Steering and Wheel Alignment - Repair BMW M6 E63/E64

00 Danger of poisoning if oil is ingested/absorbed through the skin

Danger of poisoning!

Ingesting oil or absorbing through the skin may cause poisoning!

Possible symptoms are

1. Headaches
2. Dizziness
3. Stomach aches
4. Vomiting
5. Diarrhoea
6. Cramps/fits
7. Unconsciousness

Protective measures/rules of conduct

1. Pour oil only into appropriately marked containers
2. Do not pour oil into drinking vessels (drinks bottles, glasses, cups or mugs)
3. Observe country-specific safety regulations

First aid measures

1. Do not induce vomiting. If the person affected is still conscious, he/she must rinse out their mouth with water, drink plenty of water and consult a doctor immediately. If the person affected is unconscious, do not administer anything by mouth, place the person in the recovery position and seek immediate medical attention.

00 Risk of injury if oil comes into contact with eyes and skin

Danger of injury!

Contact with eyes or skin may result in injury!

Possible symptoms are

1. Impaired sight
2. Irritation of the eyes
3. Reddening of the skin
4. Rough and cracked skin

Protective measures/rules of conduct

1. Wear protective goggles
2. Wear oil-resistant protective gloves
3. Observe country-specific safety regulations

First aid measures

1. Eye contact: Rinse eyes immediately with plenty of water for at least 15 minutes; if available, use an eye-rinsing bottle. If irritation of the eyes persists, consult a doctor.
2. Skin contact: Wash off with soap and water immediately. If irritation persists, consult a doctor. NOTE: Do not use solvents/thinners.

00 Safety instructions for handling oil

Recycling

Observe country-specific waste-disposal regulations.

Measures if oil is unintentionally released

1. Personal precautionary measures: Danger of slipping! Keep non-involved persons away from the work area. Wear personal protective clothing/equipment.
2. Environmental protection measures: Prevent oil from draining into drain channels, sewerage systems, pits, cellars, water and the ground.
3. Limiting spread: Use oil blocks to prevent the surface spread of oil.
4. Cleaning procedure: Bind and dispose of escaped oil with nonflammable absorbents. NOTE: Do not flush oil away with water or aqueous cleaning agents.

Scheme 1

Scheme 2

1. Car jacking point
2. Side car jacking points
3. Rear differential Risk of damage: It is not permitted to raise the vehicle at the rear differential cover!

Scheme 3

A wheel/chassis alignment check must be carried out after the following work

1. Release of following screw/bolt connections: Steering gear to front axle carrier Control arm to front axle carrier Support bearing to body (if centering pin is missing) Tie rod end to tie rod
2. Replacement of following parts: Front axle carrier Steering gear Gaiter (if the tie rod end has to be screwed off) Control arm Support bearing (if centering pin is missing) Swivel bearing Tie rod end Tie rod

31 00 ... Instructions (damage to suspension)

Substandard roadholding, atypical noises, tires worn on one side, camber and toe-in values which deviate from nominal value and mis-shaped components are all indicators of damage to the suspension caused by road traffic accidents or similar impacts.

To repair vehicle correctly, depending on condition of vehicle, perform the following troubleshooting procedure

You must also follow the rules and guidelines for accident-related repairs to the steering gear.

Troubleshooting

TROUBLESHOOTING CHART

Scheme 4

Scheme 5

1. Tie rod end / tie rod / gaiter
2. Power steering gear
3. Vane pump
4. Oil container
5. Steering spindle lower section
6. Sleeve
7. Steering column / electronic steering column lock
8. Overview of steering wheel/casing components

Scheme 6

32 00 ... Chassis/wheel alignment check procedure

CHASSIS/WHEEL ALIGNMENT CHECK PROCEDURE

Scheme 7

32 00 ... General information and definitions

Toe angle difference

1. Toe angle difference

1. D Center point of operating circle

The toe angle difference is the angle adjustment of the inner cornering wheel relative to the outer cornering wheel when negotiating a curve. Steering is designed in such a way that angular position of wheels changes as steering lock progresses.

A correctly adjusted toe angle difference produces equal values for left and right lock with consideration of factory tolerances.

Toe angle difference provides information on corresponding operation of steering trapezoid for left or right steering lock from center position.

Scheme 8

Camber

Inclination of the wheel from the perpendicular.

Scheme 9

Toe

Reduction in distance of front of front wheels to rear of front wheels. The toe-in prevents the wheels from moving apart during driving and thus

1. the wheels from vibrating and grinding
2. excessive tire wear
3. excessive strain on the steering linkage and its links/joints
4. heavy vehicle steering

Measurement is performed in "straight-ahead mode".

Scheme 10

Caster

Is the inclination of the kingpin in the direction of travel viewed from the side. The line through the center point of the spring strut support bearing and the control arm ball joint corresponds to the "kingpin".

Thanks to caster, wheels are pulled and not pushed. In a similar manner to king pin inclination, when driving in curves or around corners, returning forces are reproduced to help return wheels to straight-ahead position.

Scheme 11

Geometrical axis 1

Is the angle bisector from the total rear-wheel toe.

Front-wheel measurements are taken in reference to this axis.

Symmetrical axis 2

Center line running through front and rear axles.

Scheme 12

Wheel offset

Angle by which one front wheel is displaced more towards front or rear than the other front wheel. The wheel offset angle is positive when the right wheel is displaced towards the front and negative when it is displaced towards the rear.

Scheme 13

Kingpin offset/scrub radius

Is the distance from the center of the wheel contact face to the intersection point of the kingpin extension. The line through the center point of the spring strut support bearing and the control arm ball joint corresponds to the "kingpin".

The scrub radius is influenced by camber, kingpin angle and wheel offset of the wheel rim.

Scheme 14

32 00 ... Identification of suspension without label

Note. If the front spring strut does not have a label for suspension identification, the type of suspension can be identified from the part number in the Electronic Parts Catalogue.

32 00 ... Identifying suspension from label on front axle

Note. The type of suspension can be identified from the label on the spring strut/shock absorber.

Label

Scheme 15

1. BMW part number
2. Type of suspension BA = Standard suspension (basic) SP = Sport suspension or rough road package 60BAX =E60, E61 AWD MSP = M Sport suspension CHL = China Long Option SA 815 = rough road package

In the case of "SP" identification, there is a further distinction between

Scheme 16

1. Sport suspension without spacer ring (A)
2. Rough road package with spacer ring (A) above the support bearing

32 00 ... Information on replacing steering gear after accident damage

Facts

In the event of accidents or driving conditions similar to accidents, shocklike loads can cause different types of damage to steering gears. When a steering gear is externally undamaged, it is sometimes only possible to identify damage with great difficulty and with great effort. However, damage of this nature poses an unacceptable risk to the vehicle because it can result in failure of the steering system.

Because of the disproportionate amount of effort involved, it is generally not sensible to check thoroughly all the individual components of the steering gear and as an alternative it is necessary to take into account other components which can be checked more easily.

Procedure

The steering gear must be replaced if one or more of the following points apply

1. Visible or noticeable damage to the steering gear
2. Unacceptable torque increase and jamming when the steering gear is turned from lock to lock (without hydraulic assistance)
3. Permissible tolerances exceeded during axle/wheel alignment check (if necessary, include alignment record with invoice / report)
4. Fire damage
5. Damage, permanent deformation or fractures to: Wheel rims in the event of a negative result from the wheel/axle alignment check Spring struts, steering knuckles, wheel carriers Control arms Compression or tension struts or stabilizer bars with this function Body-side screwing/bolting points for wheel guide/control components Front axle carrier Pitman arms Tie rods Steering gear fixtures Steering column

This guideline is binding for all accident repairs to BMW and MINI vehicles.

Note. If the steering gear replacement work which is required for safety reasons is refused by the customer or an insurance company for cost reasons, a memorandum to that effect must be drawn up and countersigned by the party bearing the costs of the accident repair.

32 00 ... Moving vehicle into design position

Necessary preliminary tasks

1. Move vehicle into normal position
2. Version with air spring system: Remove ignition key Pull fuse for air supply unit control unit
3. Add/distribute weights in area of spring struts until the vehicle ride height is within the tolerance (refer to «FRONT AXLE - RIDE HEIGHT»(/bmw/m6/e63e64-2005-2010/remont/axle-shafts/#front-axle-technical-data__31-00-front-axle-ride) - Technical Data). Measure ride-level height of vehicle .

32 00 ... Moving vehicle into normal position

Necessary preliminary tasks

1. Check compliance with test conditions, bring vehicle to a stop if necessary.
2. Version with air spring system: Carry out ride-height-calibration
3. Check vehicle interior and luggage compartment (incl. luggage compartment recess) for load, unload vehicle if necessary
4. Introduce DIN load into vehicle. See «FRONT AXLE - RIDE HEIGHT»(/bmw/m6/e63e64-2005-2010/remont/axle-shafts/#front-axle-technical-data__31-00-front-axle-ride) .
5. Determine vehicle ride height NOTE: If the vehicle ride height is not inside the tolerance (refer to Technical Data article), the vehicle must be repaired (coil spring/leakage). See «FRONT AXLE - RIDE HEIGHT»(/bmw/m6/e63e64-2005-2010/remont/axle-shafts/#front-axle-technical-data__31-00-front-axle-ride) .

32 00 ... Performing rim runout compensation

Note. Rim runout compensation involves electronically recording the lateral runout of the rim and the possible clamping error of the quick-clamping unit for one wheel rotation and compensating the toe and camber for measurement/alignment.

Raise body.

Perform rim runout compensation in accordance with equipment manufacturer's instructions.

Compress/deflect car.

32 00 ... Test conditions for chassis/wheel alignment check

Observe the following test conditions prior to the chassis/wheel alignment check

1. Correct and identical rim and tire sizes.
2. Correct tread depth. The tread depth for each axle may differ from left to right by max. 3-4 mm.
3. Correct tire inflation pressure (see instruction plate on car).
4. Wheel bearing clearance OK
5. Steering backlash OK
6. Condition of suspension and shock absorbers OK
7. Cars with ride level control: Pull fuse of air supply unit so that there is no controlling down or up.

32 00 ... Troubleshooting after wheel/chassis alignment check on front axle

Substandard roadholding, atypical noises, tires worn on one side and toe-in/camber values which deviate from the nominal value are all indicators of damage to the suspension caused by road traffic accidents or similar impacts.

