Communication: Overview Audi S8 D3 facelift

General information

General information

The components of the systems Radio R / Telephone Transceiver R36 / Navigation System with CD Drive Control Module J401 / Speech Input Control Module J507 / TV Tuner R78 / Chip Card Reader Control Module J676 / Media Player, Position 1 R118 / Media Player, Position 2 R119 / Digital Sound System Control Module J525 / Data Bus On Board Diagnostic Interface J533 are combined with one another in a "ring". This "ring" represents the optical MOST-Bus.

The connection to the other BUS systems in the vehicle are provided by the Data Bus On Board Diagnostic Interface J533.

The "central control module" is the Front Information Display Control Head Control Module J523. The transfer of signals representing the instrument cluster display occurs via the MOST-Bus to Data Bus On Board Diagnostic Interface J533 and from there via CAN-Bus (instrument cluster) to the instrument cluster.

Scheme 1

Fault finding is performed via "Guided Fault Finding" using.

Additional information 286New Data Bus Systems - LIN, MOST Bluetooth , 293Audi A8 Infotainment.

Information on optical MOST-Bus

In addition to the CAN-Bus systems, an optical data bus system has been implemented.

Data exchange of the systems Radio R / Digital Sound System Control Module J525 / TV Tuner R78 / Media Player, Position 1 R118 / Media Player, Position 2 R119 / Telephone Transceiver R36 , Navigation System with CD Drive Control Module J401 / Chip Card Reader Control Module J676 / Data Bus On Board Diagnostic Interface J533 occurs via the MOST-Bus.

A fiber optic cable is utilized as the "connecting cable".

Fiber optic cables are routed inside corrugated tubes for protection.

Ensure that harness connector end faces are not soiled.

Scheme 2

If harness connectors are disconnected: Install Protective Cap For Cable Connector VAS 6223/9 - 1 -.

Fiber optic cables cannot be repaired, they must be replaced completely.

Observe the minimum bending radius of 25 mm when routing fiber optic cables. Fiber optic cables must not be pinched or bent.

Repairs on fiber optic cables --> 97 - WIRING .

For more information, refer to 286New data bus systems - LIN, MOST, Bluetooth.

Microphone Unit (in front roof module) R164 , overview

The Microphone Unit (in front roof module) R164 in the Front Interior Light W1 consists of a maximum of three microphones.

As of calendar week 22/04, only two microphones were installed.

For this, one microphone is connected directly to Telephone Transceiver R36. The other microphones are connected to the Digital Sound System Control Module J525.

Scheme 3

Microphone Unit (in front roof module) R164

A - Driving direction

B - Front Interior Light W1

C - Microphone 1 (black/gray) to Digital Sound System Control Module J525 or Telephone Transceiver R36

D - Microphone 2 (white) to Digital Sound System Control Module J525 (left-side steering only) up to calendar week 21/04

E - Telephone Transceiver R36

F - Digital Sound System Control Module J525

G - Microphone 4 (red) to Digital Sound System Control Module J525 (right-side steering only) up to calendar week 21/04

H - Microphone 3 (blue/green) to Digital Sound System Control Module J525 or Telephone Transceiver R36

Microphone Unit (in front roof module) R164 , removing and installing --> Microphone Unit (in front roof module) R164 , removing and installing .

General information

The components of the systems Radio R / Navigation System with CD Drive Control Module J401 / Media Player, Position 1 R118 / Digital Sound System Control Module J525 / Data Bus On Board Diagnostic Interface J533 are combined with one another in a "ring". This "ring" represents the optical MOST-Bus.

The connection to the other BUS systems in the vehicle are performed by the Data Bus On Board Diagnostic Interface J533.

The "central control module" is the Front Information Display Control Head Control Module J523. The transfer of signals representing the instrument cluster display occurs via the MOST-Bus to Data Bus On Board Diagnostic Interface J533 and from there via CAN-Bus (instrument cluster) to the instrument cluster.

Fault finding is performed via "Guided Fault Finding" using.

Additional information 971303New Data Bus Systems , 993303A8L Infotainment.

Information on optical MOST-Bus

In addition to the CAN-Bus systems, an optical data bus system has been implemented.

Data exchange of the systems Radio R / Digital Sound System Control Module J525 / CD Changer R41 / Navigation System with CD Drive Control Module J401 / Data Bus On Board Diagnostic Interface J533 occurs via the MOST-Bus.

A fiber optic cable is utilized as the "connecting cable".

Fiber optic cables are routed inside corrugated tubes for protection.

Ensure that harness connector end faces are not soiled.

If harness connectors are disconnected: Install Protective Cap For Cable Connector VAS 6223/9 - 1 -.

Fiber optic cables cannot be repaired, they must be replaced completely.

Observe the minimum bending radius of 25 mm when routing fiber optic cables. Fiber optic cables must not be pinched or bent.

Repairing fiber optic cables --> 97 - WIRING .

Additional information 971303New Data Bus Systems.

The Microphone Unit (in front roof module) R164 in the Front Interior Light W1 consists of a maximum of three microphones.

