00 Danger of poisoning if oil is ingested/absorbed through the skin

Danger of poisoning!

Ingesting oil or absorbing through the skin may cause poisoning!

Possible symptoms are

1. Headaches
2. Dizziness
3. Stomach aches
4. Vomiting
5. Diarrhoea
6. Cramps/fits
7. Unconsciousness

Protective measures/rules of conduct

1. Pour oil only into appropriately marked containers
2. Do not pour oil into drinking vessels (drinks bottles, glasses, cups or mugs)
3. Observe country-specific safety regulations

First aid measures

1. Do not induce vomiting. If the person affected is still conscious, he/she must rinse out their mouth with water, drink plenty of water and consult a doctor immediately. If the person affected is unconscious, do not administer anything by mouth, place the person in the recovery position and seek immediate medical attention.

00 Risk of injury if oil comes into contact with eyes and skin

Danger of injury!

Contact with eyes or skin may result in injury!

Possible symptoms are

1. Impaired sight
2. Irritation of the eyes
3. Reddening of the skin
4. Rough and cracked skin

Protective measures/rules of conduct

1. Wear protective goggles
2. Wear oil-resistant protective gloves
3. Observe country-specific safety regulations

First aid measures

1. Eye contact: Rinse eyes immediately with plenty of water for at least 15 minutes; if available, use an eye-rinsing bottle. If irritation of the eyes persists, consult a doctor.
2. Skin contact: Wash off with soap and water immediately. If irritation persists, consult a doctor.

Note. Do not use solvents/thinners.

00 Safety instructions for handling oil

Risk of injury if oil comes into contact with eyes and skin!

Recycling

Observe country-specific waste-disposal regulations.

Measures if oil is unintentionally released

1. Personal precautionary measures: Danger of slipping! Keep non-involved persons away from the work area. Wear personal protective clothing/equipment.
2. Environmental protection measures: Prevent oil from draining into drain channels, sewerage systems, pits, cellars, water and the ground.
3. Limiting spread: Use oil blocks to prevent the surface spread of oil.
4. Cleaning procedure: Bind and dispose of escaped oil with nonflammable absorbents.

Note. Do not flush oil away with water or aqueous cleaning agents.

Scheme 1

Scheme 2

Scheme 3

00 ... ... Information on service functions for twin clutch transmission (GS7D36SG)

Note. The service functions must be carried out in the relevant order!

TWIN CLUTCH TRANSMISSION SERVICE FUNCTIONS CHART

00 ... ... Lifting vehicle with a lifting platform

Note. The lifting platform must comply with the relevant statutory accident prevention regulations and be serviced according to the manufacturer's instructions.

Scheme 4

00 ... ... Raising vehicle with trolley jack

Scheme 5

Scheme 6

Risk of damage: It is not permitted to raise the vehicle at the rear differential cover!

Scheme 7

1. Car jacking point on front axle carrier (all-wheel drive)

00 0 Test specifications for technical vehicle inspection

TECHNICAL VEHICLE INSPECTION SPECIFICATIONS CHART

00 00 ... Battery: Checking display. If necessary, recharge battery

Vehicles with low-maintenance battery

Check acid level, top up with distilled water if necessary

If level drops below Max. marking, top up distilled water to Max. marking.

Vehicles with maintenance-free battery

Check charge start by way of magic eye

00 00 ... Body and underbody: checking for corrosion and damage

Inspect chassis, underbody and wheel arches and check for corrosion and damage.

Note. It is absolutely essential to rectify any identified faults after consulting the customer and to issue a separate invoice.

00 00 ... Body: Check for corrosion (except cavities)

1. Visually inspect underbody and attachment parts (brake lines, exhaust system branch, sills) for corrosion and check for damage.
2. Check wheel arches for corrosion.
3. Open doors and check A-, B- and C-pillars for corrosion, especially door hinges.
4. Check door frame for corrosion, folding back door seal slightly if necessary.
5. Check outer body for stone impacts, scratches or damage to paintwork and associated corrosion.

Check brake lines and connections

1. Visual inspection in visible area for: Check brake fluid level in expansion tank leaks traces of fluid damage crushing/flattening correct routing of brake lines correct seating of brake lines in holders

Note. Detected faults must urgently be repaired after consultation with the customer!

