Communication: Wiring Audi S8 D3 facelift

Front Information Display Control Head Control Module J523 , harness connectors

Note. Unlisted connector terminals are not assigned.

Scheme 27

Connectors

A - Black 20-pin multi-pin harness connector

B - MOST-Bus

C - Harness connector to Front Information Display Control Head J685

Connector (black) to Information Display Control Head Switching Unit J728 (Japan Nav)

D - FBAS input (green) from TV Tuner R78 / Rear View Camera System Control Module J772

Scheme 28

A - Black 20-pin multi-pin harness connector

1 - Terminal 30

2 - Terminal 31

3 - Ring-break diagnostic wire

6 - Wake-up for Multimedia Control Head E380

7 - Voltage supply for Multimedia Control Head E380

8 - Ground (GND) for Multimedia Control Head E380

11 - CAN-Bus High (Infotainment)

12 - CAN-Bus Low (Infotainment)

13 - RESET from Multimedia Control Head E380

14 - RESET to Multimedia Control Head E380

15 - Data to Multimedia Control Head E380

16 - Data from Multimedia Control Head E380

20 - NF mute from cell phone preparation preliminary setup/US Telematics/Japan Nav

Scheme 29

B - MOST Bus

1 - Input

2 - Output

Multimedia Control Head E380 , harness connectors

Note. Unlisted connector terminals are not assigned.

Scheme 30

Black 16-pin multi-pin harness connector

6 - Wake up from Front Information Display Control Head Control Module J523

7 - Voltage supply from Front Information Display Control Head Control Module J523

8 - Ground (GND) from Front Information Display Control Head Control Module J523

9 - Open/close signal display to Vehicle Electrical System Control Module 2 J520

10 - Signal from Front Display Open/close Button E462

13 - RESET to Front Information Display Control Head Control Module J523

14 - RESET from Front Information Display Control Head Control Module J523

15 - Data from Front Information Display Control Head Control Module J523

16 - Data to Front Information Display Control Head Control Module J523

Radio R , harness connectors

Note. Unlisted connector terminals are not assigned.

Scheme 31

Connectors

A - Black 8-pin multi-pin harness connector

B - MOST-Bus

C - HF (white) connection from Antenna Amplifier R24

D - IF (yellow) connection to Antenna Amplifier R24

Scheme 32

A - Black 8-pin multi-pin harness connector

1 - Terminal 31

2 - Terminal 30

5 - Ring-break diagnostic wire

B - MOST Bus

1 - Input

2 - Output

Digital Sound System Control Module J525 , harness connectors

Note. Unlisted connector terminals are not assigned.

Scheme 33

Connectors

A - Blue 23-pin multi-pin connector

B - MOST-Bus

A - Blue 23-pin multi-pin connector

1 - Microphone 1 (-) from Microphone Unit (in front roof module) R164

2 - Microphone 1 (+) from Microphone Unit (in front roof module) R164

3 - Microphone 2 (+), NF (+) from Japan Nav/US Telematics (from KW 22/04)

4 - Microphone 2 (-), NF (-) from Japan Nav/US Telematics (from KW 22/04)

6 - Ring-break diagnostic wire

8 - Loudspeaker, left rear (+)

9 - Loudspeaker, left rear (-)

11 - Loudspeaker, right rear (-)

12 - Loudspeaker, right rear (+)

14 - Loudspeaker, left front (+)

15 - Loudspeaker, left front (-)

17 - Loudspeaker, right front (-)

18 - Loudspeaker, right front (+)

20 - Subwoofer (on rear shelf) R157 (+)

21 - Subwoofer (on rear shelf) R157 (-)

22 - Terminal 31

23 - Terminal 30

B - MOST Bus

1 - Input

2 - Output

Telephone Transceiver R36 - cellular telephone preparation, harness connectors

Note. Unlisted connector terminals are not assigned.