As of calendar week 22/04, only two microphones were installed.

For this, one microphone is connected directly to Telephone Transceiver R36. The other microphones are connected to the Digital Sound System Control Module J525.

Microphone Unit (in front roof module) R164

A - Driving direction

B - Front Interior Light W1

C - Microphone 1 (black/gray) to Digital Sound System Control Module J525 or Telephone Transceiver R36

D - Microphone 2 (white) to Digital Sound System Control Module J525 (left-side steering only) up to calendar week 21/04

E - Telephone Transceiver R36

F - Digital Sound System Control Module J525

G - Microphone 4 (red) to Digital Sound System Control Module J525 (right-side steering only) up to calendar week 21/04

H - Microphone 3 (blue/green) to Digital Sound System Control Module J525 or Telephone Transceiver R36

Microphone Unit (in front roof module) R164 , removing and installing --> Microphone Unit (in front roof module) R164 , removing and installing .

Radio system is a component of the MMI Infotainment system. A "radio unit" is no longer installed, rather the Radio R consists of a radio tuner with additional connector positions in the left rear luggage compartment.

Operation is performed via the Multimedia Control Head E380. Data transfer to the Digital Sound System Control Module J525 occurs via the optical MOST-Bus.

Signals of rear window antenna reach the Radio R via the Antenna Amplifier R24 with integrated Antenna Selection Control Module J515.

For regions with digital radio reception, a Digital Radio (DAB) R147 can also be installed.

Fault finding is performed via "Guided Fault Finding" using.

Repairs on antenna wires --> 97 - WIRING .

Radio system, overview of component locations

Scheme 4

1 - Loudspeaker in instrument panel

1. Left Front Treble Speaker R20 / Right Front Treble Speaker R22
2. Removing and installing
3. BOSE: Left Front Mid-range Speaker R26 / Center Mid/High Range Speaker R158 / Right Front Mid-range Speaker R27
4. Removing and installing --> «Speaker in instrument panel, removing and installing»(ref-289229-S06881710632008062700000)

1. BANG and OLUFSEN: Left Front Treble Speaker R20 / Center Mid/High Range Speaker R158 / Right Front Treble Speaker R22
2. Removing and installing

2 - Media Player, Position 1 R118

1. In glove compartment

CD-ROM Drive R92 / CD Changer R41

1. Connector assignment --> «CD Changer R41 / CD-Player R89 / CD-ROM Drive R92 , connector assignments»(ref-289229-S21605642552008062700000)
2. Removing and installing --> «CD Changer R41 , removing and installing»(ref-289229-S32492911232008062700000)

Mini Disk Player R153

1. Connector assignment --> «Mini Disk Player R153 , connector assignments»(ref-289229-S26778657182008062700000)
2. Removing and installing --> «CD Changer R41 , removing and installing»(ref-289229-S32492911232008062700000)

Media Player, Position 2 R119

1. In glove compartment

CD Changer R41

1. Connector assignment --> «CD Changer R41 / CD-Player R89 / CD-ROM Drive R92 , connector assignments»(ref-289229-S21605642552008062700000)
2. Removing and installing --> «CD Changer R41 , removing and installing»(ref-289229-S32492911232008062700000)

3 - Front Information Display Control Head J685

1. In center of instrument panel
2. Removing and installing --> «Front Information Display Control Head J685 , removing and installing»(ref-289229-S26521810502008062700000)

Multimedia Control Head E380

1. In center console, bottom
2. Connector assignment --> «Multimedia Control Head E380 , harness connectors»(ref-289229-S34043757452008062700000)
3. Removing and installing --> «Multimedia Control Head E380 , removing and installing»(ref-289229-S16421003162008062700000)

4 - Antenna Amplifier R24

1. Behind left roof end trim
2. Connector assignment --> «Antenna Amplifier R24 , connector assignments»(ref-289229-S28845210642008062700000)
3. Removing and installing --> «Antenna Amplifier R24 , removing and installing»(ref-289229-S24249758222008062700000)

5 - Loudspeaker in rear shelf

1. Subwoofer (on rear shelf) R157 in center
2. With BOSE, additional Speaker (in shelf) R150 at left and right in rear
3. Removing and installing --> «Speaker in rear shelf, removing and installing»(ref-289229-S20836662342008062700000)
4. BANG and OLUFSEN: Left Rear Mid-range Speaker R105 / Subwoofer (on rear shelf) R157 / Right Rear Mid-range Speaker R106

1. Removing and installing

6 - Radio R

1. Behind luggage compartment left side trim
2. Optional with Speech Input Control Module J507
3. Connector assignment Radio R --> «Radio R , harness connectors»(ref-289229-S22274235632008062700000)
4. Removing and installing Radio R --> «Radio R , removing and installing»(ref-289229-S38054691272008062700000)

