Entertainment System Buick Rendezvous I

Fastener Tightening Specifications

Fastener Tightening Specifications

Entertainment Schematic Icons

Entertainment Schematic Icons Icon Icon Definition CAUTION: This vehicle is equipped with a Supplemental Inflatable Restraint (SIR) System. Failure to follow the correct procedure could cause the following conditions: Air bag deployment Personal injury Unnecessary SIR system repairs In order to avoid the above conditions, observe the following guidelines: Refer to SIR Component Views in order to determine if you are performing service on or near the SIR components or the SIR wiring. If you are performing service on or near the SIR components or the SIR wiring, disable the SIR system. Refer to Disabling the SIR System in SIR. IMPORTANT: Twisted-pair wires provide an effective "shield" that helps protect sensitive electronic components from electrical interference. If the wires were covered with shielding, install new shielding. In order to prevent electrical interference from degrading the performance of the connected components, you must maintain the proper specification when making any repairs to the twisted-pair wires shown: The wires must be twisted a minimum of 9 turns per 31 cm (12 in) as measured anywhere along the length of the wires. The outside diameter of the twisted wires must not exceed 6.0 mm (0.2 in)

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Entertainment Connector End Views

Audio Amplifier - C1 (UQ3) Connector End Connector Part Information 12110626 8-Way F Metri-Pack 280 Series Flexlock (WHT) Pin Wire Color Circuit No. Function A - - Not Used B ORN 926 Amplifier Present Signal C-D - - Not Used E PPL 493 Rear Seat Audio Enable Signal PPL 493 Rear Seat Audio Enable Signal (Buick) F PPL 927 Amplifier Control G ORN 2040 Battery Positive Voltage H BLK/WHT 351 Ground

Audio Amplifier - C2 (UQ3) Connector End Connector Part Information 12110088 24-Way F Micro-Pack 100 Series (GRY) Pin Wire Color Circuit No. Function A1 LT GRN/BLK 1794 Left Rear Subwoofer Speaker Output (-) A2 DK BLU/ WHT 346 Left Rear Subwoofer Speaker Output (+) A3 LT BLU/BLK 315 Right Rear Subwoofer Speaker Output (-) A4 DK GRN 1795 Right Rear Subwoofer Speaker Output (+) A5 WHT 1959 Left Rear Midrange Speaker Output (-) (Pontiac) YEL 1956 Left Front Tweeter Speaker Output (-) (Buick) A6 TAN 1859 Left Rear Midrange Speaker Output (+) (Pontiac) BLK 1856 Left Front Tweeter Speaker Output (+) (Buick) A7 RED 1955 Right Rear Midrange Speaker Output (-) (Pontiac) PPL 1952 Right Front Tweeter Speaker Output (-) (Buick) A8 TAN 1855 Right Rear Midrange Speaker Output (+) (Pontiac) LT GRN 1852 Right Front Tweeter Speaker Output (+) (Buick) A9 DK BLU 46 Right Rear Speaker Output (+) (Pontiac) LT GRN 200 Right Front Speaker Output (+) (Buick) A10 LT BLU 115 Right Rear Speaker Output (-) (Pontiac) DK GRN 117 Right Front Speaker Output (-) (Buick) A11 BRN 199 Left Rear Speaker Output (+) (Pontiac) TAN 201 Left Front Speaker Output (+) (Buick) A12 YEL 116 Left Rear Speaker Output (-) (Pontiac) GRY 118 Left Front Speaker Output (-) (Buick) B1 BLK/WHT 1946 Right Rear Low Level Audio Signal (-) (Pontiac) LT GRN 1948 Right Front Low Level Audio Signal (-) (Buick) B2 DK BLU 546 Right Rear Low Level Audio Signal (+) (Pontiac) LT GRN 512 Right Front Low Level Audio Signal (+) (Buick) B3 BRN 1999 Left Rear Low Level Audio Signal (-) (Pontiac) DK GRN 1947 Left Front Low Level Audio Signal (-) (Buick) B4 BRN 599 Left Rear Low Level Audio Signal (+) (Pontiac) TAN 511 Left Front Low Level Audio Signal (+) (Buick) B5 LT GRN 1948 Right Front Low Level Audio Signal (-) (Pontiac) BLK/WHT 1946 Right Rear Low Level Audio Signal (-) (Buick) B6 LT GRN/BLK 512 Right Front Low Level Audio Signal (+) (Pontiac) DK BLU 546 Right Rear Low Level Audio Signal (+) (Buick) B7 DK GRN 1947 Left Front Low Level Audio Signal (-) (Pontiac) BRN 1999 Left Rear Low Level Audio Signal (-) (Buick) B8 TAN 511 Left Front Low Level Audio Signal (+) (Pontiac) BLK/WHT 599 Left Rear Low Level Audio Signal (+) (Buick) B9 LT GRN 200 Right Front Speaker Output (+) (Pontiac) DK BLU 46 Right Rear Speaker Output (+) (Buick) B10 DK GRN 117 Right Front Speaker Output (-) (Pontiac) LT BLU 115 Right Rear Speaker Output (-) (Buick) B11 TAN 201 Left Front Speaker Output (+) (Pontiac) BRN 199 Left Rear Speaker Output (+) (Buick) B12 GRY 118 Left Front Speaker Output (-) (Pontiac) YEL 116 Left Rear Speaker Output (-) (Buick)

Digital Radio Receiver (U2K) Connector End Connector Part Information 15394150 16-Way F Metri-Pack (GRY) Pin Wire Color Circuit No. Function 1 - - Not Used 2 BRN/WHT 367 Remote Radio Left Audio Signal 3 DK GRN/WHT 368 Remote Radio Right Audio Signal 4-8 - - Not Used 9 BLK 351 Ground 10 BLK/WHT 372 Remote Radio Audio Output (-) 11 BARE 7814 Drain Wire 12-14 - - Not Used 15 TAN 9807 Class 2 Serial Data 16 ORN 3840 Battery Positive Voltage

Radio - C1 Connector Part Information 12110088 24-Way F Micro-Pack 100 Series (GRY) Pin Wire Color Circuit No. Function A1 ORN 1044 Radio Class 2 Serial Data A2 - - Not Used A3 PPL 493 Rear Seat Audio Enable Signal (UQ3) A4-A5 - - Not Used A6 PPL 1375 Remote Radio Control Supply Voltage A7 DK BLU 1796 Steering Wheel Controls Signal A8 TAN 201 Left Front Speaker Output (+) (w/o UQ3) TAN 511 Left Front Low Level Audio Signal (+) (UQ3) A9 GRY 118 Left Front Speaker Output (-) (w/o UQ3) DK GRN 1947 Left Front Low Level Audio Signal (-) (UQ3) A10 LT BLU 115 Right Rear Speaker Output (-) (w/o UQ3) BLK 1946 Right Rear Low Level Audio Signal (-) (UQ3) A11 DK BLU 46 Right Rear Speaker Output (+) (w/o UQ3) DK BLU 546 Right Rear Low Level Audio Signal (+) (UQ3) A12 BLK/WHT 351 Ground B1 ORN 5640 Battery Positive Voltage B2 - - Not Used B3 PPL 927 Amplifier Control (UQ3) B4 GRY 8 Instrument Panel Lamp Supply Voltage - 1 B5 BLK 1450 Ground B6 ORN 926 Amplifier Present Signal (UQ3) B7 LT GRN 1011 Remote Radio Control Signal (RSA) B8 BRN 199 Left Rear Speaker Output (+) (w/o UQ3) BRN/WHT 599 Left Rear Low Level Audio Signal (+) (UQ3) B9 YEL 116 Left Rear Speaker Output (-) (w/o UQ3) BRN 1999 Left Rear Low Level Audio Signal (-) (UQ3) B10 DK GRN 117 Right Front Speaker Output (-) (w/o UQ3) LT GRN 1948 Right Front Low Level Audio Signal (-) (UQ3) B11 LT GRN 200 Right Front Speaker Output (+) (w/o UQ3) LT GRN/BLK 512 Right Front Low Level Audio Signal (+) (UQ3) B12 - - Not Used

Radio - C2 (UE1/UQ3) Connector End Connector Part Information 12064799 12-Way F Micro-Pack 100 Series (BLK) Pin Wire Color Circuit No. Function A-B - - Not Used C BARE 814 Drain Wire (U32) D - - Not Used E DK GRN 389 Vehicle Speed Signal F-G - - Not Used H DK GRN/WHT 368 Remote Radio Right Audio Signal J BRN/WHT 367 Remote Radio Left Audio Signal K BLK/WHT 372 Remote Radio Audio Output (-) L BLK/WHT 9372 Remote Radio Audio Output (-) M BRN/WHT 9367 Remote Radio Left Audio Signal

Rear Seat Audio Control (UQ3) Connector End Connector Part Information 12110259 16-Way F Micro-Pack 100 Series (GRN) Pin Wire Color Circuit No. Function A1 BLK 1946 Right Rear Low Level Audio Signal (-) A2 DK BLU 546 Right Rear Low Level Audio Signal (+) A3 BRN 1999 Left Rear Low Level Audio Signal (-) A4 BRN 599 Left Rear Low Level Audio Signal (+) A5 LT GRN 1011 Remote Radio Control Signal A6 GRY 8 Instrument Panel Lamp Supply Voltage A7 - - Not Used A8 PPL 1375 Remote Radio Control Supply Voltage B1 LT BLU 115 Right Rear Speaker Output (-) (Base Radio) B2 DK BLU 46 Right Rear Speaker Output (+) (Base Radio) B3 YEL 116 Left Rear Speaker Output (-) (Base Radio) B4 BRN 199 Left Rear Speaker Output (+) (Base Radio) B5 PPL 493 Rear Seat Audio Enable Signal B6 BLK 650 Ground B7 - - Not Used B8 BRN 9 Park Lamp Supply Voltage

Rear Seat Entertainment (RSE) Assembly (U32) Connector End Connector Part Information 15341086 12-Way F Multi-Lock Series (BLK) Pin Wire Color Circuit No. Function 1 - - Not Used 2 PNK 1045 VCM Class 2 Serial Data 3-4 - - Not Used 5 DK GRN/WHT 368 Remote Radio Right Audio Signal 6 BRN/WHT 367 Remote Radio Left Audio Signal 7 BLK/WHT 351 Ground 8 - - Not Used 9 ORN 4240 Battery Positive Voltage 10-11 - - Not Used 12 BLK/WHT 372 Remote Audio Output (-)

Speaker Connector End - LF Door Connector Part Information 12186847 2-Way F Metri-Pack 150 Series (WHT) Pin Wire Color Circuit No. Function A GRY 118 Left Front Speaker Output (-) B TAN 201 Left Front Speaker Output (+)

Speaker Connector End - LR Door Connector Part Information 12052832 2-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A YEL 116 Left Rear Speaker Output (-) B BRN 199 Left Rear Speaker Output (+)

Speaker Connector End - LR (Pontiac UQ3 Only) Connector Part Information 12064760 4-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A LT GRN/BLK 1794 Left or Rear Subwoofer Speaker Output (-) B DK BLU/ WHT 346 Left Subwoofer Speaker Output (+) C WHT 1959 Left Rear Midrange Speaker Output (-) D TAN 1859 Left Rear Midrange Speaker Output (+)

