Steering Column Adjustment Switch, Removing and Installing

Special tools, testers and auxiliary items required

1. T8 screwdriver T40056 A

Removing

1. Remove drivers storage compartment --> «68 - INTERIOR EQUIPMENT»(/audi/s8/d3-2007-2011/remont/gauges-instrument-panels/#body-interior) .
2. Adjust steering wheel downward and to rear as far as possible, use entire adjustment range of steering column adjustment for this.

Scheme 274

1. Remove bolts - 3 - and - 4 - using T8 screwdriver T40056 A.
2. Remove TORX bolt - 5 -.
3. Disconnect upper trim - 2 - for steering column switch from lower trim - 1 - and remove both sections.
4. Disconnect electrical harness connector at lower trim.

Note. Steering wheel has been removed in illustration.

Scheme 275

1. Remove screws - arrows -.
2. Remove Steering Column Adjustment Switch E167 - item 1 - upward from bottom trim.

Installing

Install in reverse order of removal, observing the following

1. Install drivers storage compartment --> «68 - INTERIOR EQUIPMENT»(/audi/s8/d3-2007-2011/remont/gauges-instrument-panels/#body-interior) .