To carry out proper repairs, you must follow the procedure set out in the troubleshooting table below depending on the condition of the vehicle in question.

You must also follow the rules and guidelines for accident-related repairs to the steering gear.

Note. If after chassis/suspension components have been replaced adjustment of camber/track alignment is not possible, the vehicle must be placed on the straightening bench.

TROUBLESHOOTING CHART

32 00 ... Troubleshooting after wheel/chassis alignment check on rear axle

Substandard roadholding, atypical noises, tires worn on one side and toe/camber values which deviate from the nominal value are all indicators of damage to the suspension caused by road traffic accidents or similar impacts.

To carry out proper repairs, you must follow the procedure set out in the troubleshooting table below depending on the condition of the vehicle in question.

Note. If after chassis/suspension components have been replaced adjustment of camber/track alignment is not possible, the vehicle must be placed on the straightening bench

TROUBLESHOOTING CHART

32 00 150 KDS chassis/wheel alignment check with load up to design position

Except M models

Note. Read and comply with General information and definitions . Read and comply with General chassis definition.

Scheme 17

Scheme 18

Scheme 19

Scheme 20

1. If necessary, prepare lifting platform.
2. Drive vehicle onto lifting platform. NOTE: The front and rear wheels must be positioned centrally on the rotary and sliding plates.
3. Remove locking pins from both rotary and sliding plates, align pickup using bubble level and activate
4. Attach quick-clamping holder/quick-clamping unit to vehicle and remove clamping levers in area of front wheels
5. Attach pickup to quick-clamping holder/quick-clamping unit, align using bubble level and connect to rotary plates NOTE: When using quick-clamping units, perform «RIM RUNOUT COMPENSATION»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-00-performing-rim-runout) after installing the pickups.
6. If necessary, attach spoiler adapter.
7. If necessary, switch on chassis alignment system
8. Enter customer and vehicle data
9. Identify chassis version and select vehicle
10. Enter tire pressure and tread depth
11. Move «vehicle into design position»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-00-moving-vehicle-into) .
12. Install brake tensioner.

E87, E90, E91, E92

Note. After the drive-in routine, reconnect the pickups to the quick - clamping holders/quick-clamping units, align using the bubble levels and secure in place.

1. Perform input measurement in accordance with equipment manufacturer's instructions.
2. Compare specified values with actual values.

Only in event of customer complaint (e.g. poor driving performance)

Slacken all screws/bolts (front axle carrier to engine carrier / body) and then retighten to specified torque.

Lowering front axle carrier. See 31 11 001 REPLACING FRONT AXLE CARRIER .

1. If necessary, adjust front axle and rear axle
2. Perform output measurement in accordance with equipment manufacturer's instructions.
3. Save and print out test record.
4. Carry out steering angle sensor adjustment/adjustment for active front steering . See «61 31 996 Carry out steering angle sensor adjustment»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__61-31-996-steering-angle-sensor) .
5. Insert locking pins into both rotary and sliding plates
6. Remove chassis/wheel alignment system

32 00 155 KDS chassis/wheel alignment check with ride-height measurement without load

Note. Read and comply with General information and definitions . Read and comply with General chassis definition.

1. Check compliance with test conditions, bring vehicle to a stop if necessary.
2. If necessary, prepare lifting platform.
3. Drive vehicle onto lifting platform. NOTE: The front and rear wheels must be positioned centrally on the rotary and sliding plates.
4. Remove locking pins from both rotary and sliding plates, align pickup using bubble level and activate
5. If necessary, switch on chassis alignment system
6. Enter customer and vehicle data.
7. Identify chassis version and select vehicle
8. Enter tire pressure and tread depth
9. Measure and enter vehicle ride height . See «FRONT AXLE - RIDE HEIGHT»(/bmw/m6/e63e64-2005-2010/remont/axle-shafts/#front-axle-technical-data__31-00-front-axle-ride) .
10. Attach quick-clamping holder/quick-clamping unit to vehicle and remove clamping levers in area of front wheels
11. Attach pickup to quick-clamping holder/quick-clamping unit, align using bubble level and connect to rotary plates NOTE: When using quick-clamping units, perform «RIM RUNOUT COMPENSATION»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-00-performing-rim-runout) after installing the pickups.
12. If necessary, attach spoiler adapter.
13. Install brake tensioner.

E87, E90, E91, E92

Note. After the drive-in routine, reconnect the pickups to the quick - clamping holders/quick-clamping units, align using the bubble levels and secure in place.

1. Perform input measurement in accordance with equipment manufacturer's instructions.
2. Compare specified values with actual values

Only in event of customer complaint (e.g. poor driving performance)

Slacken all screws/bolts (front axle carrier to engine carrier / body) and then retighten to specified torque.

1. If necessary, adjust front axle and rear axle
2. Perform output measurement in accordance with equipment manufacturer's instructions.
3. Save and print out test record.
4. Carry out steering angle sensor adjustment/adjustment for active front steering . See «61 31 996 steering angle sensor adjustment»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__61-31-996-steering-angle-sensor) .
5. Insert locking pins into both rotary and sliding plates
6. Remove chassis/wheel alignment system
7. Drive vehicle off lifting platform.

32 00 610 Adjusting toe-in and camber on front axle

Special tools required

1. 32 3 190
2. 32 4 150 . See «STEERING & WHEEL ALIGNMENT - SPECIAL TOOLS»(ref-203033) .

Note. Camber and toe-in influence each other. Adjust the toe-in first in order to simplify the adjustment procedure. The centering pin may only be driven or twisted out if the camber is outside the specified tolerance after toe adjustment.

Version with active front steering

1. Align steering wheel
2. Set cumulative steering angle by means of the service function. Carry out initial operation/adjustment for active front steering to "zero". See «32 10 005 Adjustment for active front steering»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-10-005-adjustment-for-active) .
3. Install special tool 32 4 150 to secure active front steering power steering gear. NOTE: If special tool 32 4 150 cannot be installed, the steering wheel must be secured with the steering wheel arrester. The cumulative steering angle must remain at "zero" during the adjustment operation.

1. Check cumulative steering angle, reposition special tool 32 4 150 if necessary.

Version without active front steering

If necessary, remove steering gear cover at side Move steering into straight-ahead position by means of markings on cap (1) and steering gear (2).

Align steering wheel and secure with steering wheel arrester.

Scheme 21

Adjust toe-in

Clean thread on tie rod.

Slacken clamping nut (2), gripping tie rod end (1) in the process.

Remove clamp (4).

Adjusting procedures

1. Turn tie rod (3) to adjust toe-in to specified value.
2. Check cumulative steering angle; if necessary, set to "zero"
3. Check toe values; if necessary, repeat adjustment procedure

Tighten down clamping nut (2).

Tightening torque 32 21 5AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Fit clamp (4).

Scheme 22

Adjusting camber

M5

Disconnect connector (2).

Unclip connecting cable (1) from spring strut dome cover (3).

Detach connecting cable (1) from front spring strut.

Scheme 23

If necessary, release expander rivet (1).

If necessary, unclip spring strut dome cover (2) from front cross-strut.

Scheme 24

If necessary, remove protective cap.

Knock out centering pin (1) in downwards direction.

Clean wheel arch from below in area of support bearing with compressed air.

Slacken nut (2) approx. 1 to 1.5 turns.

Scheme 25

Insert special tool 32 3 190 into wheel arch opening and over nut.

Replace nuts (3) and screw on but do not tighten down fully. Adjusting procedures

1. Turn nut (4) in special tool 32 3 190 to adjust camber to specified value.
2. Check cumulative steering angle; if necessary, set to "zero"
3. Check camber values; if necessary, repeat adjustment procedure

Tighten down nuts (3)

Tightening torque 31 31 1AZ. See FRONT AXLE - TIGHTENING TORQUES -- 650I .

Scheme 26

Remove special tool 32 3 190.

Replace nut (2) and tighten down.

Tightening torque 31 31 1AZ. See FRONT AXLE - TIGHTENING TORQUES -- 650I .

Scheme 27

After installation

1. Check directional stability of car; if necessary, repeat toe-in adjustment
2. Version with active front steering: Remove special tool 32 4 150.

32 00 620 Adjusting rear axle

Note. A camber change always means a toe change as well. The camber must therefore be adjusted first.

Adjusting camber

Replace nut (2) and tighten to 5 Nm.

Turn eccentric bolt (1) to adjust camber to setpoint value.

Tighten nut (2).

Tightening torque 33 32 20AZ. See REAR AXLE - TIGHTENING TORQUES .

Scheme 28

Adjusting toe

Replace nut (2) and tighten to 5 Nm.

Turn eccentric bolt (1) to adjust toe to specified value.

Tighten nut (2).

Tightening torque 33 32 5AZ. See REAR AXLE - TIGHTENING TORQUES .

Scheme 29

32 10 005 Adjustment for active front steering

Note. Adjustment of the active front steering must be carried out: after adjustment work on the front axle/steering after all mechanical work on the steering system Build date up to 03/2007: after the battery has been disconnected or electrical plug connections on the steering column switch cluster have been disconnected after replacement/programming or coding of the following components: Steering column switch cluster DSC control unit Active front steering control unit ARS control unit

Connect vehicle to BMW diagnosis system.

Select and carry out initial operation/adjustment for active front steering under Service functions.

Scheme 30

A wheel/chassis alignment check must be carried out after the following work

1. Release following screw/bolt connections: Swinging arm, front/rear, to rear axle carrier Swinging arm to integral link / wheel carrier Integral link to wheel carrier Guide arm to rear axle carrier Control arm to rear axle carrier
2. Replacement of following parts: Rear axle carrier Swinging arm Integral link Wheel carrier / ball joint Control arm Guide arm

61 31 996 Steering angle sensor adjustment

Note. Steering angle sensor adjustment must be carried out: after adjustment work on the front axle/steering after all mechanical work on the steering system after replacement / coding / programming of the following components: Fixture for switches of steering column / switch cluster / steering angle sensor Dynamic Stability Control (DSC) control unit Control unit active anti-roll stabilization (ARS)

Connect vehicle to BMW diagnosis system or Software Service Station.

Select and carry out steering angle sensor adjustment under Service functions.

