Convertible Top: Overview Audi S5 I facelift

TRIM AND DECORATIVE TRIM STRIP OVERVIEW

Convertible top compartment cover trim, decorative trim strip

Scheme 16

1. Nut For the correct tightening specifications, refer to «MOLDINGS AND TRIM OVERVIEW»(ref-522338-S22971202222013011400000).
2. Decorative Trim Strip For the convertible top compartment cover. Overview, refer to «MOLDINGS AND TRIM OVERVIEW»(ref-522338-S22971202222013011400000).
3. Clip For the convertible top compartment cover trim.
4. Bolt 2 Nm
5. Bolt 2 Nm
6. Left Trim For the anti-roll bar. Removing and installing, refer to «ROLLOVER PROTECTION TRIM»(ref-522389-S14587357372013011400000).
7. Right Trim For the anti-roll bar. Removing and installing, refer to «ROLLOVER PROTECTION TRIM»(ref-522389-S14587357372013011400000).
8. Bolt 2 Nm
9. Trim For the convertible top compartment cover. Removing and installing, refer to «TRIM»(ref-522389-S18042085592013011400000).

Convertible top compartment cover inner section, convertible top compartment cover outer section

Scheme 17

1. Stop For the convertible top compartment cover inner section.
2. Bolt 2 Nm
3. Frame For the convertible top compartment cover inner section.
4. Bolt 2 Nm
5. Convertible Top Compartment Cover Outer Section Removing and installing, refer to «OUTER SECTION»(ref-522389-S04474457892013011400000).
6. Bolt 2 Nm
7. Bracket For the antenna module. Removing and installing, refer to «Removal and Installation»(ref-522368-S20722761032013011400000).
8. Convertible Top Compartment Cover Inner Section Removing and installing, refer to «COVER»(ref-522389-S16847809972013011400000).
9. Service Cover For the antenna module.

Scheme 18

1. Convertible Top Compartment Cover Seal Removing and installing, refer to «SEAL»(ref-522389-S22147147392013011400000).
2. Small Seal Installation position, refer to «SEAL»(ref-522389-S22147147392013011400000).
3. Bolt 8 Nm
4. Small Seal Installation position, refer to «SEAL»(ref-522389-S22147147392013011400000).
5. Bolt 8 Nm

Convertible top compartment cover seal with auxiliary water drain hose

Scheme 19

1. Convertible Top Compartment Cover Seal Removing and installing, refer to «SEAL»(ref-522389-S22147147392013011400000).
2. Water Drain Hose Routing

Scheme 20

1. Bolt 30 Nm Quantity: 3
2. Convertible Top Main Bearing
3. Convertible Top Removing and installing, refer to «CONVERTIBLE TOP»(ref-522389-S27067047782013011400000).
4. Bolt 15 Nm Quantity: 3
5. Retaining Plate CAUTION: Leaks may occur if the convertible top is not in its originally installed position. Do not loosen the retaining plate as it cannot be adjusted with workshop tools.

Scheme 21

1. Bolt 2.5 Nm Quantity: 2
2. Front Trim Removing and installing, refer to «FRONT TRIM»(ref-522389-S11021389932013011400000).
3. Convertible Top Headliner Overview, refer to «HEADLINER, TENSION AND GUIDE CABLE OVERVIEW»(ref-522389-S35054583812013011400000).
4. Convertible Top Cover Removing and installing, refer to «COVER»(ref-522389-S02638034832013011400000).
5. Bolt 3 Nm
6. Bolt 3 Nm Quantity: 2
7. Center Trim Panel Removing and installing, refer to «CENTER TRIM»(ref-522389-S07772746412013011400000).

HEADLINER, TENSION AND GUIDE CABLE OVERVIEW

Convertible Top Headliner

Scheme 22

1. Convertible Top Frame With Convertible Top Cover
2. Convertible Top Headliner Removing and installing, refer to «HEADLINER»(ref-522389-S11885387862013011400000).
3. Convertible Top Seals
4. Convertible Top Frame Trim

Scheme 23

1. "Rail 2"
2. Center Guide Cable For C-pillar door
3. Diverting Eye For The Front Guide Cable On the C-pillar door near "Rail 2"
4. Rear Guide Cable For C-pillar door
5. Diverting Eye For The Center Guide Cable Rear on the C-pillar door
6. C-pillar Door
7. Front Guiding Eye
8. Convertible Top Cover Tensioning Cable
9. Front Diverting Eye For C-pillar door guide cable
10. Front Guiding Eye

Rear Tension and Guide Cables

Scheme 24

1. Center Guide Cable For C-pillar door
2. Tensioning Band
3. Tension Cable For C-pillar door
4. Guide Cable Diverting Eye
5. Rear Window Control Tension Cable
6. Tensioning Band
7. Tension Cable Pull-Spring
8. C-pillar Door Not a replacement part, part of the convertible top headliner service kit.
9. Tension Cable
10. Diverting Eye Center and rear guide cable on the C-pillar door.
11. Front Guiding Eye

