N52 VALVETRONIC - E60, E61, E63, E64, E65, E66, E90, E91

The Valvetronic consists of fully variable control of the valve lift combined with the variable camshaft control unit (VANOS).

As of the N52 engine, the 6-cylinder petrol engine is equipped with Valvetronic. The advantages this technology are

1. Enhancement Of Engine Dynamics
2. Improvement In The Emission Values

Scheme 13

Scheme 14

The fully variable valve lift timing is implemented with the following components

1. Electric Servomotor
2. Eccentric Shaft
3. Intermediate Lever
4. Return Spring
5. Roller Cam Follower

The actuator motor is fitted above the camshafts in the cylinder head. The actuator motor adjusts the eccentric shaft. The worm shaft of the electric motor engages in the work gear attached to the eccentric shaft. After adjustment, the eccentric shaft does not have to be locked in any special way, as the worm gear has an adequate self-regulation system. The eccentric shaft adjusts the valve lift on the inlet side. The intermediate lever changes the transmission coefficient between the camshaft and roller cam follower. In the full load position, the valve lift and opening duration are at the maximum. In the idle position, the valve lift and opening duration are at the minimum. The roller cam followers and associated intermediate levers are split into 4 groups. To this end, an ID code is stamped in the components. Each pair always has the same class. The assignment of the roller cam followers and intermediate levers ensures that the cylinders are evenly filled, even with minimum lift.

Advance

In the lower range of motion of the valves, the possibility for harmonisation by means of so-called advance is supported. The inlet valves of a cylinder are opened synchronously up to a lift of 0.2 mm. As of this lift, valve 1 begins to advance. Valve 2 opens with a slight delay a little later. Valve 2 catches up with valve 1 with a stroke of approx. 6 mm. From then on, they open synchronously. These response characteristics favour the gas mixture flowing into the cylinders. The cross section of the inlet valve openings has been kept small to achieve a significantly higher flow rate with the intake volume remaining the same. This flow rate is used for better mixing of the intake mixture.

Construction

The DME control unit MSV70 has 2 connections.

Scheme 15

Functions

The digital engine electronics MSV70 regulate the following functions

1. Ignition Control Unit
2. Control Of The Injection System
3. Control Of The Valvetronic
4. Control Of The Engine Temperature
5. Control Of The Electrical Coolant Pump
6. Knock Control
7. Lambda Control System
8. Control Of The Tank Ventilation
9. Control Of The Air-Conditioning Compressor Via The IHKA Control Unit
10. Control Of The Differential Air Intake Control (DISA)
11. Electrical Air Flap Control
12. Control Of The Electrical Fuel Pump
13. Cruise Control System
14. Control Of The Alternator
15. Activation Of The Engine Breather
16. Registering The Engine Oil Quality And Oil Level
17. Power Management
18. Signal Evaluation And Calculation Of Substitute Program And Emergency Running
19. Self-Diagnosis

N52 ELECTRICAL COOLANT PUMP - E60, E61, E63, E64, E65, E66, E90, E91

Fast heating-up of the engine after a cold start significantly lowers fuel consumption and helps comply with exhaust threshold values.

High engine temperatures after stopping the engine can lead to a reduction in the engine service life. These function requirements can only be implemented with conventional cooling concepts with a high level of overhead and a great many compromises.

An electrically driven water pump delivers exactly the amount of coolant required in each operating condition. A low coolant flow volume with a cold engine enables rapid warm-up. Pumping after stopping the engine leads to a significant reduction in the engine temperature in the engine's afterheating phase.

Scheme 16

How it works

The coolant pump of the N52 engine is an electrically driven pump. The power output of the electric motor is controlled electronically by control electronics.

These control electronics are connected to the Digital Engine Electronics (DME) across the bit-serial data interface. The DME uses the load, the operating range and the data from the temperature sensors to determine the required cooling output. The DME provides the control electronics with the corresponding control signals to control the coolant pump.

The motor of the coolant pump is rinsed with coolant. This lubricates the bearings of the electrical coolant pump.

N52 ENGINE BLOCK - E60, E61, E63, E64, E65, E66, E90, E91

The 6-cylinder engine is available with a number of different power outputs. Depending on the type or national version, the cylinder capacity and power output are adapted.