7 - Digital Sound System Control Module J525

1. Behind luggage compartment left side trim
2. Connector assignment --> «Digital Sound System Control Module J525 , harness connectors»(ref-289229-S12126231412008062700000)
3. Removing and installing, up to model year 05 --> «Digital Sound System Control Module J525 - up to model year 05, removing and installing»(ref-289229-S30387750362008062700000)
4. Removing and installing, as of model year 06 --> «Digital Sound System Control Module J525 - as of model year 06, removing and installing»(ref-289229-S08603539152008062700000)

1. BOSE connector assignment --> «Digital Sound System Control Module J525 - BOSE, connector assignments»(ref-289229-S31694796182008062700000)
2. Removing and installing BOSE, up to model year 05 --> «Digital Sound System Control Module J525 BOSE - up to model year 05, removing and installing»(ref-289229-S26434350292008062700000)
3. Removing and installing BOSE, as of model year 06 --> «Digital Sound System Control Module J525 - as of model year 06, removing and installing»(ref-289229-S08603539152008062700000)
4. BOSE 6000 connector assignment --> «Digital Sound System Control Module J525 - BOSE 6000, connector assignments»(ref-289229-S26077573712008062700000)

1. Removing and installing 6000 --> «Digital Sound System Control Module J525 BOSE 6000, removing and installing»(ref-289229-S14454070922008062700000)
2. BANG and OLUFSEN, connector assignments --> «Digital Sound System Control Module J525 - Bang and Olufsen, connector assignments»(ref-289229-S00467864042008062700000)
3. BANG and OLUFSEN, removing and installing --> «Digital Sound System Control Module J525 BANG and OLUFSEN, removing and installing»(ref-289229-S40842547052008062700000)

Digital Sound System Control Module 2 J787

1. Only with BANG and OLUFSEN
2. Behind luggage compartment left side trim
3. Connector assignment --> «Digital Sound System Control Module 2 J787 - Bang and Olufsen, connector assignments»(ref-289229-S09817700062008062700000)
4. Removing and installing --> «Digital Sound System Control Module 2 J787 BANG and OLUFSEN, removing and installing»(ref-289229-S17204297072008062700000)

8 - Loudspeaker in doors

1. Left Front Mid-Bass Speaker R101 / Right Front Mid-Bass Speaker R102 at bottom in front doors
2. BOSE: Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors
3. Left Rear Mid/Low Range Speaker R159 / Right Rear Mid/Low Range Speaker R160 at bottom in rear doors
4. Left Rear Treble Speaker R14 / Right Rear Treble Speaker R16 at top in rear doors

1. Removing and installing --> «Speakers in doors, removing and installing»(ref-289229-S20823182212008062700000)
2. BANG and OLUFSEN: Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors
3. Left Front Mid-range Speaker R103 / Right Front Mid-range Speaker R104 in front doors, center
4. Left Rear Treble Speaker R14 / Right Rear Treble Speaker R16 at top in rear doors

1. Left Rear Mid/Low Range Speaker R159 / Right Rear Mid/Low Range Speaker R160 at bottom in rear doors
2. Removing and installing

9 - Multifunction Steering Wheel

1. Removing and installing buttons --> «Multi-function buttons, removing and installing»(ref-289229-S39333448092008062700000)

Radio system is a component of the communication system. A "radio unit" is no longer installed, rather the Radio R consists of a radio tuner with additional connector positions in the left rear luggage compartment.

A Satellite Radio R146 (SDARS) may also be installed.

Operation is performed via the Multimedia Control Head E380. Data transfer to Multimedia Control Head E380 and to Digital Sound System Control Module J525 occurs via the MOST-Bus.

Signals of rear window antenna reach the Radio R via the Antenna Amplifier R24 with integrated Antenna Selection Control Module J515.

In contrast, SDARS signals from Radio, Telephone, Navigation System Antenna R52 (Ter/Sat/GPS/GSM-emergency) to Satellite Radio R146.

Fault finding is performed via "Guided Fault Finding" using.

Repairs on antenna wires --> 97 - WIRING .

Repairing fiber optic cables --> 97 - WIRING

Scheme 5

1 - Loudspeaker in instrument panel

1. Left Front Mid-range Speaker R26 / Right Front Mid-range Speaker R27 / Center Mid/High Range Speaker R158
2. Removing and installing --> «Speaker in instrument panel, removing and installing»(ref-289229-S06881710632008062700000)
3. BANG and OLUFSEN: Left Front Treble Speaker R20 / Center Mid/High Range Speaker R158 / Right Front Treble Speaker R22
4. Removing and installing

2 - Media Player, Position 1 R118

1. In glove compartment

CD Changer R41

1. Connector assignment --> «CD Changer R41 / CD-Player R89 / CD-ROM Drive R92 , connector assignments»(ref-289229-S21605642552008062700000)
2. Removing and installing --> «CD Changer R41 , removing and installing»(ref-289229-S32492911232008062700000)

Media Player, Position 2 R119

1. In glove compartment

CD Changer R41

1. Connector assignment --> «CD Changer R41 / CD-Player R89 / CD-ROM Drive R92 , connector assignments»(ref-289229-S21605642552008062700000)
2. Removing and installing --> «CD Changer R41 , removing and installing»(ref-289229-S32492911232008062700000)