Facts

In the event of accidents or driving conditions similar to accidents, shocklike loads can cause different types of damage to steering gears. When a steering gear is externally undamaged, it is sometimes only possible to identify damage with great difficulty and with great effort. However, damage of this nature poses an unacceptable risk to the vehicle because it can result in failure of the steering system.

Because of the disproportionate amount of effort involved, it is generally not sensible to check thoroughly all the individual components of the steering gear and as an alternative it is necessary to take into account other components which can be checked more easily.

Procedure

The steering gear must be replaced if one or more of the following points apply

1. Visible or noticeable damage to the steering gear
2. Unacceptable torque increase and jamming when the steering gear is turned from lock to lock (without hydraulic assistance)
3. Permissible tolerances exceeded during axle/wheel alignment check (if necessary, include alignment record with invoice / report)
4. Fire damage
5. Damage, permanent deformation or fractures to: Wheel rims in the event of a negative result from the wheel/axle alignment check Spring struts, steering knuckles, wheel carriers Control arms Compression or tension struts or stabilizer bars with this function Body-side screwing/bolting points for wheel guide/control components Front axle carrier Pitman arms Tie rods Steering gear fixtures Steering column

This guideline is binding for all accident repairs to BMW and MINI vehicles.

Note. If the steering gear replacement work which is required for safety reasons is refused by the customer or an insurance company for cost reasons, a memorandum to that effect must be drawn up and countersigned by the party bearing the costs of the accident repair.

32 11 ... Notes on checking steering backlash on vehicles with rack-and-pinion steering (with front axle raised)

Note. When the front axle is raised, the applied force is distributed via the tie rod into horizontal and vertical forces. If there is now no electric or hydraulic assistance, the forces created cause the thrust member (1) to be unloaded against the spring (2). The play created in this way is incorrectly referred to as steering backlash. 3 = Rack

Scheme 31

Note. For checking purposes, the steering gear must be pressurized by means of electric or hydraulic assistance. Hydraulic steering assistance: Start engine. Electro-hydraulic steering assistance: Switch ignition on. Electric steering assistance: Turn on ignition and start engine.

32 11 100 Replacing gaiter for steering gear on left or right

Necessary preliminary tasks

1. Remove «tie rod end»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-21-231-replacing-left-or)
2. Remove underbody protective plate. See «51 47 490 REMOVING AND INSTALLING / REPLACING FRONT UNDERBODY PROTECTION»(/bmw/m6/e63e64-2005-2010/remont/axle-shafts/#front-axle-repair__51-47-490-removing-and-installing) .
3. If necessary, remove steering gear cover at side.

Clean tie rod.

Release band clamp (1) and ear clip (3).

Detach gaiter (2) from tie rod.

Installation

Clean rack and check surface for damage (e.g. by corrosion).

Grease rack.

Clean tie rod and apply grease to taper.

Scheme 32

Note. This ensures that the gaiter is not rotated when the tie rod is rotated.

Replace and grease O-ring (1).

Scheme 33

After installation

1. Perform chassis alignment check
2. Carry out steering angle sensor adjustment/adjustment for active front steering . See «61 31 996 Carry out steering angle sensor adjustment»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__61-31-996-steering-angle-sensor) .

Facts

In the event of accidents or driving conditions similar to accidents, shocklike loads can cause different types of damage to steering gears. When a steering gear is externally undamaged, it is sometimes only possible to identify damage with great difficulty and with great effort. However, damage of this nature poses an unacceptable risk to the vehicle because it can result in failure of the steering system.

Because of the disproportionate amount of effort involved, it is generally not sensible to check thoroughly all the individual components of the steering gear and as an alternative it is necessary to take into account other components which can be checked more easily.

Procedure

The steering gear must be replaced if one or more of the following points apply

1. Visible or noticeable damage to the steering gear
2. Unacceptable torque increase and jamming when the steering gear is turned from lock to lock (without hydraulic assistance)
3. Permissible tolerances exceeded during axle/wheel alignment check (if necessary, include alignment record with invoice / report)
4. Fire damage
5. Damage, permanent deformation or fractures to: Wheel rims in the event of a negative result from the wheel/axle alignment check Spring struts, steering knuckles, wheel carriers Control arms Compression or tension struts or stabilizer bars with this function Body-side screwing/bolting points for wheel guide/control components Front axle carrier Pitman arms Tie rods Steering gear fixtures Steering column

This guideline is binding for all accident repairs to BMW and MINI vehicles.

Note. If the steering gear replacement work which is required for safety reasons is refused by the customer or an insurance company for cost reasons, a memorandum to that effect must be drawn up and countersigned by the party bearing the costs of the accident repair.

32 13 006 Bleeding power steering (version with Dynamic Drive)

Note. To avoid mix-ups when filling with hydraulic fluid, mark the fluid reservoirs or their caps with identification marks.

ATF Automatic transmission fluid

CHF Pentosin CHF11S

Scheme 34

1. Thoroughly clean fluid reservoir and its immediate surroundings
2. Check and correct fill level NOTE: The fill level can come to rest above the "MAX" mark when the engine is at normal operating temperature. This is dictated by the design in that the marking on the dipstick is referred to a fluid temperature of 20 °C. With the engine at normal operating temperature (approx. 50-60 °C fluid temperature) adjust a fill height 15 mm above the "MAX" mark. Do not under any circumstances draw off the fluid to the "MAX" mark when the engine is at normal operating temperature. Hydraulic fluid: BMW Service Operating Fluids . See «STEERING - OPERATING FLUIDS»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-operating-fluids) .
3. Start engine
4. Turn steering wheel left and right twice in each case up to full lock; if necessary, top up hydraulic fluid (e.g. if hydraulic system is completely drained)
5. Move steering wheel to straight-ahead position and turn off engine
6. Check and correct fill level with engine stopped
7. Check hydraulic system for leaks After filling: If necessary, carry out initial Dynamic Drive operation . See «37 10 001 INITIAL OPERATION WITH TEST RUN OF DYNAMIC DRIVE»(/bmw/m6/e63e64-2005-2010/remont/electronic-suspension/#integrated-suspension-systems-repair__37-10-001-initial-operation-with) .

32 13 006 Bleeding power steering unit

Note. To avoid mix-ups when filling with hydraulic fluid, mark the fluid reservoirs or their caps with identification marks.

ATF Automatic transmission fluid

CHF Pentosin CHF11S

1. Thoroughly clean fluid reservoir and its immediate surroundings
2. Check and correct fill level NOTE: The fill level can come to rest above the "MAX" mark when the engine is at normal operating temperature. This is dictated by the design in that the marking on the dipstick is referred to a fluid temperature of 20 °C. With the engine at normal operating temperature (approx. 50-60 °C fluid temperature) adjust a fill height 10 mm above the "MAX" mark. Do not under any circumstances draw off the fluid to the "MAX" mark when the engine is at normal operating temperature. Hydraulic fluid: BMW Service Operating Fluids . See «STEERING - OPERATING FLUIDS»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-operating-fluids) .
3. Start engine
4. Turn steering wheel left and right twice in each case up to full lock; if necessary, top up hydraulic fluid (e.g. if hydraulic system is completely drained)
5. Move steering wheel to straight-ahead position and turn off engine
6. Check and correct fill level with engine stopped
7. Check hydraulic system for leaks

32 13 060 Removing and installing/replacing power steering gear

Necessary preliminary tasks

1. Disconnect battery negative lead . See «THE BATTERY»(/bmw/m6/e63e64-2005-2010/remont/charging-system/#battery-overview__the-battery) .
2. Draw off and dispose off hydraulic fluid from fluid reservoir
3. Secure engine in installation position
4. Remove tie rod end on both sides from swivel bearing . See «32 21 151 Replacing left or right tie rod»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-21-151-replacing-left-or) .
5. Replacement only: Remove tie rod end at both ends of tie rod . See «32 21 151 Replacing left or right tie rod»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-21-151-replacing-left-or) .
6. Lower front axle support . See «31 11 001 REPLACING FRONT AXLE CARRIER»(/bmw/m6/e63e64-2005-2010/remont/axle-shafts/#front-axle-repair__31-11-001-replacing-front-axle) .
7. Remove left mounting bracket or engine mount from front axle carrier . See «11 FRONT SUB-FRAME»(/bmw/m6/e63e64-2005-2010/remont/axle-shafts/#front-axle-repair) .
8. Engine mount with vacuum connection: Remove right engine mount from front axle carrier . See «11 FRONT SUB-FRAME»(/bmw/m6/e63e64-2005-2010/remont/axle-shafts/#front-axle-repair) .

Scheme 35

If necessary, remove heat shield from power steering gear.

Release banjo bolts (1).

Disconnect pressure line and return line from power steering gear.

Installation

Replace all sealing rings.

Make sure hydraulic lines are laid without tension and with sufficient spacing to adjoining components.

Tightening torque 32 41 3AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Scheme 36

Release bolt (1).

Release nuts (2) and remove screws towards bottom.

Installation

Replace screws and self-locking nuts.

Tightening torque 32 00 1AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Scheme 37

Version with active steering

Disconnect plug connections (1-4).

Raise power steering gear and unclip wiring harness.

Scheme 38

Move power steering gear to right and remove towards rear.

After installation

1. Fill And Bleed Hydraulic System . See «32 13 006 Bleeding power steering (version with Dynamic Drive)»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) or «32 13 006 Bleeding power steering unit»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) .
2. Check pipe connections for leaks
3. Perform chassis alignment check .
4. Carry out steering angle sensor adjustment/adjustment for active front steering . See «61 31 996 Carry out steering angle sensor adjustment»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__61-31-996-steering-angle-sensor) .
5. If necessary, carry out initial Dynamic Drive operation . See «37 10 001 INITIAL OPERATION WITH TEST RUN OF DYNAMIC DRIVE»(/bmw/m6/e63e64-2005-2010/remont/electronic-suspension/#integrated-suspension-systems-repair__37-10-001-initial-operation-with) .

32 13 065 Removing and installing/replacing active front steering power steering gear

Note. Procedure is described in Removing and installing/replacing power steering gear. See 32 13 060 Removing and installing/replacing power steering gear .

32 13 650 Removing and installing/replacing EH converter for Servotronic

Necessary preliminary tasks

1. Remove reinforcement plate . See «11 FRONT SUB-FRAME»(/bmw/m6/e63e64-2005-2010/remont/axle-shafts/#front-axle-repair) .
2. If necessary, remove heat shield.

Disconnect plug connection (1).