Scheme 17

Scheme 18

1. Crankcase, upper section
2. Bedplate

Magnesium cannot be used in certain areas, for example in the cylinder bushes. This is why the crankcase is of composite design. The aluminium-silicon insert holds the bolt connections to the gearbox, cylinder head and crankshaft bearings as well as to the cooling ducts. This means that the magnesium cannot come into contact with the coolant and the water it contains.

Scheme 19

1. Aluminium-silicon alloy insert in crankcase
2. Magnesium-aluminium alloy crankcase

The crankcase consists of an aluminium-silicon insert, inseparably and seamlessly cast in with a magnesium alloy. This magnesium alloy has been developed by BMW.

Bedplate

A split crankcase is used in the N52. The upper part consists of a magnesium-aluminium composite construction. To increase the rigidity, the lower part has been designed as a bedplate. This bedplate is also made of magnesium. To hold the main mounting forces, inserts made of sintered steel are used.

Scheme 20

Scheme 21

Scheme 22

The actuator forms a unit with the drive. The actuator is driven by an electric motor and gearing. The control electronics are integrated in the DISA actuator motor. The DME controls the DISA actuator motor by means of a pulse-modulated signal. There are only 2 possible positions. The actuator can be closed or opened. When activated, the actuator moves the flap to each end position.

Depending on the engine concerned, engines are fitted with the following number of DISA actuator motors

1. N52 engine with 2 DISA actuator motors
2. N52 engine with 1 DISA actuator motor
3. N52 engine without a DISA actuator motor

The power and dynamics of an engine depend heavily on the quality of the cylinder filling. The intake air mass oscillates due to the piston motion. These oscillations are overlapped in turn by oscillations from pressure peaks.

To guarantee optimum air intake, the N52 engine has a three-stage differentiated air intake system (DISA).

The air intake guide is realised by a switchover mechanism in the inlet pipe with two DISA actuator motors and an overshoot pipe in the intake area.

The DISA actuator motors are each driven by an electric motor. The two DISA actuator motors are of different sizes.

DISA actuator motor 2 is fitted in the overshoot pipe and DISA actuator motor 1 is fitted in the collector for intake air in front of the resonating pipe.

1st Stage - Idling/Lower Engine Speed Range

At idle speed and in the lower engine speed range, the DISA actuator motors 1 and 2 are closed.

The intake air flows past the throttle valve into the resonance pipe. In the resonance pipe, the intake air mass splits. The air is fed via the collector pipe and resonating pipes into the individual cylinders. In this way, three cylinders are provided with a comparably high air mass.

Scheme 23

2nd Stage - Medium Engine Speed Range

In the medium engine speed range, DISA actuator motor 2 is opened.

In this case, it is assumed that the inlet valves of the first cylinder are just closing. The gas motion creates a pressure peak at the closing inlet valves. This pressure peak is passed on via the resonating and collector pipes to the in next cylinder in the firing order. This improves the filling of the next cylinder to be charged.

Scheme 24

3rd Stage - Upper Engine Speed Range

In the upper engine speed range, both DISA actuator motors are opened.

In this case, it is assumed that the inlet valves of the first cylinder are just closing. The gas motion creates a pressure peak in front of the closing inlet valves. The intake air mass is now fed via the resonating, overshoot and collector pipes.

Scheme 25

Scheme 26

The oil condition sensor consists of two cylinder capacitors arranged one above the other. The engine oil quality is measured by the lower, smaller capacitor.

Two metal tubes are arranged one inside the other as capacitor electrodes. The engine oil is located between the electrodes as an electrical non-conductor (insulator). The electrical material property of the engine oil changes with increasing wear and dissipation of the fuel additive. The changed electrical material properties of the engine oil change the capacitance of the capacitor. This capacitance value is processed in the integrated electronic evaluation unit into a digital signal. The digital sensor signal is passed on as an indication of the engine oil quality to the digital engine electronics (DME). This actual value is processed in the DME to calculate the next engine oil service.

The oil level is determined in the top of the sensor. This part of the sensor is located at the height of the oil level in the oil pan. As the oil level falls, the capacitance of the capacitor falls accordingly. This capacitance value is processed by the electronic evaluation unit into a digital signal and also sent to the DME.

A temperature sensor has been fitted to the electronic evaluation unit to measure the engine oil temperature.

The oil level, engine oil temperature and engine oil quality are measured continuously from ignition ON.

