11 0 000 Engine lifter for removing and installing engines
Minimum set: Mechanical tools
Engine: M10, M47T2, M47TU, M52, M52TU, M54, M56, M60, M62, M67, M70, M73, N52, N62, N62TU, N73, S14, S54, S62, W10, W11
SI number: 113 94(888)
Order number: 11 0 000
Engine lifter for removing and installing engines
Consisting of
1 = 11 0 001 Lifting beam
2 = 11 0 002 Chain, long
3 = 11 0 003 Chain, short
4 = 11 0 009 Shackle (2 x)
Identifying Lifting Beam, Shackle And Chain Long/Short. Scheme 365
11 0 020 Engine hoist for removing and installing engines
Minimum set: Mechanical tools
Engine: M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M47TU, M50, M51, M52, M54, M57, M57D25, M57D30, M57TU, N52, N62, N73, S38, S50B30, S50B32, S50US, S85
SI number: 1 13 94(888)
Order number: 11 0 020
Engine hoist for removing and installing engines
Consisting of
1 = 11 0 021 Lifting beam
2 = 11 0 022 Chain, medium
3 = 11 0 023 Chain, long
4 = 11 0 024 Chain, short
5 = 11 0 029 Shackle (2 x)
Identifying Lifting Beam, Shackle And Chain, Medium. Scheme 366
11 0 070 Engine hoist
Note: For removing and installing engines
Engine: M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47T2, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57T2, M57TU, M60, M62, M62VAN, M67, M67TU, M70, M73, M88, N40, N42, N45, N46, N52, N62, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, S85, W10, W11, W17
SI number: 1 16 96(107)
Order number: 11 0 070
Engine hoist
Consisting of
1 = 11 0 071 Lifting beam
2 = 11 0 072 Carrying chain, long
3 = 11 0 073 Carrying chain, short
4 = 11 0 079 Shackle (2 x)
Identifying Lifting Beam And Carrying Chain, Long/Short. Scheme 367
11 0 240 Coupling
In conjunction with: 11 0 222, 11 0 226, 11 0 227, 11 0 225
Note: For adapting test probes to pressure gauge 11 0 162
Engine: All models
Order number: 11 0 240 Coupling
Identifying Coupling (11 0 240). Scheme 368
11 0 290 Holder
Minimum set: Mechanical tools
Note: For removing and installing triangular drive (vacuum pump) on crankcase.
Engine: N51, N52, N53, N54
SI number: 1 17 04(130)
Order number: 11 0 290
Holder
Identifying Holder (11 0 290). Scheme 369
11 0 300 Plug mandrel
Minimum set: Mechanical tools
Note: For locking flywheel in TDC position
Engine: N51, N52, N53, N54
SI number: 1 17 04 (130)
Order number: 11 0 300
Plug mandrel
Identifying Plug Mandrel (11 0 300). Scheme 370
11 1 310 Drift
Note: For driving needle bearing out of crankcase (M20) and pressing out propeller shaft centering mount
Series: E28, E30, E38, E39, E46, E52, E65, E66, E70, E81, E85, E87, E90, E91, E92, RR1
Order number: 11 1 310
Drift
Identifying Drift (11 1 310). Scheme 371
11 1 480 Pliers
Minimum set: Mechanical tools
Note: For removing valve stem seal
Engine: M40, M41, M42, M43, M44, M50, M51, M52, M52TU, M54, M56, M60, M62, M70, M73, N12, N14, N45, N52, N53, N54, S38, S50B30, S50B32, S50US, S52US, S54, S62, W10, W11
Storage location: A10, B10
SI number: 1 01 93 (621)
Order number: 11 1 480
Pliers
Identifying Pliers Teeth (11 1 480). Scheme 372
11 2 030 Drift
Minimum set: Mechanical tools
In conjunction with: 00 5 500
Note: For driving the guide bearing into the crankshaft (S14, S38, M10, M20, M21, M30, M40, M42, M50, M51 M52) and driving the centering support into the propeller shaft
Series: E28, E30, E32, E34, E36, E38, E39, E46, E52, E65, E66, E70, E81, E85, E87, E90, E92, RR1
Storage location: A28
Order number: 11 2 030
Drift
Identifying Drift (11 2 030). Scheme 373
11 3 340 Locking pin (2)
Minimum set: Mechanical tools
