17 00 009 Checking cooling system for leaks (S65)
| WARNING | Danger of scalding! Only perform this work after engine has cooled down. |
Protective measures/rules of conduct
- Wear protective goggles
- Wear protective gloves
- Observe national/country-specific regulations
| IMPORTANT | Risk of slipping due to coolant on the floor. |
Danger of injury!
Catch and dispose of drained coolant in drip tray (1) and if necessary special tool 00 2 030 00 2 030 DEVICE (universal hydraulic lifter).
Recycling
Observe country-specific waste-disposal regulations.
Scheme 42
Checking pressure drop in cooling system
Open cap on coolant expansion tank. Fit special tools 17 0 101/17 0 113.
Build up gauge pressure of 2 bar, wait approx. 2 minutes.
Cooling system is impervious to leaks if pressure drop is max. 0.1 bar.
Scheme 43
Checking pressure relief valve in cap
Note. Coolant residue can cause the pressure relief valve in the cap to stick, therefore repeat the check procedure on the cap 2-3 times.
Screw cap (1) onto special tool 17 0 114.
Build up pressure with special tool 17 0 101 (hand pump); observe pressure gauge to ascertain when opening pressure is achieved.
Scheme 44
17 00 005 Draining and adding coolant (S65)
| WARNING | Risk of scalding! Only carry out repair work on the cooling system after the engine has cooled down! Risk of skidding due to coolant on the floor. |
Protective measures/rules of conduct
- Wear safety goggles
- Wear protective gloves
- Observe national/country-specific regulations
| IMPORTANT | Lifetime coolant filling: Never reuse used coolant! When replacing and removing components which rely on the corrosion protection effect of the coolant, it is essential to change the coolant. The cooling system must therefore be drained and refilled. In the case of other removal work involving the draining of partial quantities of coolant, replace these quantities which have been drained with new coolant. |
| IMPORTANT | For dirt contamination of the cooling system (e.g. by engine oil), the cooling system must be rinsed with water until all dirt contamination is removed! |
| IMPORTANT | Risk of skidding due to coolant on the floor. |
Danger of injury!
Catch and dispose of drained coolant in drip tray (1) and if necessary special tool 002030 DEVICE (universal hydraulic lifting equipment).
Recycling
Observe country-specific waste disposal regulations.
Necessary preliminary work
- Remove «FRONT UNDERBODY PROTECTION»(/bmw/m3/e90-2007-2013/remont/door-locks-anti-theft-systems/#body-equipment-repair-e90__51-47-490-removing-and-installingreplacing)
- «FOLLOW NOTES FOR REPAIR WORK ON COOLING SYSTEM»(/bmw/m3/e90-2007-2013/remont/cooling-system-mechanical/#cooling-system-repair-e90__17-00-instructions-for-working-on)
Draining coolant
Open sealing cap (1) on coolant expansion tank (2).
Scheme 45
If fitted, release drain connector (1) on coolant radiator.
On coolant radiators which do not have a drain connector, remove coolant hose.
Drain, catch and dispose of coolant from radiator.
Scheme 46
Installation note
Replace sealing ring.
Adding coolant
17 00... Instructions for working on cooling system
| WARNING | Danger of scalding! Work on the cooling system should only be carried out when the engine has cooled down. |
| IMPORTANT | Wear protective gloves and safety goggles. |
| IMPORTANT | Lifetime coolant filling: Never reuse used coolant. When replacing and removing components which rely on the corrosion protection effect of the coolant, it is essential to change the coolant. The cooling system must therefore be drained and refilled. In the case of other removal work involving the draining of partial quantities of coolant, replace these quantities which have been drained with new coolant. |
| IMPORTANT | Open cooling system only when it has cooled down. Opening the cooling system while hot can result in air entering the system. This can cause overheating with permanent damage to the engine. |
| IMPORTANT | You must protect the alternator against contamination before carrying out any work on the cooling circuit. Cover alternator with suitable materials. Failure to comply with this procedure may result in an alternator malfunction. |
| IMPORTANT | Do not fill coolant expansion tank over MAX level as overfilling will cause the coolant to overflow. This may give rise to traces of residual coolant on the expansion tank or in the engine compartment and wrongly suggest possible leakages. |
Recycling
Catch and dispose of drained coolant.
Observe country-specific waste-disposal regulations.