3 - Front Information Display Control Head J685

1. In center of instrument panel
2. Removing and installing --> «Front Information Display Control Head J685 , removing and installing»(ref-289229-S26521810502008062700000)

Multimedia Control Head E380

1. In center console, bottom
2. Connector assignment --> «Multimedia Control Head E380 , harness connectors»(ref-289229-S34043757452008062700000)
3. Removing and installing --> «Multimedia Control Head E380 , removing and installing»(ref-289229-S16421003162008062700000)

4 - Antenna Amplifier R24

1. Behind left roof end trim
2. Connector assignment --> «Antenna Amplifier R24 , connector assignments»(ref-289229-S28845210642008062700000)
3. Removing and installing --> «Antenna Amplifier R24 , removing and installing»(ref-289229-S24249758222008062700000)

5 - Radio, Telephone, Navigation System Antenna R52

1. Ter/Sat/GPS/GSM-emergency (up to 10/06)
2. Sat/GPS/GSM-emergency (as of 11/06)
3. Roof antenna
4. Removing and installing --> «Radio, Telephone, Navigation System Antenna R52 , removing and installing»(ref-289229-S22909234062008062700000)

6 - Subwoofer (on rear shelf)

1. Subwoofer (on rear shelf) R157 in center
2. Speaker (in shelf) R150 left and right at rear
3. Removing and installing --> «Speaker in rear shelf, removing and installing»(ref-289229-S20836662342008062700000)
4. BANG and OLUFSEN: Left Rear Mid-range Speaker R105 / Subwoofer (on rear shelf) R157 / Right Rear Mid-range Speaker R106

1. Removing and installing

7 - Radio R

1. Behind luggage compartment left side trim
2. Connector assignment --> «Radio R , harness connectors»(ref-289229-S22274235632008062700000)
3. Removing and installing --> «Radio R , removing and installing»(ref-289229-S38054691272008062700000)

8 - Satellite Radio R146

1. Behind luggage compartment left side trim
2. Connector assignment --> «Satellite Radio R146 , connector assignments»(ref-289229-S30964673942008062700000)
3. Removing and installing, up to model year 05 --> «Satellite Radio R146 - up to model year 05, removing and installing»(ref-289229-S23530940802008062700000)
4. Removing and installing, as of model year 06 --> «Satellite Radio R146 - as of model year 06, removing and installing»(ref-289229-S01068337992008062700000)

1. Removing and installing with RSE light --> «Satellite Radio R146 - RSE light, removing and installing»(ref-289229-S16183942772008062700000)

9 - Digital Sound System Control Module J525

1. Behind luggage compartment left side trim
2. BOSE connector assignment --> «Digital Sound System Control Module J525 - BOSE, connector assignments»(ref-289229-S31694796182008062700000)
3. Removing and installing BOSE, up to model year 05 --> «Digital Sound System Control Module J525 BOSE - up to model year 05, removing and installing»(ref-289229-S26434350292008062700000)
4. Removing and installing BOSE, as of model year 06 --> «Digital Sound System Control Module J525 BOSE - as of model year 06, removing and installing»(ref-289229-S17897935572008062700000)

1. BOSE 6000 connector assignment --> «Digital Sound System Control Module J525 - BOSE 6000, connector assignments»(ref-289229-S26077573712008062700000)
2. Removing and installing 6000 --> «Digital Sound System Control Module J525 BOSE 6000, removing and installing»(ref-289229-S14454070922008062700000)
3. BANG and OLUFSEN, connector assignments --> «Digital Sound System Control Module J525 - Bang and Olufsen, connector assignments»(ref-289229-S00467864042008062700000)
4. BANG and OLUFSEN, removing and installing --> «Digital Sound System Control Module J525 BANG and OLUFSEN, removing and installing»(ref-289229-S40842547052008062700000)

Digital Sound System Control Module 2 J787

1. Only with BANG and OLUFSEN
2. Behind luggage compartment left side trim
3. Connector assignment --> «Digital Sound System Control Module 2 J787 - Bang and Olufsen, connector assignments»(ref-289229-S09817700062008062700000)
4. Removing and installing --> «Digital Sound System Control Module 2 J787 BANG and OLUFSEN, removing and installing»(ref-289229-S17204297072008062700000)

10 - Loudspeaker in doors

1. Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors
2. Left Rear Mid/Low Range Speaker R159 / Right Rear Mid/Low Range Speaker R160 at bottom in rear doors
3. Left Rear Treble Speaker R14 / Right Rear Treble Speaker R16 at top in rear doors
4. Removing and installing --> «Speakers in doors, removing and installing»(ref-289229-S20823182212008062700000)

1. BANG and OLUFSEN: Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors
2. Left Front Mid-range Speaker R103 / Right Front Mid-range Speaker R104 in front doors, center
3. Left Rear Treble Speaker R14 / Right Rear Treble Speaker R16 at top in rear doors
4. Left Rear Mid/Low Range Speaker R159 / Right Rear Mid/Low Range Speaker R160 at bottom in rear doors

1. Removing and installing

11 - Multifunction Steering Wheel

1. Removing and installing buttons --> «Multi-function buttons, removing and installing»(ref-289229-S39333448092008062700000)

General information

The telephone system consists of the versions

1. Telephone fixed installation

Telephone Transceiver R36 is incorporated into the MMI Infotainment system via the MOST-Bus.

