Bumpers Audi Q5 I

Scheme 15

1. Bumper Cover NOTE: Note different versions. The transport brace must be removed before painting and installing an S-line bumper. On some versions, the side parts of the bumper can be replaced individually. Refer to «BUMPER COVER SIDE COMPONENTS»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers__bumper-cover-side-components) . Before removing, the upper lock carrier cover must be removed. Refer to «LOCK CARRIER COVER»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers) -- Remove the upper screws -2- and the lower screws -6- on the end plate. Refer to «FRONT BUMPER COVER END PLATE»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers__front-bumper-cover-end-plate) . -- Loosen the wheel housing liner in the area of the screws -5-, push it back «PUSH BACK WHEEL HOUSING LINER»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers) and remove the screws -5-. -- Unclip cover sideways from the bracket on the transition to the fender. -- Pull the cover slightly forward and disconnect the connectors for the fog lamps and for the parking sensor, if applicable. -- Disconnect the headlamp washer system wire, if applicable. -- Remove the cover forward.
2. Bolt 4 Nm.
3. Noise Insulation
4. Fender Mount -- The bumper cover must engage between the mount and the fender when installed.
5. Bolt 2.5 Nm.
6. Bolt 5 Nm.
7. Spring Nut

Scheme 16

Remove the wheel housing liner screws and push it to the side.

Remove the cover screws.

Scheme 17

Remove the bumper cover. Refer to LOCK CARRIER COVER .

If the gap dimension is not even, loosen the adjusting screw -2-, adjust the cover and radiator grille -1- and then tighten the screw.

Check the gap dimension again and repeat the adjustment if necessary.

IMPACT BAR ASSEMBLY OVERVIEW

Scheme 18

1. Side Impact Bar Removing and Installing, refer to «IMPACT MEMBER»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers__impact-member)
2. Bolt 20 Nm
3. Bolt 4 Nm For attaching to the lock carrier
4. Right Impact Bar Bracket Removing and Installing, refer to «IMPACT MEMBER BRACKET»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers)
5. Right Support Piece
6. Lock Carrier
7. Bolt 8 Nm
8. Distance Regulation Control Module -J428
9. Left Support Piece
10. Left Impact Bar Bracket Removing and Installing, refer to «IMPACT MEMBER BRACKET»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers)
11. Bolt For attaching to the lock carrier 4 Nm

REAR BUMPER COVER ASSEMBLY OVERVIEW

Scheme 19

1. Rear Bumper Cover Removing and Installing, refer to «REAR BUMPER COVER»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers__rear-bumper-cover)
2. Bolt 1.5 Nm
3. Guide Piece Removing and Installing, refer to «GUIDE PIECE»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers)
4. Bolt 1.5 Nm
5. Clip
6. Side Impact Bar
7. Bolt 1.5 Nm
8. Spoiler Special equipment Removing and Installing, refer to «REAR SPOILER»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers)
9. Trim
10. Clips Unclip on both sides before removing the bumper cover to the rear.

BUMPER COVER TRANSPORT BRACE, S-LINE

Remove the transport brace -2- from the left -arrow- and right cover -1- before painting.

Scheme 20

Scheme 21

1. Bolt 2.5 Nm
2. Front Spoiler Bumper cover and end plate removed. -- Disengage the lower spoiler locking mechanisms one by one on the bumper and radiator grille and then remove the spoiler. -- All the locking mechanisms must engage correctly when installing the spoiler as illustrated -arrows-.
3. End Plate -- Remove the screws -1- and remove the end plate.
4. Bumper Cover

BUMPER COVER SIDE COMPONENTS

Note. In order to disassemble the individual components, the bumper cover must be completely removed.

Scheme 22

1. Front Spoiler Removal and Installation, refer to «FRONT SPOILER»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers)
2. Bolt 2.5 Nm
3. End Plate Removed with the bumper cover. Remove the screws on the spoiler and remove it to the rear.
4. Connection Clipped into the radiator grille at the bottom
5. Right Air Intake Grille To remove, insert a screwdriver an at angle from underneath into the opening on the top, pry it upward and loosen the cover. Beginning at the top of the radiator grille, remove the air intake grille from the cover.
6. Right Bumper Cover Remove the screws on the radiator grille, unclip the spoiler locking mechanisms at the bottom and remove it sideways from the connecting piece.
7. Radiator Grille Removal and Installation, refer to «RADIATOR GRILLE»(/audi/q5/i-2008-2012/remont/mirrors/#exterior-equipment)
8. Bolt 2.5 Nm
9. Left Bumper Cover Remove the screws on the radiator grille, unclip the spoiler locking mechanisms at the bottom and remove it sideways from the connecting piece.
10. Left Air Intake Grille Removal is the same as for the right grille

Scheme 23

1. Lock Carrier Cover Removing Remove the clamping pins for the expanding clips. Remove the expanding clips from the cover. Lift the rear cover and remove it from the radiator grille. Installing -- Install the cover on the radiator grille, install the expanding clips and push the screws all the way in.
2. Spreader Clip
3. Lock Carrier
4. Radiator Grille Removal and Installation, refer to «RADIATOR GRILLE»(/audi/q5/i-2008-2012/remont/mirrors/#exterior-equipment)

FRONT BUMPER COVER END PLATE

Removing

Scheme 24

Remove the bolts -1- and -2-.

Remove the end plate to the rear.

Installation

1. Tightening specifications, refer to «FRONT NOISE INSULATION ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/mirrors/#exterior-equipment) .

To install, perform the steps used in removal in reverse order.

