72 Safety precautions and general information
Safety instructions
> Safety regulations for handling airbag modules, airbag components and pyrotechnical seat belt tensioners
> Notes on scrapping vehicles with gas generators
Handling electrical and electronic equipment
> Repairing airbag leads. See 61 00 ... REPAIRING AIRBAG CABLES .
> Handling optical fibres . See 61 00 ... NOTES ON HANDLING OPTICAL FIBERS .
Check
> Check seat belt .
Airbag system
72 00 ... Safety regulations for handling components with gas generators
It is essential to comply with the regulations as specified in the law relating to the use of explosives when working on airbag units and seat belt tensioners.
Airbags, seat belt tensioners etc. are pyrotechnical objects. Pyrotechnical objects are assigned to different danger classes on the basis of the quantity of propellant that they contain. The assignment can be ascertained from the identification marking on the product
| IMPORTANT | Failure to comply with the warning notices and repair instructions for gas generator components can cause accidental deployment and result in injury and vehicle damage! |
This applies in particular to the following components
- Airbag modules (driver's/front passenger airbags, side airbags)
- Buckle/belt tensioner
- Head airbag (ITS, AHPS)
- Active knee protection
- Active head restraint
- Safety battery terminal (SBK)
- Regulations The regulations quoted in the following refer to the Federal Republic of Germany. In all other countries, the relevant legislation and regulations must be observed in each case. Country-specific legal regulations that go beyond this information or court decisions based thereon must be followed in each case or given precedence over these regulations. The following components used by BMW: Pyrotechnical restraint systems are subject to danger class PT1 Gas generators are pyrotechnical objects belonging to danger class T1. Handling, transporting and storing non-fired gas generators are subject to the "Explosive Materials Act" (law relating to the use of explosives dated 13/09/1976). The relevant trade supervisory authority must be notified at least 2 weeks before pyrotechnical objects are handled for the first time. Here the relevant authority must be notified in writing of the person responsible (e.g. dealership owner, holder of general power of attorney or if necessary workshop supervisor). A certificate of qualification, i.e. specific training, is not required for the person responsible.
- Disassembly and assembly Inspection, testing and installation work may only be carried out by expert trained personnel in BMW Service. Work on components of the airbag system should only ever be carried out with the battery disconnected, the negative terminal post covered and the plug connection of the cable leading to the gas generator disconnected. If only the battery is disconnected, the following prescribed waiting period must be observed without fail: 30 minutes for vehicles up to 9/93; 1 minute for vehicles from 9/93 In the event of breaks in work, a component with a gas generator that has been removed must be secured against access by other persons. Individual components must never be repaired. Instead, always replace them. Do not treat airbag system components with cleaning agents or grease. Components of the airbag system must not be exposed to temperatures in excess of 75 °C. Airbag system components, including electronic diagnostic components, which have been dropped from heights in excess of 0.5 m must not be reinstalled in the vehicles. Before installing, subject airbag system components (including electronic diagnostic components) to a visual inspection for damage and replace if necessary. Airbag system components may only be electrically tested while they are installed and only with the BMW diagnostic system / DIS. Danger of injury: The airbag module may only be set down with the airbag itself facing upwards . Otherwise the generator will be thrown upwards if it is fired. Do not point the firing pellet of a gas generator at other persons. Components with gas generators must not be fired while they are removed. They must be disposed of by special disposal companies or returned to BMW in the packaging of the new components. When carrying out straightening and welding work with an electric welder: Disconnect battery Cover negative terminal (post) Avoid all contact with the skin when removing a fired airbag module - wear gloves. Wash with water after contact with the skin.
- Transport Components with gas generators must be sent off in the packaging of the new components.
- Storage Observe the regulations of the relevant trade supervisory authority and the applicable national regulations.
Scheme 1
Safety instructions
> Safety regulations for handling airbag modules, airbag components and pyrotechnical seat belt tensioners
> Notes on scrapping vehicles with gas generators
Handling electrical and electronic equipment
> Repairing airbag leads. See 61 00 ... REPAIRING AIRBAG CABLES
> Handling optical fibres . See 61 00 ... NOTES ON HANDLING OPTICAL FIBERS
Check
Airbag system
72 11 ... Checking automatic safety belt
General considerations when checking seat belts
The seat belts must be checked after an accident.
For the check, you should start by trying to get information on which seats in the car involved in the accident were occupied. If this is not possible, check all the seat belts in the car and replace them if necessary.
In the event of deformations on the car, you must subject the components of the restraint system affected in this area such as e.g.
- Seat belt
- Seatbelt height adjustment
- Belt buckle tensioner
- Triggering sensors
- etc.
to a function check and a visual inspection.
If you are in any doubt as to the unimpaired functional capability of restraint system components, these components must be replaced in the interests of safety!
If a seat belt has to be replaced following an accident (e.g. in the event of a frontal and/or side impact with permanently deformed impact dampers/deformation elements or cross-members), the complete seat belt must be replaced! The complete seat belt comprises
- Top belt
- Lower strap
- Seat belt buckle (buckle tensioner)
- Seatbelt height adjustment
- Retaining screws of all components
The following must also be checked and if necessary replaced
- Seatbelt mountings on the car body
- Seatbelt mountings on the seat
- seat runners.
- Seat structure (frame, etc.)
Alignment tests on the seat and the seat runners are not permitted!
The following explanations and the checklist for the automatic safety belt can provide help.
An unusable seat belt or a seat belt worn in a serious accident should be destroyed immediately after removal to guarantee that it cannot be used again.
Checking automatic reel and seatbelt strap
The automatic reel has two independent activation systems for seat-belt locking.
The first activation system locks the automatic reel when driving quickly around curves, driving in tight curves, on extreme inclinations (vehicle rolls over) and during sharp braking or impact.
