actuator with the timing chain black link (8) and install the actuator on the camshaft with the actuator timing mark perpendicular (90 degrees) to the cylinder head deck surface near the top of its rotation.
7. Loosely install the oil control valve (2) to secure the intake actuator.
8. Use an open-end wrench on the hex cast into the camshaft in order to prevent the camshaft from rotating when tightening the oil control valve. Tighten: Tighten the oil control valve to 120 N.m (89 lb ft).
9. Align the timing mark (3) of the RB exhaust camshaft position actuator with the timing chain black link and install the actuator on the camshaft with the actuator timing mark perpendicular (90 degrees) to the cylinder head deck surface near the top of its rotation.
10. Loosely install the oil control valve (1) to secure the exhaust actuator.
11. Use an open-end wrench on the hex cast into the camshaft in order to prevent the camshaft from rotating when tightening the oil control valve. Tighten: Tighten the oil control valve to 120 N.m (89 lb ft).
12. Install the right secondary timing chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-tensioner-replacement) .
13. Remove the EN 46328 . See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
14. Install the right camshaft position actuator housing. Refer to «Camshaft Position Actuator Housing Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
15. Install the oil pump. Refer to «Oil Pump Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

Secondary Camshaft Drive Chain Tensioner Replacement - Left Side

Tools Required

1. J 39946 Crankshaft Rotation Socket. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
2. EN 46328 Camshaft Holding Tool. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .

1. Remove the left camshaft cover. Refer to «Camshaft Cover Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
2. Remove the engine oil pump. Refer to «Oil Pump Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
3. Align the primary timing marks (1) using the J 39946 . See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
4. Install the EN 46328 (1) on the left bank camshafts (2). See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
5. Create 2 reference marks (1) using a paint stick to identify the chain link adjacent to each actuator timing mark (2, 3).
6. Remove the 2 bolts attaching the left secondary camshaft drive chain tensioner to the engine block.
7. Remove the left secondary camshaft drive chain tensioner, allowing the tensioner to expand as you remove it.
8. Clean and inspect the camshaft timing drive components. Refer to «Camshaft Timing Drive Components Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-3-of-5) .

1. Collapse the left secondary camshaft chain tensioner using the following procedure: Rotate the ratchet release lever (2) counterclockwise and hold. Collapse the tensioner shoe (1) and hold. Release the ratchet lever (2).
2. Slowly release the pressure on the shoe (1), until the ratchet lever (2) moves to the first detent and a "click" is heard and felt.
3. Collapse the tensioner shoe (1) and hold.
4. Insert a pin through the hole in the release lever in order to lock the tensioner shoe in the collapsed position.
5. Install the left secondary camshaft drive chain tensioner and retaining bolts. Tighten: Tighten the secondary camshaft drive chain tensioner bolts to 25 N.m (18 lb ft).
6. Remove the pin holding the tensioner to tighten any slack in the timing chain.
7. Inspect the 2 paint marks created previously to ensure they remain aligned with the timing marks (1, 2) on the actuator.
8. Install the engine oil pump. Refer to «Oil Pump Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
9. Remove the EN 46328 (1). See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
10. Install the camshaft cover. Refer to «Camshaft Cover Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

Secondary Camshaft Drive Chain Tensioner Replacement - Right Side

Tools Required

1. EN 46328 Camshaft Holding Tool. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
2. J 39946 Crankshaft Socket. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .

1. Remove the right camshaft cover. Refer to «Camshaft Cover Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
2. Remove the engine oil pump. Refer to «Oil Pump Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
3. Align the primary timing marks (1) using the J 39946 . See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
4. Install the EN 46328 (1) on the right bank camshafts (2). See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
5. Create 2 reference marks (1) using a paint stick to identify the chain link adjacent to each actuator timing mark (2, 3).
6. Install an engine front cover bolt (2) into the front of the engine.
7. Wrap mechanics wire (1) tightly around both the right secondary camshaft drive chain shoe (3) and the front cover bolt (2).
8. Remove the 2 bolts attaching the right secondary camshaft drive chain tensioner to the engine block.
9. Remove the right secondary camshaft drive chain tensioner, allowing the tensioner to expand as you remove it.
10. Clean and inspect the camshaft timing drive components. Refer to «Camshaft Timing Drive Components Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-3-of-5) .