Note. To disconnect coolant hoses, use commercially available disconnect tools such as HAZET brand tools (see table).
| HAZET no. | Description |
|---|---|
| 4590-1 | Disconnect tool, length (mm): 150 |
| 4590-2 | Disconnect tool, length (mm): 180 |
| 4590-3 | Disconnect tool, length (mm): 253 |
| 4590/2 | Disconnect/plier set |
| 4590/3 | Disconnect/plier set |
HAZET BRAND TOOLS REFERENCE CHART
Scheme 47
Note. Tightening torque, hose clamps 17 00 1AZ .
Scheme 48
Instructions for disassembly/assembly of coolant hose quick-connect couplings
Disassembly of quick-connect coupling
Pull out lock (1) and (2). Pull off hose.
Scheme 49
Installation
Check O-rings (1).
Do not coat O-rings (1) with antiseize agent.
Scheme 50
Assembly of quick-connect coupling
Press in lock (1) before installing fast-release coupling.
Push on hose.
Quick-connect coupling must clearly snap audibly into place.
Scheme 51
17 00... Notes on retrofitting a trailer towing device
Starting with delivery of the E90, in certain vehicle types, the size of the electric cooler fan will be linked to the optional extra trailer tow hitch or trailer provision.
A larger fan may therefore be required for retrofits.
The larger fan is necessary to ensure mountain driving with a full trailer load in accordance with BMW-internal specifications. Otherwise the engine electronics will detect possible overheating of the cooling system and activate protective functions.
For the customer, this involves impaired A/C output, automatic transmission and engine power. These will be continuously reduced, which in the end may result in the vehicle coming to a standstill in the mountain area.
00 Safety information for working on vehicles with automatic engine start-stop function (MSA)
| WARNING | If the engine hood/bonnet contact is pulled upwards (workshop mode), the information "switch closed" is output. The automatic engine start-stop function is active. An automatic engine start is possible. |
Observe safety precautions when working on MSA vehicles
Before carrying out practical work on the engine, always ensure that the MSA functionality is deactivated so as to prevent automatic engine starting while work is being carried out in the engine compartment.
MSA function is deactivated by
- Deactivate MSA by means of button (1) in passenger compartment
- Open seat belt buckle and driver's door
Scheme 52
Scheme 53
- Open engine bonnet/hood and ensure that engine hood/bonnet contact is not in workshop mode Workshop mode A = 10 mm Basic setting (engine hood/bonnet open) B = 7 mm To make sure that the engine hood/bonnet contact is at the basic setting, if necessary press the hood/bonnet contact up to the limit position before starting work and slowly release.
When working with diagnosis tools
- Observe instructions in diagnosis tool
17 00 039 Venting and filling cooling system with vacuum filling unit
| Type | Engine | Number |
|---|---|---|
| E60/E61/E63/E64 | All | 17 0 113 |
| E65/E66 | M54/N52/N62/N62T/N73 | 17 0 105 |
| E65/E66 | M57S/M57T/M67/M67T | 17 0 113 |
| E70/E71/E72 | All | 17 0 113 |
| E81/E82/E84/E87/E88/E89 | All | 17 0 113 |
| E83 | M54/N46/N52K | 17 0 105 |
| E83 | M47S/M57S/M57T/M57Y/N47 | 17 0 113 |
| E85/E86 | All | 17 0 105 |
| E90/E91/E92/E93 | All | 17 0 113 |
| F01/F02/F03/F04/F07/F10 | All | 17 0 113 |
| R50/R52 | W10 | 17 0 107 and 17 0 102 |
| R50 | W17 | 17 0 109 |
| R52/R53 | W11 | 17 0 109 |
| R55/R56/R57/R60 | All | 17 0 109 |
| F25 | All | 17 0 113 |
SPECIAL TOOLS DESCRIPTION CHART
| IMPORTANT | Lifetime coolant filling: Never reuse used coolant! When replacing and removing components which rely on the corrosion protection effect of the coolant, it is essential to change the coolant. The cooling system must therefore be drained and refilled. In the case of other removal work involving the draining of part quantities of coolant, replace these quantities which have been drained with new coolant. |
| IMPORTANT | You must protect the alternator against contamination by coolant when carrying out repair work on the cooling circuit. Cover alternator with suitable materials. Failure to comply with this procedure may result in an alternator malfunction. |
Note on ordering
- Workshop equipment
- Workshop equipment catalogue
- Filler unit no. 81 39 2 152 473
- Collecting vessel no. 81 49 2 152 347
- Adapter: 170100
| IMPORTANT | Risk of slipping due to coolant on the floor. Danger of injury! |
Catch and dispose of emerging coolant in drip tray (1) and if necessary special tool 00 2 030 DEVICE (universal hydraulic lifting equipment).