To check, the seat backrest must be placed in the upright position and both hands held in a supporting position close to the steering wheel. The brakes are then applied fully while driving on a dry surface and at a road speed equal to twice that of walking speed.
The seat belt must lock.
The second activation system provides additional safety and is controlled by inertia mass.
If the reel locks when the strap is pulled out suddenly, this system is also OK.
Automatic reel does not require servicing and must not be opened.
Precondition for complete, problem-free retraction of straps
- the straps must not be twisted!
- the straps must not be damaged!
When placed to one side, the straps of the front seats must retract fully.
With the straps in the rear seat bench, a small remaining loop is acceptable due to increased friction between the strap and the rear seat bench cover if
- this remaining loop is fully retracted when the strap is reguided.
Belt straps should only be cleaned with a luke-warm soap solution or a commercial laundry detergent.
Belt straps must never be cleaned chemically or dyed.
The automatic reel and strap must be replaced in the event of
- creases
- unraveling
- pinches
- cracks and tears
- traces of melting
- traces of wear on casing of seat belt tongue or on reversing clip.
Checking lower strap (belt buckle tensioner)
To fasten a seat belt, the tongue should insert easily and with a loud click in the lock.
When the "Red button" is pressed, the tongue must be ejected from the lock under spring pressure.
If the lock cover is missing or damaged, the lower strap must be replaced.
Replace the triggered belt buckle tensioner including the complete seat belt with seatbelt height adjustment and retaining screws and check the
- Seatbelt mountings on the car body
- Seatbelt mountings on the seat
- seat runners.
- Seat structure.
Criteria for a triggered mechanical belt buckle tensioner
- very low position of seatbelt buckle (comparisons with new part).
Criteria for a triggered pyrotechnical belt buckle tensioner
- very low position of seatbelt buckle (comparisons with new part).
- Airbag warning lamp permanently lit: read out airbag system fault memory.
The belt buckle tensioners can be triggered under certain circumstances even when the seat is not occupied. If it is definite that the belt system was not used (seat was not occupied), there is no need to replace the
- upper strap
- attachment parts (belt height adjustment, screws)
- seatbelt mountings on the car body
- Seatbelt mountings on the seat
- seat runners.
after a check.
72 11 ... Inspection list for automatic seat belt
| Was the automatic seat belt with lower strap replaced after an accident, e.g. frontal and/or oblique impact in which the impact absorbers/deformation elements were permanently deformed? | No | Replace complete automatic seat belt The following must also be checked and replaced, if necessary: seatbelt mountings on the car body seatbelt mountings on the seat seat runners. |
|---|---|---|
| Yes | ||
| Does seat belt lock when pulled out suddenly? | No | Replace automatic seat belt (upper strap). |
| Yes | ||
| Can the strap be pulled out without jamming? | No | Automatic reel is loose - tighten reel. If fault persists: Return spring broken - replace automatic seat belt (upper strap). |
| Yes | ||
| Does the strap on the front seat belts retract automatically? Does the strap on the rear seat belts retract automatically, a small remaining loop is acceptable if this remaining loop is fully retracted when the strap is readjusted. | No | Automatic reel is loose - tighten reel. Excessive friction in belt guides - replace automatic seat belt (upper strap). Return spring broken - replace automatic seat belt (upper strap). |
| Yes | ||
| Does automatic reel make a squeaking noise when belt is fastened or unfastened? | Yes | Excessive friction in belt guides - replace automatic seat belt (upper strap). Reel is loose - tighten reel. Return spring broken - replace automatic seat belt (upper strap). |
| No | ||
| Is the plastic casing on the latch free from damage in the area of the belt opening? | No | Replace complete automatic seat belt |
| Yes | ||
| Is the fully extended strap free from pinches, burn marks, tears and cuts, folding and unravelling? | No | Replace complete automatic seat belt |
| Yes | ||
| When the seat belt is fitted, is the latch ejected with spring pressure from the buckle when the "Red button" is pressed? | No | Replace complete automatic seat belt |
| Yes | ||
| Does fastened seat belt lock when stopping vehicle quickly on a dry road at a road speed twice as fast as walking speed? | No | Replace complete automatic seat belt |
| Yes | ||
| Is fully pulled-out belt free of serious dirt and other marks? | No | If dirt and marks cannot be removed with commercially available mild-action detergent, the automatic seat belt (upper strap) must be replaced. |
| Yes | ||
| In the case of seat-integrated seat belts, is front tongue of reclining mechanism or seat rail free of deformation? | No | Replace both damaged parts and complete automatic-reel seat belt. The following must also be checked and replaced, if necessary: seatbelt mountings on the car body seatbelt mountings on the seat seat runners. |
| Yes | ||
| The automatic seat belt is O.K.! |
AUTOMATIC SEAT BELT INSPECTION REFERENCE LIST
72 11 030 Removing and installing/replacing front seat belt (complete)
| WARNING | Read and comply with Safety regulations for handling airbag modules and pyrotechnical belt tensioners. Inexpert handling can trigger off the airbag or the belt tensioner and thus cause injuries. |
Necessary preliminary tasks
- Disconnect battery negative lead . See «61 00 ... BATTERY»(/bmw/m6/e63e64-2005-2010/remont/horns/#general-electrical-system-repair__61-00-battery) .
- Follow instructions for unlocking and locking airbag plug connections. See «72 12 ... Unlocking/locking airbag plug connections»(/bmw/m6/e63e64-2005-2010/remont/airbag/#restraint-systems-repair__72-12-unlockinglocking-airbag-plug) .
- Removing and installing rear left or right side trim panel . See «51 43 002 REMOVING AND INSTALLING REAR LEFT OR RIGHT SIDE TRIM PANEL»(/bmw/m6/e63e64-2005-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-43-002-removing-and-installing) .
