Engine - Repair (N63): Overview BMW X6 E71

Mechanical 16 illustrations ~205 words

11 00... Overview of consumables (Electronic Parts Catalogue - EPC)

1.0 Sealing compound for injection .

Repair instructions (engine)Designation EPCPart number EPCApplication examples
1.1N40, N42, N45, N46, N43, N45N, N46NLoctite 171000 primer83 19 7 515 683For hardening Loctite 128367 sealing compound
1.2N40, N42, N45, N46, N43, N45N, N46NLoctite 128357 liquid gasket83 19 7 536 051Sealing between crankcase upper and lower halves
1.3N51, N52, N53, N54, N52N, N55Loctite 171000 primer83 19 7 515 683For hardening Loctite 193140 sealing compound
1.4N51, N52, N53, N54, N52N, N55Loctite 193140 liquid gasket83 19 0 439 030Sealing between crankcase upper and lower halves
1.5S65, S85Loctite 171000 primer83 19 7 515 683For hardening Loctite 193140 sealing compound
1.6S65, S85Loctite 193140 liquid gasket83 19 0 439 030Sealing between crankcase upper and lower halves

INSTRUCTIONS CHART

2.0 Sealing compound for application .

Designation in repair instructionDesignation EPCPart number EPCApplication examples
2.1M41, M47, M47TU, M47T2, M50, M51, M52, M52TU, M54, M57, M57TU, M57T2, M60, M62 N40, N42, N45, N45N, N46, N46N, N43, N47, N47S N51, N52, N52N, N53, N54, N55, N57, N57S N62, N62TU, N73, N73H S14, S38, S50, S52, S54, S62, S65, S85Drei Bond 1209 liquid gasket07 58 9 062 376For sealing junction points on crankcase
2.2N12, N14, W16Loctite 5970 liquid gasket83 19 0 404 517Sealing between crankcase upper and lower halves
2.3N12, N14, W16Loctite 273 liquid gasket83 19 0 443 083Sealing between cover sleeve and crankcase

INSTRUCTIONS CHART

Engine identification

Drive in engine numbers at marked surface with impact tool.

M47 / M47TU / M47T2

Scheme 40

Scheme 40: Engine identification
Scheme 40: Engine identification

M57 / M57TU / M57T2

Scheme 41

Scheme 41
Scheme 41

M67 / M67TU

Scheme 42

Scheme 42
Scheme 42

N47 / N47S

Scheme 43

Scheme 43
Scheme 43

M52 / M52TU

Scheme 44

Scheme 44
Scheme 44

M54

Scheme 45

Scheme 45
Scheme 45

M56

Scheme 46

Scheme 46
Scheme 46

N40 / N45 / N45T / N43

Scheme 47

Scheme 47
Scheme 47

N42 / N46 / N46T

Scheme 48

Scheme 48
Scheme 48

N51 / N52 / N52K / N53 / N54

Scheme 49

Scheme 49
Scheme 49

N62

Scheme 50

Scheme 50
Scheme 50

N73

Scheme 51

Scheme 51
Scheme 51

S54

Scheme 52

Scheme 52
Scheme 52

S85 / S65

Scheme 53

Scheme 53
Scheme 53

W10 / W11

Scheme 54

Scheme 54
Scheme 54

W17

Scheme 55

Scheme 55
Scheme 55

Assemble engine.