The Telephone Base plate R126 for SIM card and for wireless Telephone Handset R37 (Bluetooth technology) is located in the center console/center armrest. Operation is performed via Multimedia Control Head E380 or via Telephone Handset R37.

Microphones for the Microphone Unit (in front roof module) R164 are integrated in the Front Interior Light W1. Of these, one microphone is connected to Telephone Transceiver R36.

1. Cellular telephone preparation

Telephone Transceiver R36 is incorporated into the MMI Infotainment system via the MOST-Bus. In addition, a Bluetooth Antenna R152 is available.

The Telephone Base plate R126 is installed in the center console/center armrest. Operation is performed via Multimedia Control Head E380 or via Cellular Telephone R54.

Two microphones for the Microphone Unit (in front roof module) R164 are integrated in the Front Interior Light W1. Of these, one microphone is connected to Telephone Transceiver R36.

1. Bluetooth car telephone

The Bluetooth car telephone is also equipped with operation for the Bluetooth cellular phone. The Bluetooth cellular telephone must not be incorporated into a base plate and not into the vehicle handsfree equipment.

Incorporation occurs exclusively via the Bluetooth connection. In this way, the SIM card of the cellular telephone (phone book) can also be read out.

The Bluetooth car telephone possesses its own handset (Bluetooth handset) with SIM card insert slot and charge cradle.

The Bluetooth car telephone and cellular phone can be operated via the Bluetooth handset, the handsfree equipment in the multi-function steering wheel and via the speech dialogue system.

With the cellular phone preparation and the Bluetooth car telephone, all Audi-approved Cellular Telephones R54 with Bluetooth interface can be operated.

Information on operation and approved cellular phone types

1. www.audi.de/telefon

1. Cell phone preparation preliminary setup

The preliminary setup connector is located in the center console. The Microphone Unit (in front roof module) R164 is integrated in the Front Interior Light W1.

A microphone is connected to the connector.

The Radio, Telephone, Navigation System Antenna R52 antenna connector is located on the connector.

Fault finding is performed via "Guided Fault Finding" using.

Repairs on antenna wires --> 97 - WIRING .

Information on Bluetooth technology

Bluetooth technology is a radio communication standard used for transferring data between Telephone Transceiver R36 and Telephone Handset R37 / Cellular Telephone R54.

An additional telephone transceiver is located in the Telephone Transceiver R36. A separate Bluetooth Antenna R152 connects Telephone Transceiver R36 and Telephone Base plate R126 / Cellular Telephone R54 so that Telephone Handset R37 / Cellular Telephone R54 can be operated wirelessly, thus without a wire connection.

Signal range of radio connection is approx. 10 m.

For more information, refer to 286New data bus systems - LIN, MOST, Bluetooth.

The Microphone Unit (in front roof module) R164 in the Front Interior Light W1 consists of a maximum of three microphones.

As of calendar week 22/04, only two microphones were installed.

For this, one microphone is connected directly to Telephone Transceiver R36. The other microphones are connected to the Digital Sound System Control Module J525.

Microphone Unit (in front roof module) R164

A - Driving direction

B - Front Interior Light W1

C - Microphone 1 (black/gray) to Digital Sound System Control Module J525 or Telephone Transceiver R36

D - Microphone 2 (white) to Digital Sound System Control Module J525 (left-side steering only) up to calendar week 21/04

E - Telephone Transceiver R36

F - Digital Sound System Control Module J525

G - Microphone 4 (red) to Digital Sound System Control Module J525 (right-side steering only) up to calendar week 21/04

H - Microphone 3 (blue/green) to Digital Sound System Control Module J525 or Telephone Transceiver R36

Component locations, general overview

Scheme 6

1 - Front Information Display Control Head Control Module J523

1. Behind glove compartment

2 - Front Information Display Control Head J685

1. In center of instrument panel

Multimedia Control Head E380

1. In center console, bottom

3 - Microphone Unit (in front roof module) R164

1. Overview --> «Microphone Unit (in front roof module) R164 , overview»(ref-289229-S03145165392008062700000)
2. Removing and installing --> «Microphone Unit (in front roof module) R164 , removing and installing»(ref-289229-S04481158842008062700000)

4 - Telephone Amplifier R86

1. Behind lower right C-pillar trim
2. Connector assignment --> «Harness connectors on Telephone Amplifier R86»(ref-289229-S27689395852008062700000)
3. Removing and installing --> «Telephone Amplifier R86 , removing and installing»(ref-289229-S36160105922008062700000)

