35 11 000 Removing and installing complete bearing block for foot pedal
Necessary preliminary tasks
- Remove «clutch pedal»(/bmw/m3/e90-2007-2013/remont/mechanical-hydraulic/#pedals-repair-e9293__35-31-000-removing-and-installing) .
Release screws (1) and gently press clutch master cylinder (2) to one side.
Installation
Line remains connected.
Replace self-locking nuts.
Tightening torque see. 21 52 CLUTCH OPERATION (HYDRAULIC) .
Scheme 111
Disconnect plug connection (1).
Remove locking clip (2) and pull out pin.
Unscrew nut (3).
Release nuts (4) and gently swivel bearing block to left and remove.
Installation
Tighten nuts (4) before nut (3).
Replace self-locking nuts.
Tightening torque, see 35 11 PEDAL ASSEMBLY CONSOLE .
Scheme 112
35 21 041 Replacing spring for brake pedal
Necessary preliminary tasks
- Remove trim panel for pedal assembly . See «51 45 185 REMOVING AND INSTALLING/REPLACING PANEL FOR PEDALS»(/bmw/m3/e90-2007-2013/remont/door-locks-anti-theft-systems/#body-equipment-repair-e9293-m3__51-45-185-removing-and-installingreplacing) .
Disconnect return spring (1).
Scheme 113
35 31 041 Replacing spring for clutch pedal
Necessary preliminary tasks
- Remove trim panel for pedal assembly . See «51 45 185 REMOVING AND INSTALLING/REPLACING PANEL FOR PEDALS»(/bmw/m3/e90-2007-2013/remont/door-locks-anti-theft-systems/#body-equipment-repair-e9293-m3__51-45-185-removing-and-installingreplacing) .
Disconnect return spring (1).
Scheme 114
35 31 000 Removing and installing or replacing clutch pedal
Necessary preliminary tasks
- Remove pedal trim . See «51 45 185 REMOVING AND INSTALLING/REPLACING PANEL FOR PEDALS»(/bmw/m3/e90-2007-2013/remont/door-locks-anti-theft-systems/#body-equipment-repair-e9293-m3__51-45-185-removing-and-installingreplacing) .
- If necessary, remove «over-centre helper spring»(/bmw/m3/e90-2007-2013/remont/mechanical-hydraulic/#pedals-repair-e9293__35-31-050-removing-and-installingreplacing)
Disconnect return spring (1).
Press end of pin (2) together with offset pliers and press out pin.
Detach locking clip (3) and pull clutch pedal off bearing block.
Installation
Replace locking clip (3).
Locking clip (3) must be seated with both legs in the pin groove.
Scheme 115
Installation
Check bearing bushings (1) and replace if necessary.
Lightly grease bearing bushings (1).
Scheme 116
35 31 011 Replacing bearing bushes for clutch pedal
Operation is described in
Necessary preliminary tasks
- Remove trim panel for pedal assembly . See «51 45 185 REMOVING AND INSTALLING/REPLACING PANEL FOR PEDALS»(/bmw/m3/e90-2007-2013/remont/door-locks-anti-theft-systems/#body-equipment-repair-e9293-m3__51-45-185-removing-and-installingreplacing) .
Disconnect return spring (1).
35 31 050 Removing and installing/replacing overcentre helper spring
Necessary preliminary tasks
- Remove pedal trim . See «51 45 185 REMOVING AND INSTALLING/REPLACING PANEL FOR PEDALS»(/bmw/m3/e90-2007-2013/remont/door-locks-anti-theft-systems/#body-equipment-repair-e9293-m3__51-45-185-removing-and-installingreplacing) .
Press end of pin (1) together with offset pliers and press out pin.
Scheme 117
Push in pin (1) fully in direction of arrow.
Scheme 118
Detach retainers (1).
Installation
Check retainers, replace if necessary.
Retainers must lie with both legs in the groove and snap audibly into place.
Slide out pin (2).
Installation
Lightly grease pin.
Scheme 119
Remove over-centre helper spring (3).
There are two versions
- Over-centre helper spring
- Reinforced over-centre helper spring
Assembly of over-centre helper spring
- Secure black holder (1) to clutch pedal
- Smaller coil spacing of spring (2) points to black holder (1)
- Secure grey holder (3) to bearing block
Lightly grease holder and spring contact surfaces.
Scheme 120
Installation
Secure over-centre helper spring first with black holder to clutch pedal.
Gently press over-centre helper spring together and secure with grey holder to bearing block.
Connect clutch pedal to clutch master cylinder.
When replacing reinforced over-centre helper spring
Remove locking clamp (1).
Scheme 121
35 40 001 Removing and installing or replacing accelerator pedal module
Take off cap.
Release screw.
Pull accelerator pedal module upwards out of fixture.
Installation
Tightening torque, see 35 40 PEDALS .
Scheme 122
Pull off plug (1).
Remove accelerator pedal module.
Scheme 123
| IMPORTANT | Accelerator pedal module can only be replaced completely with adapter plate. |