Recycling
Observe country-specific waste disposal regulations.
| IMPORTANT | Check all the coolant hoses before filling the cooling system with the vacuum filling unit. If necessary, replace damaged and porous coolant hoses. |
Scheme 54
- 1) Filling unit with vacuum meter and shut-off valves
- 2) Filler hose
- 3) Coolant container
- 4) Venturi nozzle
- 5) Compressed air connection (max. 6 bar)
- 6) Outgoing-air hose (lead outgoing-air hose into a collecting container)
Requirements
- Cooling system expansion tank must be empty.
- There must be sufficiently premixed coolant in the filling unit container, 1-2 liters more than the vehicle filling capacity. Observe capacities.
- Position the filling unit container at the same height as the coolant expansion tank.
- Compressed-air connection with 6 bar pressure present.
- Set vehicle heater to maximum temperature.
Select adapter (Y) according to table and connect to coolant expansion tank.
Connect filler unit to adapter connection (X).
Scheme 55
Shut-off valves (A) and (B) of the filling unit (1) must be closed.
X) Expansion tank connection
Scheme 56
Connect venturi nozzle (1) to filling unit (2).
X) Expansion tank connection
Scheme 57
Connect compressed air (1).
X) Expansion tank connection
Scheme 58
Open shut-off valve (B).
The venturi nozzle produces a flow noise.
Scheme 59
Then open shut-off valve (A) until the filling hose (1) is free of bubbles.
Close shut-off valve (A) again. The filling hose (1) is vented in this way.
Scheme 60
Shut-off valve (B) remains open. Generate vacuum in coolant system for approx. 2 minutes. The final vacuum is reached at a vacuum of -0.7 to -0.95 bar. Green scale on the vacuum meter.
Note. The coolant hoses contract during vacuum build-up.
Then close shut-off valve (B) again.
Scheme 61
Both shut-off valves (A) and (B) must be closed. Then seal Venturi nozzle (1).
Scheme 62
The cooling system must hold the vacuum for 30 seconds. If the needle in the vacuum meter falls, this indicates a leak in the cooling system.
If the vacuum remains constant, proceed with filling.
In event of leaks, check cooling system for leaks.
Scheme 63
| IMPORTANT | There must be sufficiently premixed coolant in the filling unit container, 1-2 liters more than the vehicle filling capacity. Position the filling unit container at the same height as the coolant expansion tank. |
Shut-off valve (B) remains closed during the filling process.
To fill the cooling system, open shut-off valve (A) to filling unit container.
Scheme 64
Coolant is now added.
The filling process is finished when the needle in the vacuum meter is at 0 bar or no longer falls.
If necessary, reduce remaining vacuum. Open shut-off valve (B) to do so.
Scheme 65
Remove filling unit with adapter from expansion tank.
Adjust coolant level to max.
Close coolant expansion tank.
Scheme 66
Check function of cooling system.
Check cooling system for leaks.
17 00 039 Venting cooling system and checking for water leaks (S65)
| WARNING | Danger of scalding! Open sealing cap only after engine has cooled down. |
Only when refilling!
| IMPORTANT | Do not fill coolant expansion tank over MAX level as overfilling will cause the coolant to overflow. This may give rise to traces of residual coolant on the expansion tank or in the engine compartment and wrongly suggest possible leakages. |
Only when refilling!
Perform filling operation slowly.
Adjust coolant level to MAX.
Close coolant expansion tank.
Installation
Close cap (1) until the arrow marks line up.
| IMPORTANT | The following venting procedure is necessary e.g. when a part is replaced in the cooling system or when the cooling system is refilled. |
Only when filling!
- Perform filling operation slowly.
- Set heater to maximum temperature and turn fan down to lowest speed.
- Start engine and run at idle speed.
- Fill coolant expansion tank with 250 ml above max. (250 ml correspond to A=18 mm).
- Run engine for 15 mins.
- Cooling system vents itself.
- Coolant level must drop to marking.
- If necessary, correct coolant level.
- Close cap on expansion tank.