Scheme 34

Connectors

A - Black 54-pin multi-pin harness connector (T54)

B - Bluetooth Antenna R152 connection (yellow)

C - MOST-Bus

A - 54-pin multi-pin harness connector (T54)

1 - Terminal 30

2 - Terminal 31

3 - Signal "cellular telephone ON" to Telephone Amplifier R86

11 - Microphone input (+) from Microphone Unit (in front roof module) R164

12 - Microphone input (-) from Microphone Unit (in front roof module) R164

14 - Ring-break diagnostic wire

37 - Terminal 30 to Telephone Base plate R126

39 - Terminal 31 to Telephone Base plate R126

41 - Terminal 30 to Telephone Base plate R126

42 - Microphone output (+) to Telephone Base plate R126

43 - Microphone output (-) to Telephone Base plate R126

44 - Terminal 31 (screen ground)

45 - NF (+) from Telephone Base plate R126

46 - NF (-) from Telephone Base plate R126

47 - SNDREQ signal from Telephone Base plate R126

49 - Ser-Tx (+) to Telephone Base plate R126

50 - Ser-Tx (-) to Telephone Base plate R126

51 - Ser-Rx (+) from Telephone Base plate R126

52 - Ser-Rx (-) from Telephone Base plate R126

C - MOST-Bus

1 - Input

2 - Output

Telephone Transceiver R36 - Bluetooth car telephone, harness connectors

Note. Unlisted connector terminals are not assigned.

Scheme 35

Connectors

A - Bluetooth Antenna R152 connection (yellow)

B - MOST-Bus

C - Black 54-pin multi-pin harness connector (T54)

D - GSM connection (purple) from Telephone Antenna R65

B - MOST Bus

1 - Input

2 - Output

C - Black 54-pin multi-pin harness connector (T54)

1 - Terminal 30

2 - Terminal 31

3 - Signal "cellular telephone ON" from Telephone Base plate R126

10 - Terminal 31 (screen ground)

11 - Microphone input (+) from Microphone Unit (in front roof module) R164

12 - Microphone input (-) from Microphone Unit (in front roof module) R164

14 - Ring-break diagnostic wire

Harness connectors on Telephone Amplifier R86

Note. Unlisted connector terminals are not assigned.

Scheme 36

Connectors

A - Black 3-pin multi-pin harness connector

B - GSM connection (purple) to Telephone Antenna R65

C - Antenna connection (purple) to Cellular Telephone R54

A - Black 3-pin multi-pin harness connector

1 - Terminal 30

2 - Terminal 31

3 - Signal "cellular telephone ON" from Telephone Transceiver R36

Center arm rest wiring set, removing and installing

Removing

First, front center armrest in center console must be disassembled.

Scheme 37

1. Pull off top trim support base - 1 - upward.
2. Remove bolts - 2 - (15 Nm) and swivel center armrest to the side.

Scheme 38

1. Unclip storage compartment - 2 - from center console.
2. Pull wire - 1 - in - direction of arrow - out of storage compartment - 2 -.
3. Disconnect electrical connection beneath storage compartment.

Installing

1. Install in reverse order.

Telephone/Telematics Control Module J526 , harness connectors

Note. Unlisted connector terminals are not assigned.

Scheme 39

Connectors

A - Blue 42-pin multi-pin connector (T42a)

B - GPS connection (blue) from Radio, Telephone, Navigation System Antenna R52

C - GSM emergency connection (purple) from Radio, Telephone, Navigation System Antenna R52

A - Blue 42-pin multi-pin connector (T42a)

3 - NF input from Telephone Base plate R126

4 - Battery feedback from Telephone Base plate R126

5 - Ground (GND) to Telephone Base plate R126

6 - Ser-Tx (+) to Telephone Base plate R126

8 - Telephone Base plate R126 ground shielding

9 - CAN-Bus High (Comfort)

10 - NF (+) to Digital Sound System Control Module J525

11 - Auxiliary Speaker (Telematics) R91 (+)