Unfasten screws (2).

Remove EH converter (3).

Installation

Clean side return orifice with compressed air.

Align EH converter (3) to opening in power steering gear, press by hand into power steering gear up to stop, insert screws (2) and tighten down.

Tightening torque 32 13 12AZ.

Scheme 39

After installation

1. Fill and bleed hydraulic system . See «32 13 006 Bleeding power steering (version with Dynamic Drive)»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) or «32 13 006 Bleeding power steering unit»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) .
2. If necessary, carry out initial Dynamic Drive operation . See «37 10 001 INITIAL OPERATION WITH TEST RUN OF DYNAMIC DRIVE»(/bmw/m6/e63e64-2005-2010/remont/electronic-suspension/#integrated-suspension-systems-repair__37-10-001-initial-operation-with) .

32 21 151 Replacing left or right tie rod

Necessary preliminary tasks

1. Remove front wheel

After installation

1. Perform chassis alignment check
2. Carry out steering angle sensor adjustment/adjustment for active front steering See «61 31 996 Carry out steering angle sensor adjustment»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__61-31-996-steering-angle-sensor) .

Release nut; if necessary, grip brace at Torx socket.

Remove tie rod end from swivel bearing.

Installation

Keep journal on tie rod end and bore hole in swivel bearing clean and free from grease.

Replace self-locking nut.

Tightening torque 32 21 3AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Scheme 40

Determine measurement (A) to simplify following adjustment of front axle.

Release clamping nut.

Screw off tie rod end; if necessary, grip tie rod with open-end wrench.

Installation

Check gaiter, replace if necessary.

Mount clamping ring (1).

Screw in tie rod end to measurement (A).

Scheme 41

Tightening torque 32 21 5AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

32 21 231 Replacing left or right tie rod

Special tools required

1. 32 3 160 . See «STEERING & WHEEL ALIGNMENT - SPECIAL TOOLS»(ref-203033) .

Necessary preliminary tasks

1. Remove tie rod end from swivel bearing
2. Remove gaiter from power steering gear and slide back

Unscrew tie rod with special tool 32 3 160 from rack of power steering gear and remove

Tightening torque 32 21 2AZ.

Scheme 42

Clean rack and check surface for damage (e.g. by corrosion).

Replace O-ring (1).

Grease rack and O-ring (1) (Refer to STEERING - OPERATING FLUIDS ).

Assembling new component with gaiter

Release clamping nut (2).

Screw off tie rod end; if necessary, grip tie rod with open-end wrench. tie rod end

Remove clamping ring (1) and screw off clamping nut (2).

Slide gaiter (4) and band clamp (3) onto tie rod.

Screw clamping nut (2) onto tie rod.

Slide clamping ring (1) onto tie rod.

Determine measurement (A) on old part to simplify following adjustment of front axle.

Screw tie rod end onto tie rod to measurement (A).

Tighten down clamping nut (2).

Tightening torque 32 21 5AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Scheme 43

After installation

1. Perform chassis alignment check
2. Carry out steering angle sensor adjustment/adjustment for active front steering See «61 31 996 Carry out steering angle sensor adjustment»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__61-31-996-steering-angle-sensor) .

32 41 ... Instructions for removing and installing ear clips

Special tools required

1. 32 1 260 . See «STEERING & WHEEL ALIGNMENT - SPECIAL TOOLS»(ref-203033) .

Note. The work steps are show on assorted components. Ear clip must always be replaced.

To remove an ear clip, place special tool 32 1 260 at right angles to ear and cut ear open.

Scheme 44

The ear clip can be fitted not only axially but also radially after the hook fastener has been opened.

Scheme 45

Attach hook fastener and press ear together with special tool 32 1 260.

Scheme 46

Side cutter of special tool 32 1 260 can be used in areas which are difficult to access.

Scheme 47

Scheme 48

32 31 004 Removing and installing / replacing upper section of steering column trim

Necessary preliminary tasks

1. Remove lower section of trim
2. Move steering column into "lower" and "extended" position

Unclip steering column cover (1) from upper section of trim.

Scheme 49

Unfasten screws.

Installation

Replace expansion rivets.

Scheme 50

Bend upper section of trim on both sides outwards and remove towards top.

Scheme 51

Installation

Locks (2) must engage in hooks (1) on both sides.

Scheme 52

32 31 010 Removing and installing/replacing front section of steering column cover

Necessary preliminary tasks

1. Disconnect battery negative lead
2. Remove «steering wheel»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair)

Pull of front section.

Scheme 53

Installation

Locks (2) must engage in hooks (1).

Scheme 54

32 31 020 Removing and installing / replacing lower section of steering column trim

Necessary preliminary tasks

1. Remove front section of trim
2. Move steering column in "top" and "extended" position.

Release screw.

Unclip lower trim section (1).

If necessary, unclip wiring harness from lower trim section (1).

Installation

Replace expansion rivet.

Scheme 55

Installation

Locks (2) must engage in hooks (1) on both sides.

Unclip steering column cover (1) from lower section of trim (2).

Remove lower section of trim (2).

Scheme 56

32 31 070 Removing and installing/replacing lower section of steering spindle

If necessary, remove steering gear cover at side.

Release clamping screw.

Remove lower section of steering spindle from power steering gear.

Installation

Recut thread.

Lower section of steering spindle can only be attached in one position to the power steering gear.

Replace clamping screw.

Clamping screw must rest in groove of power steering gear.

Tightening torque 32 31 1AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Scheme 57

Remove trim panel for pedal assembly. . See 51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY .

When reinstalling lower section of steering spindle: mark installation position of universal joint in relation to steering column.

Switch on ignition.

Turn steering wheel approx. 45 °, hold securely and release clamping screw (1).

Turn steering wheel back and remove ignition key.

Remove lower section of steering spindle from steering column.

Installation

Scheme 58

Recut thread.

Replace clamping screw (1).

Clamping screw (1) must rest in groove of steering column.

Tightening torque 32 31 1AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

After installation

1. Carry out steering angle sensor adjustment/adjustment for active front steering . See «61 31 996 Steering angle sensor adjustment»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__61-31-996-steering-angle-sensor) .
2. Turn steering wheel in both directions to full lock NOTE: The airbag warning lamp must not light up in the process.
3. Check directional stability of car

32 31 082 Removing and installing/replacing steering angle sensor

Note. Steering angle sensor is integrated in the steering column stalk fixture.

After installation

1. Replacement only: Carry out programming/coding
2. Only when replacing / programming / coding: Carry out steering angle sensor adjustment/adjustment for active front steering See «61 31 996 Carry out steering angle sensor adjustment»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__61-31-996-steering-angle-sensor) .
3. Version with active front steering: Teach in center position for power steering gear

32 31 087 Removing and installing/replacing steering column lock

Note. Steering column lock can only replaced in vehicles from 09/2005 with electric steering column adjustment.

Necessary preliminary tasks

1. Remove trim panel for pedal assembly. See «51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY»(ref-202134-S35575834462005102700000) .

Disconnect plug connection (1).

Note. There is the risk of mixing up the 3-pin plug connection for the footwell light.

Release shear screws (2).

Remove steering column lock (3).

Installation

Spherical side of shim must point to steering column lock (3).

Scheme 59

After installation

1. Carry out operational check.

32 31 090 Removing and installing/replacing steering column

Necessary preliminary tasks

1. Return steering to straight-ahead drive setting and remove ignition key
2. Remove trim panel for pedal assembly. See «51 45 185 REMOVING AND INSTALLING/REPLACING TRIM FOR PEDAL ASSEMBLY»(ref-202134-S35575834462005102700000) .
3. Remove steering spindle lower section from steering column . See «32 31 070 Removing and installing/replacing lower section of steering spindle»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-31-070-removing-and-installingreplacing) .
4. Remove «upper section of trim»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-31-004-removing-and-installing) .

Replacement only

1. Remove fixture for steering column stalk . See «61 31 006 REMOVING AND INSTALLING (REPLACING) FIXTURE FOR STEERING COLUMN STALK»(/bmw/m6/e63e64-2005-2010/remont/horns/#general-electrical-system-repair__61-31-006-removing-and-installing) .

Vehicles (up to 09/2005) with automatic transmissions

Remove interlock cable (1) from steering lock positioning unit.

Disconnect plug connections (2).

Scheme 60

Version with electric steering column adjustment (build date up to 09/2004)

Note. As from 09/2004 the new steering column with a 6 -pin plug connection and matching adapter lead will be supplied.

Installation

Fit adapter lead between wiring harness and steering column.

Secure adapter lead to wiring harness.

Version with electric steering column adjustment

Disconnect plug connection (3) from drive for electric steering column adjustment.

From 09/2005: Disconnect plug connection from electric steering column lock.

Vehicles (up to 09/2005) with automatic transmissions

Remove interlock cable (1) from steering column.

Remove wiring harness (2) from steering column and place to one side.

Installation

Replace ribbon cable from ignition starter switch to CAS control unit and secure with adhesive tape.

Scheme 61

Mark installation position of steering column.

Unfasten screws.

Tightening torque 32 31 6AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Scheme 62

Mark installation position of steering column (2).

Release screws (1).

Remove steering column (2) towards rear.

Installation

Insert steering column (2) through instrument panel and insert screws (1).

Align steering column (2) by way of markings and tighten down screws (1).

Tightening torque 32 31 6AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Scheme 63

Replacement

1. Remove ignition starter switch
2. Remove ring antenna . See «61 31 020 REMOVING AND INSTALLING/REPLACING IGNITION STARTER SWITCH»(/bmw/m6/e63e64-2005-2010/remont/horns/#general-electrical-system-repair__61-31-020-removing-and-installingreplacing) .
3. Remove lock cylinder . See «32 steering lock»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair) .

After installation

1. Carry out steering angle sensor adjustment/adjustment for active front steering . See «61 31 996 Carry out steering angle sensor adjustment»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__61-31-996-steering-angle-sensor) .
2. Perform function check: Check for ease of movement in overall adjustment range of steering column to adjoining components/wires Turn steering wheel in both directions to full lock. The airbag warning lamp must not light up in the process.
3. Check directional stability of car

32 31 102 Replacing steering spindle sleeve

Necessary preliminary tasks

1. Remove lower section of steering spindle See «32 31 070 Removing and installing/replacing lower section of steering spindle»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-31-070-removing-and-installingreplacing) .
2. Remove accelerator pedal module . See «PEDAL ASSEMBLY - REPAIR»(/bmw/m6/e63e64-2005-2010/remont/mechanical-hydraulic/#pedals-repair) .

