Exterior Trim Buick Rendezvous I

Fastener Tightening Specifications

Fastener Tightening Specifications

Tools Required

J 25070: Heat Gun. See Special Tools and Equipment .

Removal Procedure

Scheme 3

1. Apply tape to the area around the door emblem.
2. Heat the emblem/nameplate, using a heat gun J 25070 152 mm (6.0 in) from the surface.
3. Apply the heat using a circular motion for about 30 seconds. NOTE: Refer to Exterior Trim Emblem Removal Notice in Cautions and Notices.
4. Remove the emblem/nameplate from the door surface using a plastic, flat-bladed tool.
5. Remove all adhesive from the door panel surface and the back of the emblem/nameplate using 3M™ scotch brite molding adhesive remover disk 3M™ P/N 07501 or equivalent.
6. Clean the door surface using varnish makers and painters (VMP) naptha.

Scheme 4

1. If the location of the emblem/nameplate has not been marked apply tape and use the following dimensions: Dimension (a) is 41 mm (1.625 in) from the rear door edge to the emblem/nameplate. Dimension (b) is 146 mm (5.750 in) from the feature line on the door to the bottom of the emblem/nameplate.
2. Warm the door surface with a heat gun J 25070 152 mm (6.0 in) from the surface to a minimum of 21°C (70°F). IMPORTANT: Do not touch the adhesive backing of the emblem/nameplate.
3. Remove the backing from the front end of the emblem/nameplate.
4. Press the emblem/nameplate to the door panel surface while continuing to remove the backing.
5. Hand roll the emblem/nameplate to the door panel to ensure proper adhesion.
6. Inspect the emblem/nameplate for bonding.
7. Remove the tape from the area around the door emblem.

J 25070: Heat Gun. See Special Tools and Equipment .

Scheme 5

1. Apply tape to the area around the door emblem.
2. Heat the emblem/nameplate, using a heat gun J 25070 152 mm (6.0 in) from the surface.
3. Apply the heat using a circular motion for about 30 seconds. NOTE: Refer to Exterior Trim Emblem Removal Notice in Cautions and Notices.
4. Remove the emblem/nameplate from the door surface using a plastic, flat-bladed tool.
5. Remove all adhesive from the door panel surface and the back of the emblem/nameplate using 3M™ scotch brite molding adhesive remover disk 3M™ P/N 07501 or equivalent.
6. Clean the door surface using varnish makers and painters (VMP) naptha.

Scheme 6

1. If the location of the emblem/nameplate has not been marked apply tape and use the following dimensions: Dimension (a) is 19.5 mm (0.78 in) above the feature line on the door. Dimension (b) is 68.7 mm (2.7 in) from the front edge of the door.
2. Warm the door surface with a heat gun J 25070 152 mm (6.0 in) from the surface to a minimum of 21°C (70°F). IMPORTANT: Do not touch the adhesive backing of the emblem/nameplate.
3. Remove the backing from the front end of the emblem/nameplate.
4. Press the emblem/nameplate to the door panel surface while continuing to remove the backing.
5. Hand roll the emblem/nameplate to the door panel to ensure proper adhesion.
6. Inspect the emblem/nameplate for bonding.
7. Remove the tape from the area around the door emblem.

J 25070 Heat Gun. See Special Tools and Equipment .

1. Apply tape to the area around the liftgate emblem/nameplate.
2. Heat the emblem/nameplate, using a heat gun J 25070 152 mm (6 in) from the surface. Apply the heat using a circular motion for about 30 seconds.
3. Remove the emblem/nameplate from the liftgate surface using a plastic, flat-bladed tool.
4. Remove all adhesive from the liftgate surface and the back of the emblem/nameplate using 3M™ scotch brite molding adhesive remover disk 3M™ P/N 07501 or equivalent.
5. Clean the liftgate surface using Varnish Makers and Painters (VMP) naptha.