Note: For locking chain tensioner piston in position (e.g. when removing and installing cylinder head) as well as for locking drive belt tensioner
Engine: M41, M43, M44, M47, M47T2, M47TU, M51, M57, M57T2, M57TU, M62, N40, N42, N45, N46, N47, N51, N52, N53, N54, N62, N73
Storage location: A13
SI number: 1 09 91(416)
Order number: 113 340
Locking pin (2)
Identifying Locking Pin (11 3 340). Scheme 374
11 4 050 Reducer
Minimum set: Mechanical tools
In conjunction with: 13 3 063 or 13 6 051
Note: For connection of pipe bend 13 6 054 to pressure gauge 13 3 061 or BMW DIS for checking oil pressure
Engine: M10, M20, M21, M30, M47, M47T2, M47TU, M50, M51, M52, M54, M56, M57, M57T2, M57TU, M60, M62, M70, M73, N52, N53, N54, N62, N73, S14, S38, S50B30, S50B32, S62
Storage location: B9
Order number: 114 050
Reducer
Identifying Reducer (11 4 050). Scheme 375
11 4 120 Locking pin
Minimum set: Mechanical tools
Note: For chain tensioner to lock chain tensioner piston in position (e.g. when removing and installing cylinder head)
Engine: M43, N51, N52, N53, N54
Storage location: C12
SI number: 112 93(701)
Order number: 11 4 120
Locking pin
Identifying Locking Pin (11 4 120). Scheme 376
11 4 180 Screwdriver socket Torx T60
Minimum set: Mechanical tools
Note: For releasing and tightening dual-mass flywheel - model year: from Jan 94
Engine: M60, M62, N52, N53, N54, S62, S85
Storage location: B8
SI number: 1 02 94 (777)
Order number: 11 4 180
Screwdriver socket Torx T60
Identifying Screwdriver Socket Torx T60 (11 4 180). Scheme 377
11 4 190 1/4" extension piece
Minimum set: Mechanical tools
In conjunction with: 11 3 390, 00 2 050
Note: M73 For removing and installing pedal travel sensor M60 Pretensioning timing chain E53 Mounting airbag control unit
Series: All models
Storage location: B6
SI number: 1 06 94(801)
Order number: 114 190
1/4" extension piece
Identifying Extension Piece. Scheme 378
11 4 250 Gauge with adapter plate
Minimum set: Mechanical tools
Note: For securing oil spray nozzles.
Engine: N51, N52
SI number: 1 17 04(130)
Order number: 11 4 250
Gauge with adapter plate
Consisting of
1 = 11 4 251 Gauge
2 = 11 4 252 Adapter plate
Identifying Gauge With Adapter Plate. Scheme 379
11 4 260 Box spanner
Note: For removing and installing lambda oxygen sensors.
Engine: N51, N52
SI number: 1 17 04 (130)
Order number: 11 4 260
Box spanner
Identifying Box Spanner (11 4 260). Scheme 380
11 4 280 Gauge
Minimum set: Mechanical tools
Note: For locating camshaft in TDC position.
Engine: N51, N52, N53, N54
SI number: 117 04(130)
Order number: 11 4 280
Gauge
Consisting of
1 = 11 4 281 Gauge
2 = 11 4 282 Adapter
3 = 11 4 283 Bracket
4 = 11 4 284 Set of M6 screws
Note: Engine: N54
Identifying Gauge, Adapter And Bracket. Scheme 381
11 4 290 Gauge
Minimum set: Mechanical tools
Note: For disconnecting camshaft sensor gears.
Engine: N51, N52
SI number: 1 17 04 (130)
Order number: 11 4 290
Gauge
Identifying Gauge (11 4 290). Scheme 382
11 4 370 Pressing fixture
Note: For pressing out sealing compound for bedplate.
Engine: N51, N52, N53, N54, S85
SI number: 1 17 04 (130)
Order number: 11 4 370
Pressing fixture
Identifying Pressing Fixture (11 4 370). Scheme 383
11 4 420 Torx socket T50
Minimum set: Mechanical tools
Note: For removing and installing cylinder head.
Engine: N51, N52, N53, N54
SI number: 1 17 04 (130)
Order number: 11 4 420
Torx socket T50
Identifying Torx Socket T50 (11 4 420). Scheme 384
11 4 430 Seal plugs (2 x)
Minimum set: Mechanical tools
Note: For sealing off oil holes in oil pump.