Remove sleeve (1) from bulkhead.

Installation

Coat sleeve from outside with silicone grease and insert from passenger compartment. Arrow (1) on sleeve must point horizontally to left.

Check seating of sleeve in bulkhead, correct if necessary.

Scheme 64

After installation

1. Carry out steering angle sensor adjustment/adjustment for active front steering . See «61 31 996 Carry out steering angle sensor adjustment»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__61-31-996-steering-angle-sensor) .

32 32 050 Removing and installing/replacing lock cylinder for steering lock (up to 09/2005)

Special tools required

1. 32 3 110 . See «STEERING & WHEEL ALIGNMENT - SPECIAL TOOLS»(ref-203033) .

Necessary preliminary tasks

1. Disconnect battery negative lead
2. Remove «steering column trims»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair) .
3. Remove ring antenna . See «61 31 020 REMOVING AND INSTALLING/REPLACING IGNITION STARTER SWITCH»(/bmw/m6/e63e64-2005-2010/remont/horns/#general-electrical-system-repair__61-31-020-removing-and-installingreplacing) .

Insert ignition key into lock cylinder in such a way that release opening (arrow) remains accessible.

Turn ignition key to "R" position.

Insert special tool 32 3 110 into release opening (arrow) until end cap (1) is released.

Slide end cap (1) to ignition key and remove with special tool 32 3 110.

Pull out lock cylinder with end cap (1) and ignition key, turn ignition key forward and back if necessary.

Scheme 65

Installation

Insert lock cylinder with end cap (1) and ignition key into steering column.

Align end cap (1) by way of opening to steering column and press into place.

Turn ignition key to "zero" position and remove.

32 32 170 Removing and installing / replacing interlock cable (vehicles up to 09/2005)

Necessary preliminary tasks

1. Remove trim for storage tray
2. Remove front insert for ashtray

After installation

1. Adjusting interlock cable

Release screw (1) and remove bracket (2).

Move interlock cable (3) to left and then remove towards front.

If necessary, secure cord/cable to interlock cable (3).

Scheme 66

Turn guide sleeve (1) through approx. 45°.

Remove interlock cable (2) from steering column and pull out.

If necessary, remove cord/wire from interlock cable (2).

Scheme 67

Replacement only

Tie cord/wire to end of new interlock cable.

32 33 ... Replacing decorative strip for sport steering wheel

The procedure is described in 61 31 220 REMOVING AND INSTALLING/REPLACING MULTIFUNCTION STEERING WHEEL SWITCH (SPORTS STEERING WHEEL) .

32 33 001 Removing and installing / replacing steering wheel

Necessary preliminary tasks

1. Remove airbag unit . See «32 34 020 Removing and installing / replacing airbag unit»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-34-020-removing-and-installing) .

Move sport steering wheel to straight-ahead position.

Disconnect plug connection (1).

Release screw (2) and remove steering wheel.

Secure volute spring cassette with adhesive tape against twisting.

Installation

Make sure connecting lead(s) is/are correctly laid.

Tightening torque 32 33 1AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Scheme 68

Installation

If necessary, move wheels to straight-ahead position.

Align steering wheel using grooved toothing (1) to steering column and attach.

Scheme 69

Replacement

Release screws (1).

Disconnect plug connections on rear side.

Remove connecting lead from steering wheel.

Scheme 70

Installation

Make sure connecting lead is correctly laid.

Make sure that decorative strip (3) and multifunction steering wheel switches (2) are correctly positioned on steering wheel (guide pins must not be damaged).

Tightening torque 32 33 2AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Version with Sequential Manual Gearbox/Transmission: remove shift paddles. See 61 31 104 REMOVING AND INSTALLING/REPLACING SHIFTERS FOR SMG TRANSMISSION (BOTH) .

32 34 020 Removing and installing / replacing airbag unit

1. Comply with safety regulations for handling components with gas generators.
2. Do not exert any force on the airbag unit.
3. Use only specified tools for releasing the airbag unit.

Note. Incorrect handling may result in triggering of the airbag unit and thereby cause serious injury.

Necessary preliminary tasks

1. Disconnect battery negative lead

Insert Torx screwdriver (T25) from below into opening on rear side of steering wheel until a spring resistance is felt (approx. 3 cm).

Increase pressure on annular spring using Torx screwdriver (T25) until airbag unit is unlocked on both sides.

Installation

Make sure connecting cables are correctly routed.

Snap airbag unit with uniform pressing force plane-parallel in direction of steering column shaft into steering wheel.

Scheme 71

Tilt airbag unit (1) towards front.

Disconnect plug connection (2) and remove airbag unit (1).

Scheme 72

65 77 ... Notes on scrapping BMW vehicles with gas generators (central airbag control unit, airbag system)

The gas generator is a pyrotechnic component of

1. Airbag module Driver's/passenger airbag Side airbags Head airbag Knee airbag
2. Belt pretensioner
3. Belt buckle tensioner
4. Safety battery terminal

1. 1 Series: E81, E87
2. 3 Series: E46, E90, E91, E92, E93
3. 5 Series: E60, E61 from build date 09/2005
4. 6 Series: E63, E64 from build date 09/2005

X3: E83

X5: E53, E70

Z4: E85, E86

Gas generators that have not fired constitute a hazard (also to the environment)!

In accordance with accident prevention regulations and specific national regulations, gas generators must be rendered unusable before they are scrapped. This is necessary because pyrotechnical objects can cause injury if improperly activated (e.g. scrapping with flame cutters).

With above-mentioned vehicles which are scheduled for scrapping, it is always essential prior to draining and further stripping work to ensure that all the gas generators in the vehicle are fired. The fired gas generators can then be scrapped together with the vehicle.

Triggering failure

If correct triggering is not possible, the relevant components must (while observing the safety regulations for handling airbag system components) be removed and disposed of by special disposal companies!

If a triggering operation has failed

1. Disconnect the triggering device from the battery and
2. only approach the vehicle after a few minutes have elapsed

The components of an airbag system must always be disposed of. Such components must not be sold on as used parts.

Triggering

Triggering of the gas generators may only be carried out by expert personnel and under the supervision of a responsible person. Other standard accident prevention regulations (safety goggles, ear defenders etc.) must also be observed.

The gas generators must be fired from the outside in the vehicle scheduled for scrapping with the doors closed but with the tailgate, door windows and sunroof open. To fire the gas generators, use the BMW-developed triggering device with the corresponding cables.

1. Vehicles with central airbag control unit (all airbags, seat belt pretensioners, safety battery terminal) Expose airbag control unit. Connect "Airbagmaster". For subsequent procedure, refer to operating instructions.

65 77 ... Notes on scrapping BMW vehicles with gas generators (vehicles with gateway module, airbag system, up to build date 09/2005)

The gas generator is a pyrotechnic component of

1. Airbag module Driver's/passenger airbag Side airbags Head airbag Knee airbag
2. Belt tensioner
3. Belt buckle tensioner
4. Safety battery terminal

1. 5 Series: E60, E61
2. 6 Series: E63, E64

Gas generators that have not fired constitute a hazard (also to the environment)!

In accordance with accident prevention regulations and specific national regulations, gas generators must be rendered unusable before they are scrapped. This is necessary because pyrotechnical objects can cause injury if improperly activated (e.g. scrapping with flame cutters).

With above-mentioned vehicles which are scheduled for scrapping, it is always essential prior to draining and further stripping work to ensure that all the gas generators in the vehicle are fired. The fired gas generators can then be scrapped together with the vehicle.

Firing failure

If correct firing is not possible, the relevant components must (while observing the safety regulations for handling airbag system components) be removed and disposed of by special disposal companies!

If a firing operation has failed

1. Disconnect the firing device from the battery and
2. only approach the vehicle after a few minutes have elapsed

The components of an airbag system must always be disposed of. Such components must not be sold on as used parts.

Firing

Firing of the gas generators may only be carried out by expert personnel and under the supervision of a responsible person. Other standard accident prevention regulations (safety goggles, ear defenders etc.) must also be observed.

The gas generators must be fired from the outside in the vehicle scheduled for scrapping with the doors closed but with the tailgate, door windows and sunroof open. To fire the gas generators, use the BMW-developed firing device with the corresponding cables.

1. Vehicles with gateway module (all airbags, seat belt tensioners, safety battery terminal) Expose airbag plug connections. Connect "Airbagmaster". For subsequent procedure, refer to operating instructions.

72 00 ... Safety regulations for handling components with gas generators

It is essential to comply with the regulations as specified in the law relating to the use of explosives when working on airbag units and seat belt tensioners.

Airbags, seat belt tensioners etc. are pyrotechnical objects. Pyrotechnical objects are assigned to different danger classes on the basis of the quantity of propellant that they contain. The assignment can be ascertained from the identification marking on the product

This applies in particular to the following components

1. Airbag modules (driver's/front passenger airbags, side airbags)
2. Buckle/belt tensioner
3. Head airbag (ITS, AHPS)
4. Active knee protection
5. Active head restraint
6. Safety battery terminal (SBK)

1. Regulations The regulations quoted in the following refer to Germany. In all other countries, the relevant legislation and regulations must be observed in each case. Country-specific legal regulations that go beyond this information or court decisions based thereon must be followed in each case or given precedence over these regulations. The following components used by BMW: Pyrotechnical restraint systems are subject to danger class PT1 Gas generators are pyrotechnical objects belonging to danger class T1. Handling, transporting and storing non-fired gas generators are subject to the "Explosive Materials Act" (law relating to the use of explosives dated 13/09/1976). The relevant trade supervisory authority must be notified at least 2 weeks before pyrotechnical objects are handled for the first time. Here the relevant authority must be notified in writing of the person responsible (e.g. dealership owner, holder of general power of attorney or if necessary workshop supervisor). A certificate of qualification, i.e. specific training, is not required for the person responsible.
2. Disassembly and assembly Inspection, testing and installation work may only be carried out by expert trained personnel in BMW Service. Work on components of the airbag system should only ever be carried out with the battery disconnected, the negative terminal post covered and the plug connection of the cable leading to the gas generator disconnected. If only the battery is disconnected, the following prescribed waiting period must be observed without fail: 30 minutes for vehicles up to 9/93; 1 minute for vehicles from 9/93 In the event of breaks in work, a component with a gas generator that has been removed must be secured against access by other persons. Individual components must never be repaired. Instead, always replace them. Do not treat airbag system components with cleaning agents or grease. Components of the airbag system must not be exposed to temperatures in excess of 75 °C. Airbag system components, including electronic diagnostic components, which have been dropped from heights in excess of 0.5 m must not be reinstalled in the vehicles. Before installing, subject airbag system components (including electronic diagnostic components) to a visual inspection for damage and replace if necessary. Airbag system components may only be electrically tested while they are installed and only with the BMW diagnostic system / DIS. Danger of injury: The airbag module may only be set down with the airbag itself facing upwards. Otherwise the generator will be thrown upwards if it is fired. Do not point the firing pellet of a gas generator at other persons. Components with gas generators must not be fired while they are removed. They must be disposed of by special disposal companies or returned to BMW in the packaging of the new components. When carrying out straightening and welding work with an electric welder: Disconnect battery Cover negative terminal (post) Avoid all contact with the skin when removing a fired airbag module - wear gloves. Wash with water after contact with the skin.
3. Transport Components with gas generators must be sent off in the packaging of the new components.
4. Storage Observe the regulations of the relevant trade supervisory authority and the applicable national regulations.

