Sunroof: Overview Audi S5 I facelift

Scheme 1

1. Glass Panel Removal «GLASS PANEL»(ref-520209-S33026878252012123100000)
2. Left/right boot Removal, refer to «BELLOWS»(ref-520209-S06193449432012123100000)
3. Inner trim Removing and installing, refer to «INTERIOR TRIM, REMOVING AND INSTALLING»(ref-520209-S10822257052012123100000)
4. Rear seal Self-adhesive: NOTE: The front and rear seals must be pressed on from the end caps outward towards the center. -- Tilt the glass panel. -- Remove the old seal from the glass panel and remove the adhesive residue completely. -- Clean adhesive surface with Cleaning Solution -D 009 401 04-. -- Apply bonding agent -D 009 200 02- to the adhesive surface and let it dry for 10 minutes. -- Remove the protective film from the adhesive tap and press it firmly onto the edge of the panel as shown.
5. Front seal Self-adhesive -- The glass panel is removed. NOTE: The front and rear seals have end caps. Press the seal on by pressing on the end caps and working toward the center. -- Remove the old seal from the glass panel and remove the adhesive residue completely. -- Clean adhesive surface with Cleaning Solution -D 009 401 04-. -- Apply bonding agent -D 009 200 02- to the adhesive surface and let it dry for 10 minutes. -- Remove the protective film from the adhesive tap and press it firmly onto the edge of the panel as shown.
6. Body seal For removal, the glass panel is removed and the seal is removed from the side body flange. Installing, refer to «BODY SEAL, INSTALLING»(ref-520209-S16390862662012123100000)
7. Bolt 2.5 Nm
8. Glide piece The sun shade is removed.
9. Mount Self-adhesive. To remove, warm the body using a hot air gun if necessary. -- Remove adhesive residue. NOTE: Adhesion surface must be free of dust and grease. -- Clean adhesive surface with Cleaning Solution -D 009 401 04-. -- Remove the protective film, position the mount with the front stop and press it only firmly.
10. Sun shade Removal: «SUN SHADE»(ref-520209-S15676746582012123100000) The glass panel is removed. The wind deflector is removed. CAUTION: Do not operate the sun shade when it is removed or it will be damaged and will have to be replaced.
11. Bolt 1 Nm
12. Wind deflector Removal item, refer to item 4 4
13. Bolt 1.5 Nm
