2.5L - Cooling System - Engine Code(s): Cepb (Coupe): Overview Audi TT 8J facelift

COOLANT PUMP AND COOLANT THERMOSTAT WITH HOUSING OVERVIEW

Scheme 1

1. Seal Replace
2. Bolt 9 Nm
3. Coolant Pump Removing and installing, refer to «COOLANT PUMP»(ref-505591-S24714884342012100100000)
4. After-Run Coolant Pump -V51- Removing and installing, refer to «After-Run Coolant Pump -V51»(ref-505591-S11921654472012100100000)
5. Bolt 9 Nm
6. Coolant Circuit Solenoid Valve -N492- Removing and installing, refer to «Cooling Circuit Solenoid Valve -N492»(ref-505591-S36220825662012100100000)
7. Bolt 9 Nm
8. Coolant Distribution Housing Removing and installing, refer to «COOLANT DISTRIBUTION HOUSING»(ref-505591-S42373051382012100100000)
9. O-ring Replace
10. Bolt 6 Nm
11. Front Coolant Pipes
12. Bolt 9 Nm
13. O-ring Replace
14. Coolant Thermostat with Housing Removing and installing, refer to «COOLANT THERMOSTAT WITH HOUSING»(ref-505591-S07235387372012100100000)
15. Bolt 9 Nm

RADIATOR AND COOLANT FAN OVERVIEW

Radiator, Coolant Fan

Scheme 2

1. Coolant Fan -V7- Removing and installing, refer to «Coolant Fan -V7- /Coolant Fan 2 -V177»(ref-505591-S27117321122012100100000)
2. Nut 10 Nm
3. Fan Shroud Removing and installing, refer to «FAN SHROUD»(ref-505591-S19924321522012100100000)
4. Upper Coolant Hose Connect to the radiator (Scheme 3)
5. Coolant Hose
6. O-ring Replace
7. Radiator Removing and installing, refer to «RADIATOR»(ref-505591-S20454516472012100100000) After replacing, replace entire amount of coolant
8. Bolt 5 Nm
9. Bracket
10. Mount
11. O-ring Replace
12. Lower Coolant Hose Connect to the radiator (Scheme 3)
13. Nut 10 Nm
14. Bolt 5 Nm
15. Coolant Fan 2 -V177- Removing and installing, refer to «Coolant Fan -V7- /Coolant Fan 2 -V177»(ref-505591-S27117321122012100100000)

Scheme 3

Remove the old O-ring -2- in the coolant hose -3-.

Coat the new O-ring with coolant and install it in the coolant hose.

Press the coolant hose onto the radiator -1- until it engages audibly.

Press the coolant hose on again and pull to make sure the connection is engaged correctly.

Left Auxiliary Cooler

Scheme 4

1. Air Guide
2. Grommet
3. Bolt 8 Nm
4. Upper Bracket
5. Grommet
6. Bolt 8 Nm
7. Coolant Hoses
8. Left Auxiliary Cooler For coolant circuit for the transmission Removing and installing, refer to «LEFT AUXILIARY COOLER»(ref-505591-S36383935562012100100000)
9. Grommet
10. Lower Bracket
11. Washer
12. Nut 8 Nm

Scheme 5

1. Bolt 6.5 Nm
2. Air Guide
3. Right Auxiliary Cooler For coolant Removing and installing, refer to «RIGHT AUXILIARY COOLER»(ref-505591-S40744212592012100100000)
4. Coolant Hoses
5. Upper Bracket
6. Grommets
7. Coolant Hose
8. Grommet
9. Bushing
10. Bolt 6.5 Nm
11. Lower Bracket
12. Bolt 8 Nm
13. Grommet
14. Bolt 6 Nm