12 - Microphone input (+) from Microphone Unit (in front roof module) R164

13 - K-wire

14 - Terminal 75

15 - "Red" LED to Telematics Control Head E264

16 - "Green" LED to Telematics Control Head E264

18 - Terminal 31

19 - Terminal 31

24 - NF input from Telephone Base plate R126

25 - Telephone Base plate R126 NF ground

26 - Terminal 30 to Telephone Base plate R126

27 - Ser-Rx (+) from Telephone Base plate R126

30 - CAN-Bus Low (Comfort)

31 - NF (-) to Digital Sound System Control Module J525

32 - Auxiliary Speaker (Telematics) R91 (-)

33 - Microphone input (-) from Microphone Unit (in front roof module) R164

34 - LF Mute to Front Information Display Control Head Control Module J523

35 - from Telematics Control Head E264

36 - to Telematics Control Head E264

38 - Crash signal from Airbag Control Module J234

39 - Terminal 30

40 - Terminal 30

41 - Emergency Battery (Telematics) A16 (+)

42 - Emergency Battery (Telematics) A16 (-)

Scheme 40

1 - Front Information Display Control Head J685

1. In center of instrument panel

Multimedia Control Head E380

1. In center console, bottom

2 - Auxiliary Speaker (Telematics) R91

1. In right B-pillar trim
2. Removing and installing --> «Auxiliary Speaker (Telematics) R91 , removing and installing»(ref-289229-S12059316382008062700000)

3 - Front Interior Light W1

1. Control head for telematics E264
2. A: Roadside Assistance Button E275
3. B: Telematics Indicator Lamp K186
4. C: Emergency Call Button E276

1. D: End Conversation Button (Telematics USA) E331
2. E: Microphone Unit (in front roof module) R164
3. Telematics Control Head E264 , removing and installing --> «Telematics Control Head E264 , removing and installing»(ref-289229-S20120345692008062700000)
4. Microphone Unit (in front roof module) R164 , overview --> «Microphone Unit (in front roof module) R164 , overview»(ref-289229-S03145165392008062700000)

1. Microphone Unit (in front roof module) R164 , removing and installing --> «Microphone Unit (in front roof module) R164 , removing and installing»(ref-289229-S04481158842008062700000)

4 - Telephone antenna R65

1. GSM
2. Behind right roof end trim
3. Removing and installing --> «Telephone Antenna R65 - up to model year 02, removing and installing»(ref-289229-S31340130762008062700000)

5 - Radio, Telephone, Navigation System Antenna R52

1. Ter/Sat/GPS/GSM emergency
2. Roof antenna
3. Removing and installing --> «Radio, Telephone, Navigation System Antenna R52 , removing and installing»(ref-289229-S22909234062008062700000)

6 - Digital Sound System Control Module J525

1. Behind luggage compartment left side trim

7 - Cellular Telephone R54

1. In center console, bottom
2. Removing and installing Telephone Base plate R126 --> «Telephone Base plate R126 - center console, removing and installing»(ref-289229-S24859384562008062700000)
3. In center armrest
4. Removing and installing Telephone Base plate R126 front center armrest --> «Telephone Base plate R126 - front center armrest, removing and installing»(ref-289229-S33737517022008062700000)

1. Removing and installing Telephone Base plate R126 rear center armrest --> «Telephone Base plate R126 - rear center armrest, removing and installing»(ref-289229-S21081022502008062700000)

8 - Telephone/Telematics Control Module J526

1. In foot well, beneath floor mat
2. Connector assignment --> «Telephone/Telematics Control Module J526 , harness connectors»(ref-289229-S20207073262008062700000)
3. Removing and installing --> «Telephone/Telematics Control Module J526 , removing and installing»(ref-289229-S31783074062008062700000)

9 - Multifunction Steering Wheel

1. Removing and installing buttons --> «Multi-function buttons, removing and installing»(ref-289229-S39333448092008062700000)

TV Tuner R78 (analog), harness connectors

Note. Unlisted connector terminals are not assigned.