N52 ENGINE, OIL PUMP - E60, E61, E63, E64, E65, E66, E90, E91

The oil pump must ensure reliable oil supply under all operating conditions. The N52 engine has a volume-flow-regulated oil pump. This pump only delivers exactly as much oil as each operating range of the engine requires.

The oil pump in the N52 engine is a pendulum slide cell pump.

Scheme 27

The oil pump is driven by a chain from the crankshaft. The oil pressure generated affects the control piston with oblique thrust surface (hinged bracket) against the force of a compression spring. The hinged bracket varies the location of the pendulum slide. If the pump shaft is located centrally on the pendulum slide, changes in volume and the delivery capacity will be small. If the pump shaft is located away from the middle, changes in volume and the delivery capacity will be larger. If the oil requirement of the engine rises, the pressure in the lubricating system falls and thus also at the control piston. The pump increases the delivery volume and restores the pressure conditions. If the oil requirement of the engine falls, the pump regulates a low delivery volume towards zero delivery accordingly.

Scheme 28

Scheme 29

SYSTEM FUNCTIONS

The following system functions are described

1. Volume-Flow-Regulated Oil Supply
2. Oil Level Check, Engine Oil Quality Check And Engine Oil Temperature Check
3. Valvetronic
4. Heat Management

Volume-Flow-Regulated Oil Supply

The N52 has a volume-flow-regulated oil pump. This pump only delivers as much oil as each operating range of the engine requires. A conventional oil pump would have to be approximately three times the size of that in the N52 engine. This oil pump would also require more driving power accordingly.

No superfluous oil is supplied for ranges with a smaller load. The fuel consumption of the engine is reduced and wear to the oil is slowed down. A pendulum slide cell pump is used. The pump shaft is located off-centre in the housing during pump activation. The impeller shifts radially during rotation. This means that the chambers on the impeller form different volumes. The oil is taken into the enlarging volume. The oil is pumped into the oil ducts at the reducing volume.

Oil Level Check, Engine Oil Quality Check And Engine Oil Temperature Check

The oil level is measured by the oil condition sensor and shown in the Central Information Display (CID). This protects the engine from excessively low oil level and the associated engine damage. Excessive oil filling of the engine, which can lead to leaks, is displayed as a Check Control message.

The oil condition sensor also registers the engine oil quality. This means that the system is able to compute exactly when it is necessary to change the engine oil.

Condition Based Service (CBS) allows the engine oil to be changed in line with needs.

The engine oil temperature is also detected or calculated by the oil condition sensor. The signal of the oil condition sensor is evaluated in the DME. The evaluated signal is then sent across the PT-CAN to the safety and gateway module (SGM). From the SGM, the signal is sent across the K-CAN to the instrument cluster and to the CID.

Valvetronic

The Valvetronic consists of fully variable control of the valve lift combined with the variable camshaft control unit (VANOS).

The valve lift is only regulated on the inlet side, but the camshaft is also adjusted on the exhaust side. Valvetronic is controlled by

1. A Variable Valve Lift Of The Inlet Valve
2. A Variable Opening Duration Of The Inlet Valve
3. A Variable Camshaft Control Of The Inlet And Exhaust Camshaft (Double VANOs)

The system is optimised by adapting the valve gear, changing the actuator motor and varying the camshaft timing control. Major innovations are

1. On the intermediate lever, the plain bearing to the eccentric shaft has been replaced by a roller bearing. This reduces the friction in the valve gear.
2. The guide of the intermediate lever is more precise. Only one spring is required to guide and retain the intermediate lever.
3. The moved mass of the valve gear has been reduced by 13%.
4. The range of motion of the inlet valves has been improved. The maximum lift has risen to 9.9 mm, but above all the minimum lift has been further reduced to 0.18 mm.

Heat Management

The possibilities of conventional cooling systems are used for the cooling system with electrical coolant pump.

The following components are influenced by the heat management

1. Electrical coolant pump
2. Map thermostat
3. Digital engine electronics (DME)

The cooling output of the system is adapted by means of a freely variable volumetric flow of the coolant.

The heat management determines the current cooling requirement and regulates the cooling system accordingly. If necessary, the coolant pump can even be switched off altogether, for example to heat up the coolant quickly during the warm-up phase.

If the engine is not running but very hot, the coolant pump will also work while the vehicle is out of use. Cooling output can thus be called up regardless of engine speed.

The heat management now permits various characteristic maps to be used as a basis for controlling the coolant pump, over and above the map thermostat. In this way, the engine control unit can adapt the engine temperature to the driving characteristics.

