Installation
Oil filter element (3) must snap audibly into place.
Scheme 72
Note. Presentation: without underbody protection and reinforcement plate.
Installation
Replace sealing rings .
Insert screw plug (2) for oil sump and tighten down.
Tightening torque 11 13 1AZ, see OIL SUMP
Insert screw plug (1) for oil filter cap and tighten down.
Tightening torque 11 42 2AZ, see 11 42 OIL FILTER AND PIPES
Note. Pour in engine oil . Start engine and run at idle until oil pressure warning lamp goes out. Turn off engine. Check oil filter cap and screw plugs (1 and 2) for oil filter cap and oil sump for leaks.
Assemble engine.
Checking engine oil level
- Park vehicle on a horizontal surface
- Allow engine at normal operating temperature to run for three minutes with increased revs (approx. 1100 RPM)
- Read off engine oil level in instrument cluster or on Control Display
- Top up engine oil if necessary
11 00 670 Securing engine in installation position (N63)
Special tools required
- 00 0 200
- 00 0 202
- 00 0 204
- 00 0 208
- 00 0 451
- 00 0 452
- 11 0 000
See MAINTENANCE AND GENERAL INFORMATION - SPECIAL TOOLS .
See ENGINE - SPECIAL TOOLS (N54, N63) .
| WARNING | Risk of injury! Observe following instructions relating to special tool: Prior to each use, check the special tools for defects, modifications and operational reliability. Damaged/modified special tools must not be used! No changes or modifications may be made to the special tools! Keep special tools dry, clean and free of grease. |
Necessary preliminary tasks
- Secure engine bonnet/hood in service position
- Remove intake filter housing . See «13 71 030 REMOVING AND INSTALLING BOTH INTAKE FILTER HOUSINGS (N63)»(ref-349797-S00938821222009121000000) .
Assemble cross member 00 0 200 with special tools 00 0 202, 00 0 204, 00 0 208.
Modification
Replace profile strips with special tools 00 0 451.
Replace front supports with special tools 00 0 452.
Note. Ensure that the longer feet of special tools 00 0 452 point to the middle of the vehicle.
Scheme 73
Note. The support points on the left side are shown. Position transverse member 00 0 200 with a 2nd person helping on designated areas (1, 2).
Note. Make sure that the front supports 00 0 452 are correctly positioned on the support carriers.
Scheme 74
| IMPORTANT | Avoid a change of engine position in the transverse or longitudinal direction. Always make sure there is sufficient clearance between the engine (or its attachment parts) and the body. |
| IMPORTANT | Risk of damage! With the aid of an assistant and the supports (1), place cross member 00 0 200 on the screw connections of the side panels. |
Secure special tool 11 0 000 to spindle 00 0 202.
Attach suitable chains to special tool 11 0 000 and suspend from both engine suspension eyelets.
Scheme 75
| WARNING | Risk of injury! Tighten down all adjusting screws and nuts on cross member 00 0 200. |
Unscrew nuts (1).
Tightening torque 22 11 2AZ, see 22 11 ENGINE SUSPENSION
Raise engine approx. 10 mm with transverse member.
Installation
Replace self-locking nuts.