Scheme 67
Note. If necessary, check COOLING SYSTEM FOR WATER LEAKS .
64 53... Instructions for replacement of air conditioning capacitors and radiator/coolers
| IMPORTANT | Even when they are correctly installed or due to normal driving, coolers (oil cooler, radiator, charge air cooler) or air conditioning capacitors may show slight impressions or deformations on their discs (picture). This is not damage. Radiators, cooler or capacitors are not to be replaced in this case. |
Note. The deformations shown in illustration "1" (Scheme 68) can be bent back with a standard fin comb.
Damage to lines carrying media or on the flat pipe require replacement of the radiator/ or air conditioning condenser. Examples of such damage are shown in illustrations "2", "3", "4", "5", and "6" (Scheme 68)
Scheme 68
17 11 046 Removing and installing/replacing module carrier
Necessary preliminary tasks
- Remove coolant cooler
- If necessary, slacken power steering cooling coil; refer to «REMOVING POWER STEERING COOLING COIL»(/bmw/m3/e90-2007-2013/remont/cooling-system-mechanical/#cooling-system-repair-e90__17-11-370-removing-and-installingreplacing)
- If necessary, slacken A/C condenser and secure against damage and against falling down. Refer to «REMOVE A/C CONDENSER»(/bmw/m3/e90-2007-2013/remont/automatic-hvac-system/#heating-and-air-conditioning-repair-e90__64-53-550-removing-and-installing) .
Release damping pieces.
Scheme 69
Press lock (1) and remove holder (2) downwards.
Illustration shows the left holder: The same procedure applies to the opposite side.
Installation
Rubber mounts fall out easily, ensure correct installation position.
S65 only: Engine oil cooler loose, see REMOVING OIL COOLER .
Scheme 70
Remove module carrier (1) individually towards bottom.
Scheme 71
When replacing module carrier
Convert power steering COOLING LOOP .
17 11 000 Removing and installing radiator (N51, S65)
| WARNING | Danger of scalding! Only perform this work after engine has cooled down. |
| IMPORTANT | Wear protective goggles and gloves. |
Necessary preliminary tasks
- Follow «INSTRUCTIONS FOR WORKING»(/bmw/m3/e90-2007-2013/remont/cooling-system-mechanical/#cooling-system-repair-e90__17-00-instructions-for-working-on) on cooling system
- Remove intake duct (S65).
- Remove «INTAKE FILTER HOUSING»(/bmw/m3/e90-2007-2013/remont/fuel-system/#fuel-system-repair-e90__13-71-000-removing-and-installingreplacing)
- Remove «FAN COWL»(/bmw/m3/e90-2007-2013/remont/cooling-system-mechanical/#cooling-system-repair-e90__17-11-035-removing-and-installingreplacing)
- Draining «COOLANT»(/bmw/m3/e90-2007-2013/remont/cooling-system-mechanical/#cooling-system-repair-e90__17-00-005-draining-and-adding)
- Unlock coolant hoses and detach
If fitted
- Remove heat exchanger for automatic transmission fluid
Automatic only
Release bolt and detach hose (1).
Scheme 72
Release screws.
Carefully feed out radiator (1) towards top and remove.
Note. Illustration shows N54.
Scheme 73
17 11 100 Removing and installing/replacing coolant expansion tank (S65)
Necessary preliminary tasks
- Drain «COOLANT»(/bmw/m3/e90-2007-2013/remont/cooling-system-mechanical/#cooling-system-repair-e90__17-00-005-draining-and-adding) from radiator
Unlock coolant hoses and detach.
Release screws.
Raise expansion tank slightly until plugs on coolant level switch and lower coolant hose are accessible.
Unlock plugs on coolant level switch and lower coolant hose and disconnect.
Remove coolant expansion tank.
Installation
Insert locating pin in rubber grommet.
Scheme 74
VENT COOLING SYSTEM and check for leaks.
17 11 370 Removing and installing/replacing cooling loop for power steering (N54, N52, N52K, N51, N53, S65)
| WARNING | Danger of scalding! Only perform this work after engine has cooled down. |
| IMPORTANT | When working on the oil and cooling circuits, protect the alternator against dirt/contaminants. |
Cover alternator with suitable materials.
Failure to comply with this procedure may result in an alternator malfunction.
Necessary preliminary tasks
- After completing this operation, check «FLUID LEVEL»(/bmw/m3/e90-2007-2013/remont/manual-power-steering/#steering-and-wheel-alignment-repair-e90__32-13-006-bleeding-power-steering) in power steering fluid reservoir.
