Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Check Link Fasteners | 9 N.m | 80 lb in |
| Door Latch Screws | 10 N.m | 90 lb in |
| Door Striker Screws | 28 N.m | 21 lb ft |
| Door Trim Panel Screws | 1 N.m | 9 lb in |
| Hinge-to-Body Bolts | 25 N.m | 18 lb ft |
| Hinge-to-Door Bolts | 25 N.m | 18 lb ft |
| Inside Door Handle Fasteners | 2 N.m | 18 lb in |
| Mirror Nuts | 9 N.m | 80 lb in |
| Outside Door Handle Bolts | 5 N.m | 44 lb in |
| Rear Stationary Window Division Post Bolt | 9 N.m | 80 lb in |
| Upper Auxiliary Molding Screws | 2 N.m | 18 lb in |
| Window Clamp Nuts | 11 N.m | 95 lb in |
| Window Regulator Bolts | 9 N.m | 80 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Power Window Schematics
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 5: Door Lock/Indicator Schematics
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 10: Outside Mirror Schematics
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 14: Door Control Module Schematics
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
Scheme 20
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 24: Power Door Systems Component Views
| Callout | Component Name |
|---|
| 1 | Driver Door Switch Assembly (DDSA) |
| 2 | Door Lock Switch - Driver |
| 3 | Mirror Switches |
| 4 | Outside Rearview Mirror - Driver |
| 5 | Window Motor - Driver |
| 6 | Driver Door Module (DDM) |
| 7 | Courtesy Lamp - Left Front Door |
| 8 | Rear Compartment Lid Release Switch - Interior |
| 9 | Door Latch Assembly - Driver |
| 10 | Door Status Indicator - Driver |
Scheme 25
| Callout | Component Name |
|---|
| 1 | Outer Door Panel |
| 2 | Door Handle Switch Assembly -LF, RF Similar |
Scheme 26
| Callout | Component Name |
|---|
| 1 | Outside Rearview Mirror - Passenger |
| 2 | Window Switch - Front Passenger |
| 3 | Door Status Indicator - Passenger |
| 4 | Door Latch Assembly - Passenger |
| 5 | Courtesy Lamp - Right Front Door |
| 6 | Front Passenger Door Module (FPDM) |
| 7 | Speaker - LF Door (UXP/UY5) |
| 8 | Window Motor - Front Passenger |
| 9 | Door Lock Switch - Passenger |
Scheme 27
| Callout | Component Name |
|---|
| 1 | Door Latch Assembly - Left Rear |
| 2 | Window Switch - Left Rear |
| 3 | Speaker - LR Door |
| 4 | Courtesy Lamp - Left Rear Door |
| 5 | Left Rear Door Module |
| 6 | Window Motor - Left Rear |
Scheme 28
| Callout | Component Name |
|---|
| 1 | Window Switch - Right Rear |
| 2 | Door Latch Assembly - Right Rear |
| 3 | Right Rear Door Module (RRDM) |
| 4 | Courtesy Lamp - Right Rear Door |
| 5 | Speaker - RR Door |
| 6 | Window Motor - Right Rear |