5 - Telephone Antenna R65

1. Behind right roof end trim (through model year 02)
2. Removing and installing --> «Telephone Antenna R65 - up to model year 02, removing and installing»(ref-289229-S31340130762008062700000)
3. Roof antenna (as of model year 03)
4. Removing and installing --> «Telephone Antenna R65 - as of model year 03, removing and installing»(ref-289229-S18405347342008062700000)

6 - Digital Sound System Control Module J525

1. Behind luggage compartment left side trim

7 - Telephone Base plate R126

1. In lower center console
2. Removing and installing --> «Telephone Base plate R126 - center console, removing and installing»(ref-289229-S24859384562008062700000)
3. In center armrest
4. Removing and installing Telephone Base plate R126 front center armrest --> «Telephone Base plate R126 - front center armrest, removing and installing»(ref-289229-S33737517022008062700000)

1. Removing and installing Telephone Base plate R126 rear center armrest --> «Telephone Base plate R126 - rear center armrest, removing and installing»(ref-289229-S21081022502008062700000)
2. Adapting Telephone Handset R37 (telephone fixed installation) --> «Telephone Handset R37 - telephone fixed installation, adapting»(ref-289229-S16308654742008062700000)

8 - Telephone Transceiver R36

1. In foot well, beneath floor mat
2. Telephone fixed installation, connector assignment --> «Telephone Transceiver R36 - telephone fixed installation, harness connectors»(ref-289229-S18071858072008062700000)
3. Cellular telephone preparation, connector assignment --> «Telephone Transceiver R36 - cellular telephone preparation, harness connectors»(ref-289229-S19682164392008062700000)
4. Bluetooth car telephone, connector assignment --> «Telephone Transceiver R36 - Bluetooth car telephone, harness connectors»(ref-289229-S24385846092008062700000)

1. Removing and installing --> «Telephone Transceiver R36 , removing and installing»(ref-289229-S13311214142008062700000)

9 - Multifunction Steering Wheel

1. Removing and installing buttons --> «Multi-function buttons, removing and installing»(ref-289229-S39333448092008062700000)

The Audi-Motorola Digital telephone is available as an option and works in conjunction with the Telematics system. The Telephone/Telematics system is linked to the Communication system via the CAN-Bus to the Data Bus On Board Diagnostic Interface J533.

The base plate/cradle for the telephone handset ( Telephone Base plate R126 ) is located in the center console. When the telephone handset is removed from the base plate, it functions as a normal cellular telephone, i.e. no interaction with vehicle systems (Telematics, MMI or other) is possible.

When the telephone handset is docked, telephone functions are performed either with the telephone handset or Multimedia Control Head E380. Information is displayed on either of the two Multimedia Interface (MMI) displays.

Two microphones in Microphone Unit (in front roof module) R164 that support the voice recognition system are integrated in the front roof module ( Front Interior Light W1 ).

Before troubleshooting or servicing, technicians must be familiar with the functions and operation specifics of the Telephone/Telematic System. Always read the Telephone/Telematic system owners manual and review applicable system functions.

Additional information: 993303A8L Infotainment971303New Data Bus Systems

Antenna cable repair: --> 97 - WIRING .

The navigation system is incorporated into the MMI Infotainment system via the fiber optic MOST-Bus.

A DVD is used as the Navigation data storage medium. This allows navigation data for several countries as well as additional information (hotels, restaurants, etc.) to be stored.

The Navigation System with CD Drive Control Module J401 is located in luggage compartment on left side. Navigation functions are performed via the Multimedia Control Head E380.

Before troubleshooting or servicing, technicians must be familiar with the functions and operation specifics of the Navigation system. Always read the Navigation system owners manual and review applicable system functions.

Additional information

993303A8L Infotainment

971303New Data Bus Systems

Repairs on antenna wires --> 97 - WIRING .

TV system is a component of the MMI Infotainment system.

TV Tuner R78 is connected via the MOST-Bus to the other components of the MMI Infotainment system. Operation is performed via the Multimedia Control Head E380.

For regions with digital TV reception (DVB-T), a Digital TV Tuner R171 can also be installed. Digital TV Tuner R171 is operated using a separate remote control.

Digital TV Tuner R171 is not integrated into any BUS system and only has limited diagnostic capabilities via the analog TV Tuner R78.

Signals of rear window antenna reach the Digital TV Tuner R171 via the Antenna Amplifier R24 and from there to the TV Tuner R78 (looped in).

As of model year 06, a "hybrid" - TV Tuner R78 for reception of analog and digital TV broadcasts have been installed.

Fault finding of the analog/hybrid TV Tuner R78 is performed via "Guided Fault Finding" using.

Repairs on antenna wires --> 97 - WIRING .