Speaker Connector End - LR Subwoofer (Buick UQ3) Connector Part Information 12052832 2-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A LT GRN/BLK 1794 Left Subwoofer Speaker Output (-) B DK BLU/WHT 346 Left Subwoofer Speaker Output (-)

Speaker Connector End - RF Door Connector Part Information 12186847 2-Way F Metri-Pack 150 Series (WHT) Pin Wire Color Circuit No. Function A DK GRN 117 Right Front Speaker Output (-) B LT GRN 200 Right Front Speaker Output (+)

Speaker Connector End - RR Door Connector Part Information 12052832 2-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A LT BLU 115 Right Rear Speaker Output (-) B DK BLU 46 Right Rear Speaker Output (+)

Speaker Connector End - RR (Pontiac UQ3 Only) Connector Part Information 12064760 4-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A LT BLU/BLK 315 Right Subwoofer Speaker Output (-) B DK GRN 1795 Right Subwoofer Speaker Output (+) C RED 1955 Right Rear Midrange Speaker Output (-) D TAN 1855 Right Rear Midrange Speaker Output (+)

Speaker Connector End - RR Subwoofer (Buick UQ3) Connector Part Information 12052832 2-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A LT BLU/BLK 315 Right Subwoofer Speaker Output (-) B DK GRN 1795 Right Subwoofer Speaker Output (+)

Steering Wheel Controls Connector End - Left (U96 or UK3) Connector Part Information 50579405 5-Way F (BLK) Pin Wire Color Circuit No. Function 1 DK BLU 1796 Steering Wheel Controls Signal 2 - - Not Used 3 BLK 350 Ground 4 YEL/BLK 1458 Instrument Panel Lamp Supply Voltage - 4 5 DK BLU 1796 Steering Wheel Controls Signal

Steering Wheel Controls Connector End - Right (U96 or UK3) Connector Part Information 50579406 6-Way F (BLK) Pin Wire Color Circuit No. Function 1 PPL 1375 Remote Radio Control Supply Voltage 2 DK BLU 1796 Steering Wheel Controls Signal 3 GRY/BLK 14 Instrument Panel Lamp Supply Voltage - 4 4 - - Not Used 5 BLK 350 Ground 6 DK BLU 1796 Steering Wheel Controls Signal

Tailgate Audio Controls Connector End (Pontiac W/UQ3) Connector Part Information 12092162 4-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A PPL 1375 Remote Radio Control Supply Voltage B - - Not Used C DK BLU 1796 Steering Wheel Controls Signal D - - Not Used

Tweeter Connector End - LF Door Connector Part Information 12052832 2-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A GRY 118 Left Front Speaker Output (-) B TAN 201 Left Front Speaker Output (+)

Tweeter Connector End - RF Door Connector Part Information 12052832 2-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A DK GRN 117 Right Front Speaker Output (-) B LT GRN 200 Right Front Speaker Output (+)

Diagnostic Starting Point - Entertainment

Begin the system diagnosis with the Diagnostic System Check - Entertainment System . The Diagnostic System Check will provide the following information

1. The identification of the control modules which command the system.
2. The ability of the control modules to communicate through the serial data circuit.
3. The identification of any stored diagnostic trouble codes (DTCs) and their status.

The use of the Diagnostic System Check will identify the correct procedure for diagnosing the system and where the procedure is located.

Test Description

The numbers below refer to the step numbers on the diagnostic table.

1. 2: Lack of communication may be due to a partial malfunction of the class 2 serial data circuit or due to a total malfunction of the class 2 serial data circuit. The specified procedure will determine the particular condition.
2. 4: The symptom list in Symptoms will determine the correct diagnostic procedure to use.
3. 5: The presence of DTCs which begin with "U" indicate some other module is not communicating. The specified procedure will compile all the available information before tests are performed.

Diagnostic System Check - Entertainment System

Scan Tool Data List

Radio/Integrated Radio Control Scan Tool Data List (IRC)

Digital Radio Receiver Scan Tool Data List

Diagnostic Trouble Code (DTC) List

Diagnostic Trouble Code (DTC) List

Circuit Description

Each time the ignition cycles from OFF to ON, the radio receives VIN data over the class 2 communication circuit. If the VIN data in the radio memory matches the VIN data it receives over the class 2 communication circuit, the radio will operate normally.

Conditions for Running the DTC

1. The DTC is run when the radio is turned from OFF to ON.
2. Battery voltage is between 9-16 volts.

Conditions for Setting the DTC

Installing a radio from a different vehicle platform or installing a new body control module (BCM) and not entering the correct setup information with the scan tool.

Action Taken When the DTC Sets

The radio does not function properly. The radio displays "CAL".

Conditions for Clearing the DTC

1. Installing a radio from another vehicle of the same platform or a new radio of the same platform.
2. Installing a new BCM setup properly with the correct VIN for that vehicle.

The DTC status will turn to history when the above criteria is met. The scan tool can now clear the history DTC, or the scan tool will automatically clear after 100 consecutive fault free ignition cycles.

The numbers below refer to the step numbers on the diagnostic table.

1. 2: Clear all DTCs and cycle the ignition in order to verify that the DTC did not falsely set.
2. 3: Clear all DTCs after the repair procedure is complete.

DTC B1001

When the radio is powered up, the radio supplies low level audio signals to the speakers. If the vehicle is equipped with an audio amplifier, the amplifier will boost the signal sent to the speakers.

The test is performed when the radio switches from OFF to ON. The radio will continue to test for the fault once every 0.5 seconds.

The radio sets a current status for this DTC when a short to ground or voltage is detected on any of the speaker channels for 1.5 seconds.

No sound is present from one or more of the speakers.

The fault condition is not present for 5 seconds.

The numbers below refer to the step numbers on the diagnostic table.

1. 2: This step verifies that the DTC is still present.
2. 3: This step isolates the fault condition.

DTC B1025, B1035, B1045, or B1055

The digital radio antenna is connected to the digital radio receiver by 2 coax cables. One coax carries the satellite signal, the other coax carries the terrestrial signal. The antenna cable for the satellite antenna also provides a path for D.C. current for powering the antenna.

This test is run every 300 milliseconds.

The digital radio receiver detects an antenna fault.

The radio displays "No XM Signal."

The condition must be corrected.

The number below refers to the step number on the diagnostic table.

1. 2: Early design modules support the mV reading while later design modules support the mA reading.
2. 3: Due to current limiting capabilities in the module, an antenna cable shorted to ground could still show 1200-1800 mV.

DTC B1259

Each time the ignition cycles from OFF to ON, the radio receives VIN data over the class 2 communication circuit. If the VIN data in the radio memory matches the VIN data the radio receives over the class 2 communication circuit, the radio will operate normally.

1. The DTC is run when the radio is turned from OFF to ON.
2. Battery voltage is between 9-16 volts.

Installing a radio from another vehicle or installing a new body control module (BCM) and not entering the correct VIN information with the scan tool.

The radio does not function. The radio displays "LOC".

1. When installing a radio from another vehicle of the same platform, clear the VIN data using the scan tool.
2. Installing a new BCM setup properly with the correct VIN for that vehicle.

The DTC status will turn to history when the above criteria is met. The scan tool can now clear the history DTC or the scan tool will clear automatically after 100 consecutive fault free ignition cycles.

The numbers below refer to the step numbers on the diagnostic table.

1. 2: Clear all DTCs and radio theft information. Cycle the ignition in order for the radio to learn the VIN.
2. 3: Clear all DTCs after the repair procedure is complete.

DTC B1780

Symptoms - Entertainment

Visual/Physical Inspection

1. Inspect for aftermarket devices which may affect the operation of the Radio/Audio System. Refer to «Checking Aftermarket Accessories»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__checking-aftermarket-accessories) in Wiring Systems.
2. Inspect for easily accessible or visible system components for obvious damage or conditions which may cause the symptom.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems.

Symptom List

Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom

1. «Radio Poor Reception»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system)
2. «Digital Radio Poor or No Reception»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system__digital-radio-poor-or-no-reception)
3. «Audio Distortion - One or More Speakers»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system__audio-distortion-one-or-more)
4. «Audio Too Loud at Low Settings»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system__audio-too-loud-at-low-settings)
5. «Radio Controls Inoperative - Rear Seat»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system__radio-controls-inoperative-rear-seat)
6. «Rear Seat Audio Power Indicator Always On»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system__rear-seat-audio-power-indicator-always)
7. «Tape Player Weak, Slow, or Garbled Output»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system__tape-player-weak-slow-or-garbled)
8. «Steering Wheel Controls Inoperative»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system__steering-wheel-controls-inoperative)
9. «Tailgate Audio Controls Inoperative»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system__tailgate-audio-controls-inoperative)
10. «Speakers Inoperative - One or More»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system__speakers-inoperative-one-or-more)
11. «Video Entertainment System Troubleshooting Hints»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system)
12. «Radio Audio Inoperative at Rear Seat Audio (RSA) Control»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system__radio-audio-inoperative-at-rear-seat)

Audio System Troubleshooting Hints

Many conditions that affect radio operation may be corrected without removing the radio from the car. Verify the condition, and follow the diagnostic procedures in order to isolate and correct the condition. In order to properly diagnose any audio system problems, ensure that you have a fully charged battery.

Tools Required

J 39916-A CD and Cassette Diagnostic Audio Kit

Preliminary Inspections

1. Inspect for any aftermarket equipment that may have been installed on the vehicle. If aftermarket equipment is found, disconnect the equipment and verify that the audio noise is still present. Verify that the antenna connector and the antenna coaxial cable are clean and tight.
2. For reception concerns, first determine if the customer is within the listening area of the stations they are attempting to receive.
3. Stations at the lower end of the FM band are more susceptible to audio noises than stations at the higher end.
4. If the noise is only from one speaker, inspect for the following items before speaker replacement: Isolate the noise using the J 39916-A . Inspect the speaker connections in order to ensure they are clean and tight. Refer to «Testing for Intermittent Conditions and Poor Connections»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor) in Wiring Systems. Inspect for a loose or incorrectly installed speaker or surrounding trim. Loose trim may cause a buzz or flutter which sounds like a malfunctioning speaker.
5. Ignition noise on the FM band may be an indication of an ignition system problem.
6. Verify that all vehicle grounds are clean, tight, and free of corrosion.
7. Inspect the rear defogger grid lines for large breaks or dark spots.
8. Inspect the connections at the radio antenna module, if equipped, in order to ensure that they are clean and tight.
9. Compare the customers vehicle to another of similar model and audio system in order to determine if the condition is abnormal.

Identifying Concerns

1. In order to isolate the source of the noise/poor reception, identify the ignition switch position that the concern is most noticeable: Turn the ignition switch to the accessory position. Turn ON the radio. Seek up 88 to 108 FM then 550 to 1600 AM. Record the number of valid radio stations where the tuner stops. Repeat these steps with the ignition ON, and the engine OFF, then repeat the steps again with the engine running.
2. Return the ignition switch to the position that the concern was most noticeable.
3. Remove the fuses or circuit breakers, one at a time, until the noise has been eliminated.
4. Identify what systems or components are powered by the fuse.
5. Reinstall all fuses and circuit breakers.
6. Disconnect the components powered by the fuse, one at a time, until the concern has been eliminated.

