Vibration damper, removing and installing

Removing

  1. Lock carrier pulled toward front --> «Lock carrier, pulling toward front»(ref-289202-S33545844662008062700000) .
  2. Ribbed belt removed --> «Ribbed belt, removing and installing»(ref-289202-S11016029762008062700000) .

Scheme 64

Scheme 64
Scheme 64
  1. Remove vibration damper of crankshaft after removing 8 attachment bolts - 1 -.

Installing

Installation is in reverse order of removal, note the following

Scheme 65

Scheme 65
Scheme 65
  1. When installing, make sure that notch - arrow - in vibration damper aligns with locating lug on toothed belt gear.

Torque specifications

ComponentNm
Vibration damper to crankshaft gear22

Scheme 66

Scheme 66: Toothed belt guards, assembly overview
Scheme 66: Toothed belt guards, assembly overview

1 - Plugs

2 - 43 Nm

3 - Bracket

  1. For Torque Support Valve N382

4 - Toothed belt guard, right

5 - Toothed belt guard, center

6 - Toothed belt guard, left

7 - Sleeve

8 - 10 Nm