1. Collapse the right secondary camshaft chain tensioner using the following procedure: Rotate the ratchet release lever (2) counterclockwise and hold. Collapse the tensioner shoe (1) and hold. Release the ratchet lever (2).
2. Slowly release the pressure on the shoe (1), until the ratchet lever (2) moves to the first detent and a "click" is heard and felt.
3. Collapse the tensioner shoe (1) and hold.
4. Insert a pin through the hole in the release lever in order to lock the tensioner shoe in the collapsed position.
5. Install the right secondary camshaft drive chain tensioner and retaining bolts. Tighten: Tighten the secondary camshaft drive chain tensioner bolts to 25 N.m (18 lb ft).
6. Remove the pin holding the tensioner to tighten any slack in the timing chain.
7. Inspect the 2 paint marks (1, 3) created previously to ensure they remain aligned with the timing marks (2, 4) on the actuator.
8. Remove the mechanics wire (1) supporting the right secondary camshaft drive chain shoe (3).
9. Remove the engine front cover bolt (2) from the front of the engine.
10. Install the engine oil pump. Refer to «Oil Pump Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
11. Remove the EN 46328 (1). See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
12. Install the right camshaft cover. Refer to «Camshaft Cover Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

Secondary Camshaft Drive Chain Shoe Replacement - Left Side

Tools Required

1. J 39946 Crankshaft Socket. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
2. EN 46328 Camshaft Holding Tool. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .

1. Remove the left secondary camshaft tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-tensioner-replacement) .
2. Remove the left camshaft position actuator housing. DO NOT remove the camshaft actuator solenoids from the housing. Refer to «Camshaft Position Actuator Housing Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
3. Using the J 39946 , rotate the crankshaft until both camshaft position actuator timing marks (5, 7) are at the top of their rotation. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
4. Install the EN 46328 (1) to the camshafts (2). See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
5. Use a paint stick to create a mark (1) on the timing chain link adjacent to each camshaft position actuator timing mark (2).
6. Use a paint stick to create a mark on a primary chain link and intermediate primary chain sprocket tooth adjacent to the primary chain link.
7. Use an open end wrench on the hex cast into the left intake camshaft to prevent the camshaft from rotating when loosening the camshaft oil control valve.
8. Loosen and remove the left intake oil control valve.
9. Slide the left intake camshaft actuator off of the camshaft, disengage the sprocket teeth from the secondary timing chain, and remove the actuator.
10. Remove the left secondary camshaft drive timing chain shoe bolt.
11. Remove the left secondary camshaft drive timing shoe.
12. Clean and inspect the camshaft timing drive components. Refer to «Camshaft Timing Drive Components Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-3-of-5) .

1. Position the left secondary camshaft drive chain shoe in through the left front cylinder head as shown.
2. Install the left secondary camshaft drive chain shoe bolt. Tighten: Tighten the secondary camshaft drive chain shoe bolt to 25 N.m (18 lb ft).
3. Install the left intake actuator to the secondary chain, ensuring that the actuator timing mark is aligned with the chain link that was marked during disassembly.
4. Loosely install the oil control valve to secure the intake actuator to the camshaft.
5. Use an open-end wrench on the hex cast into the camshaft in order to prevent the camshaft from rotating when tightening the oil control valve. Tighten: Tighten the oil control valve to 120 N.m (89 lb ft).
6. Install the left secondary camshaft drive chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-tensioner-replacement) .
7. Ensure that the previously created paint marks (1, 3) still line up with the sprocket timing marks (2, 4).
8. Install the left camshaft actuator housing. Refer to «Camshaft Position Actuator Housing Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

Secondary Camshaft Drive Chain Shoe Replacement - Right Side

Tools Required

1. EN 46328 Camshaft Holding Tool. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
2. J 39946 Crankshaft Socket. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .

1. Remove the right secondary camshaft tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-tensioner-replacement) .
2. Remove the right camshaft position actuator housing. DO NOT remove the camshaft actuator solenoids from the housing. Refer to «Camshaft Position Actuator Housing Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
3. Using the J 39946 , rotate the crankshaft until both camshaft position actuator timing marks (3, 5) are at the top of their rotation. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
4. Install the EN 46328 (1) to the camshafts (2). See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
5. Use a paint stick to create a mark (1) on the timing chain link adjacent to each camshaft position actuator timing mark (2, 3).
6. Use a paint stick to create a mark on a primary chain link and intermediate primary chain sprocket tooth adjacent to the primary chain link.
7. Use an open end wrench on the hex cast into the right exhaust camshaft to prevent the camshaft from rotating when loosening the camshaft oil control valve.
8. Loosen and remove the right exhaust oil control valve.
9. Slide the right exhaust camshaft actuator off of the camshaft, disengage the sprocket teeth from the secondary timing chain, and remove the actuator.
10. Remove the right secondary camshaft drive timing chain shoe bolt.
11. Remove the right secondary camshaft drive timing chain shoe.
12. Clean and inspect the camshaft timing drive components. Refer to «Camshaft Timing Drive Components Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-3-of-5) .

1. Position the right secondary camshaft drive timing chain shoe in through the right front cylinder head as shown.
2. Install the right secondary camshaft drive chain shoe bolt. Tighten: Tighten the secondary camshaft drive chain shoe bolt to 25 N.m (18 lb ft).
3. Install the right exhaust actuator to the secondary chain, ensuring that the actuator timing mark is aligned with the chain link that was marked during disassembly.
4. Loosely install the oil control valve to secure the exhaust actuator to the camshaft.
5. Use an open-end wrench on the hex cast into the camshaft in order to prevent the camshaft from rotating when tightening the oil control valve. Tighten: Tighten the oil control valve to 120 N.m (89 lb ft).
6. Install the right secondary camshaft drive chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-tensioner-replacement) .
7. Ensure that the previously created paint marks (1, 3) still line up with the sprocket timing marks (2, 4).
8. Install the right camshaft actuator housing. Refer to «Camshaft Position Actuator Housing Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

Secondary Camshaft Drive Chain Guide Replacement - Left Side

Tools Required

1. J 39946 Crankshaft Socket. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
2. EN 46328 Camshaft Holding Tool. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .

1. Remove the left secondary camshaft tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-tensioner-replacement) .
2. Remove the left camshaft position actuator housing. DO NOT remove the camshaft actuator solenoids from the housing. Refer to «Camshaft Position Actuator Housing Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
3. Using the J 39946 , rotate the crankshaft until both camshaft position actuator timing marks (5, 7) are at the top of their rotation. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
4. Install the EN 46328 (1) to the camshafts (2). See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
5. Use a paint stick to create a mark (1) on the timing chain link adjacent to each camshaft position actuator timing mark (2, 3).
6. Use a paint stick to create a mark on a primary chain link and intermediate primary chain sprocket tooth adjacent to the primary chain link.
7. Use an open end wrench on the hex cast into the left exhaust camshaft to prevent the camshaft from rotating when loosening the camshaft oil control valve.
8. Loosen and remove the left exhaust oil control valve.
9. Slide the left exhaust camshaft actuator off of the camshaft, disengage the sprocket teeth from the secondary timing chain, and remove the actuator.
10. Remove the secondary camshaft drive chain guide bolt.
11. Remove the left secondary camshaft drive chain guide.
12. Clean and inspect the camshaft timing drive components. Refer to «Camshaft Timing Drive Components Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-3-of-5) .

