35 11 000 Removing and installing complete bearing block for foot pedal
Necessary preliminary tasks
- Remove brake pedal. Refer to «35 21 000 REMOVING AND INSTALLING/REPLACING BRAKE PEDAL»(/bmw/x3/e83-2003-2006/remont/mechanical-hydraulic/#pedals-repair-instructions__35-21-000-removing-and-installingreplacing) .
- Remove clutch pedal. Refer to «35 31 000 REMOVING AND INSTALLING/REPLACING CLUTCH PEDAL»(/bmw/x3/e83-2003-2006/remont/mechanical-hydraulic/#pedals-repair-instructions__35-31-000-removing-and-installingreplacing) .
- Remove clutch master cylinder from bearing block.
Unscrew nuts (1).
Scheme 216
Release nut (2) and remove bearing block (3).
Installation
Tighten nuts (1) in front of nut (2).
Tightening torque 35 11 1AZ. Refer to PEDALS - TIGHTENING TORQUES .
35 21 000 Removing and installing/replacing brake pedal
Necessary preliminary tasks
- Remove pedal trim. Refer to «51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY»(/bmw/x3/e83-2003-2006/remont/door-locks-anti-theft-systems/#body-equipment-repair-instructions__51-45-185-removing-and-installingreplacing) .
Disconnect return spring (1).
Scheme 217
Release screw (2) and remove holder (3).
Remove locking clip (1), disconnect pin (2) and pull out.
Scheme 218
Remove locking clip (3) and feed out brake pedal (4).
Installation
Replace locking clip.
The locking clip must be seated with both legs in the pin groove.
Installation
Check bearing bushes (1) and replace if necessary.
Scheme 219
Lightly grease bearing bushes (1), BMW Service Operating Fluids .
35 31 000 Removing and installing/replacing clutch pedal
Necessary preliminary tasks
- Remove pedal trim. Refer to «51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY»(/bmw/x3/e83-2003-2006/remont/door-locks-anti-theft-systems/#body-equipment-repair-instructions__51-45-185-removing-and-installingreplacing) .
Disconnect return spring (1).
Scheme 220
Press pin ends (2) together and remove pin.
Detach locking clip (3) and pull clutch pedal off bearing block.
Installation
Replace locking clip.
The locking clip must be seated with both legs in the pin groove.
Installation
Check bearing bushes (1) and replace if necessary.
Scheme 221
Lightly grease bearing bushes (1), BMW Service Operating Fluids .
Replace rubber grommet (2) if necessary.
35 40 001 Removing and installing/replacing accelerator pedal module
Take off cap.
Scheme 222
Unscrew screw.
Pull accelerator pedal module upwards out of fixture.
Installation
Tightening torque 35 40 AZ. Refer to PEDALS - TIGHTENING TORQUES .
Pull off plug (1).
Scheme 223
Remove accelerator pedal module.
| IMPORTANT | Accelerator pedal module can only be replaced completely with adapter plate. |
