FASTENER TIGHTENING SPECIFICATIONS
| Component | Fastener Size | Nm |
|---|---|---|
| Door Glass to Window Regulator Bolts | 9 | |
| Rear Side Glass to Window Regulator Nuts | 6.5 | |
| Rear Side Window Glass Stop Nuts | 6 |
Scheme 68
Remove the door trim panel. Refer to Removal and Installation.
Remove the sealing plugs -2- and -4-.
Run the door window down until the bolts in the opening are visible.
Remove the screws -1- and loosen the screw -5- a few turns.
Note. Remove the rear bolt -1- completely. Otherwise, the door window cannot be removed.
Tilt the rear door window -3- toward the outside out of the mount in the clamping brackets.
Remove the door window upward out of the clamping bracket and remove it from the door -arrow-.