Scheme 7

1 - Front Information Display Control Head J685 in center instrument panel

2 - Front Information Display Control Head Control Module J523 behind glove compartment

3 - Multimedia Control Head E380 in lower center console

4 - Data Bus On Board Diagnostic Interface J533 behind glove compartment

5 - Media Player, Position 1 R118 / Media Player, Position 2 R119 in glove compartment

6 - TV Tuner R78 (analog/hybrid) behind left luggage compartment side trim

7 - Digital TV Tuner R171 (up to model year 05) behind left luggage compartment side trim

8 - Antenna Amplifier R24 behind left side roof end trim

9 - Rear window antennas

10 - Digital Sound System Control Module J525 behind left luggage compartment side trim

11 - Sound system

Buttons are integrated in the steering wheel to facilitate operating the radio system, telephone and navigation announcement system. With Tiptronic, rocker switches are also installed on right and left sides.

The Multi-function Steering Wheel Control Module J453 (under the right button) reads out the button information and transfers them over the LIN-Bus (single wire Bus) to the Steering Column Electronic Systems Control Module J527. Information from the Steering Column Electronic Systems Control Module J527 is transferred via CAN-Bus (Comfort) and Data Bus On Board Diagnostic Interface J533 to the individual modules.

Fault finding is performed via "Guided Fault Finding" using.

Buttons are integrated in the steering wheel to facilitate operating the radio system, telephone and navigation announcement system. With Tiptronic, rocker switches are also installed on right and left sides.

The Multi-function Steering Wheel Control Module J453 (under the right button) reads out the button information and transfers them over the LIN-Bus (single wire Bus) to the Steering Column Electronic Systems Control Module J527. Information from the Steering Column Electronic Systems Control Module J527 is transferred via CAN-Bus (Comfort) and Data Bus On Board Diagnostic Interface J533 to the individual modules.

Fault finding is performed via "Guided Fault Finding" using.

The Telematics system is integrated into the vehicle Communication system. The Telematics system is linked to the Communication system via the CAN-Bus to the Data Bus On Board Diagnostic Interface J533.

Telematics is an in-vehicle, personal communication system using cellular, Internet and Global Positioning System (GPS) technologies to provide the customer with safety, security and convenience services.

GPS is a "constellation" of 24 satellites that orbit the earth and constantly broadcast radio signals. The Telephone/Telematics Control Module J526 receives GPS data, decodes it, and transmits the vehicles location to the service providers call center via the national cellular network.

Telematics services for Audi customers are provided by OnStar via a dedicated call center. Service plans may provide route directions and concierge services as well as emergency or vehicle repair services. For details --> Audi Telematics by OnStar Owners Manual.

During events where the Airbag Control Module J234 processes a crash signal, the vehicle emergency flashers are activated and the doors are unlocked via the comfort/convenience system. In addition, the Telematics system automatically places an emergency call to the OnStar call center.

Telematics hardware includes the driver operated Telematics Control Head E264 (which contains the OnStar control buttons and system status light) in Front Interior Light W1 , Cellular Telephone R54 , microphone, backup loudspeaker, roof-mounted GPS/Cellular antenna and Telephone/Telematic Control Module with supporting software.

An emergency (back-up) battery for the Telephone/Telematic Control Module is also used in case the vehicle battery goes dead or becomes disconnected due to accident, impact etc.

An Audi-Motorola Digital Telephone ( Telephone/Telematics Control Module J526 ) is available as an option in conjunction with the Telematics system.

Telematics functions are performed via the Telematic Control Head (or Digital Telephone handset where applicable). Information can be displayed on either of the Multimedia Interface (MMI) displays. The system is also capable of speech recognition.

Before troubleshooting or servicing, technicians must be familiar with all Telematics functions, operating specifics and the particular service plan which the customer subscribes to "Audi Telematics by OnStar Owners Manual and/or OnStar " Quick Reference Guide to become familiar with applicable features and functions.

Additional information: 993203Audi Telematics by OnStar993303A8L Infotainment971303New Data Bus Systems

Antenna cable repair: --> 97 - WIRING .

Telematics system, component overview

1 - Front Information Display Control Head J685

1. In center of instrument panel

Multimedia Control Head E380

1. In center console, bottom

2 - Auxiliary Speaker (Telematics) R91

1. In right B-pillar trim
2. Removing and installing --> «Auxiliary Speaker (Telematics) R91 , removing and installing»(ref-289229-S12059316382008062700000)

3 - Front Interior Light W1

1. Control head for telematics E264
2. A: Roadside Assistance Button E275
3. B: Telematics Indicator Lamp K186
4. C: Emergency Call Button E276

1. D: End Conversation Button (Telematics USA) E331
2. E: Microphone Unit (in front roof module) R164
3. Telematics Control Head E264 , removing and installing --> «Telematics Control Head E264 , removing and installing»(ref-289229-S20120345692008062700000)
4. Microphone Unit (in front roof module) R164 , overview --> «Microphone Unit (in front roof module) R164 , overview»(ref-289229-S03145165392008062700000)

1. Microphone Unit (in front roof module) R164 , removing and installing --> «Microphone Unit (in front roof module) R164 , removing and installing»(ref-289229-S04481158842008062700000)

4 - Telephone antenna R65

1. GSM
2. Behind right roof end trim
3. Removing and installing --> «Telephone Antenna R65 - up to model year 02, removing and installing»(ref-289229-S31340130762008062700000)