Scheme 25

1. End Plate With left convertible top closed position switch -F411-, right convertible top closed position switch -F412-. Removing and installing, refer to «END PLATE»(ref-522389-S37253833972013011400000).
2. Bolt Quantity: 4 Replacing Tightening sequence (Scheme 26)
3. Convertible Top Lock With convertible top left lock switch -F169-, convertible top latch -open- switch -F294-. Are preset above the locking rods. Removing and installing, refer to «LOCK»(ref-522389-S39573582792013011400000).
4. Grommet Mounted to the back of the motor.
5. Convertible Top
6. Convertible Top Locking Motor -V223- Removing and installing, refer to «LOCKING MOTOR -V223»(ref-522389-S31208668582013011400000).
7. Convertible Top Latch Motor Removing and installing, refer to «LATCH DRIVE MOTOR»(ref-522389-S14996922352013011400000).
8. Bolt 9 Nm Quantity: 4
9. Bolt 10 Nm
10. Bolt 15 Nm Quantity: 3

Scheme 26

Tighten the bolts in the sequence -a through d- to 9 Nm.

Scheme 27

1. Center Seal Removing and installing, refer to «CENTER SEAL»(ref-522389-S36741181942013011400000).
2. Front Seal Removing and installing, refer to «FRONT SEAL»(ref-522389-S41886761562013011400000).
3. Bolt 5.5 Nm Quantity: 6
4. Retaining Strip For the front seal Removing and installing, refer to «FRONT SEAL»(ref-522389-S41886761562013011400000).
5. Rear Seal Removing and installing, refer to «REAR SEAL»(ref-522389-S13704258472013011400000).

Left Side Of The Vehicle

Scheme 28

1. Left Convertible Top Left Lock Switch -F169
2. Left Convertible Top Closed Position Switch -F411
3. Convertible Top Compartment Cover Locking Motor -V222- With convertible top compartment latch -unlocked- switch -F293-, convertible top compartment -locked- switch -F404-.
4. Left Convertible Top Compartment Cover Switch -F290- Removing and installing, refer to «CONVERTIBLE TOP COMPARTMENT SWITCHES -F407- / -F290»(ref-522389-S22407736782013011400000).
5. Convertible Top Compartment Open Switch -F407- Removing and installing, refer to «CONVERTIBLE TOP COMPARTMENT SWITCHES -F407- / -F290»(ref-522389-S22407736782013011400000).
6. Left Convertible Top Compartment Enclosure Switch -F402- Removing and installing, refer to «Removal and Installation»(ref-522378-S39340905702013011400000).
7. Left Tensioning Bow Switch -F409

Right Side Of Vehicle

Scheme 29

1. Convertible Top Open Position Switch -F171
2. Right Convertible Top Compartment Cover Switch -F291- Removing and installing, refer to «RIGHT CONVERTIBLE TOP COMPARTMENT COVER SWITCH -F291»(ref-522389-S22196577302013011400000).
3. Convertible Top Operation Control Module -J256- Removing and installing, refer to «CONVERTIBLE TOP CONTROL MODULE -J256»(ref-522389-S03902885382013011400000).
4. Right Convertible Top Compartment Enclosure Switch -F403- Removing and installing, refer to «Removal and Installation»(ref-522378-S39340905702013011400000).
5. Right Convertible Top Closed Position Switch -F412
6. Convertible Top Lock Switch (Open) -F294
7. Convertible Top Closed Position Switch -F202
8. Right Tensioning Bow Switch -F410
9. Upper Tensioning Bow Switch -F408

Scheme 30

1. Hydraulic Cylinder For The Right Bracket Overview, refer to «HYDRAULIC CYLINDER, CONVERTIBLE TOP CONTROL OVERVIEW»(ref-522389-S16259144662013011400000).
2. Hydraulic Cylinder For The Right Convertible Top Drive Overview, refer to «HYDRAULIC CYLINDER, CONVERTIBLE TOP CONTROL OVERVIEW»(ref-522389-S16259144662013011400000).
3. Rear Hydraulic Pipe The supply and return lines are supplied in pairs.
4. Hydraulic Cylinder For The Right Convertible Top Compartment Cover Overview, refer to «HYDRAULIC CYLINDER, CONVERTIBLE TOP COMPARTMENT COVER OVERVIEW»(ref-522389-S24658600902013011400000).
5. Upper Line Guide
6. Hydraulic Cylinder For The Left Convertible Top Compartment Cover Overview, refer to «HYDRAULIC CYLINDER, CONVERTIBLE TOP COMPARTMENT COVER OVERVIEW»(ref-522389-S24658600902013011400000).
7. Hydraulic Pump Overview, refer to «MOTOR OVERVIEW AND HYDRAULIC PUMP FLUID RESERVOIR»(ref-522389-S13796752262013011400000).
8. Hydraulic Cylinder For The Left Convertible Top Drive Overview, refer to «HYDRAULIC CYLINDER, CONVERTIBLE TOP CONTROL OVERVIEW»(ref-522389-S16259144662013011400000).
9. Lower Line Guide
10. Hydraulic Cylinder For The Left Bracket Overview, refer to «HYDRAULIC CYLINDER, CONVERTIBLE TOP CONTROL OVERVIEW»(ref-522389-S16259144662013011400000).
11. Front Hydraulic Line