Scheme 41

Connectors

A - Red 20-pin multi-pin harness connector (T20f)

B - MOST-Bus

C - TV3/TV4 (green) from Antenna Amplifier R24 / Digital TV Tuner R171

D - TV1/TV2 (brown) from Antenna Amplifier R24 / Digital TV Tuner R171

E - FBAS output (green) to Front Information Display Control Head Control Module J523

A - Red 20-pin multi-pin harness connector (T20f) without RSE

1 - Terminal 30

2 - Terminal 31

3 - Ring-break diagnostic wire

8 - Ground shielding 1

9 - Ground shielding 1

10 - Audio input left 1

11 - Audio input right 1

12 - Video input 1

13 - Ground shielding 1

14 - Ground shielding 2

15 - Ground shielding 2

16 - Audio input left 2

17 - Audio input right 2

18 - Video input 2

19 - Ground shielding 2

A - Red 20-pin multi-pin harness connector (T20f) with RSE

1 - Terminal 30

2 - Terminal 31

3 - Ring-break diagnostic wire

4 - Ground shielding (RSE)

5 - Video output, RSE

6 - Ground shielding (RSE)

7 - Audio output left, RSE

8 - Audio output right, RSE

9 - Ground shielding 1

10 - Audio input left 1

11 - Audio input right 1

12 - Video input 1

13 - Ground shielding 1

14 - Ground shielding 2

15 - Ground shielding 2

16 - Audio input left 2

17 - Audio input right 2

18 - Video input 2

19 - Ground shielding 2

20 - I/O switch PIN

B - MOST Bus

1 - Input

2 - Output

Digital TV Tuner R171 , harness connectors

Note. Unlisted connector terminals are not assigned.

Scheme 42

Connectors

A - TV1/TV2 connection (brown) from Antenna Amplifier R24

B - TV3/TV4 connection (green) from Antenna Amplifier R24

C - TV3/TV4 connection (green) to TV Tuner R78 (analog)

D - TV1/TV2 connection (brown) to TV Tuner R78 (analog)

E - Button for adapting remote control

F - Red 20-pin multi-pin harness connector (T20g)

G - Connection for SW download cable (not used)

F - Red 20-pin multi-pin harness connector (T20g)

1 - Screen ground

2 - Video output

3 - Screen ground

4 - Audio output left

5 - Audio output right

6 - Screen ground

7 - Screen ground

8 - Terminal 31

9 - Power on / off

10 - Terminal 30

11 - Screen ground

12 - Video input

13 - Screen ground

14 - Audio input left

15 - Audio input right

16 - Screen ground

TV Tuner R78 (hybrid), harness connectors

Note. Unlisted connector terminals are not assigned.

Scheme 43

Connectors

A - TV1/TV2 connection (brown) from Antenna Amplifier R24

B - TV3/TV4 connection (green) from Antenna Amplifier R24

C - Red 20-pin multi-pin harness connector (T20p)

D - MOST-Bus

E - FBAS output (green) to Front Information Display Control Head Control Module J523 / Rear View Camera System Control Module J772

C - Red 20-pin multi-pin harness connector (T20p)

1 - Terminal 30

2 - Terminal 31

3 - Ring-break diagnostic wire

4 - Screen ground

5 - Video output, RSE

6 - Screen ground

7 - Audio output left, RSE

8 - Audio output right, RSE

9 - Screen ground

10 - Audio input left

11 - Audio input right

12 - Video input

13 - Screen ground

14 - Screen ground

15 - Screen ground

16 - Audio input left

17 - Audio input right

18 - Video input

19 - Screen ground

20 - ID PIN

D - MOST-Bus

1 - Input

2 - Output

Scheme 44

1 - Front Information Display Control Head Control Module J523

1. Behind glove compartment

2 - Media Player, Position 1 R118 / Media Player, Position 2 R119

1. In glove compartment

3 - Front Information Display Control Head J685

1. In center of instrument panel

Multimedia Control Head E380

1. In center console, bottom

4 - Antenna Amplifier R24

1. Behind left roof end trim
2. Connector assignment --> «Antenna Amplifier R24 , connector assignments»(ref-289229-S28845210642008062700000)
3. Removing and installing --> «Antenna Amplifier R24 , removing and installing»(ref-289229-S24249758222008062700000)

