11 00 670 Securing engine in installation position (N52)
Special tools required
- 00 0 200
- 00 0 202
- 00 0 204
- 00 0 208
- 11 0 000
| WARNING | Danger of injury! Observe following instructions relating to special tool: Prior to each use, check the special tools for defects, modifications and operational reliability. Damaged/modified special tools must not be used! No changes or modifications may be made to the special tools! Keep special tools dry, clean and free of grease. |
Necessary preliminary tasks
- Secure «Engine Bonnet/Hood In Service Position»(ref-258097-S30492204132007071700000)
- Remove «cowl panel cover»(ref-258097-S00876277802007071700000)
- «Remove Both Tension Struts From Spring Strut Dome»(ref-258097-S36671123182007071700000)
- Remove «Intake Filter Housing»(ref-258116-S36590924652007071700000)
- Remove ignition coil cover
Assemble cross member 00 0 200 with special tools 00 0 202, 00 0 204, 00 0 208.
Scheme 134
Note. Use towing hook (72 15 8 108 670).
Scheme 135
| IMPORTANT | Avoid a change of engine position in the transverse or longitudinal direction. Always make sure there is sufficient clearance between the engine (or its attachment parts) and the body. |
| IMPORTANT | Risk of damage! With the aid of an assistant and the supports (2), place cross member 00 0 200 on the screw connections of the side panels. |
Screw in towing hook (1) and tighten down to approx. 30 Nm.
Secure special tool 11 0 000 to spindle 00 0 202.
Fit suitable chains to special tool 11 0 000 and attach to towing hook (1) or engine lifting eye.
Scheme 136
| WARNING | Danger of injury! Tighten down all adjusting screws and nuts on cross member 00 0 200. |
Unscrew nuts (1).
Raise engine approx. 10 mm with cross member.
Installation
Replace self-locking nuts.
For tightening torque refer to 22 11 2AZ in 22 11 ENGINE SUSPENSION .
