11 00 590 Replacement power plant (N54)
Necessary preliminary tasks
- Remove and install «engine»(ref-351443-S41027951872009122100000) .
- Mount engine on assembly stand .
- If necessary, remove foreign bodies from turbocharger group.
- Check all assemblies and convert to replacement power plant.
Remove transportation locks (1).
Note. Catch escaping engine oil with a suitable cloth (2).
Scheme 413
Transportation locks (1) are no longer needed.
Scheme 414
Modify screw plugs (1) from old power plant.
Insert screw plugs (1).
Tightening torque: 11 42 11AZ , see OIL FILTER AND LINES
Secure oil cooler lines with mounting bar (2).
Scheme 415
Assemble engine.
11 00 670 Securing engine in installation position (N54)
Special tools required
- 00 0 200
- 00 0 202
- 00 0 204
- 00 0 208
- 00 0 451
- 00 0 452
See MAINTENANCE AND GENERAL INFORMATION - SPECIAL TOOLS .
| WARNING | Risk of injury! |
Owing to the new guidelines on pedestrian protection, side panels are no longer suitable for supporting the engine.
Observe following instructions relating to special tool
- Prior to each use, check the special tools for defects, modifications and operational reliability.
- Damaged/modified special tools must not be used!
- No changes or modifications may be made to the special tools!
- Keep special tools dry, clean and free of grease.
Necessary preliminary tasks
- Secure engine bonnet/hood in service position
- Remove «acoustic cover»(ref-351443-S19076284442009122100000) .
Assemble cross member 00 0 200 with special tools 00 0 202 , 00 0 204 , 00 0 208 .
Modification
Replace profile strips with special tools 00 0 451 .
Replace front supports with special tools 00 0 452 .
Note. Ensure that the longer feet of special tools 00 0 452 point to the middle of the vehicle.
Scheme 416
Note. The support points on the left side are shown.
Position transverse member 00 0 200 with a 2nd person helping on designated areas (1, 2).
Note. Make sure that the front supports 00 0 452 are correctly positioned on the support carriers.
Scheme 417
| IMPORTANT | Avoid a change of engine position in the transverse or longitudinal direction. Always make sure there is sufficient clearance between the engine (or its attachment parts) and the body. |
Screw towing hook (72 15 8 108 670) into crankcase and tighten down to approx. 30 Nm.
Scheme 418
Align transverse member so that spindle 00 0 202 is correctly positioned over towing hook.
Secure suitable chain to spindle 00 0 202 and suspend from towing hook (1).
Scheme 419
| WARNING | Risk of injury! Tighten down all adjusting screws and nuts on cross member 00 0 200 . |
Scheme 420
Unscrew nuts (1).
Raise engine approx. 10 mm with transverse member.
Installation
Replace self-locking nut.
Tightening torque 22 11 2AZ , see 22 11 ENGINE SUSPENSION
Scheme 421
11 28 020 Replace alternator drive belt tensioner (N54)
Special tools required
- 11 3 340
See ENGINE - SPECIAL TOOLS (N54, N63) .
Necessary preliminary tasks
- Remove «drive belt»(ref-351443-S02801479942009122100000)
Remove special tool 11 3 340 .
Release screw on belt tensioner.
Tightening torque 11 28 1AZ , see 11 28 V-RIBBED BELT WITH TENSION AND DEFLECTION ELEMENT
Assemble engine.