5 - Loudspeaker in rear shelf

6 - Digital Sound System Control Module J525

1. Behind luggage compartment left side trim

7 - TV Tuner R78

1. Analog up to model year 05
2. Analog/digital (hybrid) as of model year 06
3. Behind luggage compartment left side trim
4. Analog connector assignment --> «TV Tuner R78 (analog), harness connectors»(ref-289229-S36848812572008062700000)

1. Hybrid connector assignment --> «TV Tuner R78 (hybrid), harness connectors»(ref-289229-S40737430002008062700000)
2. Removing and installing --> «TV Tuner R78 (analog/hybrid), removing and installing»(ref-289229-S29833323642008062700000)

8 - Digital TV Tuner R171 (up to model year 05)

1. Behind luggage compartment left side trim
2. Connector assignment --> «Digital TV Tuner R171 , harness connectors»(ref-289229-S24065411752008062700000)
3. Removing and installing --> «Digital TV Tuner R171 , removing and installing»(ref-289229-S06686726932008062700000)

9 - Loudspeaker in doors

10 - Multifunction Steering Wheel

1. Removing and installing buttons --> «Multi-function buttons, removing and installing»(ref-289229-S39333448092008062700000)

11 - Loudspeaker in instrument panel

Rear DVD Changer R162 , harness connectors

Note. Unlisted connector terminals are not assigned.

Scheme 45

Connectors

1 - Left audio signal, white

2 - Video signal, yellow

3 - Right audio signal, red

4 - not used

5 - not used

6 - White 4-pin multi-pin harness connector

6 - White 4-pin multi-pin harness connector

1 - Remote DVD

2 - Terminal 31

3 - Terminal 15

4 - Terminal 30

Multimedia Display 1 Control Module J744 / Multimedia Display 2 Control Module J747 , harness connectors

Note. Unlisted connector terminals are not assigned.

Scheme 46

Front side

1 - Aux output 3 (not assigned)

2 - Aux Input 3 (yellow, white, red) from Multimedia Signal Splitter R181

3 - Aux Input 2 (yellow, white, red) from Multimedia Signal Splitter R181

4 - Aux Input 1 (yellow, white, red) from Multimedia Signal Splitter R181

Scheme 47

Rear side

1 - Black 8-pin multi-pin harness connector (T8aa/T8ab)

2 - Cable to monitor

3 - Headphone connection black (T3ad/T3ae) to Auxiliary Video/Audio Connection Module R176

1 - Black 8-pin multi-pin harness connector (T8aa/T8ab)

1 - Terminal 31

3 - Terminal 15

4 - Terminal 31

7 - Monitor 1 or monitor 2

Multimedia Signal Splitter R181 , harness connectors

Note. Unlisted connector terminals are not assigned.

Scheme 48

Connectors

1 - Red 20-pin multi-pin harness connector (T20aa)

1. Connections to Multimedia Display 1 Control Module J744 / Multimedia Display 2 Control Module J747

2 - Brown 16-pin multi-pin connector (T16e)

Scheme 49

2 - Brown 16-pin multi-pin connector (T16e)

1 - Terminal 30

2 - Remote DVD

3 - Remote monitor 1

4 - Remote monitor 2

6 - Audio left from TV Tuner R78

7 - Audio right from TV Tuner R78

8 - Screen ground

9 - Terminal 31

Scheme 50

1 - Front Information Display Control Head J685

1. In instrument panel, center

Multimedia Control Head E380

1. in center console

2 - Multimedia Display Unit 2 Y23

1. In front passengers seat headrest
2. Removing and installing --> «Monitors in headrests, removing and installing»(ref-289229-S33682674012008062700000)