Scheme 7

1. Mark the tape with the measurement for the proper location of the emblem.
2. Warm the liftgate surface with a heat gun J 25070 152 mm (6 in) from the surface to a minimum of 21°C (70°F). IMPORTANT: Do not touch the adhesive backing of the emblem/nameplate.
3. Remove the backing from the front end of the emblem/nameplate.
4. Press the emblem/nameplate to the liftgate surface while continuing to remove the backing.
5. Hand roll the emblem/nameplate to the liftgate to ensure proper adhesion.
6. Inspect the emblem/nameplate for bonding.
7. Remove the tape from the area around the liftgate emblem.

J 25070 Heat Gun. See Special Tools and Equipment .

1. When replacing an emblem/nameplate do the following: Use tape to protect the mounting surface during removal. Use tape for alignment marks for installation of the emblem/nameplate.
2. To remove an emblem/nameplate, heat the emblem/nameplate using a J 25070 .
3. Apply the heat using a circular motion for about 30 seconds holding the J 25070 approximately 152 mm (6 in) from the surface. NOTE: Refer to «Exterior Trim Emblem Removal Notice»(/buick/rendezvous/i-2001-2007/remont/oem-general-information/#cautions-and-notices__exterior-trim-emblem-removal-notice) in Cautions and Notices.
4. Use a plastic, flat-bladed tool to remove the emblem/nameplate from the panel surface.
5. When replacing, remove all adhesive as follows: For body panels use a 3M™ Scotch Brite molding adhesive remover disk 3M™ P/N 07501 or equivalent. For plastic panels use a lint free cloth and Varnish Makers and Painters (VMP) naphtha or a 50/50 mixture by volume of isopropyl alcohol and water to remove the adhesive.

Installation Procedure

Scheme 8

Scheme 9

1. Clean the area where the emblem/nameplate will be installed. Use a lint free cloth and Varnish Makers and Painters (VMP) naphtha or a 50/50 mixture by volume of isopropyl alcohol and water to clean the area.
2. Dry the area thoroughly.
3. If the location of the emblem/nameplate has not been marked, apply tape and mark the location as shown below.
4. For the CX emblem/nameplate install to the following dimensions: Dimension (a) is 19.05 mm (0.750 in) from the top of the lift gate lower molding to the bottom of the emblem/nameplate. Dimension (b) is 53.975 mm (2.125 in) from the side of the emblem/nameplate to the right edge of the lift gate.
5. For the CXL emblem/nameplate install to the following dimensions: Dimension (a) is 19.05 mm (0.750 in) from the top of the lift gate lower molding to the bottom of the emblem/nameplate. Dimension (b) is 53.975 mm (2.125 in) from the side of the emblem/nameplate to the right edge of the lift gate.
6. For the VERSATRAK AWD emblem/nameplate install to the following dimensions: Dimension (a) is 58.750 mm (2.313 in) from the left edge of the lift gate to the side of the emblem/nameplate. Dimension (b) is 19.05 mm (0.750 in) from the top of the lift gate lower molding to the bottom of the emblem/nameplate.
7. Heat the mounting surface to approximately 27-41°C (80-105°F) using the J 25070 , if necessary.
8. Ensure that the temperature of the emblem/nameplate is approximately 29-32°C (85-90°F). IMPORTANT: Do not touch the adhesive backing on the emblem/nameplate.
9. Remove the protective liner from the back of the emblem/nameplate.
10. Position the emblem/nameplate to the location marks and press the emblem/nameplate to the mounting surface.
11. Apply equal pressure along the emblem/nameplate to uniformly bond the item to the mounting surface.
12. Remove the protective tape from the mounting surface.

Scheme 10

Scheme 11

1. Remove the grille from the front fascia. Refer to «Fascia Grille Replacement (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#bumper-system) or «Fascia Grille Replacement (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#bumper-system) in Bumpers.
2. Remove the nut from the back of the grille emblem.
3. Remove the emblem from the grille.

1. Position the emblem to the grille. NOTE: Refer to Fastener Notice in Cautions and Notices.
2. Install the nut to the grille emblem. Tighten: Tighten the nut to 2 N.m (18 lb in).
3. Install the grille to the front fascia. Refer to «Fascia Grille Replacement (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#bumper-system) or «Fascia Grille Replacement (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#bumper-system) in Bumpers.