Engine: N51, N52, N53, N54
SI number: 1 17 04 (130)
Order number: 11 4 430
Seal plugs (2 x)
Identifying Seal Plugs (11 4 430). Scheme 385
11 4 440 Engine support plate
In conjunction with: 00 1 450" 00 2 300
Note: For accommodating engine on assembly stand. Is replaced by 11 8 540.
Engine: N51, N52, N53, N54
SI number: 1 17 04 (130)
Order number: 11 4 440
Engine support plate
Identifying Engine Support Plate (11 4 440). Scheme 386
11 4 450 Locating fixture
Minimum set: Mechanical tools
Note: For locating guide blocks during installation.
Engine: N52
SI number: 1 17 04 (130)
Order number: 11 4 450
Locating fixture
Identifying Fixture (11 4 450). Scheme 387
11 4 460 Locating fixture
Minimum set: Mechanical tools
Note: For locating upper and lower bearing strip when installing exhaust camshaft.
Engine: N51, N52
SI number: 1 17 04 (130)
Order number: 11 4 460
Locating fixture
Consisting of
1 = 11 4 461 Press-down tool, 2nd cylinder
2 = 11 4 462 M7 screws (2 x)
3 = 11 4 463 Thrust pieces (6 x)
Identifying Thrust Pieces And M7 Screws (11 4 460). Scheme 388
11 4 470 Cleaning kit
Minimum set: Mechanical tools
Note: For cleaning sealing surfaces on magnesium crankcase/cylinder head.
Engine: N51, N52, N53, N54
SI number: 1 17 04 (130)
Order number: 11 4 470
Cleaning kit
Consisting of
1 = 11 4 471 Scraper
2 = 11 4 472 Grindstone
Identifying Scraper And Grindstone. Scheme 389
11 4 480 Placement boards (2 x)
Minimum set: Mechanical tools
Note: For storing individual components of cylinder head.
Engine: N12, N14, N51, N52, N53, N54
SI number: 1 17 04 (130)
Order number: 11 4 480
Placement boards (2 x)
Consisting of
1 = 11 4 481 Placement board, inlet side
2 = 11 4 482 Placement board, exhaust side
Identifying Placement Board (11 4 480). Scheme 390
11 5 190 Torx socket T60
Minimum set: Mechanical tools
Note: For removing and installing cylinder head.
Engine: N52
SI number: 1 17 04 (130)
Order number: 11 5 190
Torx socket T60
Identifying Torx Socket T60 (11 5 190). Scheme 391
11 5 200 Spacer ring
Minimum set: Mechanical tools
In conjunction with: 11 9 280 Counterholder
Note: For releasing and tightening down central bolt.
Engine: N52, N53, N54
SI number: 1 17 04 (130)
Order number: 11 5 200
Spacer ring
Consisting of
1 = 11 5 201 Shim
2 = 11 5 202 M8x40mm screws (3 x)
Identifying Shim And Screws (11 5 200). Scheme 392
11 6 240 Mounting sleeve set
Note: For installing piston (dia. 82 mm) with connecting rod in crankcase. Engine: N52 B25
Engine: N52
SI number: 1 02 06 (244)
Order number: 11 6 240
Mounting sleeve set
Consisting of
1 = 11 6 241 Mounting sleeve 82.00 mm
2 = 11 6 242 Mounting sleeve 82.25 mm
Identifying Mounting Sleeve Set (11 6 240). Scheme 393
11 6 260 Mounting sleeves with case
Minimum set: Mechanical tools
Note: For installing pistons of 85 mm diameter (urgently required for pistons with U-Flex ring)
Engine: M43TU, M44, N51, N52, N53, N54
Order number: 11 6 260
Mounting sleeves with case
Consisting of
1 = 11 6 261 Assembly bush
Note: Diameter 85.00 mm
2 = 11 6 262 Assembly bush
Note: Diameter 85.08 mm, repair
3 = 11 6 263 Assembly bush
Note: Diameter 85.25 mm, stage 1
4 = 11 6 264 Assembly bush
Note: Diameter 85.50 mm, stage 2
9 = 11 6 269 Case with foam inlay
Note: For holding assembly bushes, gauge 11 6 270 and lever gauge 11 6 250