00 00 ... CBS reset

The CBS service jobs can be reset in the car with the on-board computer button on the direction indicator/main-beam switch. It is only possible to code the statutory intervals specific to individual countries with the diagnosis system. It is always recommended to reset the CBS jobs via the diagnosis system.

Resetting service-relevant jobs

CBS reset in the car

Note. First carry out the service measure. Resetting of a service job must always be carried out after the service measure has been completed.

Note. Perform reset according to instructions. The resetting procedure is aborted by a timeout or a terminal change.

The service jobs can be reset in the car at the instrument cluster. Here, the availability of a service job is set to 100 % again (corresponding to a new part).

The availability is an internal computing value (not visible to the user).

Observe the following procedure when resetting with the trip odometer reset button

1. Switch on terminal 15.
2. Press the trip odometer reset button for approx. 10 seconds until the 1st service job appears in the LC display.
3. The upper display in the speedometer is illuminated by a service symbol (e.g.: an oil can denotes an oil change). The lower display in the speedometer indicates the time or distance remaining until the next service (e.g.: 14000). Set desired maintenance scope with the rocker switch on the direction indicator/main-beam switch.
4. To reset, press the on-board computer button on the direction indicator/main-beam switch until the message "RESET" appears.
5. Resetting is confirmed by pressing the on-board computer button for a slightly longer period.
6. A clock is displayed during resetting.
7. A check/tick is displayed after "RESET" on successful resetting.
8. Repeat the procedure for each additional service which is to be reset.

Note. Resetting increases the service counter. Each reset increases the service counter of the respective job by 1. The service counter is used in the SAM on a job-specific basis to control additional tasks.

Note. Sorting is chronological. The service jobs are sorted in chronological order. The most critical job is displayed first.

Note. Vehicle inspection and exhaust emission test are country-specific. The statutory intervals specific to individual countries are coded with the diagnosis system.

CBS reset with diagnosis system

1. The CBS jobs can be reset via the diagnosis system on the following path: => Diagnosis => Function selection => Service functions => Maintenance => CBS reset
2. The individual CBS items are displayed in the BMW diagnosis system with service counter and availability.
3. The service counter is increased by 1 during the reset. All service counters are set to "1" on new vehicles.
4. Availability is set to 100 % during the reset. It is basically a display quantity indicating the wear level of the job. The greater the availability, the more distant is the next service appointment. 0 % means that the service item must be carried out.

00 00 ... Check windscreen wash/wipe system

1. Check wipe pattern for smearing; if necessary, replace wiper blades after consulting with customer
2. The spray jet must emerge uniformly from the spray nozzle , replace nozzle if necessary and issue a separate invoice

00 00 ... Checking coolant level and concentration, correcting if necessary

1. Check connections, hose clamps and hoses for coolant residues and damage such as e.g. cracks.
2. Check coolant level in expansion tank. Coolant level must be between Min. and Max. markings. If necessary, top up coolant to max. fill level. If there is no coolant, also identify the cause and notify the customer.
3. In event of topping up: Check concentration with antifreeze tester (special tool) in coolant expansion tank.

If necessary, drain off the difference quantity at the coolant drain plug and top up with recommended coolant (issue a separate invoice).

Horn

Check function.

Note. In the case of twin-tone fanfares, make sure that both fanfares are working properly.

Headlight flasher

Activate headlight flashers, check high-beam headlights and blue indicator lamp in instrument cluster for correct operation.

Hazard warning system

Check function.

Note. After consultation with the customer, rectify faults and issue a separate invoice.

Instrument lighting

Check function of instrument and indicator/warning lamps.

Indication field lighting

Check function of light switches; dimmer; controls; heater/air conditioning; rear window demister; radio; (depending on equipment) on-board computer; power windows; electric sunroof; fog lamp.

Heater

Check function of all blower stages, air distribution and air outlet.

Note. After consultation with the customer, rectify faults and issue a separate invoice.