5 - Radio, Telephone, Navigation System Antenna R52

1. Ter/Sat/GPS/GSM emergency
2. Roof antenna
3. Removing and installing --> «Radio, Telephone, Navigation System Antenna R52 , removing and installing»(ref-289229-S22909234062008062700000)

6 - Digital Sound System Control Module J525

1. Behind luggage compartment left side trim

7 - Cellular Telephone R54

1. In center console, bottom
2. Removing and installing Telephone Base plate R156 --> «Telephone Base plate R126 - center console, removing and installing»(ref-289229-S24859384562008062700000)

8 - Telephone/Telematics Control Module J526

1. In foot well, beneath floor mat
2. Connector assignment --> «Telephone/Telematics Control Module J526 , connector assignments»(ref-289229-S27954369662008062700000)
3. Removing and installing --> «Telephone/Telematics Control Module J526 , removing and installing»(ref-289229-S31783074062008062700000)

9 - Multifunction Steering Wheel

1. Removing and installing buttons --> «Multi-function buttons, removing and installing»(ref-289229-S39333448092008062700000)

The speech control system provides acoustic operation of the telephone, Telematics, radio and navigation systems.

Functions may be comfortably initiated by speaking commands. System is activated via the PTT button in the multi-function steering wheel.

Fault finding is performed via "Guided Fault Finding" using.

The "Rear Seat Entertainment system" consists of

1. Rear DVD Changer R162 with remote control
2. Monitors in headrests of front seats
3. Headphone connections in rear center console
4. Connections for video or game consoles in rear center console

The playback of picture and sound information of Rear DVD Changer R162 is also performed via the MMI and the vehicle sound system.

If TV Tuner R78 is installed, playback may be viewed on all displays.

DVD navigation can also be played back over the additional monitors in the headrests.

Additional information RSE operating instructions.

Repairing fiber optic cables --> 97 - WIRING .

Repairs on antenna wires --> 97 - WIRING .

The "Rear Seat Entertainment system" - low consists of

1. Rear DVD Changer R162 with remote control
2. Monitors in headrests of front seats
3. Headphone connections in rear center console

The playback of picture and sound information of Rear DVD Changer R162 is performed exclusively via the monitors in headrests and headphone connections in center console.

The system has no connection to the MMI and vehicle sound system.

Additional information RSE - light operating instructions.

Scheme 8

1 - Multimedia Display Unit 1 Y22 in drivers seat headrest

2 - Multimedia Display Unit Y23 in front passengers seat headrest

3 - Drivers Volume Control Button E374 / Left Multimedia Headphones R123 in rear center console

4 - Front Passengers Volume Control Button E375 / Right Multimedia Headphones R124 in rear center console

5 - Multimedia Signal Splitter R181 behind left luggage compartment side trim

6 - Rear DVD Changer R162 behind left luggage compartment side trim

7 - Black harness connector T4ah, connection to vehicle wiring harness behind left luggage compartment side trim

The rear view camera system assists the driver during back-up driving by providing the driver with an image of the traffic situation behind the vehicle via the Front Information Display Control Head J685.

The rear view camera system is switched on when engaging the reverse gear. The system can be activated manually by operating the Parking Aid Button E266 in the center console.

The rear system consists of the following components

1. Rear View Camera R189
2. Rear View Camera System Control Module J772
3. Front Information Display Control Head Control Module J523
4. Steering wheel with Steering Angle Sensor G85

As an option, other control modules may be installed (e.g. TV Tuner R78.

It is not permitted to install an auxiliary license plate for vehicles with rear view camera system as it could impair the function of the rear view camera system.

Diagnosis is performed using "Guided Fault-Finding".

Scheme 9

1 - Data Bus On Board Diagnostic Interface J533 behind glove compartment

2 - Front Information Display Control Head J685 in center instrument panel

3 - Front Information Display Control Head Control Module behind glove compartment

4 - Multimedia Control Head E380 in lower center console

5 - FBAS wire from Rear View Camera System Control Module J772

6 - FBAS wire from TV Tuner R78

7 - FBAS wire from Rear View Camera R189

8 - Rear View Camera R189 in rear lid

9 - Rear View Camera System Control Module J772 behind luggage compartment front left side trim

10 - TV Tuner R78 behind luggage compartment left side trim

11 - CAN-Bus (Comfort)

12 - MOST-Bus

13 - Parking Aid Control Module J446 behind luggage compartment right side trim

14 - Vehicle Electrical System Control Module J519 behind drivers side storage compartment

15 - Comfort System Central Control Module J393 behind luggage compartment right side trim

16 - Towing Recognition Control Module J345 behind luggage compartment right side trim

17 - Access/Start Control Module J518 behind luggage compartment right side trim

18 - ABS Control Module J104 in the engine compartment

19 - Steering Angle Sensor G85 on steering column at Steering Column Electronic Systems Control Module J527

20 - CAN bus (powertrain)