The engine control unit regulates the following temperature ranges

1. 112 °C = Economy
2. 105 °C = Normal
3. 95 °C = High
4. 80 C = High and regulation by the map thermostat

If the vehicle handling causes the engine control unit to detect the economical operating range Economy, the DME regulates to a higher temperature (112 C).

In this temperature range, the engine is operated with a relatively fuel requirement. The friction inside the engine is reduced at higher temperature. The temperature increase thus favours lower fuel consumption in the low load range.

In the High and regulation by the map thermostat mode, the driver wants to use optimised power output development of the engine. To achieve this, the temperature in the cylinder head is lowered to 80 °C. This lowering leads to a better cylinder filling, which leads in turn to an increase in engine torque. The engine control unit can now regulate a certain operating range, adapted to the relevant driving situation. This makes it possible to use the cooling system to influence consumption and performance.

Notes for service staff

Service staff should note the following points

1. General information: Refer to «N52 ENGINE, GENERAL INFORMATION FOR SERVICE: E60, E61, E63, E64, E65, E66, E87, E90, E91»(ref-202154-S06932624872006030900000) .
2. Diagnosis: N/A
3. Encoding/programming: N/A
4. Car & Key Memory: N/A

E90, E91: Almost all Car & Key Memory functions are programmed inside the vehicle itself. (See Personal Profile in the Owner's Handbook: Individual settings for up to 3 remote controls via the display in the instrument cluster or via the Central Information Display)

Subject to alteration due to misprints, errors and technical modifications.

Special Factors When Handling Magnesium

Alongside the outstanding properties of magnesium and its alloys, a number of precautionary measures must be borne in mind. The work with magnesium that crops up most frequently in Service is not critical. The low amount of chips, e.g. when recutting threads, requires no special precautionary measures. However, if components made of magnesium are treated intensively, the prescribed security measures must be adhered to without fail.

Wet Processing

With respect to their material properties, magnesium alloys are well suited to dry processing. However, today wet processing is state of the art. Either cutting oil or emulsion is employed here. The greatest accident danger when cutting/machining comes from the chips. Dried chips are particularly dangerous. Chips damp with oil are very difficult to ignite. Direct ignition of the chips is unlikely during wet processing. Magnesium and water can react. In this reaction, magnesium hydroxide and hydrogen are formed. During wet processing, there is a danger of hydrogen explosions if the continuously forming hydrogen is able to collect anywhere and a critical concentration is reached. This means that the humidity in the container for chips can escape. In addition, chips must be transported out of the emulsion very quickly, as otherwise hardening occurs and the emulsion becomes useless.

Dry Processing

As a general principle, work on magnesium that forms dust must not be carried out without a suitable extraction facility. Solid components are without difficulty from a safety point of view. Even with strong influence of high temperatures, they are practically impossible to ignite. Chips and powder, on the other hand, are significantly more reactive. The critical temperature at which dry, fine chippings can ignite is approximately 450-500 °C. Incorrect cutting geometry or blunt tools can cause such high temperatures during dry processing. The formation of sparks due to tools knocking together or when processing steel is another accident danger.

Notes On Handling Aluminium Screws

Aluminium screws are indicated by blue screw heads. As a general principle, aluminium screws may only be used once. This means that the screws must be replaced every time they are removed.

Due to the low tensile strength of aluminium, aluminium screws must be tightened according to a precisely specified method. Initially, the screw is tightened to a specified torque. This has been selected in such a way that the parts to be bolted have not more play. Then the screw is turned at a specified angle. This achieves the required tension for the screw.

Notes On Handling Magnesium Screws

The metals iron (Fe) and magnesium (Mg) are chemically very different. This difference creates electrical voltage between the two metals. This voltage accelerates electrochemical corrosion.

This corrosion can be avoided by having

1. Absolutely dry contact surfaces.
2. Contact surfaces that are not wet with conducting engine oil.

Keep screw connections and contact surfaces dry. When screw/bolt connections are opened, the threaded holes must immediately be blown dry to prevent corrosion due to the coolant.

Contact corrosion between the metals can be prevented using a non-conducting seal or gasket. The oil pan gasket and cylinder head gasket are non-conducting. These gaskets separate the oil pan and cylinder head made of aluminium from the crankcase made of magnesium.

Scheme 30