00 00 ... Checking lighting system

1. Check lighting system for correct operation: Check headlights, rear lights and associated telltale/indicator lamps Check headlight adjustment Check side lights, parking lights, dipped-beam and main-beam headlights for correct operation Check headlight flasher for correct operation Check signal horn Check left/right direction indicators and hazard warning system for correct operation Check brake lights for correct operation Check reversing lights and license plate lights for correct operation Check front and rear fog lights for correct operation Check interior lights (assembly: interior lights, footwell lights, luggage compartment lights, glovebox light) for correct operation Check instrument and indication field lighting

00 00 ... Checking roadworthiness (test drive)

1. Checking roadworthiness Take vehicle for a test drive, checking service and parking brakes in the process For vehicles with rear disc brakes, brake in parking brake as instructed Check function of parking brake Check steering for play, ease of movement and directional stability Check clutch for problem-free disengagement and non-spasmodic driving off at normal operating temperature Check function of all drive positions and driving programs in cars with automatic transmissions Visually inspect shock absorbers for leaks Check indicator/warning lamps and Check Control system for correct operation Check due date for statutory roadworthiness and exhaust emission tests and advise customer of test dates

00 00 ... Diagnostic brief test

Connect diagnostic system to OBD socket.

Switch on ignition.

Carry out vehicle identification.

Click on Brief test.

The brief test is carried out.

Note. For motor vehicle diagnostics, the brief test is essential for evaluating possible stored diagnostic trouble codes. In the brief test, the control units are physically identified in succession and their fault memories read out. If the fault memory has been read out, the faults appear in the "Fault pattern selection" mask in the "Fault memory contents" field. Check identified faults and if necessary rectify these faults after consulting with customer.

Scheme 8

INFORMATION/WARNING LABELS LOCATION REFERENCE

Key

US = United States

CDN= Canada

CCC= Car Communication Computer

OBD= On-Board Diagnosis

00 00 ... Microencapsulated screws

Screw locking is a means to preventing a screwed connection from being loosened by external influences.

After the screw has been coated with the adhesive, the adhesive remains inactive until it is activated by capsule breakage when the screw is inserted and then cures at room temperature.

Installation

1. Microencapsulated screws (Loctite) must be replaced and may not be reused
2. Screw connection must be completed within 20 mins. (start of curing)
3. Microencapsulated screws must not be retightened
4. Thread of nut must be cleaned beforehand in event of repeated use

00 00 ... Raising BMW multi-trailer

The lifting platform must comply with the relevant statutory accident prevention regulations and be serviced according to the manufacturer's instructions. It is essential to follow the lifting platform operating instructions, in particular the safety instructions and carrying capacity!

Make sure you adhere to the BMW-recommended work area of 5 x 7 m and to an escape route of 0.6 m between two lifting platforms.

Before raising the BMW multi-trailer, please observe the following points

1. Raise the trailer only when it is unloaded
2. Remove a supplied loading ramp from the loading ramp frame so that all chassis areas of the BMW multi-trailer are freely accessible
3. There must be sufficient clearance between the carrier arms/flat girder bridges and the GFK aprons or the front guard of the BMW multi-trailer
4. The BMW multi-trailer must always be positioned in the middle of the lifting platform.

The areas (2) on the longitudinal members (1) marked in the adjacent diagram are the best areas for attaching the additional supports.

Scheme 9

General notes on using twin-pillar lifting platforms

For the twin-pillar lifting platforms described, the BMW multitrailer is positioned in the direction of travel on the platform. For lifting platforms which do not create sufficient clearance between disk wheel and carrier arms, move the BMW multitrailer against the direction of travel onto the platform.

Becker & Sohne twin-strut underfloor platform

The BMW multi-trailer can only be raised if it is supported at right angles to the direction of travel. For raising, use the high additional supports (1) of Becker&Sohne.

Scheme 10

MAHA twin-pillar lifting platform

The BMW multi-trailer can only be raised if you use the support plate attachment sleeves for transporters (1). Position the axle of the BMW multi-trailer in the direction of travel in front of the pillars of the platform in order to obtain the specified lifting ranges and to establish sufficient clearance between disk wheel and carrier arms. The long carrier arms raise the front and the short carrier arms raise the rear of the BMW multi-trailer.

Scheme 11

Romaico-Lift twin-pillar lifting platform

The BMW multi-trailer can only be raised if you use the 146 mm high attachments (1). Position the axle of the BMW multi-trailer in the direction of travel in front of the pillars of the platform in order to obtain the specified lifting ranges and to establish sufficient clearance between disk wheel and carrier arms. The long carrier arms raise the front and the short carrier arms raise the rear of the BMW multi-trailer.

Scheme 12

Working pit

The BMW multi-trailer can be serviced or repaired in conjunction with a working pit if the following measures are taken into consideration. The BMW multi-trailer must be secured against slipping/tilting sideways. The drawbar jockey wheel must be firmly secured against rolling.