Identifying Mounting Sleeves With Case. Scheme 394
11 6 370 Puller
Minimum set: Mechanical tools
Note: For removing valve stem seal
Engine: M47, M47TU, M57, M57TU, N40, N42, N45, N46, N52, N62, N73
Storage location: C35
SI number: 1 06 98 (306)
Order number: 11 6 370
Puller
Identifying Puller (11 6 370). Scheme 395
11 6 380 Bush
Minimum set: Mechanical tools
Note: For fitting valve stem seal
Engine: M47, M47TU, M57, M57T2, M57TU, N12, N14, N40, N42, N45, N46, N52, N53, N54, N62, N73
Storage location: A36
SI number: 1 06 98 (306)
Order number: 11 6 380
Bush
Identifying Bush (11 6 380). Scheme 396
11 8 180 Holder
Minimum set: Mechanical tools
Note: Blocking flywheel when releasing and tightening down central bolts on vibration damper
Engine: M47T2, M47TU, M57T2, M57TU, M67, N51, N52, N53, N54, W17
SI number: 1 12 99 (452)
Order number: 11 8 180
Holder
Consisting of
1 = 11 8 181 Basic body (not shown)
Note: E65/M67, E38/M67 Omitted: replaced by 11 8183
2 = 11 8 182 Locking piece
3 = 11 8 183 Basic body
4 = 11 8 184 Adapter
Note: E65/M67
5 = 11 8 185 Adapter with setting sleeve
Note: E46 M47TU
Identifying Locking Piece, Basic Body And Adapter. Scheme 397
11 8 330 Insertion tool
Minimum set: Mechanical tools
Note: For installing and removing conrod with piston
Engine: N42, N45, N46, N51, N52
Storage location: A47, B47
SI number: 1 02 04 (069)
Order number: 11 8 330
Insertion tool
Identifying Insertion Tool (11 8 330). Scheme 398
11 8 540 Engine support plate
In conjunction with: 00 1 450" 00 2 300
Note: For accommodating engine on assembly stand.
Engine: N52, N53, N54
SI number: 1 20 06 (299)
Order number: 11 8 540
Engine support plate
Consisting of
1 = 11 8 541 Engine take-up
2 = 11 8 542 Set of screws (4 x)
Identifying Engine Take-Up And Screws (11 8 540). Scheme 399
11 9 000 Cylinder head expander tool
Minimum set: Mechanical tools
In conjunction with: Assembly stand 00 1 450
Engine: M10, M20, M20B25, M20B27, M21, M30, M30B34, M30Tur, M40, M41, M42, M43, M43TU, M44, M47, M47TU, M50, M51, M52, M52TU, M54, M56, M57, M57D25, M57D30, M57T2, M57TU, M60, M62, M62VAN, M67, M70, M73, M88, N12, N14, N40, N42, N45, N46, N51, N52, N53, N54, N62, N62TU, N73, S14, S38, S50B30, S50B32, S50US, S52US, S54, S62, S85, W10, W11, W17
Storage location: Single
SI number: 1 03 02 (833)
Order number: 11 9 000
Cylinder head expander tool
Consisting of
1 = 11 9 001 Fixture
2 = 11 9 002 Rod
3 = 11 9 003 Sliding block with M10 thread
4 = 11 9 004 Tab
5 = 11 9 005 Quick tensioner
6 = 11 9 006 Aluminum profile insert
7 = 11 9 007 Slide
Identifying Quick Tensioner, Tab And Slide. Scheme 400
8 = 11 9 008 Profile plastic part
9 = 11 9 009 Lever
10 = 11 9 011 Hook
11 = 11 9 012 Valve spring cage
Note: Engine M41, M51, S50
12 = 11 9 013 Valve spring cage
Note: Engine M43, M73
13 = 11 9 014 Valve spring cage
Note: Engine M44, M52, M54, M56, M62, S52, S54, S62
14 = 11 9 015 Valve spring cage
Note: Engine M47, M47TU, M57, M57TU, N40, N42, N62, N73
15 = 11 9016 Valve spring cage
Note: Engine M21, M40
16 = 11 8 421 Valve spring cage
Note: Engine: W10, W11, W17
17 = 11 9 017 Valve spring cage
Note: Engine N52
11 9 180 Installer
Minimum set: Mechanical tools
Note: For RSS into engine block at rear
Engine: N40, N42, N45, N46, N52, N53, N54