- Removing and installing or replacing trim on left or right door pillar (top). See «51 43 ... REMOVING AND INSTALLING/REPLACING TRIM ON ARMREST OF LEFT OR RIGHT SIDE TRIM PANEL»(/bmw/m6/e63e64-2005-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-43-removing-and-installingreplacing) .
Note. If a seat belt which is damaged due to an accident is exchanged, always check the slide bar (6) for damage (bending) and replace if necessary.
1 = Protective cap
2 = Screw securing slide bar to body
Tightening torque 72 11 04AZ.
3 = Rosette
4 = Space bush
5 = Strap
6 = Slide bar
Scheme 2
Unfasten screws.
Tightening torque 72 11 03AZ.
Unscrew bracket.
Scheme 3
Release screw.
Remove reversing clip.
Tightening torque 72 11 02AZ.
Scheme 4
Release screw.
Tightening torque 72 11 01AZ.
Remove inertia reel unit.
Scheme 5
Installation
Coding (1) of automatic reel must be seated in opening (2) of body.
Retaining screw (3) locates automatic reel in position.
Scheme 6
Note. The following work step ends here: Removing and installing/replacing front seat belt (automatic reel)
Removing and installing/replacing front left or right lower strap (seat belt tensioner)
Necessary preliminary tasks
- Remove front seat . See «SEATS - REPAIR»(/bmw/m6/e63e64-2005-2010/remont/seats/#seats-repair) .
Note. If a seat belt which is damaged due to an accident is exchanged, always check the belt tensioner retaining bracket on the seat rail for damage (bending) and replace if necessary.
A bent seatbelt tensioner retaining bracket on the seat runner may make it impossible to adjust the height of the seat!
Detach cable strap (2).
Unlock plug connection (1) for belt tensioner and disconnect.
Release screw (3) and remove belt tensioner.
Tightening torque 72 11 06AZ.
Installation
Replace microencapsulated screw.
Replace cable strap.
Plug connection (1) on belt tensioner must not be under strain.
Scheme 7
Installation
Check that cable holder is in correct position on belt tensioner.
Scheme 8
Check retaining bracket (1) of belt tensioner on seat rail for damage (bending), replace if necessary.
To replace retaining bracket, release screw (2) and remove retaining bracket (1).
Scheme 9
72 11 033 Removing and installing/replacing front seat belt (reel)
| WARNING | Read and comply with Safety regulations for handling airbag modules and pyrotechnical belt tensioners. Inexpert handling can trigger off the airbag or the belt tensioner and thus cause injuries. |
Necessary preliminary tasks
- Removing and installing rear left or right See «51 43 002 REMOVING AND INSTALLING REAR LEFT OR RIGHT SIDE TRIM PANEL»(/bmw/m6/e63e64-2005-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-43-002-removing-and-installing) .
- Removing and installing or replacing trim on left or right door pillar (top). See «51 43 ... REMOVING AND INSTALLING/REPLACING TRIM ON ARMREST OF LEFT OR RIGHT SIDE TRIM PANEL»(/bmw/m6/e63e64-2005-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-43-removing-and-installingreplacing) .
Note. If a seat belt which is damaged due to an accident is exchanged, always check the slide bar (6) for damage (bending) and replace if necessary.
1 = Protective cap
2 = Screw securing slide bar to body
Tightening torque 72 11 04AZ.
3 = Rosette
4 = Space bush
5 = Strap
6 = Slide bar
Unfasten screws.
Tightening torque 72 11 03AZ.
Unscrew bracket.
Scheme 10
Release screw.
Remove reversing clip.
Tightening torque 72 11 02AZ.
Release screw.
Tightening torque 72 11 01AZ.
Remove inertia reel unit.
Installation
Coding (1) of automatic reel must be seated in opening (2) of body.
Retaining screw (3) locates automatic reel in position.
72 11 041 Removing and installing/replacing front left or right lower strap (belt tensioner)
| WARNING | Read and comply with Safety regulations for handling airbag modules and pyrotechnical belt tensioners. Incorrect handling can trigger off the bet tensioner and cause injury. |
Necessary preliminary tasks
- Disconnect battery negative lead . See «61 00 ... BATTERY»(/bmw/m6/e63e64-2005-2010/remont/horns/#general-electrical-system-repair__61-00-battery) .
- Follow instructions for unlocking and locking airbag plug connections. . See «72 12 ... Unlocking/locking airbag plug connections»(/bmw/m6/e63e64-2005-2010/remont/airbag/#restraint-systems-repair__72-12-unlockinglocking-airbag-plug) .
- Remove front seat . See «SEATS - REPAIR»(/bmw/m6/e63e64-2005-2010/remont/seats/#seats-repair) .
Note. If a seat belt which is damaged due to an accident is exchanged, always check the belt tensioner retaining bracket on the seat rail for damage (bending) and replace if necessary.
A bent seatbelt tensioner retaining bracket on the seat runner may make it impossible to adjust the height of the seat!
Detach cable strap (2).
Unlock plug connection (1) for belt tensioner and disconnect.
Release screw (3) and remove belt tensioner.
Tightening torque 72 11 06AZ.
Installation
Replace microencapsulated screw.
Replace cable strap.
Plug connection (1) on belt tensioner must not be under strain.
Installation
Check that cable holder is in correct position on belt tensioner.
Check retaining bracket (1) of belt tensioner on seat rail for damage (bending), replace if necessary.
To replace retaining bracket, release screw (2) and remove retaining bracket (1).
72 11 092 Removing and installing/replacing rear left or right seat belt (roller)
Necessary preliminary tasks
- Remove backrest for rear seat . See «SEATS - REPAIR»(/bmw/m6/e63e64-2005-2010/remont/seats/#seats-repair) .