00 00 ... Resetting CBS display according to factory specification

For further information on how to proceed, refer to CBS RESET with Tester.

Belt strap, retractor mechanism, belt interlock

Pull out strap and make sure it emerges without jerking.

Check belt strap for

1. folding
2. unravelling
3. pinches
4. cracks and tears
5. traces of melting
6. clip as retractor lock

Retract belt strap; here the inertia reel mechanism must retract the strap automatically and without squeaking noises, the last section of the strap may have to be fed in.

Pull out belt strap in short tugs - locking reel must lock.

Belt buckle

The tongue on the belt strap must easily snap into place with an audible click.

When the "Press" button is pressed, the tongue must be ejected from the buckle under spring pressure.

Note. If the seat belt is damaged, you must replace the seat belt completely after consulting the customer; issue a separate invoice for this work. Instructions on how to proceed, refer to CHECKING AUTOMATIC SEAT BELT .

00 00 ... Steering components: checking for zero clearance, leaks, damage and wear

Checking play

Scheme 13

1. For hydraulically assisted steering systems, the engine must be running
2. For electrically assisted steering systems, the ignition must be on
3. Steering wheel: Move steering wheel back and forth and check for play
4. Tie rod joint: There must no clearance between tie rod arm (2) and tie rod joint (1).

Checking for leaks

The following illustration shows the arrangement of the power steering components and lines.

Scheme 14

Check all visible connections, hoses, lines and steering gear for traces of fluid.

Checking for damage and wear

Check gaiters, flexible disc and axle and tie rod sleeves for damage (e.g. cracks, holes), for leaks or missing clamping bands on gaiters.

00 00 ... Steering fluid reservoir: Check oil level

Visual inspection and leak test

Check connections, hoses and steering gear for traces of fluid.

Checking fluid level

Check fluid level with engine switched off at expansion tank of power steering/ride-height control system. The fluid temperature should be approx. 20°C here.

Ensure that the cap is fully screwed in prior to the fill level check.

If necessary, add hydraulic fluid.

Scheme 15

Note. To avoid mix-ups when filling with hydraulic fluid, mark the fluid reservoirs or their caps with identification marks.

ATF Automatic transmission fluid

CHF Pentosin CHF11S

Scheme 16

00 00 ... Tyres: checking inflation pressure, correcting if necessary (incl. spare wheel), checking external condition, tread depth, pattern

1. Checking tyre inflation pressure: Check tyre inflation pressure in accordance with information plate on B-pillar The inflation pressure in the spare wheel must be 0.5 bar higher than the maximum specified value on the information plate Initialize Run Flat Indicator
2. Checking tyre condition: Check tread depth of all tyres with tyre tread gauge Check tyre tread surfaces and side walls for incisions and foreign particles such as nails or screws Check tyre tread pattern for localized flattening and wear on one side; if necessary, carry out wheel/chassis alignment after consulting with customer and issue a separate invoice for this work

Note. For reasons of driving safety, only use tyres of the same type and tread pattern on a single vehicle Inform customer of any incorrect or worn tyres

00 00 ... Underbody incl. all visible components: checking for damage, leaks, corrosion

1. Visually inspect underbody: For leaks (transmission, fuel system, brake components, steering) For correct routing of electrical leads (brake pad sensor, pulse generator) For leaks (shock absorber) and mounting (springs) - rebound Damage to underbody Corrosion on underbody

00 00 ... Windscreen washer system: checking fluid level, topping up if necessary

1. Top up windscreen washer fluid reservoir, if necessary rear window washer fluid reservoir and (depending on equipment specification) intensive cleaning reservoir up to edge or mark.

00 00 005 Interrogating fault memories in Diagnosis System

Connect diagnostic system to OBD socket.

Switch on ignition.

Carry out vehicle identification.

Click on Brief test.

The brief test is carried out.

Note. For motor vehicle diagnostics, the brief test is essential for evaluating possible stored diagnostic trouble codes. In the brief test, the control units are physically identified in succession and their fault memories read out. If the fault memory has been read out, the faults appear in the "Fault pattern selection" mask in the "Fault memory contents" field.

