35 11 000 Removing and installing mounting block for pedals
Remove panel for pedal assembly. Refer to 51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY .
Remove brake pedal. Refer to 35 21 000 REMOVING AND INSTALLING/REPLACING BRAKE PEDAL .
Installation
Make sure plug connections engage correctly.
Unhook return spring from clutch pedal.
Scheme 72
Press pin ends together and withdraw pin (2).
Release screws (1) from clutch master cylinder.
Remove retaining plate for brake light and clutch switches.
Release nuts (1) and remove bearing block (2).
Scheme 73
Installation
Scheme 74
- Tighten nuts (1) in front of nut (2).
- Tightening torque 35 11 1AZ. Refer to «PEDALS - TIGHTENING TORQUES»(/bmw/z4/e85e86-2002-2005/remont/mechanical-hydraulic/#pedals-tightening-torques) .
35 21 000 REMOVING AND INSTALLING/REPLACING BRAKE PEDAL
Remove trim panel for pedal assembly. Refer to 51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY .
Remove brake light switch. Refer to 61 31 310 REPLACING BRAKE LIGHT SWITCH .
Detach retainers (1).
Scheme 75
Installation
- Use new retainers (1).
Installation
- Use new retainer.
- The retainer must be seated with both legs in the pin groove.
- The workshop supervisor must mark the retainer with a dot of red paint (1) thereby acknowledging correct installation.
Disconnect return spring.
Scheme 76
Pull bearing bushing (1) out of brake pedal and press to left.
Twist brake pedal (2) downwards out of mounting in direction of arrow.
Installation
- Check bearing bushes (1) and replace if necessary.
Lightly grease bearing bushes (1), BMW Service Operating Fluids.
35 31 000 Removing and installing/replacing clutch pedal
Remove trim panel for pedal assembly. Refer to 51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY .
Disconnect return spring.
Scheme 77
Press bolt ends (1) together and remove bolt.
Remove retainer (2) and detach clutch pedal from bearing pedestal.
Installation
- Check bearing bushes (1) and replace if necessary.
Lightly grease bearing bushes (1), BMW Service Operating Fluids.
Replace rubber grommet (2) if necessary.
35 40 001 Removing and installing/replacing accelerator pedal module
Take off cap.
Scheme 78
Unscrew screw.
Pull accelerator pedal module upwards out of fixture.
Installation
Tightening torque 35 40 1AZ. Refer to PEDALS - TIGHTENING TORQUES .
Pull off plug (1).
Scheme 79
Remove accelerator pedal module.
| IMPORTANT | Accelerator pedal module can only be replaced completely with adapter plate. |