Corrective Action

1. Inspect the ground integrity of the component or system causing the noise.
2. Malfunctioning and marginal components such as relays and solenoids may cause noise and/or poor reception.
3. Always use a braided ground strap when applying additional grounds and keep the ground strap as short as possible.
4. If the noise source is found to be coming from the vehicle harness: Route the antenna cable separately from the wire harness that is emitting the noise. Use aluminum or nickel tape in order to shield the antenna cable. Try variations of the following repairs: Try adding only aluminum or nickel tape before adding a ground strap to the tape. Wrap a ground strap 360 degrees around the tape, securing the other end of the strap to chassis ground. IMPORTANT: When installing suppression devices, signal wires such as sensor and communication circuits should not be suppressed. Battery and ignition voltage circuits are the best choices for suppressing.
5. Capacitors work best on switch pops and low frequency noise.
6. Filters work best on high frequency whines and static.
7. After adding any suppression device, inspect all of the vehicle systems, including those not related to the audio system, for proper operation and function.
8. Whenever possible, make a test harness that includes filters or capacitors. Always inspect the effectiveness and operation before permanent installation.
9. If an audible pop is caused due to operating a switch, perform the following repairs as necessary: Add a capacitor across the contacts of the switch. Add a capacitor from the battery positive voltage (B+) side of the switch to chassis ground. Add a capacitor from the ground side of the switch to chassis ground.
10. Use the following available noise suppression devices: 220 micro farad (50 volt) capacitor GM P/N 1227895 This works well for ignition system related noise. 0.47 micro farad capacitor GM P/N 1227894 This works well for switches and relays. Feed through capacitor GM P/N 477371 This works well for high current situations. Filter package GM P/N 1224205 This works well for low current situations. Fuel pump suppressor GM P/N 25027405 21 inch braided ground strap GM P/N 8910791 19 inch braided ground strap GM P/N 6286800 10.5 inch braided ground strap GM P/N 6287160 8.5 inch braided ground strap GM P/N 12091511

Generator Whine Concerns

1. Inspect the ground terminal and cable for high resistance.
2. Inspect the generator and brackets for loose or coated mounting bolts.
3. Verify that the ground straps between the engine and the frame are clean and tight.
4. If the noise is still present, inspect the charging system for proper operation. Refer to «Diagnostic System Check - Engine Electrical»(/buick/rendezvous/i-2001-2007/remont/charging-system/#battery-charging-system-and-starting-system) in Engine Electrical.
5. Install a filter GM P/N 1224205 in the battery voltage feed circuit to the radio.
6. If the noise is not eliminated, install the filter in each following variation: Install the filter with the single wire side toward the radio and the ground wire attached to chassis ground. Remove the ground to the filter. Reverse the filter so that the two-wire side is toward the radio with the ground wire attached to chassis ground. Remove the ground from the filter.
7. If the filter GM P/N 1224205 causes a delay when turning the radio ON or OFF, or other problems, remove the filter and install a 0.47 micro farad capacitor to chassis ground.
8. Before reassembling the vehicle, remove any unneeded filters.
9. Test the functionality of all the vehicle systems, including those not related to the audio system, for proper operation and function.

Always perform the Radio/Audio System Diagnostic System Check before proceeding with these diagnostic procedures. Refer to Diagnostic System Check - Entertainment System .

Using a Test Antenna

Use a test mast antenna to quickly check for poor vehicle antenna operation. Unplug antenna lead-in connector from radio receiver and plug a test antenna into radio. Make sure the test antenna base is grounded to the vehicle chassis and keep hands off the mast. Check radio reception in an area away from electrical interferences. Tune to several weak and strong AM and FM stations. If the radio reception improved, the problem exists with the vehicle antenna and/or lead-in cable. If the reception is still poor, refer to Audio System Troubleshooting Hints .

Antenna Ground Test

1. Disconnect the negative battery cable.
2. Disconnect the antenna lead-in connector from the radio receiver.
3. Measure the resistance from the negative battery cable to the coaxial cable, outer conductor, connector.
4. The resistance measured should be 0.20 ohms or less.
5. Test the following when the resistance is greater than 0.20 ohms. Base of the antenna for a poor connection to body ground. The coaxial cable interconnects for a poor connection or corrosion. Test for an open or high resistance from the battery negative cable to the body. Refer to «Circuit Testing»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__circuit-testing) and «Wiring Repairs»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__wiring-repairs) in Wiring Systems.
6. After finding and correcting the condition, operate the system in order to verify the repair.

Antenna Coaxial Cable Testing

Use the appropriate chart and diagram to test the antenna coaxial cable resistances for the antenna system on the vehicle. Refer to the table when testing the antenna and/or lead-in cable.

Scheme 36

Radio Poor Reception

1. Measure the resistance from the coax center conductor to antenna mast, ohmmeter probes at points 2 and 7.
2. Total resistance from end to end of center conductor-ohmmeter probes at points 2 and 5: RG-58/RG-59 type cable - less than 0.20 ohms per foot RG-62/RG-62M type cable - less than 3.5 ohms per foot
3. When checking the resistance, cautiously wiggle the lead-in tip and cable. Refer to «Testing for Intermittent Conditions and Poor Connections»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor) in Wiring Systems.
4. Replace the antenna and/or lead-in cable when the above readings are not obtained. Refer to «Antenna Cable Replacement»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system__antenna-cable-replacement) for service procedure.

Power Type Antennas

The following chart and diagram show ohmmeter readings which should be obtained.

Scheme 37

Radio Poor Reception

Refer to the table when testing the power antenna.

1. Disconnect the negative battery cable.
2. Measure the resistance at the points specified in the table.
3. With the ohmmeter probes fastened to each point, wiggle the separate mast section and antenna housing case.
4. The resistance readings specified in the table should always be obtained. Test and/or replace the following when the resistance readings are out of specification. Replace antenna mast section. Test the ground for an open or high resistance. Refer to «Circuit Testing»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__circuit-testing) and «Wiring Repairs»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__wiring-repairs) in Wiring Systems.
5. After finding and correcting the antenna condition, make sure the antenna lead-in connector is corrosion free and properly fastened.
6. Operate the system in order to verify the repair.

Windshield Type Antennas

Inspect the antenna connector wire at base of windshield. Make sure the wire is not pinched or broken and is fully seated into the lead-in receptacle.

Inspect dipole wires within the windshield for breaks. Use the figure and table for the mast antenna as a guide to test for continuity within the antenna coaxial cable. Repair or replace any portion of the coaxial cable that does not meet the resistance measurements. If test antenna indicates radio is OK and lead-in checks fine, the windshield may need to be replaced. A defective windshield antenna results in loss of sensitivity, particularly on AM.

Scheme 38

Rear Defogger Antenna System

This antenna system uses the existing rear defogger grid as an antenna. Using the defogger as an antenna requires the circuitry in the radio antenna module to decouple the RF from the DC heater current.

Perform the Antenna System Test and test the antenna coax cable prior to performing the following tests.

1. The radio antenna module is not grounded properly. The module grounding screws should be clean and tight. Measure the resistance from the antenna module base plate to a good ground. Resistance should be 0.20 ohms or less. Find and correct the condition if the resistance is out of specification.
2. The antenna relay coil supply voltage circuit to the radio antenna module is open or shorted to ground. Test the antenna relay coil supply voltage circuit for an open or short to ground. Refer to «Circuit Testing»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__circuit-testing) and «Wiring Repairs»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__wiring-repairs) in Wiring Systems.
3. Defective radio antenna module. Replace the radio antenna module.
4. No antenna relay coil supply voltage output from the radio. Disconnect the radio antenna module connector. Turn ON the radio and measure the voltage from the antenna relay coil supply voltage circuit of the radio to a good ground. Voltage measured should be near 12 volts. If no voltage is measured, replace the radio. Refer to «Radio Replacement»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system) for service procedure.
5. If noise is present when the rear defogger is on, inspect the rear defogger grid for breaks. Repair as necessary.
6. After finding and correcting the condition, operate the system in order to verify the repair.

Diversity Antenna System

This antenna system uses two antennas to form a diversity system. The primary antenna is part of the rear window. The primary antenna receives both AM and FM signals. The secondary antenna is located on the passenger side of the windshield. The secondary antenna receives only FM signals. The radio antenna module processes the antenna reception signals and phase aligns them to create one strong signal.

Perform the Antenna System Test and test the antenna coax cable prior to performing the following tests.

1. The radio antenna module is not grounded properly. The module grounding screws should be clean and tight. Measure the resistance from the antenna module base plate to a good ground. Resistance should be 0.20 ohms or less. Find and correct the condition if the resistance is out of specification.
2. The antenna enable signal circuit to the radio antenna module is open or shorted to ground. Test the antenna enable signal circuit for an open or short to ground. Refer to «Circuit Testing»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__circuit-testing) and «Wiring Repairs»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__wiring-repairs) in Wiring Systems.
3. The FM composite signal circuit to the radio antenna module is open or shorted to ground. Test the FM composite signal circuit for an open or short to ground. Refer to «Circuit Testing»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__circuit-testing) and «Wiring Repairs»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__wiring-repairs) in Wiring Systems.
4. Improper retention of the antenna cable in the floating retainer. Poor or no connection with the radio will result when the radio is installed if the antenna cable is not properly attached in the floating retainer. Inspect the antenna cable for movement in the floating retainer. Replace the antenna cable if movement is found. Refer to «Antenna Cable Replacement»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system__antenna-cable-replacement) for service procedure.
5. Defective radio antenna module. Replace radio antenna module.
6. No FM composite signal voltage output from the radio. Disconnect the radio antenna module connector. Turn ON the radio and tune the radio to the FM band. Measure the voltage from the FM composite signal circuit of the radio antenna module to a good ground. Voltage measured should be near 8 volts. If no voltage is measured, replace the radio. Refer to «Radio Replacement»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system) for service procedure.
7. After finding and correcting the condition, operate the system in order to verify the repair.

Digital Radio Poor or No Reception

Digital Radio Poor or No Reception

Audio Distortion - One or More Speakers

Audio Distortion - One or More Speakers

Audio Too Loud at Low Settings

Audio Too Loud at Low Settings

Radio Controls Inoperative - Rear Seat

Radio Controls Inoperative - Rear Seat

Rear Seat Audio Power Indicator Always On

Rear Seat Audio Power Indicator Always On

Tape Player Weak, Slow, or Garbled Output

Tape Player Weak, Slow, or Garbled Output

Steering Wheel Controls Inoperative

Steering Wheel Controls Inoperative

Tailgate Audio Controls Inoperative

Tailgate Audio Controls Inoperative

Speakers Inoperative - One or More

Schematic Reference: Radio/Audio System Schematics

Always perform the Entertainment System Diagnostic System Check before proceeding with these diagnostic procedures. Refer to Diagnostic System Check - Entertainment System .

