Communication: Adjustments Audi S8 D3 facelift

Rear view camera system, calibrating

After performing service work on the vehicle, it may be necessary to calibrate the rear view camera system anew. In detail, this is the case after

1. Removing and installing Rear View Camera R189
2. Replacing Rear View Camera System Control Module J772
3. After repair work performed on rear lid following an accident
4. After a vehicle alignment

1. After performing a repair at front or rear axle

Preparations before starting work

Special tools, testers and auxiliary items required

1. Vehicle Diagnostic, Testing and Information System VAS 5051
2. Calibration Device VAS 6350
3. Distance Laser VAS 6350/2

Vehicle must stand on a firm and level surface to perform the calibration. No persons may be in the vehicle interior during the measurement. Vehicle must not be moved during the measurement, opening and closing of vehicle doors is to be avoided. The rear lid is closed.

1. Connect.
2. Bring the Steering Angle Sensor G85 into 0-position (wheels straight ahead).

Overview of assembled calibration equipment

Scheme 10

1 - Left paddle

2 - Right paddle

3 - Right-side angle bracket for Distance Laser VAS 6350/2 mount.

4 - Plastic foot

1. Three on underside of calibration platform
2. Adjustable for aligning horizontal position of calibration platform

5 - Linear laser on calibration platform

1. Switching on and off operating instructions

6 - Distance Laser VAS 6350/2

1. Notes on operation operating instructions

7 - Spirit level on calibration platform

1. For checking horizontal position of calibration platform

8 - Left-side angle bracket for Distance Laser VAS 6350/2 mount.

9 - Measuring field of calibration platform

1. Distance to rear wheel axle 1.47 m - 1.90 m - dimension A

Setting up measuring device

1. Check which hole circle the rims have.
2. Equip wheel pick-ups appropriately.
3. To do so, secure three wheel bolt adapters in the hole circle to each wheel pick-up.
4. Attach paddles to both wheel pick-ups and secure them with clamping screw.

1. Set the wheel pick-ups on to wheel mounting bolts at the rear wheels.

Scheme 11

When doing this, the wheel pick-ups are positioned by the "O-rings" in the adapters and held in place.

Note. Attach wheel pick-ups onto wheels so that any installed "anti-theft" wheel mounting bolts are not connected to the wheel pick-ups.

1. Set the paddles via the clamping screw so that they are free to move just above the ground.

Ensure paddles move easily.

1. Position calibration platform behind vehicle at a distance of 1.47 m -1.90 m from rear wheels, as depicted in overview - dimension A -.
2. Bring calibration platform to a horizontal position.

Scheme 12

1. Twist plastic feet under calibration platform so that air bubble in spirit level is located exactly in the center of the indicator - arrow -.

Scheme 13

1. Switch on laser - 1 - on calibration platform and align entire calibration platform so that laser beam hits center of Audi rings.
2. Switch Distance Laser VAS 6350/2 on with ON button.

Scheme 14

The following display appears and laser is switched on.

Scheme 15

1. Hold Distance Laser VAS 6350/2 - 2 - as shown in illustration on one side of calibration platform flush in bracket, laser must lie firmly on bracket when doing so.
2. Ensure laser beam from Distance Laser VAS 6350/2 hits lower, enlarged part of paddle - 1 -.

If this is not the case, paddles must be corrected accordingly via clamping screws on the wheel pick-ups.

1. With one hand, hold the Distance Laser VAS 6350/2 firmly in the bracket on the calibration platform while the laser beam is visible on the paddle.
2. Now press the ON button briefly for the distance measurement.

Scheme 16

Display readout

1. Note the value read off.
2. Repeat measuring procedure in the same manner for the rear wheel on the other side of the calibration platform.

The value read off for distance must be identical on both sides.

If values are not identical

1. Adjust calibration platform until values on both sides are identical.

When aligning the calibration platform, make sure the calibration platform laser beam still strikes the center of the Audi rings and the indicator of the spirit level remains centered. If necessary, make further corrections.

Scheme 17

1. Measure height of calibration platform, dimension - H - (top edge platform - floor).

The measured distance and height must now be entered in the Diagnostic Operation System VAS 5051A in "millimeters".

Performing calibration

In Diagnostic Operation System VAS 5051A , select "Guided Functions".

or

In Diagnostic Operation System VAS 5051A , select "Guided Fault Finding".

1. Select the corresponding vehicle data in the "vehicle selection" menu.
2. Select "Rear view camera system".
3. Select "Functions".
4. Select "Calibration".

Further assistance during calibration procedure is given by Diagnostic Operation System VAS 5051A.