J 25070 Heat Gun. See Special Tools and Equipment .

Scheme 12

1. Apply masking tape to the area around the hood emblem to protect the finish.
2. Open the hood.
3. Remove the nuts from the back of the hood emblem.
4. To remove the emblem from the hood, heat the emblem using the J 25070 152 mm (6.0 in) from the surface.
5. Apply heat in a circular motion for about 30 seconds. NOTE: Refer to Exterior Trim Emblem Removal Notice in Cautions and Notices.
6. Use a plastic, flat bladed tool to lift or remove the emblem from the hood.
7. Remove any adhesive from the hood using a 3M™ Scotch Brite molding adhesive remover disk P/N 07501 or equivalent.

1. Heat the hood emblem and mounting surface to approximately 21°C (70°F) using the J 25070 , if necessary. IMPORTANT: Apply the emblem/nameplate in an environment that is free from dust or other dirt that could come into contact with the sticky backing. Foreign material may cause improper adhesion. Do not touch the adhesive backing on the emblem/nameplate.
2. Remove the protective liner from the back of the hood emblem.
3. Position the hood emblem locating pins to the holes in the hood.
4. Apply equal pressure along the emblem to uniformly bond the emblem to the hood. NOTE: Refer to Fastener Notice in Cautions and Notices.
5. Install the hood emblem nuts to the hood emblem. Tighten: Tighten the nuts to 2.0 N.m (18 lb in).
6. Remove the masking tape from the hood.
7. Close the hood.

Scheme 13

Scheme 14

1. Remove the front wheel liner. Refer to «Front Fender Liner Replacement»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-front-end) in Body Front End.
2. Remove the bolts from the corner of the front fascia. Refer to «Fascia Replacement - Front Bumper - Upper (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#bumper-system) or «Fascia Replacement - Front Bumper - Upper (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#bumper-system) in Bumpers.
3. Remove the screws from the front wheel opening molding.
4. Pull the corner of the front fascia outward to access the front retainer on the wheel opening molding.
5. Use a thin, plastic flat-bladed tool between the fender and the molding to help release the retainers. Remove the molding from the fender.

1. Position the molding to the fender.
2. Align the push-in retainers to the holes in the fender.
3. Press the molding to the fender until all of the retainers are fully seated. NOTE: Refer to «Fastener Notice»(/buick/rendezvous/i-2001-2007/remont/oem-general-information/#cautions-and-notices__fastener-notice) in Cautions and Notices.
4. Install the screws to the front wheel opening molding. Tighten: Tighten the screws to 2 N.m (18 lb in).
5. Install the bolts to the corner of the front fascia. Refer to «Fascia Replacement - Front Bumper - Upper (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#bumper-system) or «Fascia Replacement - Front Bumper - Upper (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#bumper-system) in Bumpers.
6. Install the front wheel liner. Refer to «Front Fender Liner Replacement»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-front-end) in Body Front End.

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. Remove the screws from the front wheel opening molding.
2. Remove the screws from the front corner of the fascia.
3. Pull outward on the corner of the front fascia to access the front wheel opening molding retainer.
4. A thin, plastic flat-bladed tool may be used between the fender and molding to help release the retainers. Remove the front wheel opening molding from the fender.
5. Remove the wheel opening molding retainers from the molding, if necessary.

1. Install the wheel opening molding retainers to the molding, if removed.
2. Position the front wheel opening molding to the fender.
3. Align the push-in retainers to the holes in the fender.
4. Press the front wheel opening molding to the fender until all of the retainers are fully seated. NOTE: Refer to Fastener Notice in Cautions and Notices.
5. Install the front wheel opening molding screws to the front wheel opening molding. Tighten: Tighten the screws to 2 N.m (18 lb in).
6. Press the corner of the front fascia to the fender to seat the retainer.
7. Install the screws to the corner of the front fascia. Tighten: Tighten the screws to 2 N.m (18 lb in).

Scheme 19

1. Remove the screws from the rear wheel opening molding.
2. Pull the upper edge of the rear wheel opening molding out, to release the retainers.
3. A thin, plastic flat-bladed tool may be used between the molding and the body to help release the wheel opening molding retainers.
4. Remove the rear wheel opening molding from the vehicle.