All Speakers Inoperative

With RPO U96

1. Speaker output shorted - Test all speaker outputs for a short. Refer to «Circuit Testing»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__circuit-testing) and «Wiring Repairs»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__wiring-repairs) in Wiring Systems.
2. Defective Radio - Replace Radio. Refer to «Radio Replacement»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system) .

With RPO UQ3

1. Battery Positive Voltage circuit to the amplifier open. Test the Battery Positive Voltage circuit to the amplifier for an open. Refer to «Circuit Testing»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__circuit-testing) and «Wiring Repairs»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__wiring-repairs) in Wiring Systems.
2. Low Level Audio Signal circuit shorted. Test all Low Level Audio Signal circuits for a short to ground or short to voltage. Refer to «Circuit Testing»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__circuit-testing) and «Wiring Repairs»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__wiring-repairs) in Wiring Systems.
3. Radio On Signal circuit open or shorted to ground. Test the Radio On Signal circuit for an open or short to ground. Refer to «Circuit Testing»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__circuit-testing) and «Wiring Repairs»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__wiring-repairs) in Wiring Systems.
4. Entertainment and Comfort Serial Data circuit shorted to voltage. Test the Entertainment and Comfort Serial Data circuit for a short to voltage. Refer to «Circuit Testing»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__circuit-testing) and «Wiring Repairs»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__wiring-repairs) in Wiring Systems.
5. No low level audio output from the radio. Test for any AC voltage between the Left Front Low Level Audio Signal circuits at the amplifier harness connector, disconnected with the radio volume adjusted to 50 %. If no AC voltage is present, replace the radio. Refer to «Radio Replacement»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system) .
6. No audio output from the amplifier. Replace the amplifier. Refer to «Amplifier Replacement»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system) .

One Speaker Inoperative

With RPO U96

1. Speaker output open. Test the appropriate speaker output circuits for an open. Refer to «Circuit Testing»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__circuit-testing) and «Wiring Repairs»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__wiring-repairs) in Wiring Systems.
2. No audio output from the radio. Test for any AC voltage between the appropriate speaker output circuits at the speaker harness connector, disconnected with the radio volume adjusted to an audible level. If AC voltage is present, replace the speaker. Refer to «Speaker Replacement Reference»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system__speaker-replacement-reference) . If no AC voltage is present, replace the radio. Refer to «Radio Replacement»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system) .

With RPO UQ3

1. Speaker Output circuit from amplifier open or shorted. Test the appropriate Speaker Output circuits for an open or short. Refer to «Circuit Testing»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__circuit-testing) and «Wiring Repairs»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__wiring-repairs) in Wiring Systems.
2. Low Level Audio Circuit open. Test the appropriate Low Level Audio circuit for an open. Refer to «Circuit Testing»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__circuit-testing) and «Wiring Repairs»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__wiring-repairs) in Wiring Systems.
3. No low level audio output from the radio. Test for any AC voltage between the appropriate Low Level Audio Signal circuits at the amplifier harness connector, disconnected with the radio volume adjusted to an audible level. If no AC voltage is present, replace the radio. Refer to «Radio Replacement»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system) .
4. No audio output from the amplifier. Test for any AC voltage between the appropriate speaker output circuits at the speaker harness connector, disconnected with the radio volume adjusted to an audible level. If AC voltage is present, replace the speaker. Refer to «Speaker Replacement Reference»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system__speaker-replacement-reference) . If no AC voltage is present, replace the amplifier. Refer to «Amplifier Replacement»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system) .

All Speakers on One Channel Inoperative Only on Digital Radio

1. Right or left audio signal circuit open or shorted. Test all audio signal circuits for an open or short. Refer to «Circuit Testing»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__circuit-testing) and «Wiring Repairs»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__wiring-repairs) in Wiring Systems.
2. No audio output from the digital radio receiver. Replace the digital radio receiver. Refer to «Receiver Replacement - Digital Radio»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system) .

All Speakers Inoperative Only on Digital Radio

1. Right or left audio signal circuit shorted to battery positive voltage. Test all audio signal circuits for a short to battery positive voltage. Refer to «Circuit Testing»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__circuit-testing) and «Wiring Repairs»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__wiring-repairs) in Wiring Systems.
2. No audio output from the digital radio receiver. Replace the digital radio receiver. Refer to «Receiver Replacement - Digital Radio»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system) .

Speaker(s) - Reduced Volume

With RPO U96

1. Speaker output circuit high resistance. Test the appropriate speaker output circuits for high resistance. Refer to «Circuit Testing»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__circuit-testing) and «Wiring Repairs»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__wiring-repairs) in Wiring Systems.
2. Defective speaker - Replace the appropriate speaker. Refer to «Speaker Replacement Reference»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system__speaker-replacement-reference) .

With RPO UQ3

1. Speaker output circuit high resistance. Test the appropriate speaker output circuits for high resistance. Refer to «Circuit Testing»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__circuit-testing) and «Wiring Repairs»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__wiring-repairs) in Wiring Systems.
2. Low Level Audio circuit open. Test the appropriate Low Level Audio circuit for an open. Refer to «Circuit Testing»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__circuit-testing) and «Wiring Repairs»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__wiring-repairs) in Wiring Systems.
3. Defective speaker - Replace the appropriate speaker. Refer to «Speaker Replacement Reference»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system__speaker-replacement-reference) .

Schematic Reference: Video System Schematics

1. Many conditions that affect video system operation may be corrected without removing the radio, the digital video disc (DVD) player or the video entertainment overhead console from the vehicle. Make sure to understand all features of system operation before beginning the diagnosis of the system. Verify the condition and follow the diagnostic procedures in order to isolate and correct the condition.
2. Be sure the vehicle battery is fully charged before beginning video entertainment system diagnosis.

Video or Audio Distortion

The manufacturing process for producing DVD's does not have the same quality control processes in place that compact disk manufacturing does. If there are video or audio quality problems with an individual DVD, try playing that disk in another DVD player. If the quality is poor for both players, return the disk to the place of purchase and request an exchange. If the quality problem is only seen in one of the players, examine the disk for scratches dirt or smudges and attempt to clean the disk with one of the disk cleaning systems that are commercially available.

Video or audio distortion during auxiliary playback can often be attributed to the DC to AC inverter that is used to power the auxiliary device. The power inverters tend to introduce noisy signals into the vehicle electrical system.

1. Volume control on the wireless headphone set is turned all the way down. Adjust the volume control on the headphones.
2. Dead batteries in the wireless headphone set. Turn on power to the headphone set. If the headset indicator does not turn on, replace the batteries in the headset as needed.
3. Faulty headphone set. Test the operation of the system using a known good headphone set. If operation is OK, replace the vehicle headphone set.

The buttons on the video remote control do not operate the video disc player but the buttons on the video disc player operate normally.

1. Dead batteries in the video remote control. Replace the dead batteries.
2. Faulty remote control. Test the operation of the system using a known good remote control. If operation is OK, replace the remote control.

Video Entertainment System Inoperative

Radio Audio Inoperative at Rear Seat Audio (RSA) Control

Radio Audio Inoperative at Rear Seat Audio (RSA) Control

Radio Setup

The radio setup procedure will also clear the following messages

1. CAL
2. CAL ERROR
3. CALIBRATE

To setup a new radio for the vehicle, perform a VIN Relearn, located in the Special Functions section on the scan tool. Cycle the ignition when complete.

If the radio is not properly setup, the radio will display a locked message (LOC) or Calibrate.

Radio Tuner Calibration

To calibrate the radio, select COUNTRY CODE under the Special Functions menu on the scan tool.

Radio Chime Volume Selection

To set the chime volume, select CHIME SETTINGS under the Special Functions screen and follow correct menu headings.

Digital Radio Receiver Setup

To setup the digital radio receiver, complete the setup procedure under the Special Functions menu of the scan tool, then cycle ignition.

XM Activation

1. Turn the radio ON, tune to the XM channel 0, and record the radio ID. The radio ID will be needed for activation of the new receiver.
2. Call XM radio at 1-800-556-3600 to deactivate the faulty receiver and activate the new receiver.
3. Park the vehicle outside in an area with an unobstructed view of the southern sky.
4. Leave the vehicle outside with the ignition switch in the ACC position and the radio on for 30 minutes to activate XM service.
5. Once activated, the radio will receive the remaining XM channels.

Speaker Replacement Reference

Speaker Replacement Reference

Scheme 39

Scheme 40

1. Remove the instrument accessory panel trim plate. Refer to «Trim Plate Replacement - Instrument Panel (I/P) Accessory (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or to «Trim Plate Bezel Replacement - Instrument Panel (I/P) Cluster (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Trim Plate Bezel Replacement - Instrument Panel (I/P) Cluster (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages and Console.
2. Remove the radio screws.
3. Pull the radio away from the instrument panel (I/P).
4. Disconnect the electrical/audio electrical connectors from the radio.
5. Disconnect the coaxial cable connector from the radio.
6. Remove the radio.

Installation Procedure

1. Connect the coaxial cable connector to the radio.
2. Connect the electrical/audio connectors to the radio. IMPORTANT: If the radio locator tab is difficult to align to the I/P locator opening, pull the radio toward you and reposition the antenna cable.
3. Install the radio to the I/P. Align the radio control locator tab to the I/P locator hole while carefully pressing the radio into the I/P until fully seated. NOTE: Refer to «Fastener Notice»(/buick/rendezvous/i-2001-2007/remont/oem-general-information/#cautions-and-notices__fastener-notice) in Cautions and Notices.
4. Install the radio screws. Tighten: Tighten the radio screws to 2.5 N.m (22 lb in).
5. Install the I/P accessory trim plate. Refer to «Trim Plate Replacement - Instrument Panel (I/P) Accessory (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or to «Trim Plate Bezel Replacement - Instrument Panel (I/P) Cluster (Aztek)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) or «Trim Plate Bezel Replacement - Instrument Panel (I/P) Cluster (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages and Console.
6. Perform the radio set-up procedure. Refer to «Radio Setup»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system__radio-setup) .

Removal Procedure

Scheme 41

Scheme 42

1. Remove the I/P compartment. Refer to «Compartment Replacement - Instrument Panel (I/P)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
2. Remove the receiver bracket nuts.
3. Remove the receiver from the bracket.
4. Disengage the electrical connector and the antenna connectors from the XM radio receiver.
5. Remove the XM digital radio receiver from the vehicle.

1. Install the XM digital radio receiver to the receiver bracket. NOTE: Refer to «Fastener Notice»(/buick/rendezvous/i-2001-2007/remont/oem-general-information/#cautions-and-notices__fastener-notice) in Cautions and Notices.
2. Install the radio receiver nuts. Tighten: Tighten the nuts to 4 N.m (35 lb in).
3. Connect the electrical connector and the antenna connectors to the XM radio receiver.
4. Install the I/P compartment. Refer to «Compartment Replacement - Instrument Panel (I/P)»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
5. Perform the setup procedure for the digital radio receiver. Refer to «Digital Radio Receiver Setup»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system__digital-radio-receiver-setup) .