- Remove «RADIATOR»(/bmw/m3/e90-2007-2013/remont/cooling-system-mechanical/#cooling-system-repair-e90__17-11-000-removing-and-installing)
Press lines (1) in direction of cooling coil (2), pull back locking ring towards rear. Keep locking ring pressed and detach lines (1) from cooling coil (2).
| IMPORTANT | Catch and dispose of emerging oil. |
Scheme 75
Unlock seal (1) in direction of arrow and remove.
Release screw.
Note. Lines of A/C system remain connected to condenser.
Scheme 76
Press lock (1) upwards.
Carefully tilt condenser (2) in direction of engine, taking care not to damage the condenser or lines in the process.
Scheme 77
Press lock (1).
Unclip cooling coil (2) from holder (3) and remove.
Scheme 78
17 11 150 Removing and installing/replacing engine oil cooler (S65)
Necessary preliminary tasks
- Remove «FRONT BUMPER TRIM»(/bmw/m3/e90-2007-2013/remont/door-locks-anti-theft-systems/#body-equipment-repair-e90__51-11-156-removing-and-installing) Remove «FRONT UNDERBODY PROTECTION»(/bmw/m3/e90-2007-2013/remont/door-locks-anti-theft-systems/#body-equipment-repair-e90__51-47-490-removing-and-installingreplacing)
| WARNING | Danger of scalding! Only perform this work after engine has cooled down. |
Recycling
Engine oil escapes when oil lines are released. Catch and dispose of emerging engine oil.
Observe country-specific waste-disposal regulations.
Slacken nut (1).
Detach oil line from engine oil cooler.
Catch and dispose of escaping oil.
Installation
Replace sealing ring.
Unscrew screws (2).
Scheme 79
Slacken nut (1).
Detach oil line from engine oil cooler.
Catch and dispose of escaping oil.
Release screw (2).
Remove engine oil cooler (3).
Installation
Replace sealing ring.
Add final details to vehicle.
After completing work, check engine oil level and top up if necessary.
Scheme 80
17 11 035 Removing and installing/replacing fan cowl with electric fan (S65)
| IMPORTANT | Risk of short circuits! When removing fan cowl, protect plug and housing against moisture; dry with compressed air if necessary. |
Necessary preliminary tasks
- Read out fault memory of DDE control unit; if necessary, work through test schedules
- Switch off ignition
- Remove «FRONT UNDERBODY PROTECTION»(/bmw/m3/e90-2007-2013/remont/door-locks-anti-theft-systems/#body-equipment-repair-e90__51-47-490-removing-and-installingreplacing)
- Remove intake duct (S65).
- Unclip coolant lines from fan cowl.
Unlock connector and remove.
| IMPORTANT | Risk of short circuits! |
When removing fan cowl, protect plug and housing against moisture; dry with compressed air if necessary.
Scheme 81
Release retaining screw (1) for fan cowl.
Unclip cable.
Unclip vent lines.
Turn lower hose holder through 90°.
Remove fan cowl (2) towards top.
Scheme 82
Installation
When installing fan cowl, make sure guide tabs are correctly positioned.
Add final details to vehicle.
Clear DME fault memory.
17 11 190 Removing and installing/replacing oil line for engine oil cooler (S65)
| WARNING | Danger of scalding! Only perform this work after engine has cooled down. |
| IMPORTANT | Wear protective gloves and goggles. |
Recycling
Catch and dispose of drained oil in a suitable container.
Comply with the waste disposal regulations applicable in the relevant countries.
Necessary preliminary tasks
Remove underbody protection
Disconnect lines on engine oil cooler, refer to REMOVING ENGINE OIL COOLER
| IMPORTANT | When working on the oil, coolant or fuel circuit, you must protect the alternator against contamination. Cover alternator with suitable materials. Failure to comply with this procedure may result in an alternator malfunction. |
Unfasten nut.
Remove holder from oil cooler line (1).
Scheme 83
Unclip coolant hoses from holders.
Cover ribbed V-belt with cleaning cloth or similar.
Release nuts and remove oil lines from filter housing.
Scheme 84
Note. Add final details to vehicle. After completing work, check and correct engine oil level.