00 00 105 Standard scope of service

1. Standard scope of service Diagnosis brief test (US only) Check Check Control messages Check telltale and warning lamps Reset CBS display

00 00 555 Interrogating fault memories in diagnosis system

Connect diagnostic system to OBD socket.

Switch on ignition.

Carry out vehicle identification.

Click on Brief test.

The brief test is carried out.

Note. For motor vehicle diagnostics, the brief test is essential for evaluating possible stored diagnostic trouble codes. In the brief test, the control units are physically identified in succession and their fault memories read out. If the fault memory has been read out, the faults appear in the "Fault pattern selection" mask in the "Fault memory contents" field.

00 00 602 Service - intake muffler

1. Change air cleaner element in accordance with repair instructions. See «13 72 001 REPLACING AIR FILTER ELEMENT (S65)»(/bmw/m3/e90-2007-2013/remont/fuel-system/#fuel-system-repair-e9293__13-72-001-replacing-air-filter) .
2. Reset CBS display according to factory specification

00 00 610 Service - engine oil (S65)

1. Service - engine oil Change engine oil and oil filter . See «11 00 ... SERVICE - ENGINE OIL (S65)»(/bmw/m3/e90-2007-2013/remont/mechanical/#engine-repair-e9293__11-00-service-engine) . Parking brake Brake in and check for correct function A/C system or automatic A/C: Change microfilter . See «64 31 011 REPLACING MICROFILTER FOR INTERIOR VENTILATION»(/bmw/m3/e90-2007-2013/remont/automatic-hvac-system/#heating-and-air-conditioning-repair-e9293__64-31-011-replacing-microfilter-for) . At 1st and every 3rd engine oil change CAUTION: Twin clutch transmission - no transmission fluid change required (Lifetime oil) Manual transmission: «Change gearbox oil»(/bmw/m3/e90-2007-2013/remont/oem-general-information/#maintenance-and-general-information-repair-e9293__00-11-229-changing-topping) , clean oil filter ( not applicable to twin clutch gearboxes ) Change «rear differential oil»(/bmw/m3/e90-2007-2013/remont/oem-general-information/#maintenance-and-general-information-repair-e9293__00-11-checkingtopping-up-oil) At every 2nd engine oil change Intake muffler: change air filter element. See «13 72 001 REPLACING AIR FILTER ELEMENT (S65)»(/bmw/m3/e90-2007-2013/remont/fuel-system/#fuel-system-repair-e9293__13-72-001-replacing-air-filter) . Shorten intervals accordingly for vehicles operated in dusty regions. At every 3rd engine oil change Replace spark plugs . See «12 12 011 REPLACING ALL SPARK PLUGS (S65)»(/bmw/m3/e90-2007-2013/remont/gauges-instrument-panels/#engine-electrical-system-repair-e9293__12-12-011-replacing-all-spark) . Reset CBS display according to factory specification

00 00 612 Service - front brakes

1. Service - front brakes Change brake pads , clean brake air ducts. See «34 11 000 REMOVING AND INSTALLING/REPLACING BRAKE PADS ON BOTH FRONT DISC BRAKES (M3)»(/bmw/m3/e90-2007-2013/remont/mechanical-hydraulic/#brakes-repair-e92e93__34-11-000-removing-and-installingreplacing) . Brake discs Check surface and thickness If necessary: Replace Reset CBS display according to factory specification

Note. Clean brake air ducts. Replace brake discs if they are below the minimum brake disc thickness and if scoring, heat cracks or thickness difference are detected. See BRAKES - TECHNICAL DATA . Apply a thin coat of grease to wheel centering on light alloy wheels. Issue a separate invoice for replacing the brake discs.

00 00 614 Service - rear brakes

1. Service - rear brakes Change brake pads , clean brake air ducts. See «34 21 200 REMOVING AND INSTALLING OR REPLACING BRAKE PADS ON BOTH REAR DISC BRAKES (TEVES FLOATING CALIPER)»(/bmw/m3/e90-2007-2013/remont/mechanical-hydraulic/#brakes-repair-e92e93__34-21-200-removing-and-installing) . Brake discs Check surfaces and thickness. If necessary: Replace Handbrake Check condition, brake lining thickness and function If necessary: Replace Reset CBS display according to factory specification

Note. Clean brake air ducts. Replace brake disks if they drop below minimum thickness . See BRAKES - TECHNICAL DATA . In event of scoring, heat cracks or thickness difference. Apply a thin coat of grease to wheel centering on light alloy wheels. Issue a separate invoice for replacing the brake discs and handbrake shoes.