72 12 ... Procedure after airbag triggering as result of an accident

Check and/or replace following components after airbag triggering

Satellites (control unit + sensor)

1. Components Satellite, A-/B-pillar, left/right Satellite, front door Satellite, rear seat Satellite, driver's/front passenger seat Satellite, vehicle center
2. Procedure Read out fault memory Disconnect battery and observe waiting period Rectify faults Reconnect battery and observe waiting period Clear fault memory Turn off ignition and wait at least 2 minutes (no consumers may be switched on during this period such as e.g. inside lights, radio, etc.) Switch ignition on. Clear fault memory and if necessary rectify faults

Cables and plugs

1. Components and procedure Check cables and plugs for damage, replace if necessary.

Belt system

1. Components Automatic safety belt tensioner Belt buckle tensioner Seatbelt height adjustment
2. Procedure Check components, replace if necessary

Seats

1. Components Seat Airbag module Active head restraint
2. Procedure Check seats (function check of seat mechanism), replace if necessary Check seat screw/bolt connections Replace gas generator of active head restraint system If the severity of the impact has not caused any other damage to the seat, only the triggered gas generator needs to be replaced. External feature: The triggered head restraint is folded forwards and engaged. The repair work can be carried out in the car with the rear panel removed. The entire system can be pushed back into its original position and the new gas generator installed. The gas generator can be replaced up to 5 times. Replace airbag module and seat cover with padding

Driver's airbag

1. Components Airbag module Steering wheel Steering column (if damaged)
2. Procedure Check components, replace if necessary Replace steering wheel

Passenger airbag

1. Components Airbag module Instrument panel trim Supporting tube (if damaged)
2. Procedure Check components, replace if necessary

Side airbag, front/rear

1. Components Airbag module Door trim panel Door in white Seat
2. Procedure Check components, replace if necessary

Head airbag (AHPS)

1. Components Airbag module Trim, A-pillar Roofliner Trim, B-pillar (if damaged) Trim, C-pillar (if damaged) Bodyshell
2. Procedure Check components, replace if necessary

Knee airbag

1. Components Panel (driver's side) Lower section of glovebox Active knee protector (driver's and passenger sides)
2. Procedure Check components, replace if necessary

Passive knee protector

1. Components Panel (driver's side) Glovebox incl. knee protector (passenger side)
2. Procedure Check components for damage, replace if necessary Check fastening elements

Note. To avoid mix-ups when filling with hydraulic fluid, mark the fluid reservoirs or their caps with identification marks.

ATF Automatic transmission fluid

CHF Pentosin CHF11S

1. Thoroughly clean fluid reservoir and its immediate surroundings
2. Check and correct fill level NOTE: The fill level can come to rest above the "MAX" mark when the engine is at normal operating temperature. This is dictated by the design in that the marking on the dipstick is referred to a fluid temperature of 20 °C. With the engine at normal operating temperature (approx. 50-60 °C fluid temperature) adjust a fill height 15 mm above the "MAX" mark. Do not under any circumstances draw off the fluid to the "MAX" mark when the engine is at normal operating temperature. Hydraulic fluid: BMW Service Operating Fluids . See «STEERING - OPERATING FLUIDS»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-operating-fluids) .
3. Start engine
4. Turn steering wheel left and right twice in each case up to full lock; if necessary, top up hydraulic fluid (e.g. if hydraulic system is completely drained)
5. Move steering wheel to straight-ahead position and turn off engine
6. Check and correct fill level with engine stopped
7. Check hydraulic system for leaks

After filling

1. If necessary, carry out initial Dynamic Drive operation . See «37 10 001 INITIAL OPERATION WITH TEST RUN OF DYNAMIC DRIVE»(/bmw/m6/e63e64-2005-2010/remont/electronic-suspension/#integrated-suspension-systems-repair__37-10-001-initial-operation-with) .

Note. To avoid mix-ups when filling with hydraulic fluid, mark the fluid reservoirs or their caps with identification marks.

ATF Automatic transmission fluid

CHF Pentosin CHF11S

1. Thoroughly clean fluid reservoir and its immediate surroundings
2. Check and correct fill level NOTE: The fill level can come to rest above the "MAX" mark when the engine is at normal operating temperature. This is dictated by the design in that the marking on the dipstick is referred to a fluid temperature of 20 °C. With the engine at normal operating temperature (approx. 50-60 °C fluid temperature) adjust a fill height 10 mm above the "MAX" mark. Do not under any circumstances draw off the fluid to the "MAX" mark when the engine is at normal operating temperature. Hydraulic fluid: BMW Service Operating Fluids . See «STEERING - OPERATING FLUIDS»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-operating-fluids) .
3. Start engine
4. Turn steering wheel left and right twice in each case up to full lock; if necessary, top up hydraulic fluid (e.g. if hydraulic system is completely drained)
5. Move steering wheel to straight-ahead position and turn off engine
6. Check and correct fill level with engine stopped
7. Check hydraulic system for leaks

Special tools required

1. 32 1 260 . See «STEERING & WHEEL ALIGNMENT - SPECIAL TOOLS»(ref-203033) .

Note. The work steps are show on assorted components. Ear clip must always be replaced.

To remove an ear clip, place special tool 32 1 260 at right angles to ear and cut ear open.

The ear clip can be fitted not only axially but also radially after the hook fastener has been opened.

Attach hook fastener and press ear together with special tool 32 1 260.

Side cutter of special tool 32 1 260 can be used in areas which are difficult to access.

32 41 ... Instructions for using special tool 32 4 000

Special tools required

1. 32 4 000 . See «STEERING & WHEEL ALIGNMENT - SPECIAL TOOLS»(ref-203033) .
2. 32 4 004
3. 32 4 005
4. 32 4 006
5. 32 4 011
6. 32 4 012

Depending on the pressure hose connection on the pump, the special tool 32 4 000 must be assembled.

1 = Connection, pump

2 = Connection, steering gear

Scheme 73

Pressure hose connection to pump with M14 x 1.5 banjo bolt

Screw special tool 32 4 004 with M14 x 1.5 banjo bolt (1) and 2 sealing rings to special tool 32 4 000.

Screw special tool 32 4 011 onto pump and connect special tool 32 4 004.

Screw special tools 32 4 006 / 32 4 012 onto special tool 32 4 000 and connect pressure hose with M14 x 1.5 banjo bolts and 2 sealing rings.

Scheme 74

Pressure hose connection to pump with M16 x 1.5 banjo bolt

Screw special tool 32 4 004 with M14 x 1.5 banjo bolt (1) and 2 sealing rings to special tool 32 4 000.

Screw special tool 32 4 005 onto pump and connect special tool 32 4 004.

Screw special tool 32 4 006 onto special tool 32 4 000 and connect pressure hose with M16 x 1.5 banjo bolt and 2 sealing rings.

Scheme 75

Pressure hose connection to pump with M16 x 1.5 union screw

Screw special tool 32 4 004 with M14 x 1.5 banjo bolt (1) and 2 sealing rings to special tool 32 4 000.

Connect special tool 32 4 004 to pump.

Screw special tools 32 4 006 / 32 4 005 onto special tool 32 4 000 and connect pressure hose.

Scheme 76

Scheme 77

Scheme 78

1. Quick-connect coupling with ID marking Removing: Push quick-connect coupling (1) against pipe (4) (thereby relieving strain on spring (2)). Press plastic ring (3) into quick-connect coupling (1) and remove coupling (1). Assembly: Markings (K) on coupling (1) and pipe (4) must be flush. Push quick-connect coupling (1) onto pipe (4) until a "click" can clearly be heard. To check that quick-connect coupling (1) has been installed correctly, pull it back forcefully.
2. Quick-connect coupling with indication pins Removing: Press plastic ring (2) into quick-connect coupling (1) and remove coupling (1). Assembly: When replacing hydraulic line: remove transportation lock (T). Push quick-connect coupling (1) onto pipe (3) until both indication pins (4) can be seen and felt to point outwards at outside diameter of housing. To check that quick-connect coupling (1) has been correctly fitted, feel indication pins (4) at outside diameter of housing. When correctly seated, indication pins (4) cannot be pressed into housing. IMPORTANT: Coupling is not correctly engaged if both indication pins (4) fail to protrude from housing. Leakage is thus unavoidable.

32 41 ... Replacing level switch for Dynamic Drive fluid reservoir

Necessary preliminary tasks

Scheme 79

1. Detach fluid reservoir from holder, raise and if necessary remove sideways Disconnect plug connection (1). Turn level switch (2) through approx. 45° and remove towards bottom.

32 41 009 Checking function of power steering vane pump

Special tools required

1. 32 4 000 . See «STEERING & WHEEL ALIGNMENT - SPECIAL TOOLS»(ref-203033) .

After installation

1. Fill and bleed hydraulic system . See «32 13 006 Bleeding power steering (version with Dynamic Drive)»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) or «32 13 006 Bleeding power steering unit»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) .
2. Check pipe connections for leaks
3. Version with Dynamic Drive: If necessary, carry out initial operation for Dynamic Drive . See «37 10 001 INITIAL OPERATION WITH TEST RUN OF DYNAMIC DRIVE»(/bmw/m6/e63e64-2005-2010/remont/electronic-suspension/#integrated-suspension-systems-repair__37-10-001-initial-operation-with) .