1. Position the left secondary camshaft drive chain guide in through the left front cylinder head as shown.
2. Install the left secondary camshaft drive chain guide bolt. Tighten: Tighten the secondary camshaft drive chain guide bolt to 25 N.m (18 lb ft).
3. Install the left exhaust actuator to the secondary chain, ensuring that the actuator timing mark is aligned with the chain link that was marked during disassembly.
4. Loosely install the oil control valve to secure the exhaust actuator to the camshaft.
5. Use an open-end wrench on the hex cast into the camshaft in order to prevent the camshaft from rotating when tightening the oil control valve. Tighten: Tighten the oil control valve to 120 N.m (89 lb ft).
6. Install the left secondary camshaft drive chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-tensioner-replacement) .
7. Ensure that the previously created paint marks (1, 3) still line up with the sprocket timing marks (2, 4).
8. Install the left camshaft actuator housing. Refer to «Camshaft Position Actuator Housing Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

Secondary Camshaft Drive Chain Guide Replacement - Right Side

Tools Required

1. J 39946 Crankshaft Socket. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
2. EN 46328 Camshaft Holding Tool. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .

1. Remove the right secondary camshaft tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-tensioner-replacement) .
2. Remove the right camshaft position actuator housing. DO NOT remove the camshaft actuator solenoids from the housing. Refer to «Camshaft Position Actuator Housing Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
3. Using the J 39946 , rotate the crankshaft until both camshaft position actuator timing marks (3, 5) are at the top of their rotation. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
4. Install the EN 46328 (1) to the camshafts (2). See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
5. Use a paint stick to create a mark (1) on the timing chain link adjacent to each camshaft position actuator timing mark (2, 3).
6. Use a paint stick to create a mark on a primary chain link and intermediate primary chain sprocket tooth adjacent to the primary chain link.
7. Use an open end wrench on the hex cast into the right intake camshaft to prevent the camshaft from rotating when loosening the camshaft oil control valve.
8. Loosen and remove the right intake oil control valve.
9. Slide the right intake camshaft actuator off of the camshaft, disengage the sprocket teeth from the secondary timing chain, and remove the actuator.
10. Remove the secondary camshaft drive chain guide bolt.
11. Remove the right secondary camshaft drive chain guide.
12. Clean and inspect the camshaft timing drive components. Refer to «Camshaft Timing Drive Components Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-3-of-5) .

1. Position the right secondary camshaft drive chain guide in through the right front cylinder head as shown.
2. Install the right secondary camshaft drive chain guide bolt. Tighten: Tighten the secondary camshaft drive chain guide bolt to 25 N.m (18 lb ft).
3. Install the right intake actuator to the secondary chain, ensuring that the actuator timing mark is aligned with the chain link that was marked during disassembly.
4. Loosely install the oil control valve to secure the intake actuator to the camshaft.
5. Use an open-end wrench on the hex cast into the camshaft in order to prevent the camshaft from rotating when tightening the oil control valve. Tighten: Tighten the oil control valve to 120 N.m (89 lb ft).
6. Install the right secondary camshaft drive chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-tensioner-replacement) .
7. Ensure that the previously created paint marks (1, 3) still line up with the sprocket timing marks (2, 4).
8. Install the right camshaft actuator housing. Refer to «Camshaft Position Actuator Housing Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

J 39946 Crankshaft Socket. See Special Tools .

1. Remove the engine oil pump. Refer to «Oil Pump Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
2. Align the primary timing marks (1) using the J 39946 . See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
3. Remove the 2 bolts attaching the primary camshaft drive chain tensioner to the engine block.
4. Remove the primary camshaft drive chain tensioner, allowing the tensioner to expand as you remove it.
5. Clean and inspect the camshaft timing drive components. Refer to «Camshaft Timing Drive Components Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-3-of-5) .

1. Collapse the primary camshaft drive chain tensioner using the following procedure: Rotate the ratchet release lever (2) clockwise and hold. Collapse the tensioner shoe (1) and hold. Release the ratchet lever (2).
2. Slowly release the pressure on the shoe (1), until the ratchet lever (2) moves to the first detent and a click is heard and felt.
3. Collapse the tensioner shoe (1) and hold.
4. Insert a pin through the hole in the release lever in order to lock the tensioner shoe in the collapsed position.
5. Install the primary camshaft drive chain tensioner and retaining bolts. Tighten: Tighten the primary camshaft drive chain tensioner bolts to 25 N.m (18 lb ft).
6. Remove the pin holding the tensioner to tighten any slack in the timing chain.
7. Ensure the primary timing marks (1) are aligned vertically.
8. Install the engine oil pump. Refer to «Oil Pump Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

