Fuel System - Special Tools -- e90 BMW M3 E90

Adapter Minimum set: Mechanical tools MW

Note. (Adapter hose with coupling connector) For the DIS pressure sensor or pressure gauge 13 3 061 for measuring the fuel feed pressure

Storage Location

C3

A3

B3

SI number

01 18 96 (163)

Scheme 99

Consisting of

1 = 0491311 Adapter

Note. (Adapter hose)

2 = 0491312 Adapter

Note. (Adapter) For connecting the DIS pressure sensor

Adapter MW

Replaced by: 0491221

Note. Replaced by 13 0 094 (0 491 221)

B15

Note. For activating the diagnostic function of the CNG control unit (indicator light in the instrument panel), and for actuating the high pressure shut-off valve

W 2..

01 14 95 (014)

Scheme 100

Scheme 101

Device MW

Replaced by: 0491020

Note. (Centering device) For oil pump - Replaced by 11 4 100 (0 491 020)

Note. For checking fuel pressure and oil pressure

Consisting of

1 = 0491260 Pressure gauge

Note. (Pressure gauge 0...25 bar)

2 = 0491261 Valve

Note. (Valve) 2-way valve, engine: all except S50, S54, N73

3 = 0491262 Lines

Note. (Connection lines (2 x)) For check of fuel and oil pressure

4 = 0491263 Lines

Note. (Connection line) With T-piece for L-Jetronic, all except N73

5 = 0491264 Connection piece

Note. (Connection piece, distributor) All except N73

Scheme 102

6 = 0491265 Connection piece

Note. (Connection piece warm-up sensor) All except N73

7 = 0491266 Hose

Note. (Connecting hose) For checking fuel pump fuel delivery rate, all except N73

= 0491267

8 = 0491267 Connection piece

Note. (Connection piece, distributor) All except N73

9 = 0491268 Connection piece

Note. For warm-up sensor with hose, all except N73

Lines Minimum set: Mechanical tools MW

Note. Two fuel lines. Auxiliary lines for 13 3 060. For fuel pressure check in all direct injectors in comb. with IMIB and 100 bar sensor.

01 27 09 (598)

Consisting of

1 = 0496824 Lines

Note. With connection for 13 3 060 or 11 4 310.

2 = 0496825 Lines

3 = 0496826 Fastener

Scheme 103

Measuring device MW

Note. (measuring device) With connection parts for checking and adjusting low pressure regulator

01 14 95 (014)

Consisting of

1 = 0491362 Measuring device

Note. (measuring device) Without adapter hoses

Scheme 104

2 = 0491363 Adapter

Note. (adapter hose (2 pieces)) With M6connecting nipple and quick-release coupling

3 = 0491364 Adapter

Note. (adapter hose) With counterpiece for quick-release coupling

4 = 0491365 Adapter

Note. (adapter hoses) With T-piece for intake pressure connection

5 = 0491366 Adapter

Note. (adapter hose) With quick-release coupling and ring connection with banjo bolt for testing the output pressure at the metering unit

Probe MW

Replaced by: 0491217

Note. (Exhaust gas probe) For vehicles with catalytic converter - Other: only Japan and USA Replaced by 13 0 090 (0 491 217)

Puller Minimum set: Mechanical tools MW

Note. For removing injector nozzles or injectors from cylinder head

A11

B11

01 06 98 (306)

Consisting of

5 = 0495579 Adapter

Note. For removing steering shaft on E85. Refer to SI 01 11 06 (265)

Scheme 105

1 = 0493338 Rod

Note. (Guide rod)

2 = 0493339 Bush

Note. (Threaded bush)

3 = 0493340 Weight

Note. (Weight)

4 = 0493379 Claw

Note. (Clamping claw) For dismantling injector nozzles/engine: M57

Scheme 106

Terminal Minimum set: Mechanical tools MW

Note. (Hose clip) For removing a hose during repair work

Scheme 107
