Ignition/starter switch, removing and installing

Removing

1. Remove steering column switches. Refer to «Steering column switches, removing and installing»(/audi/tt/8n-2003-2006/remont/cruise-control-systems/#electrical-equipment__steering-column-switches-removing-and-installing) .

Scheme 172

1. Disconnect electrical connection -1- at ignition/starter switch.
2. Remove locking fluid from screws -arrows-.
3. Loosen screws -arrows- slightly and pull ignition/starter switch out of steering lock housing -2-.

Installing

Install in reverse order of removal, noting the following

Note. Ignition/starter switch and lock cylinder must be in "Ignition ON" position when installing.

1. Apply locking fluid to lock housing screws -2-.

Scheme 173

15 - Terminal 15

30 - Terminal 30

50 - Terminal 50

50b- Terminal 50b

75 - Terminal 75

86s- Terminal 86s

P - Park position

The automatic vertical headlight aim control system is installed on vehicles with High Intensity Gas Discharge (HID) headlights.

The system contains the following components

1. Level control system sensors at front and rear axles
2. Headlight range control module
3. Headlight beam adjusting motors integrated with headlight units

When driving, the system automatically adapts the headlight beam inclination dependent on vehicle suspension movement and load. Headlight glare to oncoming traffic is minimized.

The headlight range control module is controlled by a microprocessor and has On Board Diagnostic (OBD) capability. If malfunctions occur in any of the system components, corresponding DTCs are stored in the Diagnostic Trouble Code (DTC) memory.

Before performing any troubleshooting or inspection, always begin by checking for DTCs using the On Board Diagnostic (OBD) program. DTCs stored in memory are retrieved/checked with VAS 5051/5052 tester in mode "Guided Fault Finding".

Scheme 174

1 - Headlights with High Intensity Gas Discharge (HID) Lamps

1. With Headlight Beam Adjusting Motors -V48- & -V49
2. Removing and installing. Refer to «Headlight housing, removing and installing»(/audi/tt/8n-2003-2006/remont/cruise-control-systems/#electrical-equipment__headlight-housing-removing-and-installing) .

2 - Left Front Level Control System Sensor -G78

1. Located at left front control arm of front axle
2. Removing and installing. Refer to «Left Front Level Control System Sensor -G78-, removing and installing»(/audi/tt/8n-2003-2006/remont/cruise-control-systems/#electrical-equipment__left-front-level-control-system-sensor)

3 - Left rear level control system sensor -G76

1. Front-wheel drive: located at rear axle
2. Removing and installing. Refer to «Left Rear Level Control System Sensor -G76-, removing and installing»(/audi/tt/8n-2003-2006/remont/cruise-control-systems/#electrical-equipment)
3. All-wheel drive: located at rear crossmember left
4. Removing and installing. Refer to «Left Rear Level Control System Sensor -G76-, removing and installing»(/audi/tt/8n-2003-2006/remont/cruise-control-systems/#electrical-equipment)

4 - Headlight Range Control Module -J431

1. Coupe: located below rear seat bench
2. Removing and installing. Refer to «Headlight Range Control Module -J431- - Coupe, removing and installing»(/audi/tt/8n-2003-2006/remont/cruise-control-systems/#electrical-equipment__headlight-range-control-module-j431)
3. Roadster: located behind bulkhead, center, below convertible top storage compartment, on floor
4. Removing and installing. Refer to «Headlight Range Control Module -J431- - Roadster, removing and installing»(/audi/tt/8n-2003-2006/remont/cruise-control-systems/#electrical-equipment__headlight-range-control-module-j431)