00 00 616 Service - microfilter

1. Service - microfilter Heating/air conditioning: change microfilter / carbon canister . See «64 31 011 REPLACING MICROFILTER FOR INTERIOR VENTILATION»(/bmw/m3/e90-2007-2013/remont/automatic-hvac-system/#heating-and-air-conditioning-repair-e9293__64-31-011-replacing-microfilter-for) . Reset CBS display according to factory specification

00 00 618 Service - brake fluid

1. Service - brake fluid Changing brake fluid . See «34 00 025 REPLACING FLUID IN ABS/ASC+T BRAKE SYSTEM»(/bmw/m3/e90-2007-2013/remont/mechanical-hydraulic/#brakes-repair-e92e93__34-00-025-replacing-fluid-in) . Reset CBS display according to factory specification

00 00 622 Service - spark plugs

1. Service - spark plugs Replace spark plugs . See «12 12 011 REPLACING ALL SPARK PLUGS (S65)»(/bmw/m3/e90-2007-2013/remont/gauges-instrument-panels/#engine-electrical-system-repair-e9293__12-12-011-replacing-all-spark) . Reset CBS display according to factory specification

00 11 ... Checking/topping up oil level in rear differential (M3)

Undo oil filler plug (1).

Check oil level.

If necessary, pour in rear differential oil up to lower edge of opening for oil filler plug (1).

Installation

Replace oil filler plug.

Tightening torque 33 11 3AZ , see FINAL DRIVE WITH COVER .

Scheme 17

00 11 229 Changing / topping up / checking gear oil in manual transmission

Recycling

Catch and dispose of gear oil with suitable equipment.

Observe country-specific waste-disposal regulations.

Necessary preliminary tasks

1. Remove rear underbody protection. See «51 47 491 REMOVING AND INSTALLING/REPLACING REAR UNDERBODY PROTECTION»(/bmw/m3/e90-2007-2013/remont/door-locks-anti-theft-systems/#body-equipment-repair-e9293-m3__51-47-491-removing-and-installingreplacing) .

Draining gear oil

1. Open oil drain plug (1) and drain gear oil
2. Activate gear oil pump using DIS Tester for approx. 30 seconds The residual oil is pumped out of the pump circuit of the transmission oil cooler into the transmission housing and flows off
3. Allow gear oil to flow off sufficiently
4. Clean oil drain plug (1) and screw in. See «OIL DRAIN PLUG TIGHTENING TORQUE»(/bmw/m3/e90-2007-2013/remont/oem-general-information/#maintenance-and-general-information-repair-e9293) .

OIL DRAIN PLUG TIGHTENING TORQUE

Release screw (1).

Tightening torque 40 Nm .

Check transmission oil screen, replace if necessary.

Scheme 18

Installation

Replace sealing ring

Scheme 19

Adding gear oil.

1. Undo oil filler plug (2).
2. Pour in oil until it overflows at inspection opening.
3. Check gear oil level (see below).

Checking gear oil level

Note. Can also be carried out individually - without an oil change!

1. Activate gear oil pump via DIS Tester.
2. Open oil filler plug.
3. Top up gear oil with pump running to lower edge of filler opening.
4. Refit oil filler plug. Tightening torque, see «OIL DRAIN PLUG TIGHTENING TORQUE»(/bmw/m3/e90-2007-2013/remont/oem-general-information/#maintenance-and-general-information-repair-e9293) .
5. Switch off pump activation.

00 11 259 Oil change in rear differential incl. used oil disposal

Note. Only change oil when rear differential is at normal operating temperature.

Recycling

Catch and dispose of emerging differential oil.

Observe country-specific waste-disposal regulations

Place oil collecting apparatus underneath.

Open plug (1).

Drain and dispose of differential oil.

Replace screw plug.

Tightening torque 33 11 3AZ , see FINAL DRIVE WITH COVER .

Open plug (2).

Add differential oil up to lower edge of opening for screw plug (2) for necessary fill quantity.

Replace screw plug.

Tightening torque 33 11 3AZ , see FINAL DRIVE WITH COVER .