1. Position the rear wheel opening molding to the rear quarter panel.
2. Align the wheel opening molding retainers to the holes in the rear quarter panel.
3. Press the molding to the rear quarter panel until all of the retainers are fully seated. NOTE: Refer to Fastener Notice in Cautions and Notices.
4. Install the wheel opening molding screws. Tighten: Tighten the wheel opening molding screws to 2 N.m (18 lb in).

J 25070 Heat Gun. See Special Tools and Equipment .

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

1. Use a heat gun J 25070 . NOTE: Refer to Exterior Trim Emblem Removal Notice in Cautions and Notices.
2. Use a plastic, flat-bladed tool to remove the upper edge of the front door body side molding from the surface.
3. Pull the upper edge of the front door body side molding out, in order to release the retainers.
4. Remove the front door body side molding from the door. CAUTION: Refer to Safety Glasses Caution in Cautions and Notices.
5. Drill a small hole into the center of the center retainer pins of the support retainer.
6. Install a small screw into the hole in the center retainer pin.
7. Remove the center retainer pin using small pliers and pulling out the center retainer pin.
8. Remove the front door body side molding support from the door.
9. Remove all adhesive from the rear door body panel using 3M™ ScotchBrite molding adhesive remover disk 3M™ P/N 07501 or equivalent.
10. Clean the rear door panel surface using Varnish Makers and Painters (VMP) naphtha and allow to air dry.

Scheme 26

Scheme 27

1. Position the support retainer with the notch down and the retainers to the holes in the door panel.
2. Install in the center pins of the retainers using a small hammer.
3. Use a heat gun J 25070 .
4. Position the lower flange of the front door body side molding to the retainer support and align the tab to the notch in the retainer support. IMPORTANT: Do not touch the adhesive backing on the molding.
5. Remove the protective liner from the back side of the door body side molding.
6. Position the upper edge of the front door body side molding retainer clips to the holes in the door panel.
7. Install the retainer clips to the door panel by pressing in until fully seated.
8. Install the upper edge of the front door body side molding by applying pressure to the entire length of the molding starting at the center and working outward to ensure a maximum bond to the door panel.

Scheme 28

1. Open the front door. NOTE: Refer to Exterior Trim Emblem Removal Notice in Cautions and Notices.
2. A thin, plastic flat-bladed tool may be used between the molding and the door to help release the retainers. Pull the upper edge of the front door body side molding out, in order to release the retainers.
3. Remove the front door body side molding from the door. CAUTION: Refer to Safety Glasses Caution in Cautions and Notices.
4. Drill a small hole into the center of the center retainer pins of the support retainer.
5. Install a small screw into the hole in the center retainer pin.
6. Remove the center retainer pin using small pliers and pulling out the center retainer pin.
7. Remove the front door body side molding support from the door.

1. Position the support retainer with the notch down and the retainers to the holes in the door panel.
2. Install in the center pins of the retainers using a small hammer.
3. Position the lower flange of the front door body side molding to the retainer support and align the tab to the notch in the retainer support.
4. Position the upper edge of the front door body side molding retainer clips to the holes in the door panel.
5. Install the retainer clips to the door panel by pressing in until fully seated.
6. Close the front door.

J 25070: Heat Gun. See Special Tools and Equipment .

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

1. Open the rear door.
2. Remove the screws from the rear edge of the rear door body side molding.
3. Use a heat gun J 25070 . NOTE: Refer to Exterior Trim Emblem Removal Notice in Cautions and Notices.
4. Use a plastic, flat-bladed tool to remove the upper edge of the rear door body side molding from the surface.
5. Pull the upper edge of the rear door body side molding out, to release the retainers.
6. Remove the rear door body side molding from the door. CAUTION: Refer to Safety Glasses Caution in Cautions and Notices.
7. Drill a small hole into the center of the center retainer pins of the lower support retainer.
8. Install a small screw into the hole in the center retainer pin.
9. Remove the center retainer pin using small pliers and pulling out the center retainer pin.
10. Remove the rear door body side molding lower support from the door.
11. Drill a small hole into the center of the center retainer pins of the rear support retainer.
12. Install a small screw into the hole in the center retainer pin.
13. Remove the center retainer pin using small pliers and pulling out the center retainer pin.
14. Remove the rear door body side molding rear support from the door.
15. Remove all adhesive from the rear door body panel using 3M™ ScotchBrite molding adhesive remover disk 3M™ P/N 07501 or equivalent.
16. Clean the rear door panel surface using Varnish Makers and Painters (VMP) naphtha and allow to air dry.