Scheme 43

1. Remove the left instrument panel (IP) insulator. Refer to «Closeout/Insulator Panel Replacement - Left»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
2. Push in the retaining tab to release the amplifier.
3. Slide the amplifier out of the bracket.
4. Disconnect the electrical connectors.
5. Remove the amplifier from the vehicle.

1. Connect the electrical connectors to the amplifier.
2. Align the pins on the amplifier to the slots on the bracket.
3. Slide the amplifier forward until the lock tab is seated.
4. Install the left IP insulator. Refer to «Closeout/Insulator Panel Replacement - Left»(/buick/rendezvous/i-2001-2007/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console

Scheme 44

Scheme 45

Scheme 46

Scheme 47

1. Remove the headliner. Refer to «Headliner Replacement (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) or «Headliner Replacement (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
2. Disconnect the antenna cables from the antenna base cable connectors.
3. Remove the antenna base bolt.
4. Disengage the retainers at the inside of the roof.
5. Remove the antenna base assembly.

1. Route the antenna base cables through the roof opening.
2. Install the antenna base to the roof. NOTE: Refer to «Fastener Notice»(/buick/rendezvous/i-2001-2007/remont/oem-general-information/#cautions-and-notices__fastener-notice) in Cautions and Notices.
3. Secure the antenna base with the bolt. Tighten: Tighten the bolt to 3 N.m (27 lb in).
4. Connect the antenna cables to the antenna base cable connectors.
5. Install the headliner. Refer to «Headliner Replacement (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) or «Headliner Replacement (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.

Antenna Cable Replacement

Scheme 48

Scheme 49

Scheme 50

1. Remove the radio. Refer to «Radio Replacement»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system) .
2. Remove the sunshade. Refer to «Sunshade Replacement»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
3. Remove the sunshade anchor. Refer to «Sunshade Anchor Replacement»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
4. Remove the trim panel from the right cowl side. Refer to «Trim Panel Replacement - Cowl Side»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
5. Remove the garnish molding from the windshield. Refer to «Garnish Molding Replacement - Windshield Pillar»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
6. Remove the bolt that secures the antenna cable extension to the roof. This bolt is located under the right front corner of the headliner.
7. Remove the antenna cable from the instrument panel carrier.
8. Remove the following components from the vehicle: The antenna cable The antenna cable extension

1. Install the following components to the vehicle: The antenna cable The antenna cable extension
2. Install the antenna cable to the instrument panel carrier. NOTE: Refer to Fastener Notice in Cautions and Notices.
3. Install the bolt which secures the antenna cable extension to the roof. Tighten: Tighten the bolt to 3.2 N.m (28 lb in).
4. Install the trim panel at the right cowl side. Refer to «Trim Panel Replacement - Cowl Side»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
5. Install the garnish molding to the windshield. Refer to «Garnish Molding Replacement - Windshield Pillar»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
6. Install the sunshade anchor. Refer to «Sunshade Anchor Replacement»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
7. Install the sunshade. Refer to «Sunshade Replacement»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
8. Install the radio. Refer to «Radio Replacement»(/buick/rendezvous/i-2001-2007/remont/entertainment-systems/#entertainment-system) .

Scheme 51

Scheme 52

1. Remove the headliner. Refer to «Headliner Replacement (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) or «Headliner Replacement (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
2. Disconnect the antenna cable from the antenna base cable connector.
3. Remove the antenna cable retainer clips.
4. Open the right side end cap from the instrument panel (I/P) to disconnect the cable connectors.
5. Disconnect the antenna cable from the digital radio receiver.
6. Remove the antenna cable retainers from the receiver bracket.
7. Remove the antenna cable.

1. Install the antenna cable retainers to the receiver bracket.
2. Connect the antenna cable to the digital radio receiver.
3. Install the cable connectors to the right side end cap on the I/P.
4. Install the right rear compartment trim panel.
5. Install the antenna cable retainer clips.
6. Connect the antenna cable to the antenna base cable connector.
7. Install the headliner. Refer to «Headliner Replacement (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) or «Headliner Replacement (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.

Scheme 53

1. Remove the front door trim panel. Refer to «Trim Panel Replacement - Side Front Door (Aztek)»(/buick/rendezvous/i-2001-2007/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) or «Trim Panel Replacement - Side Front Door (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) in Doors.
2. Remove the front door water deflector. Refer to «Water Deflector Replacement - Front Door»(/buick/rendezvous/i-2001-2007/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) in Doors.
3. Remove the speaker screws.
4. Disconnect the wire harness from the speaker.
5. Remove the speaker.

1. Connect the wire harness to the speaker. NOTE: Refer to Fastener Notice in Cautions and Notices.
2. Install the speaker screws. Tighten: Tighten the screws to 3.2 N.m (28 lb in)
3. Install the front door water deflector. Refer to «Water Deflector Replacement - Front Door»(/buick/rendezvous/i-2001-2007/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) in Doors.
4. Install the front door trim panel. Refer to «Trim Panel Replacement - Side Front Door (Aztek)»(/buick/rendezvous/i-2001-2007/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) or «Trim Panel Replacement - Side Front Door (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) in Doors.

Scheme 54

1. Remove the front door trim panel assembly in order to expose the speaker. Refer to «Trim Panel Replacement - Side Front Door (Aztek)»(/buick/rendezvous/i-2001-2007/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) or «Trim Panel Replacement - Side Front Door (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) in Doors.
2. Remove the speaker screws.
3. Disconnect the wire harness from the speaker.
4. Remove the speaker.

Note. Refer to Fastener Notice in Cautions and Notices.

1. Install the speaker to the door trim panel assembly. Tighten: Tighten the speaker screws to 3.2 N.m 28 lb in).
2. Connect the wire harness to the speaker.
3. Install the trim panel assembly to the front door. Refer to «Trim Panel Replacement - Side Front Door (Aztek)»(/buick/rendezvous/i-2001-2007/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) or «Trim Panel Replacement - Side Front Door (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) in Doors.

Scheme 55

1. Remove the rear door trim panel. Refer to «Trim Panel Replacement - Side Rear Door (Aztek)»(/buick/rendezvous/i-2001-2007/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) or «Trim Panel Replacement - Side Rear Door (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) in Doors.
2. Remove the screws from the speaker.
3. Disconnect the electrical connector from the speaker.
4. Remove the speaker from the rear door.

1. Connect the electrical connector to the rear door speaker. NOTE: Refer to Fastener Notice in Cautions and Notices.
2. Align the speaker to the rear door and install the screws. Tighten: Tighten the speaker screws to 3.2 N.m (28 lb in).
3. Install the rear door trim panel. Refer to «Trim Panel Replacement - Side Rear Door (Aztek)»(/buick/rendezvous/i-2001-2007/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) or «Trim Panel Replacement - Side Rear Door (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/door-locks-anti-theft-systems/#door-system-mirror-system-window-system) in Doors.

Scheme 56

1. Remove the rear quarter trim. Refer to «Trim Panel Replacement - Rear Quarter Lower (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) or «Trim Panel Replacement - Rear Quarter Lower (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
2. Remove the speaker bolts.
3. Disconnect the electrical connectors from the speaker.
4. Remove the speaker.

1. Connect the electrical connector to the rear radio speaker.
2. Install the rear radio speaker. NOTE: Refer to Fastener Notice in Cautions and Notices.
3. Install the speaker screws. Tighten: Tighten the screws to 3 N.m (28 lb in).
4. Install the rear quarter trim. Refer to «Trim Panel Replacement - Rear Quarter Lower (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) or «Trim Panel Replacement - Rear Quarter Lower (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.

Scheme 57

1. Using a flat-bladed tool, gently pry the second seat audio control out from the overhead console.
2. Disconnect the electrical connector.

1. Connect the electrical connector.
2. Align the second seat control to the overhead console.
3. Gently install the second seat control into the overhead console by pushing forward and inward.

Scheme 58

Scheme 59

Scheme 60

1. Raise the front armrest.
2. Remove 2 screws that secure the rear console trim plate.
3. Pull the trim plate away from the console.
4. Disconnect the electrical connectors.
5. Press the back of the audio control to release the control from the trim plate.
6. Remove the second seat audio control.

1. Press the second seat audio control into the rear console trim plate.
2. Connect the electrical connectors to the audio control
3. Press the trim plate onto the center console. NOTE: Refer to Fastener Notice in Cautions and Notices.
4. Install 2 screws that secure the rear console trim plate. Tighten: Tighten the screws to 2 N.m (18 lb in).
5. Close the front armrest.

Scheme 61

Scheme 62

1. Remove the trim panel. Refer to «Trim Panel Replacement - Rear Quarter Lower (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) or «Trim Panel Replacement - Rear Quarter Lower (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) .
2. Disconnect the electrical connector.
3. Remove the screws which retain the rear cargo audio control.
4. Remove the rear cargo audio control from the trim panel.

1. Align the rear cargo audio control to the trim panel. NOTE: Refer to Fastener Notice in Cautions and Notices.
2. Install the screws. Tighten: Tighten the screws to 2 N.m (18 lb in).
3. Connect the electrical connector.
4. Install the rear trim panel. Refer to «Trim Panel Replacement - Rear Quarter Lower (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) or «Trim Panel Replacement - Rear Quarter Lower (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) .

DVD Player Replacement

Scheme 63

Scheme 64

Scheme 65

Scheme 66

1. Move the screen to the open position.
2. Open the rear screw cover using a flat-bladed tool.
3. Remove the 4 retaining bolts.
4. With one hand holding the DVD player assembly, pull down the retainer from the bracket.
5. Allow the DVD player assembly to come to rest on the hook. IMPORTANT: Observe the routing of the wiring harness (2).
6. Disconnect the wire connector (1).
7. Slightly lift up the DVD player assembly so that the hook can be removed from its resting position.
8. Remove the DVD player from the vehicle.

Scheme 67

1. Install the DVD player hook (1) into the hook opening. IMPORTANT: Ensure the harness is routed to the right side of the large plastic pin (2) as shown.
2. Connect the wire connector (1) to the DVD player assembly.
3. Install the harness retainer to the panel.
4. Swing the rear part of the assembly to the headliner so that the retainer is seated. NOTE: Refer to «Fastener Notice»(/buick/rendezvous/i-2001-2007/remont/oem-general-information/#cautions-and-notices__fastener-notice) in Cautions and Notices.
5. Install the rear retaining bolts. Tighten: Tighten the bolts to 9 N.m (80 lb in).
6. Move the screen to the open position.
7. Install the front retaining bolts (2). Tighten: Tighten the bolts to 9 N.m (80 lb in).
8. Close the rear screw cover.

Radio/Audio System Description and Operation

The entertainment system on this vehicle is configured with either a base or an uplevel system. Both the base and uplevel systems contain a radio, antenna, speakers, and on some vehicle lines an audio amplifier and/or rear seat audio (RSA).

The uplevel system differs from the base level system by providing the customer with enhanced audio system features. Some of those features may include the radio data system (RDS), extended range speakers, an audio amplifier, or an uplevel amplifier, RSA, video entertainment system and a remote playback device.

