Scheme 104
Scheme 105
| Callout | Component Name |
|---|---|
| 1 | Dimmer/Head Up Display (HUD) Switch |
| 2 | Turn Signal/Multifunction Switch |
| 3 | Inflatable Restraint Steering Wheel Module |
| 4 | Instrument Panel Cluster (IPC) |
| 5 | Air Temperature Sensor - Inside |
| 6 | Windshield Wiper/Washer Switch |
| 7 | Driver Information Center (DIC) Switch |
| 8 | Hazard Switch |
| 9 | CD Changer |
| 10 | Valet Switch |
| 11 | Inflatable Restraint I/P Module |
| 12 | Inflatable Restraint I/P Module Disable Switch |
| 13 | I/P Compartment Lamp |
| 14 | Radio |
| 15 | HVAC Control Module |
| 16 | Cigar Lighter |
| 17 | Courtesy Lamp Switch - Console |
| 18 | Folding Top Switch |
| 19 | Inflatable Restraint I/P Module Disable Switch LED |
| 20 | Traction Control Switch |
| 21 | Auxiliary Power Outlet |
| 22 | Courtesy Lamp - Console |
| 23 | Automatic Transmission Shift Lever |
| 24 | Ignition Mode Switch |
| 25 | Steering Wheel Controls - Right |
| 26 | Horn Switch |
| 27 | Data Link Connector (DLC) |
| 28 | Steering Wheel Controls - Left |
Scheme 106
| Callout | Component Name |
|---|---|
| 1 | DLC Connector |
| 2 | C231 |
| 3 | C311 |
| 4 | Fuse Block - Underhood C3 |
| 5 | Fuse Block - Underhood C4 |
| 6 | C220 |
| 7 | Auxiliary Power Relay |
| 8 | Splice Pack, SP208 |
| 9 | C180 |
| 10 | C600 |
| 11 | C602 |
| 12 | Splice Pack, SP202 |
| 13 | G202 |
| 14 | C380 |
| 15 | C382 |
| 16 | Splice Pack, SP302 |
| 17 | G302 |
| 18 | C482 |
| 19 | C480 |
| 20 | C455 |
| 21 | C437 |
| 22 | C433 |
| 23 | C435 |
| 24 | Splice Pack, SP301 |
| 25 | G301 |
| 26 | C377 |
| 27 | C375 |
| 28 | C379 |
| 29 | Splice Pack, SP201 |
| 30 | G201 |
| 31 | C501 |
| 32 | C503 |
Scheme 107
| Connector Part Information OEM: 12176445 Service: 15305919 Description: 3-Way F Metri-Pack 280 Series, Flexlock (NA) |
|---|
| Terminal Part Information Pins: A, C Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
Power Outlet Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | YE | 543 | Accessory Voltage |
| B | Not Used | ||
| C | BK | 1550 | Ground |
Auxiliary Power Outlet
Scheme 108
| Connector Part Information OEM: 12129715 Service: 12129715 Description: 6-Way F Metri-Pack 280 Series, Flexlock (GY) |
|---|
| Terminal Part Information Pins: A1, C2, C2 Terminal/Tray: 12110844/4 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-4A (PU) Pins: A2, C1 Terminal/Tray: 15324340/19 Core/Insulation Crimp: F/G Release Tool/Test Probe: 12094430/J-35616-4A (PU) |
Power Outlet Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A1 | BK | 1550 | Ground |
| A2 | YE | 443 | Accessory Voltage |
| B1-B2 | Not Used | ||
| C1 | RD/BK | 742 | Battery Positive Voltage |
| C2 | D-GN | 1399 | RAP Relay Coil Supply Voltage |
| C2 | D-GN | 1399 | RAP Relay Coil Supply Voltage (Europe) |
Auxiliary Power Relay
Cigar Lighter
| Connector Part Information OEM: 12176445 Service: 15305919 Description: 3-Way F Metri-Pack 280 Series, Flexlock (NA) |
|---|
| Terminal Part Information Pins: A, C Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
Power Outlet Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | YE | 543 | Accessory Voltage |
| B | Not Used | ||
| C | BK | 1550 | Ground |
Cigar Lighter
Tools Required
J 42059 Cigar Lighter Socket Remover. See Special Tools .
Removal Procedure
- Remove the auxiliary power outlet fuse from the fuse block.
- Remove the receptacle: Look into the receptacle. There are two 3 mm (0.11 in) tab windows 12 mm (0.47 in) from the front of the receptacle. The J 42059 pushes the plastic latches from these tab windows and the receptacle can be pulled straight out. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#power-outlets__special-tools) . Place one side of the "T" portion of the J 42059 into the tab window. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#power-outlets__special-tools) . The J 42059 will not fit straight into the receptacle. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#power-outlets__special-tools) . Angle the J 42059 slightly for insertion into the receptacle. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#power-outlets__special-tools) . Insert the other side of the "T" into the opposite tab window. You must move the J 42059 handle toward horizontal to engage the other tab window. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#power-outlets__special-tools) . Use the J 42059 to pull the receptacle straight out. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#power-outlets__special-tools) .
- If J 42059 tool fails to release the lighter socket from the retainer, perform the following alternate method:. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#power-outlets__special-tools) . Insert a small grinding tool with a cutoff wheel into the socket. Remove the plastic latches in the 3 mm (0.11 in) square windows. Use the J 42059 as directed above to remove the socket. See «Special Tools»(/cadillac/xlr/i-2003-2009/remont/body-electrical/#power-outlets__special-tools) .
Installation Procedure
- Route the connector through the retainer. Align the accessory power receptacle retainer to the slot in the opening.
- Install the retainer by pressing into place fully seated.
- Connect the electrical connector to the receptacle.
- Align the tabs on the receptacle to the slots in the retainer. Install the accessory power receptacle by pressing into place until fully seated.
- Install the accessory power receptacle fuse.
Special Tools
Special Tools Illustration Tool Number/Description J 42059 Cigar Lighter Socket Remover
