Fuel Supply System - Special Tools -- e90

Fuel Supply System - Special Tools -- e90 BMW M3 E90

Fuel System 6 illustrations ~230 words

Adapter MW

Note. For connecting the workshop compressed air supply to the CNG system via the CNG filling connection.

SI number

01 14 95 (014)

Scheme 108

Scheme 108: SI number

Hose Minimum set: Mechanical tools MW

Note. (Hose guide) For unlocking new fuel tank flap systems with safety lock (incorrect fuelling, diesel/gasoline)

Storage Location

B19

01 16 06 (282)

Scheme 109

Scheme 109: SI number

Lifting gear MW

Note. (Lifting beam) For removing and installing the gas tank

01 14 95 (014)

Scheme 110

Scheme 110: SI number

Pin wrench Minimum set: Mechanical tools MW

Note. For removing and installing fuel level sensor in fuel tank

01 04 99 (425)

Consisting of

1 = 0493639 Pin wrench

Note. (Pin wrench)

2 = 0493640 Adapter

Note. (Adapter) 2 pieces Model series: E46, E38, E39, R50, R53

Scheme 111

Scheme 111: SI number

Plug MW

Note. (Plug (carbon canister)) For sealing the carbon canister (ECE) for leakage test

C49

01 14 01 (766)

Scheme 112

Scheme 112: SI number

Tester MW

Note. (tester with test adapter) leakage test for fuel tank and fuel filler cap

01 10 00 (593)

Consisting of

1 = 0493734 Tester

2 = 0493735 Adapter

Note. (test adapter for fuel filler cap)

Scheme 113

Scheme 113: SI number

3 = 0493736 Adapter

Note. (test adapter for fuel filler cap)

4 = 0493737 Adapter

Note. (test adapter for fuel tank)

5 = 0494557 Hose

Note. (connection hose)

6 = 0495345 Plug

Note. (seal plug)