The following list shows the radios available for this vehicle

1. Uplevel Radio (U1N) - AM/FM Stereo, Cassette with Programmable Equalizer and RDS
2. Uplevel Radio (U1P ) - AM/FM Stereo, CD with Programmable Equalizer and RDS
3. Uplevel Radio (U1Q) - AM/FM Stereo, Cassette, CD with Programmable Equalizer, Rear Seat Audio (RSA) System and RDS
4. Uplevel Radio (UC6) - AM/FM, Integral Multi Disc CD Changer (IMCX) with Programmable Equalizer, Rear Seat Audio (RSA) System and RDS

Radio Features

Cassette Features

Compact Disc Features

Each item in the list below represents topics covered in detail below.

1. AM/FM Reception
2. Antenna
3. Audio Amplifier
4. Theft Deterrent
5. Integral Multi Disc CD Changer (IMDX)
6. Remote Playback Device
7. Rear Seat Audio (RSA)
8. Radio Data System (RDS)
9. Steering Wheel and Tailgate Audio Controls
10. Tape/CD Player Error Messages

Radio Signal

The radio signal is sent from a broadcast station and is then received by an antenna. The strength of the signal received depends on the following

1. The power output, or wattage of the broadcasting station
2. The location of the vehicle, or receiver relative to the broadcast tower.
3. Obstacles between the tower and the receiver
4. Atmospheric conditions
5. What band, AM or FM the station is broadcasting
6. Type of antenna and the ground plane

AM Reception

The AM band has a lower frequency range than the FM band. These longer wavelengths

1. Bend around obstacles
2. Follow the curvature of the earth
3. May reflect off the ionosphere-skip

The AM frequencies have longer range due to the ground wave. The ground wave follows the curvature of the earth and is affected by its conductivity. Greater conductivity equates to less signal loss thus transmission over water is better than over land. The AM band has a range of 80-320 km (50-200 miles).

FM Reception

The shorter wavelengths of the higher frequency FM band

1. Reflect off obstacles
2. Are absorbed by the ground
3. Penetrate the ionosphere

Broadcasts in the FM band are limited to "line of sight" reception which is typically 40 km (25 miles). Even when out of a direct line of sight, the signal may be reflected into areas that would be in a "shadow" otherwise. Factors which affect the line of sight include

1. Height of the broadcast antenna
2. Height of the receiving antenna
3. Terrain and buildings in the broadcast path

XM Reception

XM satellite radio provides digital radio reception. The XM signal is broadcast from two satellites and, where necessary, terrestrial repeaters. The high power satellites allow the antenna to receive the XM signal even when foliage and other partial obstructions block the antennas view of the satellite. Terrestrial repeaters are used in dense urban areas. These repeaters will receive the satellite signal and re-broadcast them at much higher power levels in order to ensure reception in areas with densely packed tall buildings.

Antenna

The antenna is comprised of a very thin metal grid which is permanently affixed to the top center of the windshield. If the antenna becomes damaged, the windshield must be replaced.

Audio Amplifier

The purpose of an amplifier is to increase the power of a voltage or current signal. The output signal of an amplifier may consist of the same frequencies as the input signal or it may consist of only a portion of the frequencies of the input signal, as in the case of a subwoofer or a mid-range amplifier.

When the radio is turned on, the radio sends a voltage signal to the audio amplifier via the amplifier control circuit. The amplifier present signal circuit allows the radio to recognize that an amplifier is present. Once the radio detects the amplifier, the radio will output low level audio signals to the amplifier. With the amplifier enabled, the signal that drives the speakers is now amplified.

Theft Deterrent

The "Theftlock" theft deterrent system is a feature on all base and uplevel radios. There is no need to program a security code into the radio as in past model years. The theft deterrent system now utilizes class 2 serial data to determine if the radio is in the appropriate vehicle. Each time the radio receives the "run" power mode message, it compares the VIN information it has stored to the VIN information received from a module on the class 2 serial data circuit responsible for transmitting that information. If a mis-match occurs, the radio display will indicate to the user the radio is locked. Once this takes place, a DTC will set, the radio will not respond to any button presses and become inoperative. The 2 scenarios able to cause this condition are

1. A radio is installed from another vehicle
2. A module which communicates on the class 2 serial data circuit which supplies VIN information to the radio is replaced and not properly setup with the correct VIN information for that vehicle

The only way to unlock the radio is by using a scan tool. Always refer to the table in this section to diagnose the "Theftlock" DTC for further information.

Integral Multi Disc CD Changer (IMDX [Uplevel])

The Integral Multi Disc CD Changer has the capability of storing and playing up to 6 compact discs. The Integral Multi Disc CD Changer has a shock-absorbing system. Only under extreme operating temperatures or severe shock or vibration should the compact disc player skip or mute. If the customer travels an abnormally rough road, a skip condition may be normal. Test drive the vehicle on a normal road with a known good CD. If the condition is still present, replace the radio.

The use of CD lens cleaner discs is not advised, due to the risk of contaminating the lens of the CD optics with lubricants internal to the CD mechanism.

Single Disc Loading

To operate the Integral Multi Disc CD Changer in the single play mode, press and release the LOAD button and wait for the LED to the right of the disc door to turn green. Load a disc when the LED turns green. If the radio is ON, the disc will begin to play automatically. If the radio is OFF, press the LOAD button for the disc to play.

Multi Disc Loading

To operate the Multi Disc CD Changer in the multi disc mode, press and hold the LOAD button for 2 seconds. An audible beep will be heard and the LED to the right of the disc door begins to flash. The radio will also display the message "INSERT CD". When the LED stops flashing and turns green, load a disc. Once the disc is loaded the LED begins to flash again. The radio will also display the message "MULTI LOAD" to indicate the multi load mode has been initiated and the changer will begin accepting a disc for however many empty slots there may be. When the LED stops flashing and turns green, load another disc. Repeat this procedure to continue loading discs. The CD changer holds up to 6 discs.

When the changer is full, 6 discs are loaded, and the LOAD button is pressed, 3 audible beeps are heard and the message "CHANGER FULL" is displayed.

To play one of the CD's, press one of the preset buttons.

Removing CDs

Use the eject button, the button labeled CD to remove a disc or discs.

Perform the following to eject

1. To remove a single disc, press and release the CD button. The message "REMOVE CD" is displayed.
2. To remove multiple discs, press and release the CD button for 2 seconds. An audible beep is heard and the LED to the right of the disc door begins to flash indicating a disc is being ejected. The message "REMOVE CD" is displayed.

Song List Feature

The Multi Disc CD Changer has a feature called Song List. This feature is capable of saving 20 track selections to a play list.

To save tracks into Song List, perform the following

1. The disc player must be ON with at least one disc loaded.
2. The message "S-LIST" should not be displayed on the radio. If "S-LIST" is present, press the SONG LIST button to turn it OFF.
3. Select the desired disc by pressing the numbered push-button and then use the SEEK right arrow button to locate the track that you want to save. The track will begin to play.
4. Press and hold the SONG LIST button for 2 or more seconds to save the track into memory. When SONG LIST is pressed an audible beep is heard. After 2 seconds of pressing SONG LIST continually, 2 audible beeps will sound to confirm that the track has been saved. The message "TRACK ADD" is displayed.
5. Repeat steps 3 and 4 for saving other selections.

To play the Song List press the SONG LIST button. One beep is heard and "S-LIST" appears on the display. The recorded tracks will begin to play in the order that they were saved.

To delete tracks from the Song List.

1. The disc player must be on.
2. Press the SONG LIST button. The message "S-LIST" appears on the display.
3. Press the SEEK button to locate desired track to be deleted.
4. Press and hold the SONG LIST button for 2 seconds. After 2 seconds, 2 beeps are heard confirming that the track has been deleted. The message "TRACK DELETE" is displayed.

To delete the entire Song List.

1. The disc player must be on.
2. Press the SONG LIST button. The message "S-LIST" appears on display.
3. Press the SEEK button to locate desired track to be deleted.
4. Press and hold the SONG LIST button for more than 4 seconds. After 2 seconds, a beep will be heard followed by 2 beeps and a final beep after 4 seconds. The message "S-LIST EMPTY" appears on the display.

Remote Playback Device

The remote playback device is either installed at the factory or in some instances it is dealer installed. There are 3 types of remote playback devices, a multi disc remote CD changer, a single disc CD player and a cassette player. All 3 devices have a wiring harness which plugs into the back of the radio. The radio controls and communicates with the remote playback device through an entertainment and comfort (E & C) or Class 2 communication circuit.

Remote CD Changer (CDX)

The remote CD changer allows for multiple compact disks to be played continuously without having to manually change compact discs. Normal size discs may be played using the slots supplied in the magazine. The magazine must first be loaded with discs before it can played. To load CDs, insert the CDs from bottom to top, placing the discs in the magazine label side up. If a disc is loaded label side down, the disc will not play and an error will occur. Care should be used to align and insert the disc into one disc tray only. Repeat this procedure for loading all of the discs in the magazine. Once the discs are loaded into the magazine, push the magazine into the changer in the direction of the arrow marked on the magazine. When the CD magazine is loaded, the changer will begin checking for discs in the magazine. This will continue for up to one and a half minutes, depending on the number of discs loaded. To eject the magazine from the player, push the CD changer door. The door will open. Then press the eject button. NOTICE: If the CD magazine fails to eject after the EJECT button has been pressed, do not attempt to pry the magazine from the CD changer. Whenever a CD magazine with discs is loaded in the changer, the CD changer symbol will appear on the radio display. If the CD changer is checking the magazine for CDs, the CD symbol will flash on the display until the changer is ready to play.

Rear Seat Audio (RSA)

The rear seat audio (RSA) control allows the rear seat passengers to listen to a different music source than the front seat passengers. For example, the rear seat passengers may listen to the cassette or CD through headphones while the driver listens to the radio through the front speakers. The rear seat passengers have control of the volume for each headphone. The primary radio controls always override the RSA controls.

The remote radio control supply voltage circuit, from the radio, supplies voltage to the RSA control when the radio is ON. When the RSA control is turned ON, a voltage signal is sent back to the radio on the RSA enable circuit. After receiving the voltage signal, the radio is enabled to control RSA audio functions. The radio controls RSA functions through the remote radio control signal (RUI2) circuit, some vehicles may use a class 2 communication circuit. When the radio receives the enable signal the rear speakers are muted. This allows the user to listen to the audio through the headphones.

Seek (SEEK)

Press the SEEK button in order to seek to the next higher or lower station. The sound will mute when seeking another frequency. The SEEK button is inactive when the front radio is in the SEEK mode.

Power (PWR)

Press the PWR push button in order to turn the rear seat audio system ON or OFF. The rear speakers mute when the power is turned ON. The rear seat audio functions are operable even when the primary radio power is OFF.

Band Switching (AM/FM)

Press the AM/FM push button in order to select between (AM and FM) or (AM, FM1 and FM2) for radios with 2 FM bands. The selection appears on the display. If the front passengers are already listening to AM-FM, the rear seat audio controller will not switch between the bands and cannot change the frequency.

Source Switching (TAPE CD)

Press the TAPE CD push button in order to activate the source switching feature. There must be a cassette tape and/or compact disc in the player.