Note. Illustration shows removal of left side. The right side is removed in the same way as the left side.
Note. Before removing reversing clip, mark position to ensure correct alignment when installing.
Release screw (1).
Tightening torque 72 11 24AZ.
Remove reversing clip (2).
Scheme 11
Release screw (1) on automatic reel (2).
Tightening torque 72 11 20AZ.
Remove automatic reel (2) in direction of arrow.
Installation
Coding (3) of automatic reel must be seated in opening (4) of body.
Scheme 12
Release screw (2).
Tightening torque 72 11 22AZ.
Remove seat belt (1).
Scheme 13
Installation
Secure fitting of seat belt (1) by means of stop (3) in guide.
72 11 096 Removing and installing/replacing rear left or right lower strap (belt buckle)
Necessary preliminary tasks
- Remove rear seat See «SEATS - REPAIR»(/bmw/m6/e63e64-2005-2010/remont/seats/#seats-repair) .
- (2) Seat belt buckle, left
- (3) Seat belt buckle, right
Release screw (1) on left and right.
Tightening torque 71 11 23AZ.
Remove relevant seat belt buckle.
Scheme 14
72 11 100 Removing and installing/replacing rear left or right seat belt (complete)
Necessary preliminary tasks
- Remove backrest for rear seat . See «SEATS - REPAIR»(/bmw/m6/e63e64-2005-2010/remont/seats/#seats-repair) .
Note. Illustration shows removal of left side. The right side is removed in the same way as the left side.
Note. Before removing reversing clip, mark position to ensure correct alignment when installing.
Release screw (1).
Tightening torque 72 11 24AZ.
Remove reversing clip (2).
Release screw (1) on automatic reel (2).
Tightening torque 72 11 20AZ.
Remove automatic reel (2) in direction of arrow.
Installation
Coding (3) of automatic reel must be seated in opening (4) of body.
Release screw (2).
Tightening torque 72 11 22AZ.
Remove seat belt (1).
Installation
Secure fitting of seat belt (1) by means of stop (3) in guide.
Note. The work step for "Removing and installing/replacing left or right seat belt" ends here.
Removing and installing/replacing rear left or right lower strap (belt buckle).
Necessary preliminary tasks
- Remove rear seat . See «SEATS - REPAIR»(/bmw/m6/e63e64-2005-2010/remont/seats/#seats-repair) .
- (2) Seat belt buckle, left
- (3) Seat belt buckle, right
Release screw (1) on left and right.
Tightening torque 72 11 23AZ.
Remove relevant seat belt buckle.
Scheme 15
Scheme 16
61 00 ... Repairing airbag cables
| IMPORTANT | Only repair those cables which show visible signs of damage. In the event of visible damage, make sure there is only one cable repair in effect after the repair work. If no visible damage can be identified, the entire cable must be replaced. When carrying out repairs to the airbag wiring harness, you must use the spare parts offered in the Electronic Parts Catalogue (EPC). |
Safety regulations
Safety regulations for handling components of airbag system. . See Safety regulations .
Instructions for disconnecting and connecting battery. See 61 00 ... BATTERY .
Procedure for cable repair
In event of non-visible damage to wiring harness
Disconnect plug connection on airbag module or on adapter plug. It is absolutely vital to disconnect the contacts in succession as there is a risk of them being mixed up! Cut through one cable after the other at an appropriate position, do not under any circumstances cut through both cables at the same time. Insulate cables remaining in wiring harness with insulating tape. Now disconnect plug connection on airbag control unit. Unpin contacts. Cut through one cable after the other at an appropriate position and insulate with insulating tape, do not under any circumstances cut through both cables at the same time. Pin contacts of repair cable for airbag control unit in control unit plug, assignment of repair cables is relevant. Lay repair cable in car parallel to existing airbag lead. Now pin in contacts for airbag control unit or contacts of adapter plug, assignment of repair cables is relevant. Cut off excess length of repair cable in proximity (visible area) of airbag module or of adapter plug. Twist open cables. With the connectors and shrink-fit hoses in the Electronic Parts Catalogue (EPC), reconnect the cables with the same cable colours. Twist cables again, open length (twist) must not exceed 40 mm. Secure interface (shrink-fit hoses) with insulating tape to prevent cables from twisting open.
Instructions for cutting off, insulating, crimping cables, installing and removing contacts
Cutting off and insulating cables.
Repairing a plug connection using connectors.
Installing and removing contacts. See PLUG CONNECTION TERMINAL .
In event of visible damage
Expose cable at damaged areas. Cut through one cable after the other at an appropriate position and insulate cables no longer required in wiring harness with insulating tape, do not under any circumstances cut through both cables at the same time. Now, depending on the scope of work, unpin contacts either on airbag control unit/airbag module or on adapter plug. Cut off unpinned cables. Insulate cables remaining in wiring harness with insulating tape. Now pin in contacts of repair cable, assignment of repair cables is relevant. Lay repair lead in car parallel to existing airbag lead up to cutting point. Cut off excess length of repair lead. Twist open cables. Connect cables with connectors and shrink-fit hoses in Electronic Parts Catalogue (EPC), assignment of repair cables is relevant. Twist cables again, open length (twist) must not exceed 40 mm. Secure interface (shrink-fit hoses) with insulating tape to prevent cables from twisting open.
Instructions for cutting off, insulating, crimping cables, installing and removing contacts
Cutting off and insulating cables.
Repairing a plug connection using connectors.
Installing and removing contacts. See PLUG CONNECTION TERMINAL .
