Rear Doors (Cabriolet): Overview Audi S5 I facelift

Windows 3 illustrations ~150 words

Scheme 119

Scheme 119: WINDOW REGULATOR MOTOR AND WINDOW REGULATOR OVERVIEW
Scheme 119: WINDOW REGULATOR MOTOR AND WINDOW REGULATOR OVERVIEW
  1. Bolt Be sure to use the correct bolt version. (Scheme 120)3.5 Nm
  2. Nut 20 Nm
  3. Double Bolt For adjusting the window regulator.
  4. Bolt 8 Nm
  5. Mounting Piece For the side window Removing and installing. Refer to «SIDE WINDOW MOUNT»(ref-522433-S17455273882013011400000).
  6. Nut 8 Nm
  7. Window Regulator Removing and installing. Refer to «WINDOW REGULATOR»(ref-522433-S22069633992013011400000).
  8. Rear Window Regulator Left Rear Window Regulator Motor -V26- Right Rear Window Regulator Motor -V27- Removing and installing. Refer to «LEFT AND RIGHT REAR WINDOW REGULATOR MOTORS»(ref-522433-S28572215132013011400000).

Scheme 120

Scheme 120
Scheme 120
CAUTIONDanger of causing damage to the window regulator. Use self-tapping screws to attach the rear window regulator motor (included in the mounting kit) when replacing the window regulator. If a new window regulator motor is being installed, then use the standard screws (included in the mounting kit).

Scheme 121

Scheme 121: INNER WINDOW SHAFT STRIP AND OUTER/INNER WINDOW SHAFT STRIP OVERVIEW
Scheme 121: INNER WINDOW SHAFT STRIP AND OUTER/INNER WINDOW SHAFT STRIP OVERVIEW
  1. Left Inner Window Shaft Strip Removing and installing, refer to «INNER WINDOW SHAFT STRIP TRIM»(ref-522433-S16804611182013011400000) .
  2. Right Inner Window Shaft Strip Removing and installing, refer to «INNER WINDOW SHAFT STRIP TRIM»(ref-522433-S16804611182013011400000) .
  3. Right Outer/Inner Window Shaft Strip Removing and installing, refer to «OUTER/INNER WINDOW SHAFT STRIP»(ref-522433-S09159293702013011400000) .
  4. Left Outer/Inner Window Shaft Strip Removing and installing, refer to «OUTER/INNER WINDOW SHAFT STRIP»(ref-522433-S09159293702013011400000) .