Scheme 25

1. Nut 4 Nm Remove front bumper cover. Remove the nuts -1- and remove the front bracket.
2. Mount Removing
3. Headlamp Mount
4. Fender

AIR INTAKE GRILLE

Removing

Scheme 26

Open the locking mechanisms -arrow- with a screwdriver.

Remove the air intake grille -2- from the bumper cover -1-.

IMPACT MEMBER

Removing

Scheme 27

Note. Attach all cable ties at the same locations when installing.

Remove front bumper cover.

Disconnect the electrical connector -4- on the horns and free up the electrical wiring harness -3- on the horn bracket.

Free up the washer nozzle water drain hose by disconnecting the cable tie -1-.

Remove the bolts -arrows- and the bumper cover spacer -2-.

Remove the impact bar -5- from the mounts.

Installation

1. Tightening specifications, refer to «IMPACT BAR ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers__impact-bar-assembly-overview) .

Install the front bumper cover.

Scheme 28

1. Bolt 55 Nm
2. Side Impact Bar Removal and Installation, refer to «IMPACT MEMBER»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers__impact-member) .
3. Impact Member Bracket Removing -- Mark the installation position of the lock carrier bracket. -- Remove front bumper cover. -- Remove the impact member -2-. -- Remove the bolts -1-. -- Remove the locating bolt -4-. -- Remove the impact member bracket on the lock carrier. Installing Tightening specifications, refer to «IMPACT BAR ASSEMBLY OVERVIEW»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers__impact-bar-assembly-overview) . -- Install the impact member bracket according to the marking made during removal. -- Install the impact member. Refer to «IMPACT MEMBER»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers__impact-member) . -- Install the front bumper cover.
4. Locating Bolt 5 Nm

REAR BUMPER COVER

Removing

Scheme 29

Disconnect the electrical connector -1- on the parking aid control module, if applicable.

Free up the electrical wiring harness on the control module bracket -arrow- by disconnect the cable tie -2-.

Press the grommet -3- outward.

Remove the nuts -3- from the threaded pins on the cover -1-.

Scheme 30

Remove the screws -1- on the upper cover and at the bottom of the spoiler.

Scheme 31

Remove the bolts -1- on the lower bumper cover section.

Scheme 32

Unclip the left and right cover on the rear lid end piece. Refer to REAR BUMPER COVER ASSEMBLY OVERVIEW

Unclip the left and right cover from the guides.

Remove the cover to the rear from the vehicle.

When installing, the side catches on the guide piece -2- must engage completely into the bumper cover -1

Scheme 33

Connect the electrical connector on the parking aid control module if applicable. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Install the taillamps. Refer to [For engine(s) CAEB, CALB] Removal and Installation .

Scheme 34

1. Spoiler -- Remove the bolts -3-. -- To remove, release the catches -arrows- one by one and remove them from the bumper cover. -- When installing, the clips -arrow- must engage completely into the bumper cover.
2. Bumper Cover Installed
3. Bolt 1.5 Nm

Scheme 35

1. Bolt 1.5 Nm
2. Guide Piece Remove the rear bumper cover. Refer to «REAR BUMPER COVER»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers__rear-bumper-cover) . -- When installing, tighten in sequence A, B and C.
3. Clip

Scheme 36

1. Side Impact Bar For vehicles without a trailer hitch -- Remove the rear bumper cover. Refer to «REAR BUMPER COVER»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers__rear-bumper-cover) . -- Remove the bolts -1- by counterholding the nuts -3-. -- Remove the impact member.
2. Bolt 15 Nm
3. Nut 15 Nm
4. Left Impact Member Mount

Scheme 37

1. Impact Member Mounts Removing -- Remove the rear bumper cover. Refer to «REAR BUMPER COVER»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers__rear-bumper-cover) . -- Remove the tie-downs. Refer to «Removal and Installation»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . -- Loosen the left and right luggage compartment side trim in the rear area. Refer to «Removal and Installation»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . -- Remove the bolts -3- and remove the impact member and mounts.
2. Left Console
3. Bolt 40 Nm
4. Right Console

Scheme 38

1. Trailer Hitch with Crossmember Removing -- Remove the rear bumper cover. Refer to «REAR BUMPER COVER»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers__rear-bumper-cover) . -- Remove the tie-downs. Refer to «Removal and Installation»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . -- Loosen the left and right luggage compartment side trim in the rear area. Refer to «Removal and Installation»(/audi/q5/i-2008-2012/remont/exteriorinterior-trim/#interior-trim) . -- Remove the trailer hitch socket. Refer to «Removal and Installation»(/audi/q5/i-2008-2012/remont/door-locks-anti-theft-systems/#interior-lights-switches-general-information) . -- Remove the lever bracket. -- Disengage the cable on the ball head coupling. -- Remove the bolts -3- and remove the trailer hitch to the rear.
2. Release When installing, press the grommet correctly into the rear lid end piece.
3. Left Console
4. Bolt 60 Nm
5. Bolt 60 Nm
6. Window
7. Right Console

Hand Actuator Bracket

Scheme 39

1. Hand Actuator Bracket -- Remove the rear bumper cover. Refer to «REAR BUMPER COVER»(/audi/q5/i-2008-2012/remont/exterior-body-panels/#bumpers__rear-bumper-cover) . -- To remove, remove bolts -2-. -- Disengage the cable on the ball head coupling and pull it through toward the inside.
2. Internally Threaded Pop Rivet
3. D-Pillar
4. Bolt 8 Nm
5. Actuating l Lever -- To remove, pull off the circlip. -- When installing, the circlip must lock in the lever.
6. Securing Clip
7. Release When installing, the grommet must be installed correctly into the rear lid end piece.
8. Grommet