Safety instructions
> Safety regulations for handling airbag modules, airbag components and pyrotechnical seat belt tensioners
> Notes on scrapping vehicles with gas generators
> Deactivation/activation pyrotechnical components
Handling electrical and electronic equipment
> Unlocking/locking airbag plug connections
> Repairing airbag leads . See PLUG CONNECTION TERMINAL .
> Handling optical fibres . See PLUG CONNECTION TERMINAL .
Check
Airbag system
It is essential to comply with the regulations as specified in the law relating to the use of explosives when working on airbag units and seat belt tensioners.
Airbags, seat belt tensioners etc. are pyrotechnical objects. Pyrotechnical objects are assigned to different danger classes on the basis of the quantity of propellant that they contain. The assignment can be ascertained from the identification marking on the product
| IMPORTANT | Failure to comply with the warning notices and repair instructions for gas generator components can cause accidental deployment and result in injury and vehicle damage! |
This applies in particular to the following components
- Airbag modules (driver's/front passenger airbags, side airbags)
- Buckle/belt tensioner
- Head airbag (ITS, AHPS)
- Active knee protection
- Active head restraint
- Safety battery terminal (SBK)
- Regulations The regulations quoted in the following refer to the Federal Republic of Germany. In all other countries, the relevant legislation and regulations must be observed in each case. Country-specific legal regulations that go beyond this information or court decisions based thereon must be followed in each case or given precedence over these regulations. The following components used by BMW: Pyrotechnical restraint systems are subject to danger class PT1 Gas generators are pyrotechnical objects belonging to danger class T1. Handling, transporting and storing non-fired gas generators are subject to the "Explosive Materials Act" (law relating to the use of explosives dated 13/09/1976). The relevant trade supervisory authority must be notified at least 2 weeks before pyrotechnical objects are handled for the first time. Here the relevant authority must be notified in writing of the person responsible (e.g. dealership owner, holder of general power of attorney or if necessary workshop supervisor). A certificate of qualification, i.e. specific training, is not required for the person responsible.
- Disassembly and assembly Inspection, testing and installation work may only be carried out by expert trained personnel in BMW Service. Work on components of the airbag system should only ever be carried out with the battery disconnected, the negative terminal post covered and the plug connection of the cable leading to the gas generator disconnected. If only the battery is disconnected, the following prescribed waiting period must be observed without fail: 30 minutes for vehicles up to 9/93; 1 minute for vehicles from 9/93 In the event of breaks in work, a component with a gas generator that has been removed must be secured against access by other persons. Individual components must never be repaired. Instead, always replace them. Do not treat airbag system components with cleaning agents or grease. Components of the airbag system must not be exposed to temperatures in excess of 75 °C. Airbag system components, including electronic diagnostic components, which have been dropped from heights in excess of 0.5 m must not be reinstalled in the vehicles. Before installing, subject airbag system components (including electronic diagnostic components) to a visual inspection for damage and replace if necessary. Airbag system components may only be electrically tested while they are installed and only with the BMW diagnostic system / DIS. Danger of injury: The airbag module may only be set down with the airbag itself facing upwards. Otherwise the generator will be thrown upwards if it is fired. Do not point the firing pellet of a gas generator at other persons. Components with gas generators must not be fired while they are removed. They must be disposed of by special disposal companies or returned to BMW in the packaging of the new components. When carrying out straightening and welding work with an electric welder: Disconnect battery. See «61 00 ... BATTERY»(/bmw/m6/e63e64-2005-2010/remont/horns/#general-electrical-system-repair__61-00-battery) . Cover negative terminal (post) Avoid all contact with the skin when removing a fired airbag module - wear gloves. Wash with water after contact with the skin.
- Transport Components with gas generators must be sent off in the packaging of the new components.
- Storage Observe the regulations of the relevant trade supervisory authority and the applicable national regulations.
72 12 ... Deactivating front passenger airbags with key-operated switch
| WARNING | The responsibility for deactivation/activation rests with the customer. Depending on the occupation of the front passenger seat, the front passenger and side airbags must be (de - )activated in accordance with the Owner's Handbook. |
The passenger airbag can only be deactivated in accordance with the following instructions if the vehicle is equipped with a suitable key-operated switch!
The key-operated switch can be retrofitted if it is missing and has been ordered as an optional extra.
Key-operated switch
- Optional extra SA 5DA for MINI
- Optional extra SA 470 for BMW
E83 up to 09/2004 only
E83 from 09/2004 only
Deactivation via key-operated switch, see following work steps
R50/R53 up to 04/2004 only
R50/R53 from 04/2004 only
Deactivation via key-operated switch, see following work steps
The following airbags are deactivated simultaneously with the key-operated switch (1)
- Passenger airbag
- Side airbag (passenger side)
- If necessary, knee airbag in US models (passenger side)
The airbags can only be deactivated/reactivated while the vehicle is stationary and with the door open.
Scheme 17
| IMPORTANT | The head airbag remains active. |
Deactivation
Scheme 18
- Turn key-operated switch with ignition key to "OFF" position. Deactivatable airbags on passenger side out of operation. Head airbag on passenger side remains active. All airbags on driver side remain active. Activation
- Turn key-operated switch with ignition key to "ON" position. All the airbags in the vehicle are activated and are triggered in appropriate situations.
Warning lamp
When the ignition key is turned in the ignition lock, the function of the airbag system is checked and the warning lamp in the center console lights up for several seconds.
Scheme 19
- The warning lamp is permanently lit when the passenger airbags are deactivated
- The warning lamp goes out after a few seconds when the passenger airbags are activated
72 12 ... Deactivation of airbags
| WARNING | The responsibility for (de-)activation rests with the customer. The airbags should always be deactivated if the front passenger seat is fitted with a child seat. Customer consent must be documented. Observe notes and instructions on (de -)activation procedure. |
The following airbags can be (de -)activated
- Passenger airbag
- Side airbag (front passenger), front
- Side airbag (front passenger), rear
| IMPORTANT | Head airbag on passenger side remains active. |
R50/R53 up to 04/2004 and E83 up to 09/2004 only
For details of deactivation, see following work steps.