Necessary preliminary tasks

1. Draw off and dispose off hydraulic fluid from fluid reservoir Observe country-specific waste-disposal regulations
2. Remove front assembly underside protection . See «51 47 490 REMOVING AND INSTALLING / REPLACING FRONT UNDERBODY PROTECTION»(ref-202134-S02430352092005102700000) .
3. Disconnect pressure line from vane pump

Version with Dynamic Drive only: . See 37 10 001 INITIAL OPERATION WITH TEST RUN OF DYNAMIC DRIVE .

Note. Pressure line to valve block (Dynamic Drive) Pressure line to power steering gear Suction line from fluid reservoir

Connecting special tool

Connect special tool 32 4 000 .

1. Connection, vane pump
2. Connection, power steering gear

Checking pump pressure

Scheme 80

1. Close valve (A).
2. Open valve (B).
3. Fill and bleed hydraulic system . See «32 13 006 Bleeding power steering (version with Dynamic Drive)»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) or «32 13 006 Bleeding power steering unit»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) .
4. Start engine.
5. Heat hydraulic fluid to approx. 50 °C by moving steering wheel at increased engine speed.
6. Close valve (B) for max. 10 secs. and read off pressure.
7. Compare measured pressure with specified nominal pressure. Replace vane pump if the nominal pressure is exceeded by more than 10 %. Check belt tension if the nominal pressure is undershot by more than 10 %. Replace vane pump if belt tension is OK.

32 41 033 Removing and installing/replacing power steering pump for power steering gear with active front steering (N62, N62TU)

Necessary preliminary tasks

1. Draw off and dispose off hydraulic fluid from fluid reservoir
2. Remove belt pulley
3. Remove front assembly underside protection . See «51 47 490 REMOVING AND INSTALLING / REPLACING FRONT UNDERBODY PROTECTION»(ref-202134-S02430352092005102700000) .

Release banjo bolt (1) and detach pressure line from power steering pump.

Release hose clamp (2) and detach suction line from power steering pump.

Installation

Replace sealing ring.

Make sure hydraulic lines are laid without tension and with sufficient spacing to adjoining components.

Tightening torque 32 41 3AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Scheme 81

Disconnect plug connection (1).

Scheme 82

Variant (A) - build date up to 05/2004

Release screws (1, 2).

Tightening torque 32 41 1AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Remove power steering pump (3) downwards.

Variant (B) - build date from 05/2004

Release bolt (1) and nut (2).

Tightening torque 32 41 1AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Remove power steering pump (3) downwards.

Scheme 83

After installation

1. Fill and bleed hydraulic system . See «32 13 006 Bleeding power steering (version with Dynamic Drive)»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) or «32 13 006 Bleeding power steering unit»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) .
2. Check pipe connections for leaks

32 41 037 Removing and installing/replacing power steering pump for power steering gear with Dynamic Drive (N62, N62TU)

Note. When replacing power steering pump: Fluid reservoir must be replaced in event of metal abrasion, sluggish pump shaft or increased wear! The filter integrated in the fluid reservoir can only absorb a limited amount of foreign particles. If the filter clogs, the hydraulic system can no longer be sufficiently protected. Metal abrasion is perceived in the fluid reservoir as metallically glittering hydraulic fluid. It is only necessary to replace the fluid reservoir because of leaks (e.g. at hose connections) only in the event of the unavoidably high ingress of dirt.

Necessary preliminary tasks

1. Draw off and dispose of hydraulic fluid from fluid reservoir
2. Relieve tension on drive belt and remove from power steering pump belt pulley
3. Lower front axle carrier . See «31 11 506 LOWERING/RAISING FRONT AXLE CARRIER»(/bmw/m6/e63e64-2005-2010/remont/axle-shafts/#front-axle-repair__31-11-506-loweringraising-front-axle) .

Release hose clamp (1) and detach suction line from power steering pump.

Unscrew nut (3).

Tightening torque, 32 41 6AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Release banjo bolt (2) and detach pressure line for Dynamic Drive from power steering pump.

Release banjo bolt (4) and disconnect pressure line for power steering from power steering pump.

Installation

Replace all sealing rings.

Make sure hydraulic lines are laid without tension and with sufficient spacing to adjoining components.

Tightening torque 32 41 3AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Scheme 84

Version with active front steering: Disconnect plug connection (1).

Release screw (2).

Tightening torque 32 41 1AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Scheme 85

Variant (A) - build date up to 05/2004

Release screws (1, 2).

Tightening torque 32 41 1AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Remove power steering pump (3) downwards.

Variant (B) - build date from 05/2004

Release bolt (1) and nut (2).

Tightening torque 32 41 1AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Remove power steering pump (3) downwards.

Scheme 86

After installation

1. Fill and bleed hydraulic system . See «32 13 006 Bleeding power steering (version with Dynamic Drive)»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) or «32 13 006 Bleeding power steering unit»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) .
2. Check pipe connections for leaks
3. Carry out steering angle sensor adjustment/adjustment for active front steering . See «61 31 996 Carry out steering angle sensor adjustment»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__61-31-996-steering-angle-sensor) .
4. If necessary, carry out initial Dynamic Drive operation . See «37 10 001 INITIAL OPERATION WITH TEST RUN OF DYNAMIC DRIVE»(/bmw/m6/e63e64-2005-2010/remont/electronic-suspension/#integrated-suspension-systems-repair__37-10-001-initial-operation-with) .

32 41 060 Removing and installing/replacing vane pump for power steering (N62, N62TU)

Note. See 32 41 033 Removing and installing/replacing power steering pump for power steering gear with active front steering (N62, N62TU) .

32 41 060 Removing and installing/replacing vane pump for power steering (S85)

Necessary preliminary tasks

1. Draw off and dispose of hydraulic fluid from fluid reservoir.
2. Remove «belt pulley»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-41-100-removing-and-installingreplacing) .
3. Remove drive belt tensioner. See «11 28 020 REPLACING TENSIONING DEVICE FOR ALTERNATOR DRIVE BELT (S85)»(/bmw/m6/e63e64-2005-2010/remont/mechanical/#engine-repair__11-28-020-replacing-tensioning-device)
4. Remove front underbody protection. See «51 47 490 REMOVING AND INSTALLING / REPLACING FRONT UNDERBODY PROTECTION»(/bmw/m6/e63e64-2005-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-47-490-removing-and-installing) .

Unclip cover, release screw (1) and remove deflection pulley (2). Release screws (3, 4).

Scheme 87

Release banjo bolt (1) and detach pressure line (2) from vane pump. Installation: Replace all sealing rings. Make sure pressure line is laid without tension and with sufficient spacing to adjoining components. Tightening torque, see 32 41 3AZ in 32 41 PUMP AND OIL SUPPLY .

Scheme 88

Release hose clamp (3) and detach suction line (4) from vane pump. Release screws (5) and remove vane pump towards front. Tightening torque, see 32 41 1AZ in 32 41 PUMP AND OIL SUPPLY .

After installation

1. Fill and bleed «hydraulic system»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) .
2. Check pipe connections for leaks.

32 41 061 Replacing power steering vane pump

After installation

1. Fill and bleed hydraulic system . See «32 13 006 Bleeding power steering (version with Dynamic Drive)»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) or «32 13 006 Bleeding power steering unit»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) .
2. Check pipe connections for leaks
3. Version with Dynamic Drive: If necessary, carry out initial operation for Dynamic Drive . See «37 10 001 INITIAL OPERATION WITH TEST RUN OF DYNAMIC DRIVE»(/bmw/m6/e63e64-2005-2010/remont/electronic-suspension/#integrated-suspension-systems-repair__37-10-001-initial-operation-with) .

Necessary preliminary tasks

1. Check function of vane pump
2. Remove vane pump

Release screws (1).

Tightening torque 32 41 14AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Remove belt pulley (2).

Installation

Lettering on belt pulley (2) points forwards.

Scheme 89

32 41 100 Removing and installing/replacing belt pulley on vane pump for power steering

Note. Carry out preliminary work as described in the document " Replacing drive belt".

Slacken screws (1)

Relieve tension on drive belt and remove from belt pulley (2).

Unscrew bolts (1) and remove belt pulley (2).

Installation

Lettering on belt pulley (2) must point forwards.

Tightening torque 32 41 14AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

32 41 250 Removing and installing/replacing fluid reservoir for power steering

Special tools required

1. 32 1 260 . See «STEERING & WHEEL ALIGNMENT - SPECIAL TOOLS»(ref-203033) .

Necessary preliminary tasks

1. Draw off and dispose of hydraulic fluid from fluid reservoir
2. M54, N52, N53, N54: Remove intake filter housing

Release screw (1).

Tightening torque 32 41 9AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Note. If necessary, raise and/or turn fluid reservoir in order to gain better access to hose clamps.

Remove hose clamps if necessary with special tool 32 1 260.

Disconnect suction and cooler return lines from fluid reservoir, check and if necessary replace.

Lift out fluid reservoir.

Scheme 90

After installation

1. Fill and bleed hydraulic system . See «32 13 006 Bleeding power steering (version with Dynamic Drive)»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) or «32 13 006 Bleeding power steering unit»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) .
2. Check pipe connections for leaks

32 41 253 Removing and installing / replacing fluid reservoir for power steering with Dynamic Drive / active front steering

Special tools required

1. 32 1 260 . See «STEERING & WHEEL ALIGNMENT - SPECIAL TOOLS»(ref-203033) .

Necessary preliminary tasks

1. Draw off and dispose of hydraulic fluid from fluid reservoir
2. M54, N52, N53, N54: Remove intake filter housing

Unscrew nuts.

Remove shims.

If necessary, remove bracket (not shown in illustration).

Installation

Replace self-locking nuts.

Tightening torque 32 41 9AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Scheme 91

Note. If necessary, raise and/or turn fluid reservoir in order to gain better access to plug connection and hose clamps.

If necessary, disconnect plug connection at level switch.

Remove hose clamps if necessary with special tool 32 1 260.

Disconnect suction and cooler return lines from fluid reservoir, check and if necessary replace.

Lift out fluid reservoir.

