Installing Audi TT 8N рестайлинг

Electrical Equipment 2 illustrations ~147 words

Installing

  1. Carefully lift battery onto carrier.

Scheme 32

Scheme 32
Scheme 32
  1. Install battery so battery carrier lug -arrow- engages in battery foot strip cut-out -1-.

It must not be possible to move battery to the left or right.

Scheme 33

Scheme 33
Scheme 33

Battery is inserted correctly when center cut-out in battery foot strip aligns with threaded hole in battery carrier -arrows-.

  1. Fit battery hold-down bracket.
  2. Install battery hold-down bracket bolt and torque to 20 Nm.
CAUTIONResults of inadequately secured battery: Shorter battery service life due to vibration damage. Battery cell and plate damage. Electrolyte leakage due to battery case damage. Poor collision safety.

Remaining installation is in reverse order of removal, noting the following

  1. Observe WARNINGs! regarding central gas venting. Refer to «Battery with central gas venting»(/audi/tt/8n-2003-2006/remont/cruise-control-systems/#electrical-equipment__battery-with-central-gas-venting) .

Note. Battery for 4-cylinder engine illustrated here. Reconnecting sequence must be strictly adhered to.

CAUTIONEnsure all electrical consumers are switched off and ignition key is removed.
  1. First reconnect positive ( B+ ) terminal -1- at battery.
  2. Then reconnect negative ( - ) terminal -2-.

Battery terminal tightening torque: 6 Nm.

  1. Perform work steps specified in table. Refer to «Battery, disconnecting and reconnecting»(/audi/tt/8n-2003-2006/remont/cruise-control-systems/#electrical-equipment__battery-disconnecting-and-reconnecting) .