R50/R53 from 04/2004 and E83 from 09/2004 only
Necessary preliminary tasks
- Read and comply with «Safety regulations»(/bmw/m6/e63e64-2005-2010/remont/airbag/#restraint-systems-repair__72-00-safety-regulations-for)
- Disconnect battery . See «61 00 ... BATTERY»(/bmw/m6/e63e64-2005-2010/remont/horns/#general-electrical-system-repair__61-00-battery) .
Passenger airbag
Note. Seat occupancy detector remains connected.
Scheme 20
- Expose plug connection of «passenger airbag»(/bmw/m6/e63e64-2005-2010/remont/airbag/#restraint-systems-repair__72-12-000-removing-and-installingreplacing)
- Disconnect «plug connection»(/bmw/m6/e63e64-2005-2010/remont/airbag/#restraint-systems-repair__72-12-unlockinglocking-airbag-plug)
- Tie back disconnected cable and secure with cable strap (rattling noises)
- Stick on warning signs (see below)
- Code airbag control unit (see DIS).
- Documentation of customer consent and storage in car's file
- Entry in car's documents (Germany only)
- Replacement of passenger belt with belt force limitation by version without belt force limitation
Side airbag, front
Scheme 21
- Expose plug connection of side airbag
- Disconnect plug connection of corresponding side airbags
- Tie back disconnected cables and secure with cable strap (rattling noises)
- Stick on warning signs (see below)
- Code airbag control unit (see DIS)
- Documentation of customer consent and work in car's file
- Entry in car's documents (Germany only)
Side airbag, rear
Scheme 22
- Expose plug connection of side airbag
- Disconnect plug connection of corresponding side airbags
- Tie back disconnected cables and secure with cable strap (rattling noises)
- Stick on warning signs (see below)
- Code airbag control unit (via CIP)
- Documentation of customer consent and work in car's file
- Entry in car's documents (Germany only)
Warning sign, passenger airbag
Scheme 23
- Stick on a warning sign (sourcing reference: BMW Parts Service - Component Group 01/Form BMW) with the text "Passenger airbag out of operation" from the inside to the top outer edge of the windshield on the passenger side.
Note. Remove the warning sign when the passenger airbag is reactivated.
Warning signs, side airbag
- Stick on 2 warning signs (sourcing reference: BMW Parts Service/Component Group 01 - Form BMW) with the text "Achtung Warning Side-Airbag" and "Side airbag out of operation" to the B-pillars (front side airbag) or C-pillars (rear side airbag) to the nearest free space below the door lock.
Note. Remove warning signs when reactivating side airbags.
Scheme 24
Passenger Airbag Off light (US version only)
- Remove Airbag Off indicator (POL) or trim
- Disconnect plug from Airbag Off indicator
- Tie back plug and secure with cable strap (rattling noises)
- Install trim
- Code airbag control unit
Function check (except US version)
The function of the airbag system is checked when the ignition key is turned in the ignition switch.
| Warning lamp lights up | Coding | ||
|---|---|---|---|
| Before | After | ||
| 1. | Warning lamp lights up continuously if an airbag is deactivated | X | |
| 2. | Warning lamp goes out after several seconds when airbags are deactivated | X | |
| 3. | Warning lamp goes out after several seconds when airbags are activated | X | X |
CODING OF AIRBAG CONTROL UNIT
Note. A coding of the airbag control unit must be carried out so that the warning lamp goes out again after deactivation.
72 12 ... Notes on scrapping vehicles with gas generators (airbag system)
The gas generator is a pyrotechnical component and is for the most part permanently mounted on the following components
- Airbag module Driver's/passenger airbag Side airbag Head airbag (e.g. AHPS2) Knee airbag
- Belt tensioner
- Belt buckle tensioner
- Safety battery terminal
- Active head restraint
In accordance with accident prevention regulations and specific national regulations, gas generators must be rendered unusable before they are scrapped. This is necessary because pyrotechnical objects can cause injury if improperly activated (e.g. scrapping with flame cutters).
With vehicles which are scheduled for scrapping, it is always essential prior to draining and further stripping work to ensure that all the gas generators in the vehicle are fired. The fired gas generators can then be scrapped together with the vehicle.
Gas generators that have not fired constitute a hazard (also to the environment)!
Firing failure
If correct firing is not possible, the relevant components must be removed and disposed of by special waste disposal companies!
Comply with Safety regulations for handling airbag system components.
If a firing operation has failed
- Disconnect the firing device from the battery and
- Only approach the vehicle after a few minutes have elapsed
The components of an airbag system must always be disposed of. Such components must not be sold on as used parts.
Firing
Firing of the gas generators may only be carried out by expert personnel and under the supervision of a responsible person. Other standard accident prevention regulations (safety goggles, ear defenders etc.) must also be observed.
The gas generators must be fired from the outside in this vehicle which has been earmarked for scrapping. In this process
- the doors must be closed
- the rear lid must be open
- the side windows must be open and
- the sunroof must be open
To fire the gas generators, use the firing device with the appropriate cables (follow instructions).
| WARNING | Once gas generators have been fired, observe a ventilation period of 10 minutes with the doors opened. Only then is it permitted to continue work inside the vehicle. Wear protective goggles and protective gloves when handling a fired gas generator! The burning of solid fuel will heat up the airbag unit - danger of burning hands! Wash skin with water after contact with fired gas generators! |
Scheme 25
72 12 ... Procedure after airbag triggering as result of an accident
Check and/or replace following components after airbag triggering
Satellites (control unit + sensor)
- Components Satellite, A-/B-pillar, left/right Satellite, front door Satellite, rear seat Satellite, driver's/front passenger seat Satellite, vehicle center
- Procedure Read out fault memory Disconnect battery and observe waiting period Rectify faults Reconnect battery and observe waiting period Clear fault memory Turn off ignition and wait at least 2 minutes (no consumers may be switched on during this period such as e.g. inside lights, radio, etc.) Switch ignition on. Clear fault memory and if necessary rectify faults
Cables and plugs
- Components and procedure Check cables and plugs for damage, replace if necessary.