Necessary preliminary tasks
- Remove «FRONT BUMPER TRIM»(/bmw/m3/e90-2007-2013/remont/door-locks-anti-theft-systems/#body-equipment-repair-e90__51-11-156-removing-and-installing) . Remove «FRONT UNDERBODY PROTECTION»(/bmw/m3/e90-2007-2013/remont/door-locks-anti-theft-systems/#body-equipment-repair-e90__51-47-490-removing-and-installingreplacing)
| WARNING | Danger of scalding! Only perform this work after engine has cooled down. |
Recycling
Engine oil escapes when oil lines are released. Catch and dispose of emerging engine oil.
Observe country-specific waste-disposal regulations.
Slacken nut (1).
Detach oil line from engine oil cooler.
Catch and dispose of escaping oil.
Installation
Replace sealing ring.
Unscrew screws (2).
Slacken nut (1).
Detach oil line from engine oil cooler.
Catch and dispose of escaping oil.
Release screw (2).
Remove engine oil cooler (3).
Installation
Replace sealing ring.
Add final details to vehicle.
After completing work, check engine oil level and top up if necessary.
| WARNING | Danger of scalding! Only perform this work after engine has cooled down. |
| IMPORTANT | Wear protective gloves and goggles. |
Recycling
Catch and dispose of drained oil in a suitable container.
Comply with the waste disposal regulations applicable in the relevant countries.
Necessary preliminary tasks
Remove underbody protection
Disconnect lines on engine oil cooler, refer to REMOVING ENGINE OIL COOLER
| IMPORTANT | When working on the oil, coolant or fuel circuit, you must protect the alternator against contamination. Cover alternator with suitable materials. Failure to comply with this procedure may result in an alternator malfunction. |
Unfasten nut.
Remove holder from oil cooler line (1).
Unclip coolant hoses from holders.
Cover ribbed V-belt with cleaning cloth or similar.
Release nuts and remove oil lines from filter housing.
Note. Add final details to vehicle. After completing work, check and correct engine oil level.
17 21 010 Removing and installing/replacing transmission oil cooler
| IMPORTANT | It is essential to adhere to the exact filling capacities specified. Fill transmission at room temperature only (approx. 20°-30°C). Gear oil: refer to AUTOMATIC TRANSMISSION - OPERATING FLUIDS . Failure to comply with this instruction will result in serious damage to the transmission. |
Recycling
Catch and dispose of gear oil with suitable equipment.
Observe country-specific waste-disposal regulations.
Necessary preliminary tasks
- Remove right «WHEEL ARCH COVER»(/bmw/m3/e90-2007-2013/remont/door-locks-anti-theft-systems/#body-equipment-repair-e90__51-71-038-removing-and-installingreplacing)
- Drain «TRANSMISSION OIL»(/bmw/m3/e90-2007-2013/remont/oem-general-information/#maintenance-and-general-information-repair-e90__00-11-229-changingtopping-upchecking-gear)
Release connections for transmission oil cooler.
Scheme 85
Release brackets for transmission oil cooler.
Add final details to vehicle.
Check system for leaks.
Scheme 86
17 21 500 Rinse gearbox oil cooler and lines of twin clutch gearbox
Note. Follow work steps for: Installing a new or replacement transmission.
Procedure
Double twin clutch gearbox removed.
Connect the respective adapters to all oil pipes leaving the double TCT (see description below).
Use quick-release coupling to connect line 17 2 019 from oil collecting unit.
Use quick-release coupling to connect drain line 17 2 018.
Hold and direct open end of drain line into a suitable drip tray.
Using oil collection unit, flush approx. 1 liter of transmission fluid (refer to BMW Service AUTOMATIC TRANSMISSION - OPERATING FLUIDS ) through oil lines and transmission oil cooler.
Reposition quick-release couplings.
Flush oil lines/transmission oil cooler in opposite direction with approx. 1 liter of transmission fluid (refer to BMW Service AUTOMATIC TRANSMISSION - OPERATING FLUIDS ).
Disconnect quick-release couplings.
Remove adapter.
Note. Dispose of flushing oil correctly. Do not reuse under any circumstances.
Press hydraulic lines (1) into adapters (2).
Slide clamping bar (3) into guides and secure with screw (4).
