Wiper/washer Systems (Cabriolet): Overview Audi S5 I facelift

Wiper/washer Systems 5 illustrations ~492 words

WINDSHIELD WIPER SYSTEM OVERVIEW

Observe notes on contact corrosion. Refer to CONTACT CORROSION .

Scheme 60

Scheme 60: WINDSHIELD WIPER SYSTEM OVERVIEW
Scheme 60: WINDSHIELD WIPER SYSTEM OVERVIEW
  1. Bolt Tightening sequence (Scheme 61)
  2. Windshield Wiper Motor With the wiper motor control module -J400- Removing and installing, refer to «WINDSHIELD WIPER MOTOR WITH CONTROL MODULE -J400»(ref-522414-S13515521382013011400000).
  3. Bolt Tightening sequence (Scheme 61)
  4. Nut 17 Nm
  5. Cap
  6. Windshield Wiper Arm, Passenger Side Different lengths. Removing and installing, refer to «WIPER ARM»(ref-522414-S35360853702013011400000). Adjusting, refer to «WIPER ARMS, ADJUSTING»(ref-522414-S01898369592013011400000).
  7. Windshield Wiper Blade, Passenger Side Different lengths. Replacing, refer to «WIPER BLADES, REPLACING»(ref-522414-S19324883562013011400000).
  8. Windshield Wiper Blade, Driver Side Different lengths. Replacing, refer to «WIPER BLADES, REPLACING»(ref-522414-S19324883562013011400000).
  9. Windshield Wiper Arm, Driver Side Different lengths. Removing and installing, refer to «WIPER ARM»(ref-522414-S35360853702013011400000). Adjusting, refer to «WIPER ARMS, ADJUSTING»(ref-522414-S01898369592013011400000).
  10. Cap
  11. Nut 17 Nm
  12. Bolt Tightening sequence (Scheme 61)
  13. Water Drain Channel

Scheme 61

Scheme 61
Scheme 61

Tighten the bolts -1, 2 and 3- in sequence in 2 stages as follows

Install by hand until snug.

Tighten to 8 Nm.

Scheme 62

Scheme 62: WASHER FLUID RESERVOIR, LINES AND NOZZLE OVERVIEW
Scheme 62: WASHER FLUID RESERVOIR, LINES AND NOZZLE OVERVIEW
  1. Bolt Tightening sequence (Scheme 63)
  2. O-ring Replace if damaged.
  3. Sealing Grommet Replace if damaged.
  4. Washer Fluid Fill Neck For the washer fluid reservoir. Removing and installing, refer to «WASHER FLUID RESERVOIR FILLER NECK»(ref-522414-S04152388502013011400000).
  5. Support Ring
  6. Nut Threaded connection shared with the tower brace. Tightening specifications, refer to «Description and Operation»(ref-522369-S16544826872013011400000).
  7. Cover For the fill neck.
  8. Washer Fluid Line For the windshield washer system.
  9. Right Spray Nozzle Depending on equipment, with the right washer nozzle heater -Z21-. Removing and installing, refer to «SPRAY NOZZLES»(ref-522414-S09602434972013011400000). Adjusting, refer to «WINDSHIELD SPRAY NOZZLES, ADJUSTING»(ref-522414-S35165425942013011400000).
  10. Left Spray Nozzle Depending on equipment, with the left washer nozzle heater -Z20-. Removing and installing, refer to «SPRAY NOZZLES»(ref-522414-S09602434972013011400000). Adjusting, refer to «WINDSHIELD SPRAY NOZZLES, ADJUSTING»(ref-522414-S35165425942013011400000).
  11. Washer Fluid Reservoir Removing and installing, refer to «WASHER FLUID RESERVOIR»(ref-522414-S36736953742013011400000).
  12. Headlamp Washer System Pump -V11
  13. Sealing Grommet
  14. Washer Fluid Line For the headlamp washer system.
  15. Retaining Ring For the windshield washer pump -V5-.
  16. Windshield Washer Pump -V5- Removing and installing, refer to «WINDSHIELD WASHER PUMP -V5»(ref-522414-S26816561212013011400000).
  17. Sealing Grommet
  18. Bolt Tightening sequence (Scheme 63)
  19. Sealing Grommet
  20. Windshield Washer Fluid Level Sensor -G33- Removing and installing, refer to «WINDSHIELD WASHER FLUID LEVEL SENSOR -G33»(ref-522414-S25716758732013011400000).

Scheme 63

Scheme 63
Scheme 63

Tighten the washer fluid bolts -3 and 4- in the sequence specified

Tighten the bolt -3- to 7 Nm.

Tighten the bolt -4- to 7 Nm.

Scheme 64

Scheme 64: HEADLAMP WASHER FLUID RESERVOIR, LINES AND NOZZLE OVERVIEW
Scheme 64: HEADLAMP WASHER FLUID RESERVOIR, LINES AND NOZZLE OVERVIEW
  1. Right Spray Nozzle Removing and installing, refer to «HEADLAMP WASHER SYSTEM SPRAY NOZZLES»(ref-522414-S24919085182013011400000) .
  2. Right Mount For the spray nozzle and headlamp.
  3. Washer Fluid Hose For the right spray nozzle. Secured on the bumper with cable ties.
  4. Left Mount For the spray nozzle and headlamp.
  5. Washer Fluid Reservoir
  6. Headlamp Washer System Pump -V11- Removing and installing, refer to «HEADLAMP WASHER PUMP -V11»(ref-522414-S22707254882013011400000) .
  7. Sealing Grommet For the headlamp washer pump -V11-.
  8. Washer Fluid Hose From the headlamp washer pump -V11-.
  9. Washer Fluid Hose To the spray nozzles.
  10. Left Spray Nozzle Removing and installing, refer to «HEADLAMP WASHER SYSTEM SPRAY NOZZLES»(ref-522414-S24919085182013011400000) .
  11. Washer Fluid Hose For the left spray nozzle.
  12. Impact Member