Scheme 92

Replacement

If necessary, remove level switch.

After installation

1. Fill and bleed hydraulic system . See «32 13 006 Bleeding power steering (version with Dynamic Drive)»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) or «32 13 006 Bleeding power steering unit»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) .
2. Check pipe connections for leaks

Version with Dynamic Drive

1. If necessary, carry out initial Dynamic Drive operation . See «37 10 001 INITIAL OPERATION WITH TEST RUN OF DYNAMIC DRIVE»(/bmw/m6/e63e64-2005-2010/remont/electronic-suspension/#integrated-suspension-systems-repair__37-10-001-initial-operation-with) .

32 41 312 Replacing suction line with cooler return line for power steering (S85)

Necessary preliminary tasks

1. Draw off and dispose of hydraulic fluid from fluid reservoir.
2. Remove reinforcement plate
3. Remove right intake filter housing. See «13 71 020 REMOVING AND INSTALLING RIGHT INTAKE FILTER HOUSING (S85)»(/bmw/m6/e63e64-2005-2010/remont/fuel-system/#fuel-system-repair__13-71-020-removing-and-installing) .

Loosen hose clamps (1). Disconnect suction line with cooler return line (2) from fluid reservoir. Installation: Make sure hydraulic lines are laid without tension and with sufficient spacing to adjoining components.

Scheme 93

Expose suction line with cooler return line up to cutting line on engine carrier.

Release quick-connect coupling (1) and seal hydraulic lines with a suitable plug. Release ear clamp (2) and remove suction line (3) with cooler return line in upward direction.

Installation: Make sure hydraulic line is laid without tension and with sufficient spacing to adjoining components.

Scheme 94

Remove alternator drive belt tensioner. See 11 28 020 REPLACING TENSIONING DEVICE FOR ALTERNATOR DRIVE BELT (S85) . Expose suction line up to vane pump.

Release hose clamp (1) and detach suction line (2) from vane pump.

Scheme 95

After installation

1. Fill and bleed «hydraulic system»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) .
2. Check pipe connections for leaks.

32 41 332 Replacing pressure line for power steering (S85)

Necessary preliminary tasks

1. Draw off and dispose of hydraulic fluid from fluid reservoir.
2. Remove alternator drive belt. See «11 28 010 REPLACING ALTERNATOR DRIVE BELT (S85)»(/bmw/m6/e63e64-2005-2010/remont/mechanical/#engine-repair__11-28-010-replacing-alternator-drive) .
3. Remove pressure accumulator.
4. Lower front axle support. See «31 11 506 LOWERING/RAISING FRONT AXLE CARRIER»(/bmw/m6/e63e64-2005-2010/remont/axle-shafts/#front-axle-repair__31-11-506-loweringraising-front-axle) .

Release banjo bolt (1) and screw (3). Disconnect pressure line (2) from vane pump.

Installation: Replace all sealing rings. Screw in banjo bolt (3) and screw (1) (do not tighten down). Tighten down first banjo bolt (1) and then screw (3).

Tightening torque, see 32 41 3AZ (banjo bolt) in 32 41 PUMP AND OIL SUPPLY . Tightening torque, see 32 41 5AZ (bolt) in 32 41 PUMP AND OIL SUPPLY .

Expose pressure line up to connection on power steering gear.

Scheme 96

Expose pressure line up to connection on power steering gear.

Release banjo bolt (1) and remove pressure line (2). Installation: Replace all sealing rings. Make sure hydraulic line is laid without tension and with sufficient spacing to adjoining components. Tightening torque, see 32 41 3AZ in 32 41 PUMP AND OIL SUPPLY .

Scheme 97

After installation

1. Fill and «bleed hydraulic system»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) .
2. Check pipe connections for leaks.
3. Check engine oil level, correct if necessary.

32 41 351 Replacing return line for power steering (S85)

Necessary preliminary tasks

1. Draw off and dispose of hydraulic fluid from fluid reservoir.
2. Lower front axle support. See «31 11 506 LOWERING/RAISING FRONT AXLE CARRIER»(/bmw/m6/e63e64-2005-2010/remont/axle-shafts/#front-axle-repair__31-11-506-loweringraising-front-axle) .

Release quick-connect coupling and seal power steering cooler connection with a suitable plug. Installation: Make sure hydraulic line is laid without tension and with sufficient spacing to adjoining components.

Scheme 98

Expose return line up to connection on power steering gear.

Release banjo bolt (1) and remove return line (2). Installation: Replace all sealing rings. Make sure hydraulic line is laid without tension and with sufficient spacing to adjoining components. Tightening torque, see 32 41 3AZ in 32 41 PUMP AND OIL SUPPLY .

Scheme 99

1. Fill and «bleed hydraulic system»(/bmw/m6/e63e64-2005-2010/remont/manual-power-steering/#steering-and-wheel-alignment-repair__32-13-006-bleeding-power-steering) .
2. Check pipe connections for leaks.

32 00 ... Teaching in center position for power steering (active front steering) (from 03/2007)

Note. Carry out the following procedure after disconnecting the battery or disconnecting electrical plug connections on the steering column switch cluster.

Turn on ignition, start engine if necessary.

Turn steering wheel twice in both directions to full lock.

Note. Adjustment of the active front steering must be carried out: after adjustment work on the front axle/steering after all mechanical work on the steering system Build date up to 03/2007: after the battery has been disconnected or electrical plug connections on the steering column switch cluster have been disconnected after replacement/programming or coding of the following components: Steering column switch cluster DSC control unit Active front steering control unit ARS control unit

Connect vehicle to BMW diagnosis system.

Select and carry out initial operation/adjustment for active front steering under Service functions.

32 43 010 Removing and installing/replacing control unit for active front steering

Necessary preliminary tasks

1. Remove right entrance strip . See «51 47 000 REMOVING AND INSTALLING/REPLACING FRONT (INSIDE) LEFT OR RIGHT ENTRANCE COVER STRIP»(ref-202134-S02681609562005102700000) .
2. Remove right front seat . See «SEATS - REPAIR»(/bmw/m6/e63e64-2005-2010/remont/seats/#seats-repair) .
3. Disconnect battery negative lead . See «THE BATTERY - OVERVIEW - ALL MODELS»(/bmw/m6/e63e64-2005-2010/remont/charging-system/#battery-overview) .
4. If necessary, remove front right floor mat
5. Remove side trim in front right footwell . See «51 43 075 REMOVING AND INSTALLING/REPLACING SIDE TRIM PANEL, FOOTWELL, ON A-PILLAR, RIGHT»(ref-202134-S28506220642005102700000) .

Fold back front right floor trim.

Remove kickplate in footwell in front of and next to control unit; if necessary, cut along specified lines with knife and secure later with adhesive tape.

Release screws (1) and lay grounding cable to one side.

Installation

Secure grounding cable as illustrated to retaining plate.

Tightening torque 32 43 1AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Scheme 100

Raise active front steering control unit and turn over.

Disconnect plug connections and remove active front steering control unit.

Scheme 101

After installation

1. Replacement only: Carry out programming/coding
2. Only when replacing / programming / coding: adjustment for active steering
3. Teach in mid-position for power steering

32 43 515 Removing and installing/replacing yaw sensor for active front steering

Necessary preliminary tasks

1. Remove left front seat . See «SEATS - REPAIR»(/bmw/m6/e63e64-2005-2010/remont/seats/#seats-repair) .
2. Raise rear left floor trim in area of center console

Release screws (1).

Tightening torque 32 43 2AZ. See STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES .

Unlock plug (2) and remove.

Scheme 102

32 90 ... Troubleshooting on steering

Observe troubleshooting on front axle and diagnosis help for steering (SI).

TROUBLESHOOTING CHART

See also:
• FRONT AXLE - RIDE HEIGHT
• 31 11 001 REPLACING FRONT AXLE CARRIER
• STEERING AND WHEEL ALIGNMENT - TIGHTENING TORQUES
• FRONT AXLE - TIGHTENING TORQUES -- 650I
• REAR AXLE - TIGHTENING TORQUES
• 51 47 490 REMOVING AND INSTALLING / REPLACING FRONT UNDERBODY PROTECTION
• STEERING - OPERATING FLUIDS
• 37 10 001 INITIAL OPERATION WITH TEST RUN OF DYNAMIC DRIVE
• THE BATTERY
• 11 FRONT SUB-FRAME
• 61 31 006 REMOVING AND INSTALLING (REPLACING) FIXTURE FOR STEERING COLUMN STALK
• 61 31 020 REMOVING AND INSTALLING/REPLACING IGNITION STARTER SWITCH
• PEDAL ASSEMBLY - REPAIR
• 61 31 220 REMOVING AND INSTALLING/REPLACING MULTIFUNCTION STEERING WHEEL SWITCH (SPORTS STEERING WHEEL)
• 61 31 104 REMOVING AND INSTALLING/REPLACING SHIFTERS FOR SMG TRANSMISSION (BOTH)
• 31 11 506 LOWERING/RAISING FRONT AXLE CARRIER
• 11 28 020 REPLACING TENSIONING DEVICE FOR ALTERNATOR DRIVE BELT (S85)
• 51 47 490 REMOVING AND INSTALLING / REPLACING FRONT UNDERBODY PROTECTION
• 32 41 PUMP AND OIL SUPPLY
• 13 71 020 REMOVING AND INSTALLING RIGHT INTAKE FILTER HOUSING (S85)
• 11 00 670 SECURING ENGINE IN INSTALLATION POSITION (S85)
• 11 28 010 REPLACING ALTERNATOR DRIVE BELT (S85)
• SEATS - REPAIR
• THE BATTERY - OVERVIEW - ALL MODELS
• wheel/chassis alignment check
• General information and definitions
• General chassis definition.
• RIM RUNOUT COMPENSATION
• vehicle into design position
• 61 31 996 Carry out steering angle sensor adjustment
• 32 10 005 Adjustment for active front steering
• tie rod end
• 32 21 151 Replacing left or right tie rod
• 32 13 006 Bleeding power steering (version with Dynamic Drive)
• 32 13 060 Removing and installing/replacing power steering gear
• 32 31 070 Removing and installing/replacing lower section of steering spindle
• upper section of trim
• 32 34 020 Removing and installing / replacing airbag unit
• 32 41 033 Removing and installing/replacing power steering pump for power steering gear with active front steering (N62, N62TU)
• belt pulley