Scheme 41

Scheme 42

Scheme 43

1. Position the lower support retainer with the notch down and the retainers to the holes in the door panel.
2. Install the center pins of the retainers using a small hammer.
3. Position the lower support retainer with the notch down and the retainers to the holes in the door panel.
4. Install the center pins of the retainers using a small hammer.
5. Use a heat gun J 25070 .
6. Position the lower flange of the rear door body side molding to the retainer support and align the tab to the notch in the retainer support. IMPORTANT: Do not touch the adhesive backing on the molding.
7. Remove the protective liner from the back side of the door body side molding.
8. Position the upper edge of the rear door body side molding retainer clips to the holes in the door panel.
9. Install the retainer clips to the door panel by pressing in until fully seated.
10. Install the upper edge of the rear door body side molding by applying pressure to the entire length of the molding starting at the center and working outward to ensure a maximum bond to the door panel. NOTE: Refer to Fastener Notice in Cautions and Notices.
11. Install the screws to the rear edge of the rear door body side molding. Tighten: Tighten the screws to 6 N.m (53 lb in).
12. Close the rear door.

Scheme 44

1. Open the rear door. NOTE: Refer to Exterior Trim Emblem Removal Notice in Cautions and Notices.
2. Pull the upper edge of the rear door body side molding out, to release the retainers.
3. A thin, plastic flat-bladed tool may be used between the door and the molding to help release the retainers. Remove the rear door body side molding from the door. CAUTION: Refer to Safety Glasses Caution in Cautions and Notices.
4. Drill a small hole into the center of the center retainer pins of the lower support retainer.
5. Install a small screw into the hole in the center retainer pin.
6. Remove the center retainer pin using small pliers and pulling out the center retainer pin.
7. Remove the rear door body side molding lower support from the door.

1. Position the lower support retainer with the notch down and the retainers to the holes in the door panel.
2. Install in the center pins of the retainers using a small hammer.
3. Position the lower edge of the molding to the lower door retainer.
4. Align the door molding retainers to the holes in the door.
5. Press the molding to the door until the retainers are fully seated.
6. Close the rear door.

Scheme 45

Scheme 46

1. Remove the lift gate applique. Refer to «Liftgate Applique Replacement»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) in Body Rear End.
2. Remove the lift gate handle. Refer to «Handle Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) in Body Rear End.
3. Remove the lift gate lower molding. Refer to «Molding Replacement - Liftgate Lower»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#exterior-trim) .
4. Remove the screws from the lift gate upper molding.
5. Remove the lift gate upper molding from the lift gate.

1. Position the lift gate upper molding to the lift gate. NOTE: Refer to Fastener Notice in Cautions and Notices.
2. Install the lift gate upper molding screws. Tighten: Tighten the screws to 2.0 N.m (18 lb in).
3. Install the lift gate lower molding. Refer to «Molding Replacement - Liftgate Lower»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#exterior-trim) .
4. Install the lift gate applique. Refer to «Liftgate Applique Replacement»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) in Body Rear End.
5. Install the lift gate handle. Refer to «Handle Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) in Body Rear End.

Scheme 47

Scheme 48

1. Raise the rear life gate.
2. Remove the screws from the lift gate lower molding.
3. Remove the lower molding from the lift gate.

1. Align the lift gate lower molding to the tabs in the upper molding. NOTE: Refer to Fastener Notice in Cautions and Notices.
2. Install the lift gate lower molding screws. Tighten: Tighten the screws to 2.0 N.m (18 lb in).
3. Close the rear lift gate.

J 25070: Heat Gun. See Special Tools and Equipment .