Belt system
- Components Automatic safety belt tensioner Belt buckle tensioner Seat belt height adjustment
- Procedure Check components, replace if necessary
Seats
- Components Seat Airbag module Active head restraint
- Procedure Check seats (function check of seat mechanism), replace if necessary Check seat screw/bolt connections Replace gas generator of active head restraint system If the severity of the impact has not caused any other damage to the seat, only the triggered gas generator needs to be replaced. External feature: The triggered head restraint is folded forwards and engaged. The repair work can be carried out in the car with the rear panel removed. The entire system can be pushed back into its original position and the new gas generator installed. The gas generator can be replaced up to 5 times. Replace airbag module and seat cover with padding
Driver's airbag
- Components Airbag module Steering wheel Steering column (if damaged)
- Procedure Check components, replace if necessary Replace steering wheel
Passenger airbag
- Components Airbag module Instrument panel trim Supporting tube (if damaged)
- Procedure Check components, replace if necessary
Side airbag, front/rear
- Components Airbag module Door trim panel Door in white Seat
- Procedure Check components, replace if necessary
Head airbag (AHPS)
- Components Airbag module Trim, A-pillar Roofliner Trim, B-pillar (if damaged) Trim, C-pillar (if damaged) Bodyshell
- Procedure Check components, replace if necessary
Knee airbag
- Components Panel (driver's side) Lower section of glovebox Active knee protector (driver's and passenger sides)
- Procedure Check components, replace if necessary
Passive knee protector
- Components Panel (driver's side) Glovebox incl. knee protector (passenger side)
- Procedure Check components for damage, replace if necessary Check fastening elements
72 12 ... Unlocking/locking airbag plug connections
| WARNING | Read and comply with Safety regulations for handling airbag modules and pyrotechnical belt tensioners. |
| IMPORTANT | An airbag plug connection must be replaced if it is damaged. Sourcing reference for airbag repair instructions (with plug connection), refer to BMW Parts Service. |
Following versions of plug connections on airbag module/gas generator are possible
- Airbag plug connection on gas generator/airbag module is offset by 90°
- Airbag plug connection on gas generator/airbag module is straight (3 versions)
Airbag plug connection on gas generator/airbag module offset by 90°
There are two ways of unlocking this airbag plug connection on the gas generator/airbag module
Method 1
Simultaneously pull cover (1) upwards at lugs on left and right (2).
Scheme 26
Method 2
Insert a narrow screwdriver into recess (1) in housing (2).
Carefully pry cover (3) off (4).
Scheme 27
Cover (1) is not positioned higher than housing (2).
The airbag plug connection is unlocked and can now be detached from the gas generator/airbag module.
Scheme 28
Installation
After attaching airbag plug connection to gas generator/airbag module, press cover (1) downwards until it rests flat on housing.
Check that it catches properly.
Scheme 29
Airbag plug connection on gas generator/airbag module is straight (2 versions)
Version 1
Press locking/unlocking plate (1) at edge (4).
Locking/unlocking plate (1) snaps upwards at opposite edge (3) and releases detent lug (2).
Scheme 30
The airbag plug connection is unlocked and can now be detached from the gas generator/airbag module.
Scheme 31
Installation
After attaching airbag plug connection to gas generator/airbag module, check whether detent lug (2) is visible in opening of locking/unlocking plate (1).
Only if the detent lug (2) is visible will the airbag plug connection gas generator/airbag module be correctly engaged.
Scheme 32
Version 2
Press locking/unlocking plate (1) on edge (3) and pull plug (2) out of plug housing (4).
Installation
Only if the detent lug is visible in opening (5) will the gas generator/airbag module plug connection be correctly engaged.
Scheme 33
Version 3
Press lock button (1) and pull out plug (2) up to initial engagement position.
Detach plug (2) from firing pellet.
Installation
Insert plug connection in initial engagement position in gas generator/airbag module and engage in final engagement position.
Scheme 34
Illustration of version 3 with gas generator
- Initial engagement position
- Final engagement position
Scheme 35
- Lock button
- Gas generator
Version 4 - Crash-active head restraint
Press locking clip at edge and disconnect plug (1).
Installation
Check for correct engagement.
Scheme 36
72 12 000 Removing and installing/replacing airbag module on passenger side
| WARNING | Read and comply with Safety regulations for handling airbag modules and pyrotechnical belt tensioners. Incorrect handling can activate airbag and cause injury. |
Necessary preliminary tasks
- Disconnect battery negative lead . See «61 00 ... BATTERY»(/bmw/m6/e63e64-2005-2010/remont/horns/#general-electrical-system-repair__61-00-battery) .
- Follow instructions for unlocking and locking airbag plug connections. See «Unlocking/locking airbag plug connections»(/bmw/m6/e63e64-2005-2010/remont/airbag/#restraint-systems-repair__72-12-unlockinglocking-airbag-plug) .
- Remove glovebox with housing. See «51 16 366 REMOVING AND INSTALLING RIGHT GLOVEBOX WITH HOUSING (WITHOUT ACTIVE KNEE PROTECTION)»(/bmw/m6/e63e64-2005-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair__51-16-366-removing-and-installing) .