Storage location: C43
SI number: 1 01 01(662)
Order number: 11 9 180
Installer
Consisting of
1 = 11 9 181 Bushing
2 = 11 9 182 Thrust piece
3 = 11 9 183 Nut
4 = 11 9 184 Screws (2 x)
Identifying Thrust Piece, Bushing And Screws. Scheme 401
11 9 200 Puller
Minimum set: Mechanical tools
Note: For RSS out of engine block at rear
Engine: N40, N42, N45, N46, N52, N53, N54
Storage location: C43
SI number: 1 01 01(662)
Order number: 11 9 200
Puller
Identifying Puller (11 9 200). Scheme 402
11 9 220 Puller
Minimum set: Mechanical tools
Note: For RSS out of engine block at front
Engine: N40, N42, N45, N46, N52, N53, N54
Storage location: C43
SI number: 1 01 01(662)
Order number: 11 9 220
Puller
Consisting of
1 = 11 9 221 Thrust piece
In conjunction with
2 = 11 9 222 Screw
3 = 11 9 223 Screws (6 x)
4 = 11 9 224 Screws (3 x)
Identifying Thrust Piece And Screw. Scheme 403
11 9 230 Installer
Minimum set: Mechanical tools
Note: For RSS into engine block at front
Engine: N40, N42, N45, N46, N51, N52, N53, N54
Storage location: C43
SI number: 1 01 01(662)
Order number: 11 9 230
Installer
Consisting of
1 = 11 9 231 Bushing
2 = 11 9 232 Spindle
3 = 11 9 233 Nut
4 = 11 9 234 Screws (3 x)
Identifying Bushing, Spindle And Screws. Scheme 404
11 9 240 Oil filter wrench
Minimum set: Mechanical tools
Note: For unfastening and tightening oil filter cap
Engine: N40, N42, N45, N46, N52
Storage location: A43
SI number: 1 01 01 (662)
Order number: 11 9 240
Oil filter wrench
Identifying Oil Filter Wrench. Scheme 405
11 9 260 Counter support with screw connection
Minimum set: Mechanical tools
Note: For locking flywheel with transmission removed
Engine: M47TU, M54, M57T2, M57TU, N40, N42, N45, N46, N51, N52, N53, N54, N62, N73, S85, W17
Storage location: A45, B43, C44
SI number: 1 01 01 (662)
Order number: 11 9 260
Counter support with screw connection
Consisting of
1 = 11 9 261 Counterholder, individual
2 = 11 9 262 Bolt (M10 thread) with washer
Note: For bolting down counterholder
3 = 11 9 263 Sleeve for counterholder
Note: For counterholder for locking flywheel with transmission removed engine: N62, N73
4 = 11 9 264 Bolt (M12 thread)
Note: For counterholder for locking flywheel with transmission removed
5 = 11 9 265 Sleeve
6 = 11 9 266 Sleeve
Identifying Counterholder, Sleeve And Nut. Scheme 406
Note: For counterholder for locking flywheel with transmission removed Engine: M57TU2
11 9 280 Holder
Minimum set: Mechanical tools
Note: For crankshaft when releasing/tightening central bolt
Engine: N12, N14, N40, N42, N45, N46, N52
Storage location: A43, B43, C43
SI number: 1 01 01(662)
Order number: 11 9 280
Holder
Identifying Holder (11 9 280). Scheme 407
11 9 340 Chain tensioner, complete
Minimum set: Mechanical tools
Note: For tensioning timing chain when adjusting timing
Engine: N12, N14, N40, N42, N45, N46, N51, N52, N53, N54
Storage location: B43
SI number: 1 01 01(662)
Order number: 11 9 340
Chain tensioner, complete
Consisting of
1 = 11 9 341 Screw
2 = 11 9 342 Spindle
Identifying Spindle And Screw. Scheme 408
11 9 360 Drift
Minimum set: Mechanical tools
Note: For driving valve into engine block (sealing compound)
Engine: N40, N42, N45, N46, N51, N52, N53, N54, S85
Storage location: A44
SI number: 1 01 01(662)
Order number: 11 9 360
Drift