Scheme 49

Scheme 50

Scheme 51

Scheme 52

1. Open the endgate.
2. Remove the push-in retainers from the inside rear edge of the rear quarter panel molding.
3. Use a heat gun J 25070 .
4. Use a plastic, flat-bladed tool to remove the upper edge of the rear quarter panel molding from the surface.
5. Pull the upper edge of the rear quarter panel molding out, to release the retainers.
6. Remove the rear quarter panel molding from the door.
7. Remove the push-in retainer nuts from the D-pillar, if required.
8. Remove all adhesive from the rear door body panel using 3M™ ScotchBrite molding adhesive remover disk 3M™ P/N 07501 or equivalent.
9. Clean the rear door panel surface using Varnish Makers and Painters (VMP) naphtha and allow to air dry.

1. Install the push-in retainer nuts to the D-pillar, if required.
2. Use a heat gun J 25070 . IMPORTANT: Do not touch the adhesive backing on the molding.
3. Remove the protective liner from the back side of the rear quarter panel molding.
4. Position the rear quarter panel molding to the rear quarter panel.
5. Install rear quarter panel molding starting at the D-pillar and working forward and locating the push-in retainers to the rear quarter panel, pressing rear quarter panel molding into place until fully seated.
6. Install the upper edge of the rear quarter panel molding by applying pressure to the entire length of the molding starting at the rear and working forward in order to ensure a maximum bond to the rear quarter panel.
7. Install the push-in retainers to the inside rear edge of the rear quarter panel molding.
8. Close the endgate.

Scheme 53

1. Remove the screw from the front of the rocker panel molding.
2. Remove the top edge of the rocker panel molding by pulling off to release the push-in retainers. NOTE: Refer to Exterior Trim Emblem Removal Notice in Cautions and Notices.
3. Release the push-in retainers from the lower rocker panel molding using a small flat-bladed tool inserted between the rocker panel molding and the retainer.
4. Remove the rocker panel molding from the rocker panel.

Scheme 54

1. Position the rocker molding to the holes in the rocker panel.
2. Install the rocker molding starting to the first net hole (1) then the second net hole (2) and then the third net hole (3). Press the push-in retainers into place until fully seated.
3. Install the push-in retainers to the lower rocker molding, pressing into place until fully seated. NOTE: Refer to Fastener Notice in Cautions and Notices.
4. Install the rocker molding screw to the rocker molding. Tighten: Tighten the screw to 6 N.m (53 lb in).

J 25070: Heat Gun. See Special Tools and Equipment .

Scheme 55

Scheme 56

Scheme 57

1. Remove the license plate.
2. Remove the license lamp. Refer to «License Lamp Replacement (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-lights/#lighting-systems) or «License Lamp Replacement (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-lights/#lighting-systems) in Lighting Systems.
3. Use a heat gun J 25070 . NOTE: Refer to Exterior Trim Emblem Removal Notice in Cautions and Notices.
4. Use a plastic, flat-bladed tool to remove the upper edge of the rear body panel molding from the surface.
5. Pull the upper edge of the rear body panel molding out, to release the retainers.
6. Remove the rear body panel molding from the endgate.
7. Remove all adhesive from the endgate using 3M™ ScotchBrite molding adhesive remover disk 3M™ P/N 07501 or equivalent.
8. Clean the endgate surface using Varnish Makers and Painters (VMP) naphtha and allow to air dry.

1. Use a heat gun J 25070 .
2. Position the lower flange of the rear body panel molding to the hem flange of the endgate, pulling upward and forward to align the retainer clips to the holes in the endgate. IMPORTANT: Do not touch the adhesive backing on the molding.
3. Remove the protective liner from the back side of the rear body panel molding.
4. Position the upper edge of the rear body panel molding retainer clips to the holes in the endgate.
5. Install the retainer clips to the endgate by pressing in until fully seated.
6. Install the upper edge of the rear body panel molding by applying pressure to the entire length of the molding starting at the center and working outward in order to ensure a maximum bond to the endgate.
7. Install the license lamp. Refer to «License Lamp Replacement (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-lights/#lighting-systems) or «License Lamp Replacement (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-lights/#lighting-systems) in Lighting Systems.
8. Install the license plate.