Preset Program (P.SET PROG)

Press the P.SET PROG button in order to select between pre-programmed station presets. The front passenger must be listening to something different for the P.SET PROG to operate.

Volume (VOL)

Rotate the volume control in order to increase or decrease the volume. The top VOL knob controls the top headphone and the bottom VOL knob controls the bottom headphone.

Radio Data System (RDS)

All uplevel audio systems are equipped with technology known as the radio data system (RDS). RDS is a system that sends data along with the audio of the FM station you are currently tuned to. RDS is a standard that defines how a FM broadcast station may send digital data along with the audio program. Think of it as a one-way wireless modem, allowing the broadcaster to send information about his program to your receiver.

RDS data is carried in what is known as a "subcarrier". A subcarrier is a frequency that the FM broadcaster is authorized to use to send data or other audio programs that are not audible in the main audio program. RDS information can be used to display program information and to control the radio.

To receive the RDS signal, all that is needed is an FM receiver with a RDS circuit. A special integrated circuit capable of dealing with the RDS signal is in the RDS circuit and passes it along to the receiver's microprocessor where it is decoded and acted upon.

In some cases, a radio station broadcasting incorrect information may cause the RDS features of the radio to appear to work improperly.

RDS Basic Information

1. RDS functions are provided in the FM broadcast band only.
2. RDS functions will only work with FM broadcast stations that are broadcasting RDS data.
3. Not all FM Broadcast stations broadcast RDS data or offer all of the RDS services.
4. RDS functions may not work properly when reception is weak, reception is of poor quality, or RDS is not implemented properly by the FM Broadcaster.

Displaying RDS Information

The RDS feature is always on. When tuned to a non-RDS station, the radio will display frequency information as you would normally expect. When tuned to a RDS station, the radio can operate as follows

1. The radio will change from displaying the frequency of the FM station to displaying the call letters of the station or display the nickname of the station.
2. Display the type of program.
3. Display general information such as artist and song title, call in phone numbers, etc.

Viewing and Selecting RDS Information for Display

Press the TUNE knob once for less then 2 seconds when the radio displays the program service (PS) name and the frequency of the station will be displayed. Press the knob again, and the program type (P-Type) will be displayed. Pressed again, and the program type (PTY) name will be displayed, if the broadcaster is broadcasting one. The PTY name is an 8-character name that the broadcaster may use to further identify the type of programming currently being broadcast. Should you decide that Frequency, P-Type or PTY name is more desirable to display when tuned to an RDS station than the PS name, press the TUNE knob until the desired information is displayed, then press and hold for more than 2 seconds. A beep should be heard and the radio will now display the selected information whenever tuned to an RDS broadcaster. The radio will display frequency for all non-RDS broadcast stations.

Using RDS Program Types to Tune Radio

Listed are several ways on how to tune your radio using RDS program types.

The radio will now be configured to tune based on RDS data rather than frequency.

A Fast Way to Find a RDS Station In Your Listening Area

1. Press the PROG TYPE or P-TYPE button, the radio displays the current P-Type to search for.
2. Rotate the TUNE knob until the radio displays "ANY TYPE". Press the PROG TYPE or P-TYPE button again and the radio will now seek the first RDS Broadcaster of any kind that it can find in the FM band.

Finding a RDS Station By Specific Program Type

1. Press the PROG TYPE or P-TYPE button, the radio will display the current P-Type to search for.
2. Rotate the TUNE knob until the desired program type is shown in the display.
3. Press the PROG TYPE or P-TYPE button and the radio will now seek the first RDS Broadcaster of the selected P-Type.

If the radio cannot find the desired P-Type, the radio displays "NONE" and will return to the last station you were listening to.

Using the INFO Feature

When the INFO icon appears in the radio display, a new text message is available for viewing. These text messages are from the RDS broadcaster to the listening public and may be general information such as artist and song title, call in phone numbers, etc.

How to view the INFO message

1. To view the message when the INFO icon appears, press the INFO button to display the text message. If you do not press the INFO button again, the text message will automatically be displayed 8 characters at a time, 3 seconds between updates.
2. To view the text message faster, press the INFO button for less than 1 second to scroll through the message at your own speed.
3. The INFO icon disappears as soon as you press the INFO button. The INFO icon will appear when a new different message is received.
4. To view the most recent received message, press the INFO icon at any time even if the icon does not appear in the display.

Controlling the Radio

RDS can control the radio when data the receiver can use responds to timely information performing the following

1. Interrupt the playback of your cassette or CD for traffic or emergency bulletins.
2. Search for stations by type of program.
3. Automatically follow networked programming from transmitter to transmitter as you travel from one listening area to another.
4. Set your clock to the time that the RDS broadcast station broadcasts.

Using the RDS Traffic Feature

Some RDS broadcasters may carry traffic information programming to inform you of current traffic conditions in your listening area and is indicated by the TRAF icon in the radio display. RDS enables the broadcaster to get this information to you even when you are listening to a tape or compact disc. This feature can be enabled or disabled by the listener. Press the TRAF button to find a station that claims to carry traffic information. You may do this even when playing a cassette tape or compact disc. This action will operate in the background without interrupting the current playback. If the radio is not currently tuned to an RDS traffic station, the radio will immediately seek an RDS traffic station. If the radio finds an RDS traffic station, the "TRAF" icon will appear on the radio display as will brackets around the [TRAF] icon. If the radio cannot find an RDS traffic station after searching through the entire FM band, the radio will display "NO TRAFFIC".

Traffic Interrupt Feature

Whenever the TRAF icon is displayed, the current FM station may also broadcast traffic announcements. Traffic announcements are reports of the current traffic conditions in the listening area of the tuned FM broadcasters.

Your radio can interrupt the playback of a cassette or compact disc by use of the traffic interrupt feature. The traffic interrupt feature is enabled when the TRAF icon is displayed.

If the broadcaster sends out a traffic announcement while you are listening to FM or in the playback mode, "TRAFFIC" will be displayed on the radio and the audio from the broadcaster will be heard. At the conclusion of the traffic announcement, the radio will return to the previous playback mode.

During the time the radio displays "TRAFFIC", you can adjust the volume of the traffic announcement. This will be the volume at which all future traffic announcements will be heard.

You can also interrupt a traffic announcement interrupt by pressing the TRAF button.

RDS Program Type Interrupts

When the program type feature is ON, all program types may be selected as interrupts. Perform the following to select a program type as an interrupt.

1. Turn ON the radio.
2. Select the program type.
3. Press and hold the program type button, labeled PROG TYPE or P-TYPE, for 2 seconds while the program type is displayed.

When an interrupt is set, the display shows the program type followed by an asterisk and the brackets around the [P-TYPE] icon are illuminated.

To turn an interrupt OFF

1. Select a program type marked as an interrupt.
2. Press and hold the program type button, labeled PROG TYPE or P-TYPE, for 2 seconds. The program type will be unmarked by turning OFF the asterisk. If no other program type interrupts are set, the brackets around the [P-TYPE] icon are also turned off.

When a program type interrupt is set, the radio will wait for the current FM RDS station to change its program type to one of those selected as an interrupt. When the station program type changes to a program type interrupt setting then the interrupt is activated. If the radio is in a playback mode, an interrupt will cause the radio to switch to the FM band, display the program type followed by "INT", and adjust the volume to the last active interrupt volume. If the radio is in the FM mode when an interrupt occurs, only the volume will change. The radio resumes the mode that was active prior to the interrupt, when an interrupt ends. An interrupt in progress may be canceled by pressing the program type button or a mode button.

During a national or local emergency, a special program type interrupt message "ALERT!" is displayed. This special announcement will cancel all other RDS features that are in progress, such as a traffic announcement.

Alternate Frequency (AF) Switching

RDS permits broadcaster's to send information to the radio that allows the radio to automatically switch frequency to the best quality station in that broadcaster's network.

Since the radio is displaying the broadcaster call letters or nickname, the listener will not see the frequency during an AF switch unless you have changed the default display to be frequency instead of Program Service name.

To enable or disable AF switching perform the following

1. Press and hold the AM/FM button for 2 seconds or more.
2. The radio will display AF ON or AF OFF depending on the current condition of AF and a confirmation beep will be heard.

When AF is enabled and you recall a RDS station stored on preset, the radio determines if the station stored is of acceptable quality. If not, the radio checks all available AF's for your station. If the radio fails to locate your program, AF SEARCH will be displayed as the radio scans across the band looking for your program or an affiliated network. If the radio cannot find the original station or an acceptable alternate frequency NOT FOUND will be displayed and the radio returns to the original frequency for the preset.

RDS Clock Time

Broadcasters can choose to send clock time information in the RDS data. This information can be used to update the clock time on the radio. RDS clock time is broadcast once a minute. To set the clock using RDS clock data perform the following

1. Press and hold the HR and MIN buttons together for 2 or more seconds to update the time.
2. The display will show UPDATED after receiving the broadcasted time data.
3. If the broadcaster is not broadcasting the time data, the radio will display NO UPDATE and the time remains unchanged.

Steering Wheel and Tailgate Audio Controls

Some audio functions are available using the steering wheel controls and/or tailgate audio controls. The steering wheel and tailgate audio controls are actually a resistor network which consists of multiple momentary contact switches and a series of resistors. The switches and resistor network is arranged so that each switch has a different resistance value. When a switch is pressed, a voltage drop occurs in the resistor network which produces a specific voltage value unique to the switch selected. These specific voltage values allow the radio to identify which switch has been pressed. The radio responds just as if the corresponding radio front panel button had been pressed.

The radio supplies voltage to the switches via the remote radio control supply voltage circuit, RSA/SWC power. The specific voltage signal from the switch is returned to the radio on the steering wheel controls signal circuit, RUI 1.

Tape/CD Player Error Messages

The radio displays an error when any of the following occurs.

1. The radio will display error codes for the tape player and integral CD player.
2. The radio will display the following tape player error codes for tight tape, broken tape, and wrapped tape. If these conditions are detected, the radio will switch to the radio mode and eject the tape. The error code will be displayed for 5 seconds, followed by the tuner display, then the default. E10-Tight tape. E11-Broken tape. E14-Wrapped tape.
3. The radio will display the following integral CD player error codes. If one of these problems is detected, the unit will switch to the radio mode and eject the CD. The display will show TOD, if the unit is OFF, or display the radio frequency for 5 seconds, then the default, if the unit is on. E20-Optics focus error, maybe due to moisture. E21-Optics loss of tracking control, maybe due to blemishes on disc. E22-Load/Unload motor problem. E23-Communication problem.

XM Satellite Radio

XM is a national satellite radio service that offers up to 100 coast to coast channels including music, news, sports, talk and children's programming. XM provides digital quality audio and text information, including song title and artist name. A service fee is required in order to receive the XM service. For more information, contact XM at www.xmradio.com or call 1-800-852-9696.

Digital Radio Receiver

The radio controls communicate with the digital radio receiver via the class 2 communication circuit. The digital radio receiver sends remote radio audio signals to the radio.