3 - Additional connection for video and audio R176

1. In rear center console
2. Removing and installing --> «Auxiliary Video/Audio Connection Module R176 , removing and installing»(ref-289229-S01235065542008062700000)

4 - Multimedia Display Unit 1 Y22

1. In drivers seat headrest
2. Removing and installing --> «Auxiliary Video/Audio Connection Module R176 , removing and installing»(ref-289229-S01235065542008062700000)

5 - Rear DVD changer R162

1. Behind luggage compartment left side trim
2. Connector assignment --> «Rear DVD Changer R162 , harness connectors»(ref-289229-S41020083632008062700000)
3. Removing and installing --> «Rear DVD Changer R162 , removing and installing»(ref-289229-S39302909962008062700000)

Multimedia Display 1 Control Module J744

1. Behind luggage compartment left side trim
2. Connector assignment --> «Multimedia Display 1 Control Module J744 / Multimedia Display 2 Control Module J747 , harness connectors»(ref-289229-S28777540612008062700000)
3. Removing and installing --> «Multimedia Display 1 Control Module J744 , removing and installing»(ref-289229-S24056064632008062700000)

Multimedia Display 2 Control Module J747

1. Behind luggage compartment left side trim
2. Connector assignment --> «Multimedia Display 1 Control Module J744 / Multimedia Display 2 Control Module J747 , harness connectors»(ref-289229-S28777540612008062700000)
3. Removing and installing --> «Multimedia Display 1 Control Module J744 , removing and installing»(ref-289229-S24056064632008062700000)

Multimedia Signal Splitter R181

1. Behind luggage compartment left side trim
2. Connector assignment --> «Multimedia Signal Splitter R181 , harness connectors»(ref-289229-S01859283722008062700000)
3. Removing and installing --> «Multimedia Signal Splitter R181 , removing and installing»(ref-289229-S21192157202008062700000)

6 - TV Tuner R78

1. Behind luggage compartment left side trim

7 - Remote control for Rear DVD Changer R162

1. In storage compartment in rear center armrest
2. Removing and installing storage compartment --> «Remote control storage tray, removing and installing»(ref-289229-S06613287072008062700000)

Wiring harness in backrest, removing and installing

The lower backrest cover must be removed to remove and install the wiring harness to Multimedia Display Unit 1 Y22.

Removing

1. Remove lower backrest cover --> «72 - SEAT - FRAMES»(ref-289222-S36188513802008062700000) .
2. Remove Multimedia Display Unit 1 Y22 in headrest --> «Monitors in headrests, removing and installing»(ref-289229-S33682674012008062700000) .

Wiring harness is routed in the headrest tube. If malfunctioning, the wire at lower connector must be disconnected.

1. Disconnect harness connector in seat at bottom and cut it off.

Note. Raise disconnected connectors. Use them for connector assignment.

Scheme 51

1. Remove cable clip - arrow - in headrest and pull wire - 2 - out of headrest tube - 1 -.

Installing

Wiring harness is supplied without the lower harness connector.

1. Feed free end of wire through the headrest tube and secure the wire - arrow -.
2. Install harness connector to other end of wire.

Terminal 10 is marked on the connector housing.

Scheme 52

Connector assignment

1 - Battery (+), red

2 - Common shielding, black

3 - IR-DATA, brown

4 - Video, white

5 - Video screen, black

6 - TXD, blue

7 - RXD, yellow

8-10 - not in use

1. Perform further installation in reverse order.

Note. Unlisted connector terminals are not assigned.

Scheme 53

Connectors

4 - Remote (not used)

5 - Video out 2 (not used)

6 - Video out 1 (yellow) to Multimedia Signal Splitter R181

7 - Audio out 1 (white, red) to Multimedia Signal Splitter R181

8 - SPDIF out (not used)

9 - Power supply (black) to Multimedia Signal Splitter R181

Note. Unlisted connector terminals are not assigned.