Scheme 20

28 00 ... Checking/topping up fluid level in twin clutch transmission (GS7D36SG)

Checking fluid level

1. Call up Service functions (Drive) in BMW diagnosis system
2. Carry out fluid level check in accordance with instructions

Installation

Tighten down filler plug using

Scheme 21

1. Hexagon wrench 8 A/F
2. Torque wrench
3. Socket 8 A/F

Topping up transmission fluid after a repair

Stand vehicle on a level surface and secure against rolling off.

Scheme 22

1. Open fluid adjustment screw (1). If fluid emerges, close screw again immediately If no fluid emerges, top up until fluid emerges and close fluid adjustment screw (1) again NOTE: If fluid has been replenished here, a further refill must be carried out during the actual fluid adjustment
2. Start engine (drive position N or P)
3. Record transmission temperature using Tester
4. (Drive position P)
5. Permissible starting temperature < or = 32°C
6. Idle speed: maintain at approx. 2000 RPM for 1 minute.
7. Open fluid adjustment screw (1)
8. Fill until fluid emerges Max. transmission fluid temperature 40°C
9. Insert screw

Installation

Replace screw.

Tightening torque: 22-28 Nm .

61 00 ... Notes on handling wiring harnesses and cables

In general

To avoid damage, observe the following instructions

1. Avoid compressive and tensile loads
2. Make sure cables are laid without kinks or abrasions
3. Ensure non-contacting routing at sharp-edged body parts; use muckets if necessary
4. Secure additionally laid cables/leads with cable ties

In addition

Shielded cables (coaxial cables)

1. This may lead to indifferences in noise radiation and interference immunity at contact points in the shield
2. To satisfy the requirements of the type approval, it is essential to replace shielded cables completely

Fibre-optic cables

Note. Fibre-optic cables are coloured differently as follows

1. Green = MOST (M edia O riented S ystems T ransport) fibreoptic cables
2. Yellow = ISIS (I ntegrated S ervice I nformation S erver) fibreoptic cables
3. Orange=repair fibre-optic cables

Treating cables and fibre-optic cables

FlexRay

It is possible to repair the FlexRay. In the event of damage, the cables can be joined with conventional butt connectors.

Note. The cable is a twisted cable. If possible, maintain twisted cable after repair.

86 10 ... Positioning of multitrailer hood for maintenance and repair work

For maintenance and repair work, raise the hood using a lifting platform. Twin-column lifting platforms, body lifting platforms and twin-stamp underfloor platforms are suitable. The seating plates and areas of the lifting platform must be adjustable according to the dimensions of (Scheme 23).

Scheme 23

The lifting platform must conform to the relevant legal provisions of the accident prevention regulations and be serviced as specified. Comply with the lifting platform operating instructions, in particular the safety instructions and the carrying capacity.

Make sure you adhere to the BMW-recommended work area of 5 x 7 m and to an escape route of 0.6 m between two lifting platforms.

Please comply with the following instructions before raising the hood

1. Raise only when it is unloaded
2. Ensure sufficient clearance between the seating plates/seating areas and the GFP edge of the hood
3. The hood must always be positioned in the middle of the lifting platform.

Scheme 24

See also:
• 61 00 ... SAFETY INSTRUCTIONS FOR HANDLING VEHICLE BATTERY
• BATTERY CHARGING
• CHECKING AUTOMATIC SEAT BELT
• 13 72 001 REPLACING AIR FILTER ELEMENT (S65)
• 11 00 ... SERVICE - ENGINE OIL (S65)
• 64 31 011 REPLACING MICROFILTER FOR INTERIOR VENTILATION
• 12 12 011 REPLACING ALL SPARK PLUGS (S65)
• 34 11 000 REMOVING AND INSTALLING/REPLACING BRAKE PADS ON BOTH FRONT DISC BRAKES (M3)
• BRAKES - TECHNICAL DATA
• 34 21 200 REMOVING AND INSTALLING OR REPLACING BRAKE PADS ON BOTH REAR DISC BRAKES (TEVES FLOATING CALIPER)
• 34 00 025 REPLACING FLUID IN ABS/ASC+T BRAKE SYSTEM
• FINAL DRIVE WITH COVER
• MANUAL TRANSMISSION - OPERATING FLUIDS
• 51 47 491 REMOVING AND INSTALLING/REPLACING REAR UNDERBODY PROTECTION
• CBS RESET
• Change gearbox oil
• rear differential oil
• OIL DRAIN PLUG TIGHTENING TORQUE