1. Remove the right side secondary camshaft drive chain (4). Refer to «Secondary Camshaft Drive Chain Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-replacement) .
2. Remove the left side secondary camshaft drive chain (2). Refer to «Secondary Camshaft Drive Chain Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-replacement) .
3. Remove the right side secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-shoe-replacement) .
4. Remove the right side secondary camshaft drive chain guide. Refer to «Secondary Camshaft Drive Chain Guide Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-guide-replacement) .
5. Remove the left side secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-shoe-replacement) .
6. Remove the left side secondary camshaft drive chain guide. Refer to «Secondary Camshaft Drive Chain Guide Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-guide-replacement) .
7. Remove the oil outlet tube (4) from the engine. Refer to «Oil Pump Outlet Tube Removal»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-2-of-5__oil-pump-outlet-tube-removal) .
8. Remove the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Drive Chain Tensioner Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
9. Remove the bolts attaching the primary camshaft drive chain guide to the engine block.
10. Remove the primary camshaft drive chain guide.
11. Clean and inspect the camshaft timing drive components. Refer to «Camshaft Timing Drive Components Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-3-of-5) .

1. Install the primary camshaft drive chain guide and retaining bolts. Tighten: Tighten the primary camshaft drive chain guide bolts to 25 N.m (18 lb ft).
2. Install the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Drive Chain Tensioner Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
3. Install the oil outlet tube (4) to the engine. Refer to «Oil Pump Outlet Tube Installation»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-4-of-5__oil-pump-outlet-tube-installation) .
4. Install the left side secondary camshaft drive chain guide. Refer to «Secondary Camshaft Drive Chain Guide Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-guide-replacement) .
5. Install the left side secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-shoe-replacement) .
6. Install the right side secondary camshaft drive chain guide. Refer to «Secondary Camshaft Drive Chain Guide Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-guide-replacement) .
7. Install the right side secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-shoe-replacement) .
8. Install the left side secondary camshaft drive chain (2). Refer to «Secondary Camshaft Drive Chain Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-replacement) .
9. Install the right side secondary camshaft drive chain (4). Refer to «Secondary Camshaft Drive Chain Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-replacement) .

J 39946 Crankshaft Socket. See Special Tools .

1. Remove the oil pump. Refer to «Oil Pump Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
2. Remove the crankshaft sprocket to oil pump drive friction washer.
3. Align the primary timing marks (1) using the J 39946 . See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
4. Remove the secondary camshaft drive chains. Refer to «Secondary Camshaft Drive Chain Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-replacement) and «Secondary Camshaft Drive Chain Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-replacement) .
5. Remove the primary drive chain tensioner. Refer to «Primary Camshaft Drive Chain Tensioner Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
6. Remove the oil outlet tube (4). Refer to «Oil Pump Outlet Tube Removal»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-2-of-5__oil-pump-outlet-tube-removal) .
7. Remove the primary camshaft drive chain guide bolts and guide.
8. Remove the camshaft intermediate sprocket retaining bolt.
9. Remove the following as an assembly: The primary camshaft drive chain (3) The crankshaft sprocket The camshaft intermediate sprocket
10. Remove the crankshaft to crankshaft sprocket friction washer.
11. Clean and inspect the camshaft timing drive components. Refer to «Camshaft Timing Drive Components Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-3-of-5) .