Scheme 54

Connectors

1. Connections to Multimedia Display Unit 1 Y22 (T10af)/ Left Multimedia Headphones R123 (T12ae) black
2. Connections to Multimedia Display Unit Y23 (T10ag)/ Right Multimedia Headphones R124 (T12af) black
3. DVC power, voltage supply (T4ai/T6ai) black to Rear DVD Changer R162
4. 8-pin multi-pin harness connector, CAN-Bus (not used)
5. Black 6-pin multi-pin harness connector (T6ah), voltage supply
6. Device fuse

The lower backrest cover must be removed to remove and install the wiring harness to Multimedia Display Unit 1 Y22.

Removing

1. Remove lower backrest cover --> «72 - SEAT - FRAMES»(ref-289222-S36188513802008062700000) .
2. Remove Multimedia Display Unit 1 Y22 in headrest --> «Monitors in headrests, removing and installing»(ref-289229-S33682674012008062700000) .

Wiring harness is routed in the headrest tube. If malfunctioning, the wire at lower connector must be disconnected.

1. Disconnect harness connector of black monitor wire in seat at bottom and cut it off.

Scheme 55

1. Remove cable clip - arrow - in headrest.

Scheme 56

1. Remove cable clips along the wire routing in seat backrest - arrows -.

Note. It is advantageous for the subsequent routing of the new wire to document (with photos or sketches) the wire routing in the seat backrest before removal.

The wire on the seat wiring harness is routed in the lower section of the seat.

1. Remove all cable clips here.

1. Pull wire - 2 - upward out of headrest tube - 1 -.

Installing

The wire is supplied without the lower harness connector.

1. Feed free end of wire - 2 - through the headrest tube - 1 - and secure the wire with a cable clip - arrow -.

Scheme 57

1. On the wire, mark the
2. Dimension - a - = 80 mm

and the

1. Dimension - b - = 230 mm

Dimensions represent the mounting points. Also see the "old" wire.

Scheme 58

1. Secure the wire at - dimension a - at top left spring - arrow 1 -.
2. Form a loop and secure wire at - dimension b - from behind on seat wiring harness - arrow 3 -.
3. Secure wire to backrest plate - arrow 2 -.
4. Pay special attention that the wire from outlet of headrest tube up to mount - arrow 2 - can follow the adjustment movements of the active headrest without jamming or stressing.

1. Continue routing wire at backrest and seat wiring harness - arrows - up to harness connector of seat wiring harness.

After completing work on the seat, the 12-pin harness connector is installed.

Connector assignment --> Monitor cable beneath seat, connector assignment

1. Perform further installation in reverse order.

Harness connectors on Rear View Camera System Control Module J772

Note. Unlisted connector terminals are not assigned.

Scheme 59

Connectors

A - Black 54-pin multi-pin harness connector (T54)

B - FBAS input (brown) from TV Tuner R78

C - FBAS output (green) to Front Information Display Control Head J685

D - FBAS input (gray) from Rear View Camera R189

A - 54-pin black multi-pin connector (T54)

39 - CAN-Bus Low (Comfort)

40 - CAN-Bus High (Comfort)

43 - Terminal 30

44 - Terminal 31

47 - Terminal 31 to Rear View Camera R189

48 - Voltage supply Rear View Camera R189

Scheme 60

1 - Front Information Display Control Head Control Module J523

1. Behind glove compartment

2 - Front Information Display Control Head J685

1. In center of instrument panel

3 - Rear View Camera R189

1. In rear lid next to handle
2. Removing and installing --> «Rear view camera R189 , removing and installing»(ref-289229-S35050934392008062700000)

4 - Rear View Camera System Control Module J772

1. Behind luggage compartment left side trim
2. Connector assignment --> «Harness connectors on Rear View Camera System Control Module J772»(ref-289229-S31709269182008062700000)
3. Removing and installing --> «Rear View Camera System Control Module J772 , removing and installing»(ref-289229-S29192176832008062700000)
