Cooling System - Special Tools - e90 BMW M3 E90

Adapter MW

Note. (Adapter kit) For connecting the adapters from 17 0 000 with pump 17 0 101 and hose 17 0 102.

SI number

01 07 02 (884)

Consisting of

1 = 0494430 Adapter

Note. For connecting the pump 17 0 101 and hose 17 0 102 to the adapter from 17 0 000

Scheme 34

2 = 0494431 Hose

Note. (Hose with coupling connection) For connecting pump 17 0 101 to adapter 17 0 007

3 = 0494761 Clamp

Note. (Hose clamp) For hose 17 0 132

Adapter Minimum set: Mechanical tools MW

Note. For flushing fluid cooler and lines of automatic transmission. Check lines: Plastic tubes

Storage Location

A25

01 14 08 (464)

Consisting of

1 = 0496492 Adapter

2 = 0496493 Clip

Note. (Clamping bracket)

Scheme 35

Note. (Adapter kit) For rinsing the oil cooler in automatic transmissions.

01 12 96 (103)

Consisting of

1 = 0493621 Plate

Note. (Mounting plate) For adapter 17 2 011 - Transmission: A5S 325Z

1 = 0491404 Adapter

Note. For connecting the oil cooler lines to the oil dispenser unit - Transmission: A5S 310Z, A5S 560Z, A5S 325Z

Scheme 36

2 = 0491405 Adapter

Note. (Adapter (2 pieces)) For connecting the oil cooler lines to the oil dispenser unit - Transmission: A4S 310R

3 = 0491406 Screw

Note. (Banjo bolt (2 pieces)) Thread M18x1.5 with nut and gasket for connecting the oil cooler lines to the oil dispenser unit - \Transmission: A5S 440Z

4 = 0491407 Screw

Note. (Banjo bolt (2 pieces)) Thread M16x1.5 with nut, gasket and thread piece for connecting the oil cooler lines to the oil dispenser unit - transmission: A5S 300J

5 = 0491408 Connector

Note. For the oil dispenser unit from Tecalemit

6 = 0491409 Connector

Note. For the oil dispenser unit from Horn

7 = 0491410 Adapter

Note. (Clutch) Scope: 2 pcs.

8 = 0491411 Hose

Note. (Hose, long)

9 = 0491412 Hose

Note. (Hose, short)

Note. For flushing fluid cooler and lines of automatic transmission. Check lines: Diameter 15 mm

A25

01 14 08 (464)

Consisting of

1 = 0496490 Adapter

2 = 0496491 Clip

Note. (clamping bracket)

Scheme 37

Note. For flushing fluid cooler and lines of automatic transmission. Check lines: Diameter 12 mm

A25

01 14 08 (464)

Consisting of

1 = 0496487 Adapter

2 = 0496488 Clip

Note. (Clamping bracket) Clamping bracket for aluminum line.

Scheme 38

3 = 0496489 Clip

Note. (Clamping bracket) Clamping bracket for steel line with pressed-on aluminum bush (connection).

Pliers Minimum set: Mechanical tools MW

Note. For releasing fasteners on transmission oil cooler

B46

01 14 01 (766)

Scheme 39

Tester Minimum set: Mechanical tools MW

Note. For checking engine cooling system for watertightness. For checking radiator cap.

01 07 02 (884)

Consisting of

1 = 0494418 Pump

2 = 0494419 Hose

Note. (hose with quick-release coupling)

Scheme 40

3 = 0494420 Adapter

Note. For radiator cap (normal thread)

4 = 0494421 Adapter

Note. For radiator cap (normal thread)

5 = 0494422 Adapter

Note. For radiator cap (sawtooth thread)

6 = 0494423 Adapter

Note. For radiator cap (sawtooth thread)

7 = 0494424 Adapter

Note. For radiator cap R50/W10

8 = 0494425 Adapter

Note. For radiator cap R50/W10

9 = 0494426 Adapter

Note. For radiator connection R53/W11, R50/W17 adapter corresponds to 17 0 051

10 = 0494427 Adapter

Note. For radiator cap R53/W11, R50/W17 adapter corresponds to 17 0 052

11 = 0494428 Case

12 = 0494642 Adapter

Note. For radiator cap Model series: E60, E61, E63, E64 SI no.: 1 08 03 (988)

13 = 0494643 Adapter

Note. For radiator cap Model series: E60, E61, E63, E64 SI no.: 1 08 03 (988)

14 = 0495889 Adapter

Note. For radiator cap Model series: N12, N14

Tester MW

Replaced by: 0494417

Note. For checking cooling system for leak tightness and function of pressure relief valve in radiator cap. Replaced by 17 0 100 (0 494 417)

A43

C17

Consisting of

5 = 0491389 Adapter

Note. (Adapter) For screw-on radiator caps (sawtooth thread)/Series: E31, E32, E34, E36, E38, E39 Replaced by 17 0 100 (0 494 417)

7 = 0493108 Adapter

Note. (Adapter) For testing the expansion tank cover/Series: E31, E32, E34, E36, E38, E39 Replaced by 17 0 100 (0 494 417)

Scheme 41

8 = 0494017 Hose

Note. (Pressure hose)

1 = 0491385 Adapter

Note. (Adapter) For checking the pressure relief valve in the radiator cap/Series: all, except E28

= 0491386

2 = 0491386 Tester

Note. (Tester without adapter) Pressure range 0...2.5 bar/Series: all, except E28 Free only for motorcycle!!!

3 = 0491387 Adapter

Note. (Adapter) For screw-on radiator caps (normal thread)/Series: E28, E30, E31, E32 Engine: all, except M51 Free only for motorcycle!!!

4 = 0491388 Adapter

Note. (Adapter) For screw-on radiator caps (standard thread)/Series: E28, E30, E32/Engine: M51 Free only for motorcycle!!!

6 = 0491390 Adapter

Note. (Adapter) For screw-on radiator caps (sawtooth thread)/Replaces 06/97 with 17 0 007/Reason: Expansion tank cover design change

9 = 0491391 Adapter

Note. (Adapter for radiator expansion tank) Series: E36/Model: M3 US engine: W10