Version (E60/E61) with front drinks holder
- Remove front outer cup holder carrier
- Release front inner cup holder carrier
Inner carrier can only be removed together with airbag module.
Unfasten plug connection (1) and disconnect. Remove plug connection from holder (by turning).
| IMPORTANT | Before releasing screws (3), secure airbag module (2) against falling out. |
E63/ E64
Release screws (3) and carefully feed out airbag module (2) towards bottom.
E60
Release screws (3); if necessary, slide front inner cup holder carrier slightly to one side.
Carefully remove airbag module (2), if necessary with front inner cup holder carrier, towards bottom rear.
Scheme 37
Installation
When inserting airbag module (1) in channel (2), make sure channel rests all round airbag module. If necessary, pull channel apart at sides.
Replace screws.
Tightening torque 72 12 02AZ.
Scheme 38
72 12 010 Removing and installing/replacing airbag module on left or right front door
| WARNING | Read and comply with Safety regulations for handling airbag modules and pyrotechnical belt tensioners. Incorrect handling can activate airbag and cause injury. Front and rear airbag modules must not be mixed up. |
Necessary preliminary tasks
- Disconnect battery negative lead . See «61 00 ... BATTERY»(/bmw/m6/e63e64-2005-2010/remont/horns/#general-electrical-system-repair__61-00-battery) .
- Remove front door trim . See «41 FRONT DOOR TRIM PANEL»(/bmw/m6/e63e64-2005-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair) .
Unfasten screws.
Carefully remove airbag module.
Installation
Before installing airbag module, remove all foreign bodies (screws, etc.) from installation recess.
Replace screws.
Tightening torque 72 12 01AZ.
Scheme 39
72 12 040 Removing and installing/replacing left or right AFPS1 head airbag (version without glass tilt sunroof)
| WARNING | Read and comply with Safety regulations for handling airbag modules and pyrotechnical belt tensioners. Incorrect handling can activate head airbag and cause injury. The AHPS head airbag must be replaced if it is damaged during removal or installation. A damaged AHPS head airbag exhibits an impaired protective function and in extreme cases loses its protective function altogether. |
Necessary preliminary tasks
- Disconnect battery negative lead . See «61 00 ... BATTERY»(/bmw/m6/e63e64-2005-2010/remont/horns/#general-electrical-system-repair__61-00-battery) .
- Follow instructions for unlocking and locking airbag plug connections. See «Unlocking/locking airbag plug connections»(/bmw/m6/e63e64-2005-2010/remont/airbag/#restraint-systems-repair__72-12-unlockinglocking-airbag-plug) .
- Remove roofliner . See «44 ROOF TRIM PANEL»(/bmw/m6/e63e64-2005-2010/remont/door-locks-anti-theft-systems/#body-equipment-repair) .
Scheme 40
Release all screws (1) on holder (2).
Tightening torque 72 12 03AZ.
Release rear screw.
Tightening torque 72 12 04AZ.
Remove rear AHPS1.
Scheme 41
Release front screws (1 and 2).
Tightening torques
- Screw 1 72 12 04AZ
- Screw 2 72 12 06AZ
Carefully feed gas generator out of guides towards rear, unlocking and disconnecting plug (3) in the process.
Remove gas generator completely.
Scheme 42
Note. View of retaining screw with anchor fitting of AHPS1 head airbag
Scheme 43
- Anchor fitting, AHPS1 head airbag
- Lock washer
- Retaining screw
72 12 041 Removing and installing/replacing left or right AFPS1 head airbag (version with glass tilt sunroof)
| WARNING | Read and comply with Safety regulations for handling airbag modules and pyrotechnical belt tensioners. Incorrect handling can activate head airbag and cause injury. The AHPS head airbag must be replaced if it is damaged during removal or installation. A damaged AHPS head airbag exhibits an impaired protective function and in extreme cases loses its protective function altogether. |
Note. Except for the operations for Removing headliner, this task is identical to: Removing and installing/replacing left or right AHPS head airbag (version without glass tilt sunroof). See 72 12 040 Removing and installing/replacing left or right AFPS1 head airbag (version without glass tilt sunroof) .
72 14 ... Removing and installing/replacing Top Tether eyelets for child seat
Note. Two or three Top Tether eyelets are installed, depending on the model.
Lever out covers (1) and release screws underneath.
Remove Top Tether eyelets (2).
Tightening torque 52 24 03AZ.
Scheme 44
| IMPORTANT | Ensure Top Tether eyelets (1) are in correct installation position. It must be possible for Top Tether eyelets (1) to be tilted in the direction of head restraints (2). |
Scheme 45
See also:
• 61 00 ... REPAIRING AIRBAG CABLES
• 61 00 ... NOTES ON HANDLING OPTICAL FIBERS
• 61 00 ... BATTERY
• 51 43 002 REMOVING AND INSTALLING REAR LEFT OR RIGHT SIDE TRIM PANEL
• 51 43 ... REMOVING AND INSTALLING/REPLACING TRIM ON ARMREST OF LEFT OR RIGHT SIDE TRIM PANEL
• SEATS - REPAIR
• PLUG CONNECTION TERMINAL
• 51 16 366 REMOVING AND INSTALLING RIGHT GLOVEBOX WITH HOUSING (WITHOUT ACTIVE KNEE PROTECTION)
• 41 FRONT DOOR TRIM PANEL
• Safety regulations
• Notes on scrapping
• Deactivation/activation pyrotechnical components
• Unlocking/locking airbag plug connections
• Check seat belt
• Checklist for seat belt
• Deactivating airbags
• Procedure after airbag triggering
• passenger airbag
• 72 12 040 Removing and installing/replacing left or right AFPS1 head airbag (version without glass tilt sunroof)