Scheme 87
Arrangement of flushing apparatus for TCT
Scheme 88
- Transmission-oil cooler with lines
- Oil collection unit 17 2 015 Connection for oil collection unit (2), manufacturer: Deutsche Tecalemit or 17 2 016 Connection for oil collection unit (2), manufacturer: Horn 17 2 017 Quick-release coupling (2 pieces) 17 2 019 Hose to oil collection unit (2)
- Oil drip tray 17 2 018 Hose to oil drip tray (3)
- Adapter with clamping bar 17 2 060 Adapter with clamping bar for aluminum lines and steel lines with aluminum connection (line diameter 12 mm) TCT for engine 17 2 070 Adapter with clamping bar (line diameter15 mm) TS65TCT for TCT engine
| WARNING | Danger of scalding! Only perform this work after engine has cooled down. |
| IMPORTANT | Wear protective gloves and goggles. |
Recycling
Catch and dispose of drained oil in a suitable container.
Comply with the waste disposal regulations applicable in the relevant countries.
Necessary preliminary tasks
Remove underbody protection
Disconnect lines on engine oil cooler, refer to REMOVING ENGINE OIL COOLER
| IMPORTANT | When working on the oil, coolant or fuel circuit, you must protect the alternator against contamination. Cover alternator with suitable materials. Failure to comply with this procedure may result in an alternator malfunction. |
Unfasten nut.
Remove holder from oil cooler line (1).
Scheme 89
Unclip coolant hoses from holders.
Cover ribbed V-belt with cleaning cloth or similar.
Release nuts and remove oil lines from filter housing.
Note. Add final details to vehicle. After completing work, check and correct engine oil level.
Note. Follow work steps for: Installing a new or replacement transmission.
Procedure
Double twin clutch gearbox removed.
Connect the respective adapters to all oil pipes leaving the double TCT (see description below).
Use quick-release coupling to connect line 17 2 019 from oil collecting unit.
Use quick-release coupling to connect drain line 17 2 018.
Hold and direct open end of drain line into a suitable drip tray.
Using oil collection unit, flush approx. 1 liter of transmission fluid (refer to BMW Service Gear oil for dual clutch transmission AUTOMATIC TRANSMISSION - OPERATING FLUIDS ) through oil lines and transmission oil cooler.
Reposition quick-release couplings.
Flush oil lines/transmission oil cooler in opposite direction with approx. 1 liter of transmission fluid (refer to BMW Service Gear oil for dual clutch transmission AUTOMATIC TRANSMISSION - OPERATING FLUIDS ).
Disconnect quick-release couplings.
Remove adapter.
Note. Dispose of flushing oil correctly. Do not reuse under any circumstances.
Press hydraulic lines (1) into adapters (2).
Slide clamping bar (3) into guides and secure with screw (4).
Scheme 90
Arrangement of flushing apparatus for TCT
- Transmission-oil cooler with lines
- Oil collection unit 17 2 015 Connection for oil collection unit (2), manufacturer: Deutsche Tecalemit or 17 2 016 Connection for oil collection unit (2), manufacturer: Horn 17 2 017 Quick-release coupling (2 pieces) 17 2 019 Hose to oil collection unit (2)
- Oil drip tray 17 2 018 Hose to oil drip tray (3)
- Adapter with clamping bar
17 2 060 Adapter with clamping bar for aluminum lines and steel lines with aluminum connection (line diameter 12 mm) TCT for engine
17 2 070 Adapter with clamping bar (line diameter15 mm) TS65TCT for TCT engine
See also:
• 00 2 030 DEVICE
• OPENING PRESSURE OF PRESSURE RELIEF VALVE
• FRONT UNDERBODY PROTECTION
• 17 00 1AZ
• COOLING SYSTEM - OPERATING FLUIDS
• REMOVE A/C CONDENSER
• INTAKE FILTER HOUSING
• FLUID LEVEL
• FRONT BUMPER TRIM
• AUTOMATIC TRANSMISSION - OPERATING FLUIDS
• WHEEL ARCH COVER
• TRANSMISSION OIL
• FOLLOW NOTES FOR REPAIR WORK ON COOLING SYSTEM
• FILL AND BLEED COOLING SYSTEM.
• COOLING SYSTEM FOR WATERTIGHTNESS
• INSTRUCTIONS FOR REPLACEMENT OF AIR CONDITIONING CAPACITORS AND RADIATOR/COOLERS
• REMOVING POWER STEERING COOLING COIL
• REMOVING OIL COOLER
• FAN COWL
• COOLANT
• VENT COOLING SYSTEM
• RADIATOR