Stripes or Decals

The stripes and decals adhere to a painted surface using pressure sensitive adhesive.

The use of a wetting solution aids the technician in lifting and positioning the stripe or decal during the installation. The wetting solution ensures a better bond between the stripe or decal and the panel assembly. Use a wetting solution when applying large stripe and decal packages.

Complete the following procedures before you apply a stripe or a decal

1. Metal repair or refinishing after a collision
2. Painting the underlying surface

Maintain a temperature 21-38°C (70-100°F) on the body surfaces and the decals prior to installation. The decal requires auxiliary heat sources in order to warm the body surfaces and decals. If the temperature is below 21°C (70°F) the decal may not adhere to the body surface properly.

Use the following equipment and materials in order to apply a stripe or a decal

1. A wetting solution A foaming type of window cleaner that does not contain ammonia.
2. A silicone, wax and grease remover
3. Varnish Makers and Painters (VM&P) naphtha
4. Isopropyl alcohol
5. A squeegee 75-100 mm (3-4 in) wide Made of plastic or hard rubber Remove the burrs from any sharp or rough edges in order to prevent scratching of the stripe or decal.
6. A water bucket and sponge or spray bottle
7. Sandpaper 800 grit or finer Wet or dry type
8. A heat gun or heat lamp
9. A clean, lint-free wiping cloth
10. A sharp knife or razor blade
11. A pair of scissors
12. A fine pin or needle
13. A marking pencil

Stripe or Decal Removal

1. Remove the following components: Necessary moldings or trim panel Molding attaching clips Handles Sidemarker lamps Other stripe or decal overlapping parts
2. Clean the following areas as needed: The repair surfaces The adjacent panels The openings
3. Use 3M™ ScotchBrite molding adhesive remover disk 3M™ P/N 07501 or equivalent in order to remove the stripe or decal from the body panel.
4. Use Varnish Makers and Painters (VM&P) naphtha in order to remove all traces of adhesive residue from the painted surfaces.

Stripe or Decal Installation - Wet Method

1. Prepare the surface. IMPORTANT: Remove any imperfections that would appear through the stripe or decal if the area has been refinished. Clean the painted surface using the following types of removers: Silicone Wax Grease
2. Clean the area where the stripe or decal will be applied using a 50/50 mixture of isopropyl alcohol and water.
3. Wipe the panel surface using a clean cloth while the solvent is still wet. Allow the panel surface to dry.
4. Apply the wetting solution to the area where you are installing the stripe or decal. Application of a soapy wetting solution on the top side of the stripe or decal will ease the pull of the squeegee on the stripe or decal and help to eliminate damage. IMPORTANT: Do not touch the adhesive backing of the stripes. Apply the wetting solution on the adhesive side of the stripe or decal. Remove the backing material of the stripe or the decal as needed.
5. Apply the strip or decal to the panel. The wetting solution will allow movement for proper positioning on the panel surface.
6. Working from the center where possible, squeegee the stripe or decal into position. Apply additional wetting solution as needed in order to ease installation.
7. Apply heat to the stripe or decal at the recessed areas. Press the stripe or decal into the recess in order to obtain a firm bond.
8. Use adequate light reflection in order to inspect the stripe or decal from a critical angle. This technique detects any irregularities that may have developed during the installation. IMPORTANT: Do not use a razor blade or a knife edge in order to pierce the air bubbles. Remove all air bubbles by piercing the bubble with one of the following items: A safety pin A needle A tool with the same size piercing tip
9. Pierce the bubble on the outer edge. Force the air out through the opposite edge using the blade of the squeegee.
10. Install any previously removed components. Clean the components as needed.

Special Tools

Special Tools Illustration Tool Number/Description J 25070 Heat Gun

See also:
• Exterior Trim Emblem Removal Notice
• Fascia Grille Replacement (Aztek)
• Front Fender Liner Replacement
• Fastener Notice
• Liftgate Applique Replacement
• License Lamp Replacement (Aztek)
• Special Tools and Equipment