1. Select the crankshaft to crankshaft sprocket friction washer (1). The outer diameter is 63.5 mm (2.5000 in), an inner diameter of 45.25 mm (1.7815 in) and a notch to clear the crankshaft pin.
2. Install the crankshaft to crankshaft sprocket friction washer.
3. Align the timing marks (1) of the camshaft intermediate and crankshaft sprockets. The marks should be aligned vertically in the installed position.
4. Install the primary camshaft drive chain on the drive sprockets.
5. Ensure the number one piston is at Top Dead Center (TDC) and the crankshaft pin is approximately at the 1 o'clock position. Use the J 39946 to rotate the crankshaft as necessary. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
6. Install the following as an assembly: The primary camshaft drive chain (3) The crankshaft sprocket The camshaft intermediate sprocket
7. Install the camshaft intermediate sprocket retaining bolt. Tighten: Tighten the camshaft intermediate sprocket retaining bolt to 60 N.m (44 lb ft).
8. Install the primary drive chain guide.
9. Install the primary drive chain guide bolts. Tighten: Tighten the primary drive chain guide bolts to 25 N.m (18 lb ft).
10. Install the primary drive chain tensioner. Refer to «Primary Camshaft Drive Chain Tensioner Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
11. Install the oil outlet tube (4) and bolts. Refer to «Oil Pump Outlet Tube Installation»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-4-of-5__oil-pump-outlet-tube-installation) . Tighten: Tighten the oil outlet tube bolts to 10 N.m (89 lb in).
12. Install the secondary camshaft drive chains. Refer to «Secondary Camshaft Drive Chain Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-replacement) and «Secondary Camshaft Drive Chain Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__secondary-camshaft-drive-chain-replacement) .
13. Remove the pin from the primary timing chain tensioner release lever.
14. Ensure the primary timing marks (1) are aligned vertically.
15. Install the crankshaft sprocket to oil pump drive friction washer. The crankshaft sprocket to oil pump drive friction washer outer diameter is 62.0 mm (2.4410 mm) and the inner diameter is 45.25 mm (1.7815 in).
16. Install the oil pump. Refer to «Oil Pump Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

1. Remove the camshaft intermediate drive shaft sprocket. Refer to «Primary Camshaft Drive Chain and Sprockets Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
2. Remove the camshaft intermediate drive shaft retaining bolts.
3. Remove the camshaft intermediate drive shaft from the engine.
4. Clean and inspect the camshaft intermediate driveshaft. Refer to «Camshaft Timing Drive Components Cleaning and Inspection»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-3-of-5) .

1. Position the camshaft intermediate drive shaft to the engine, aligning the bolt holes.
2. Install the camshaft intermediate drive shaft retaining bolts. Tighten: Tighten the camshaft intermediate drive shaft retaining bolts to 10 N.m (89 lb in).
3. Install the camshaft intermediate drive shaft sprocket. Refer to «Primary Camshaft Drive Chain and Sprockets Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

Camshaft Position Actuator Oil Control Valve Replacement - Bank 1 (Right Side) Intake

Tools Required

1. J 39946 Crankshaft Socket. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
2. EN 46327 Timing Chain Retention Tool. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
3. EN 46328 Camshaft Holding Tool. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .

1. Remove the right actuator housing. DO NOT remove the camshaft position (CMP) actuator solenoids from the housing. Refer to «Camshaft Position Actuator Housing Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
2. Remove the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__crankshaft-balancer-replacement) .
3. Using the J 39946 , rotate the crankshaft until both bank 1 (right) CMP actuator timing marks are perpendicular (90 degrees) to the cylinder head deck surface and near the top of their rotation. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
4. Install the EN 46328 (1) to the camshafts (2). See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
5. Use a paint stick to create a mark (1) on the timing chain link adjacent to each camshaft position actuator timing mark (2, 3).
6. Install the EN 46327 (1) using the installation of the EN 46327 timing chain retention tool procedure. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .

Installation of the EN 46327 Timing Chain Retention Tool - Right Bank

1. Rotate the wing nut (3) of the EN 46327 to the top of its travel. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
2. Position the bottom retention tool on the cylinder head with the V-notch of the block (1) adjacent to the right exhaust camshaft actuator timing sprocket and chain as shown.
3. Insert the hook end (2) into a secondary timing chain link as shown.
4. Rotate the wing nut until it contacts the retention tool block (1). DO NOT tighten the wing nut at this time.
5. Rotate the wing nut of the EN 46327 (4) to the top of its travel. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
6. Position the top retention tool on the cylinder head with the V-notch of the block (1) adjacent to the right intake camshaft actuator timing sprocket and chain as shown.
7. Insert the hook end (2) into a secondary timing chain link as shown.
8. Rotate the wing nut until it contacts the retention tool block (1). Alternately tighten both wing nuts to retain the chain.
9. Use an open end wrench on the hex cast into the right intake camshaft to prevent the camshaft from rotating when loosening the camshaft oil control valve.
10. Loosen and remove the right intake oil control valve (2).