Viewing Messages

Press the DISP or RCL button while in XM mode to view various pieces of information related to the current song or channel. By pressing and releasing the DISP or RCL button, you may view four different categories of information: Artist Name/Feature, Song/Program Title, Channel Category, and other Additional Information that may be broadcast on that channel. Additional Information messages may not always be available. If an Additional Information message is being broadcast on the tuned channel, the INFO icon will appear on the display. Each of the four information types may have multiple pages of text. To reach a category, press and release the DISP or RCL button consecutively until the desired type is displayed. If there are multiple pages of text for the selected information type, the radio will automatically display all the pages for that type at a rate of approximately one page every three seconds before timing out and returning to the default display. You may override this feature by pressing the DISP or RCL button to review all of the pages at your own pace.

XM Advisory Messages

Technical Information for MP3 Player (US8)

The US8 radio will play both standard audio CDs and CD-Rs. The CD-Rs may contain standard audio format (*.cda) or compressed audio in the *.mp3 format.

Customers who make their own music CD-Rs should be aware of the following

1. The files can be recorded on a CD-R disc with a maximum capacity of 700 MB.
2. The MP3 files must be recorded onto the disc in either a fixed bit rate (32 kbps, 40 kbps, 48 kbps, 56 kbps, 64 kbps, 80 kbps, 96 kbps, 112 kbps, 128 kbps, 160 kbps, 192 kbps, 224 kbps, 256 kbps, and 320 kbps), or in a variable bit rate.
3. Discs recorded in either one session or in multiple sessions will play. Playlists, such as those created with popular MP3 software, are also supported.
4. ID3 tag information is available during playback, providing the information was recorded with ID3 tags, version 1 or version 2. CD text information is not available with the US8 radio.
5. The radio does not play mixed media CDs (those that contain files in both the *.mp3 and the *.cda format).
6. The radio will not play CD-Rs that contain formats of compressed audio other than *.mp3 (such as *.wma, *.asf, or *.aac).
7. The radio will support a maximum of 50 folders, 50 playlists, 10 sessions, and 255 files. If the information on the disc exceeds these numbers, anything over the maximum allowable will be ignored. Files that are not in the *.mp3 format will not play, but do count toward the maximum number of files.
8. The files or playlists can be arranged in folders, up to 11 layers deep (folders within folders, within folders, etc.). Anything more than 11 layers deep will be ignored.
9. Long names (on files, folders, playlists) or combination of large number of folders and files or playlists may cause player not to be able to read up to the max numbers of folders, playlists, files, or sessions, due to memory limitations. Customers are encouraged to keep shorter names and minimize folder depth for ease of operation.

If these guidelines are not followed, a customer recorded CD may not play. Note that the radio has no ability to record *.mp3 files or any audio to a CD-R, it has only the ability to read information on a CD-R.

Scheme 68

The rear seat entertainment (RSE) system augments the vehicle's in-dash audio system with

1. A Digital Versatile Disc (DVD) player
2. A video display screen
3. Two sets of wireless infrared headphones
4. A remote control and
5. Stereo audio and video inputs in the overhead console for playing an auxiliary device

Scheme 69

DVD Player

The DVD player and the video display screen are located in the overhead console. The DVD player can be controlled by both the buttons on the DVD player and by the buttons on the remote control. The DVD player power may be turned on when the ignition is in the run, accessory, or retained accessory power (RAP) power modes. DVDs are manufactured with different region codes based on the country in which they are sold. Therefore, the RSE system DVD player is only compatible with the region code where the vehicle is sold. The DVD region code is printed on the jacket of most DVDs. The DVD player will also play audio CDs. Home recorded CDs, CD-R or CD-RW formats, will not play in this DVD player.

DVD Player Buttons

The following buttons operate the DVD player.

Playing a Disc

To play a disc, gently insert the disc with the label side up, into the loading slot. The DVD player will continue to load the disc and the player will automatically start if the vehicle ignition is in an enabled power mode. If a disc is already in the player, press the play/pause button on the face of the DVD player or on the remote control. Some DVDs will not allow the user to fast forward or skip the copyright or previews. Some DVDs will automatically begin to play after the previews have finished. If the DVD does not begin to play the main title, refer to the on-screen instructions, and press play on the DVD player buttons or on the remote control.

Stopping and Resuming Play

To stop a disc, press and release the stop/eject button on the DVD player or the remote control. To resume playback, press the play/pause button on the DVD player or the remote control. The movie should resume play from where it was stopped. If the disc has been ejected, or if the stop button has been pressed 2 times, the disc will resume play at the beginning of the main title.

Ejecting the Disc

Press the eject button on the DVD player to eject the disc.

If a disc is ejected from the DVD player but is not removed, the DVD player will reload the disc within 25 to 30 seconds. The disc will then be stored in the DVD player. The DVD player will not resume play of this disc automatically upon its reload.

DVD Messages

The following errors may be displayed on the video screen monitor.

Scheme 70

Parental Control Button

This button is located on the forward part of the DVD console, near the driver of the vehicle. Press this button while media is playing in the DVD player to freeze the video and mute the audio. The video screen will display the message Parental Control ON and the power indicator light on the DVD player will flash at one-second intervals. While in this mode, all other button operations from the remote control and the DVD player, with the exception of the eject function, will be disabled. The driver will then be able to gain the attention of the rear seat passengers. Press this button again to restore normal operation of the DVD player. This button may also be used to turn the DVD power on and automatically resume play of the media within the DVD player if the vehicle is in an enabled power mode.

Video Screen

To use the video screen, push forward on the release latch and the screen will be free to rotate down. Adjust the screen's position as desired. The display menu button will allow different screen display modes, such as normal, full screen, zoom or cinema. When the video screen is not in use, push it up into its latched position.

The DVD player and video screen will continue to operate when the screen is in either the up (closed) or down (viewing) position. The video screen contains the infrared transmitters for the wireless headphones as well as the infrared receiver for the remote control. Therefore, if the screen is in the closed position the infrared signals will not be available for the operation of the headphones and the remote control.

Avoid directly touching the video screen, as damage may occur.

Remote Control

To use the remote control, aim it at the infrared window below the video screen and press the desired remote control button. Direct sunlight or very bright light may affect the ability of the entertainment system to receive signals from the remote control. If the remote control does not seem to be working, the batteries may need to be replaced. Objects blocking the line of sight may affect the function of the remote control.

Battery Replacement

To change the batteries, do the following

1. Remove the battery compartment door located on the bottom of the remote control.
2. Remove the batteries from the compartment.
3. Replace the 2 AA-size batteries in the proper orientation.

If the remote control is to be stored for a long period of time, remove the batteries and keep them in a cool, dry place. Do not store the remote control in heat or direct sunlight. This could damage the remote control and would not be covered by your vehicle warranty. Keep the remote control stored in a cool, dry place.

Wireless Headphones

The RSE system includes 2 sets of wireless infrared headphones.

Each set of headphones has an ON/OFF control. To use the headphones activate the ON/OFF control. A red indicator light will illuminate on the headphones. If the light does not illuminate, the batteries may need to be replaced. See Battery Replacement in this section for more information. To turn the headphones OFF activate the ON/OFF control once again.

Each set of headphones has a rotary volume control. To adjust the volume, adjust this control. The headphones will automatically turn OFF if they lose the infrared signal from the system for approximately 4 minutes in order to preserve their battery power. The signal may be lost if the system is turned off or if the headphones are out of range of the infrared signal transmitters that are located below the video display screen.

To change the batteries, do the following

1. Loosen the screw on the battery compartment door located on the LEFT headphone earpiece.
2. Remove the batteries from the compartment.
3. Replace the 2 AAA-size batteries in the proper orientation.

If the headphones are to be stored for a long period of time, remove the batteries and keep them in a cool, dry place. Do not store the headphones in heat or direct sunlight. This could damage the headphones and would not be covered by your vehicle warranty. Keep the headphones stored in a cool, dry place.

Stereo RCA Jacks

The RCA jacks are located on the forward portion of the overhead console next to the parental control button. The RCA jacks allow you to connect audio and video from an auxiliary device such as a camcorder or a video game player to your RSE system just as you would to a standard television. Standard RCA cables are needed to connect the auxiliary device to the RCA jacks. The yellow connector transmits video while the red and white connectors transmit right and left stereo audio respectively. Please refer to the manufacturer's instructions for proper connection of your auxiliary device.

To use the auxiliary inputs on the RSE system, connect an external auxiliary device to the color-coded RCA jacks and turn both the auxiliary device and the RSE system power on. If the RSE system had been previously in the DVD player mode, the user will need to press the SRCE button on the faceplate or remote control to change to the auxiliary mode. Successive actuations of the SRCE button will toggle the RSE system between the auxiliary and DVD player modes.

Audio Output

Audio from the RSE system DVD player or auxiliary inputs may be heard through the following possible sources

1. Wireless infrared headphones
2. Vehicle speakers
3. Vehicle wired headphone jacks on rear seat audio controller (if equipped)

The RSE system will always transmit the audio signal by infrared to the wireless headphones, if there is audio available. The RSE system is capable of outputting audio to the vehicle speakers by pressing the CD button on the vehicle's radio. The RSE system may be selected as an audio source on the radio if the RSE system power is on. Once the RSE system is selected as an audio source on the radio you may adjust the speaker volume on the radio to control the volume of the audio to the speakers. If the RSE system power is not on, the RSE system will not be an available source on the radio head unit. Please refer to the operating instructions for the vehicle radio for more information on its operation.

The RSE system is capable of outputting audio to the wired headphone jacks on the rear seat audio controller if the vehicle is so equipped. The RSE system may be selected as an audio source on the Rear Seat Audio controller if the RSE system power is on. Please refer to the operating instructions for the Rear Seat Audio Controller for more information on its operation.

See also:
• Scan Tool Does Not Power Up
• Power Mode Mismatch
• Diagnostic Trouble Code (DTC) List
• Diagnostic Trouble Code (DTC) List
• Testing for Intermittent Conditions and Poor Connections
• Circuit Testing
• Wiring Repairs
• Connector Repairs
• Checking Aftermarket Accessories
• Diagnostic System Check - Engine Electrical
• SIR Caution
• SIR Disabling and Enabling Zone 3
• Steering Wheel Control Switch Assembly Replacement
• Trim Plate Replacement - Instrument Panel (I/P) Accessory (Aztek)
• Fastener Notice
• Headliner Replacement (Rendezvous)
• Trim Panel Replacement - Side Front Door (Aztek)
• Diagnostic System Check - Entertainment System
• Symptoms - Entertainment
• Diagnostic Trouble Code (DTC) List
• Radio Setup
• Entertainment Connector End Views
• Digital Radio Receiver Setup
• Radio/Audio System Description and Operation
• Digital Radio Poor or No Reception
• Audio Distortion - One or More Speakers
• Audio Too Loud at Low Settings
• Radio Controls Inoperative - Rear Seat
• Rear Seat Audio Power Indicator Always On
• Tape Player Weak, Slow, or Garbled Output
• Steering Wheel Controls Inoperative
• Tailgate Audio Controls Inoperative
• Speakers Inoperative - One or More
• Radio Audio Inoperative at Rear Seat Audio (RSA) Control
• Audio System Troubleshooting Hints
• Antenna Cable Replacement
• Speaker Replacement Reference
• DVD Player Replacement