1. Install the oil control valve through the opening in the right intake camshaft position actuator and thread it into the right intake camshaft.
2. Ensure both camshaft actuator timing marks (1, 3) are aligned with the paint marks on the secondary timing chain previously created.
3. Use an open end wrench on the hex cast into the right intake camshaft to prevent the camshaft from rotating when tightening the camshaft oil control valve. Tighten: Tighten the camshaft oil control valve to 120 N.m (89 lb ft).
4. Remove the EN 46327 timing chain retention tools. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
5. Remove the EN 46328 (1) from the camshafts (2). See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
6. Install the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__crankshaft-balancer-replacement) .
7. Install the right camshaft actuator housing. Refer to «Camshaft Position Actuator Housing Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

Camshaft Position Actuator Oil Control Valve Replacement - Bank 1 (Right Side) Exhaust

Tools Required

1. J 39946 Crankshaft Socket. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
2. EN 46327 Timing Chain Retention Tool. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
3. EN 46328 Camshaft Holding Tool. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .

1. Remove the right actuator housing. DO NOT remove the camshaft position (CMP) actuator solenoids from the housing. Refer to «Camshaft Position Actuator Housing Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
2. Remove the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__crankshaft-balancer-replacement) .
3. Using the J 39946 , rotate the crankshaft until both bank 1 (right) CMP actuator timing marks are perpendicular (90 degrees) to the cylinder head deck surface and near the top of their rotation. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
4. Install the EN 46328 (1) to the camshafts (2). See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
5. Use a paint stick to create a mark (1) on the timing chain link adjacent to each camshaft position actuator timing mark (2, 3).
6. Install the EN 46327 (1) using the installation of the EN 46327 timing chain retention tool procedure. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .

1. Rotate the wing nut (3) of the EN 46327 to the top of its travel. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
2. Position the bottom retention tool on the cylinder head with the V-notch of the block (1) adjacent to the right exhaust camshaft actuator timing sprocket and chain as shown.
3. Insert the hook end (2) into a secondary timing chain link as shown.
4. Rotate the wing nut until it contacts the retention tool block (1). DO NOT tighten the wing nut at this time.
5. Rotate the wing nut of the EN 46327 (4) to the top of its travel. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
6. Position the top retention tool on the cylinder head with the V-notch of the block (1) adjacent to the right intake camshaft actuator timing sprocket and chain as shown.
7. Insert the hook end (2) into a secondary timing chain link as shown.
8. Rotate the wing nut until it contacts the retention tool block (1). Alternately tighten both wing nuts to retain the chain.
9. Use an open end wrench on the hex cast into the right exhaust camshaft to prevent the camshaft from rotating when loosening the camshaft oil control valve.
10. Loosen and remove the right exhaust oil control valve (1).

1. Install the oil control valve through the opening in the right exhaust camshaft position actuator and thread it into the right exhaust camshaft.
2. Ensure both camshaft actuator timing marks (1, 3) are aligned with the paint marks on the secondary timing chain previously created.
3. Use an open end wrench on the hex cast into the right exhaust camshaft to prevent the camshaft from rotating when tightening the camshaft oil control valve. Tighten: Tighten the camshaft oil control valve to 120 N.m (89 lb ft).
4. Remove the EN 46327 timing chain retention tools. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
5. Remove the EN 46328 (1) from the camshafts (2). See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
6. Install the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__crankshaft-balancer-replacement) .
7. Install the right camshaft actuator housing. Refer to «Camshaft Position Actuator Housing Replacement - Right Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

Camshaft Position Actuator Oil Control Valve Replacement - Bank 2 (Left Side) Intake

Tools Required

1. J 39946 Crankshaft Socket. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
2. EN 46327 Timing Chain Retention Tool. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
3. EN 46328 Camshaft Holding Tool. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .

1. Remove the left actuator housing. DO NOT remove the camshaft position (CMP) actuator solenoids from the housing. Refer to «Camshaft Position Actuator Housing Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .
2. Remove the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__crankshaft-balancer-replacement) .
3. Using the J 39946 , rotate the crankshaft until both bank 2 (left) CMP actuator timing marks are perpendicular (90 degrees) to the cylinder head deck surface and near the top of their rotation. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
4. Install the EN 46328 (1) to the camshafts (2). See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
5. Use a paint stick to create a mark (1) on the timing chain link adjacent to each camshaft position actuator timing mark (2, 3).
6. Install the EN 46327 (1) using the installation of the EN 46327 timing chain retention tool procedure. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .

Installation of the EN 46327 Timing Chain Retention Tool - Left Bank

1. Rotate the wing nut (3) of the EN 46327 to the top of its travel. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
2. Position the bottom retention tool on the cylinder head with the V-notch of the block (1) adjacent to the left exhaust camshaft actuator timing sprocket and chain as shown.
3. Insert the hook end (2) into a secondary timing chain link as shown.
4. Rotate the wing nut until it contacts the retention tool block (1). DO NOT tighten the wing nut at this time.
5. Rotate the wing nut of the EN 46327 (4) to the top of its travel. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
6. Position the top retention tool on the cylinder head with the V-notch of the block (1) adjacent to the left intake camshaft actuator timing sprocket and chain as shown.
7. Insert the hook end (2) into a secondary timing chain link as shown.
8. Rotate the wing nut until it contacts the retention tool block (1). Alternately tighten both wing nuts to retain the chain.
9. Use an open end wrench on the hex cast into the left intake camshaft to prevent the camshaft from rotating when loosening the camshaft oil control valve.
10. Loosen and remove the left intake oil control valve (10).

1. Install the oil control valve through the opening in the left intake camshaft position actuator and thread it into the left intake camshaft.
2. Ensure both camshaft actuator timing marks (1, 3) are aligned with the paint marks on the secondary timing chain previously created.
3. Use an open end wrench on the hex cast into the left intake camshaft to prevent the camshaft from rotating when tightening the camshaft oil control valve. Tighten: Tighten the camshaft oil control valve to 120 N.m (89 lb ft).
4. Remove the EN 46327 (1). See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
5. Remove the EN 46328 (1) from the camshafts (2). See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-introduction__special-tools) .
6. Install the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5__crankshaft-balancer-replacement) .
7. Install the left camshaft actuator housing. Refer to «Camshaft Position Actuator Housing Replacement - Left Side»(/cadillac/xlr/i-2003-2009/remont/mechanical/#engine-mechanical-44l-1-of-5) .

See also:
• Fastener Tightening Specifications
• Air Cleaner Assembly Replacement
• Lifting and Jacking the Vehicle
• Fastener Notice
• Special Tools
• Hood Replacement
• Battery Negative Cable Disconnection and Connection
• Front Suspension Crossmember Replacement
• Charge Air Cooling System Draining and Filling (Static Fill)
• Supercharger Cleaning and Inspection
• Fuel Pressure Relief
• Oil Filter Adapter Disassemble
• Oil Filter Adapter Cleaning and Inspection
• Oil Filter Adapter Assemble
• Sealers, Adhesives, and Lubricants
• Engine Oil and Oil Filter Replacement
• Steering Gear Replacement
• Cooling System Draining and Filling (Static Fill)
• Cooling System Draining and Filling (GE 47716)
• Engine Front Cover Cleaning and Inspection
• Oil Pump Disassemble
• Oil Pump Assemble
• Component Fastener Tightening Notice
• Camshaft Holding Tool Caution
• Torque Reaction Against Timing Drive Chain Notice
• Oil Pump Outlet Tube Removal
• Oil Pump Outlet Tube Installation
• Intake Manifold Sight Shield Replacement
• Crankshaft Balancer Replacement
• Secondary Camshaft Drive Chain Replacement - Left Side
• Secondary Camshaft Drive Chain Tensioner Replacement - Left Side
• Secondary Camshaft Drive Chain Shoe Replacement - Right Side
• Secondary Camshaft Drive Chain Guide Replacement - Right Side
