Lubrication system components, removing and installing

Note. If large quantities of metal shavings or abraded material are found in the engine oil while servicing the engine, the oil passages must be carefully cleaned to prevent resulting damage and the oil cooler must be replaced. The oil level must not be above the max. mark - danger of damage to catalytic converter!

Viscosity classes and oil specifications --> 01 - MAINTENANCE

Oil system capacity: Fluid Capacity Chart

Scheme 60

Scheme 60: Oil pump, lower section of oil pan, assembly overview

1 - Oil pan (lower section)

  1. Removing and installing --> «Lower part of oil pan, removing and installing»(ref-289202-S05682217252008062700000)
  2. With Oil Level Thermal Sensor G266

2 - 10 Nm

3 - Chain sprocket

  1. For oil pump
  2. Installed location: Side with writing points toward front
  3. Removing and installing --> Chain drive for oil pump, removing and installing --> «Oil pump drive sprocket, removing and installing»(ref-289202-S08935357682008062700000)

4 - 34 Nm

5 - Chain sprocket

  1. For crankshaft
  2. Removing and installing --> Chain drive for oil pump, removing and installing --> «Oil pump drive sprocket, removing and installing»(ref-289202-S08935357682008062700000)

6 - Drive chain for oil pump

  1. Removing and installing --> Chain drive for oil pump, removing and installing --> «Oil pump drive sprocket, removing and installing»(ref-289202-S08935357682008062700000)

7 - Chain tensioner

  1. Before removing, secure using piece of wire
  2. Do not disassemble
  3. Removing and installing --> Chain drive for oil pump, removing and installing --> «Oil pump drive sprocket, removing and installing»(ref-289202-S08935357682008062700000)

8 - Oil pump

  1. Do not disassemble
  2. With relief valve approx. 7 bar
  3. Removing and installing --> «Oil pump, removing and installing»(ref-289202-S04970350792008062700000)

9 - 30 Nm

10 - Oil strainer

  1. Clean if soiled

11 - Intake tube

12 - Circlip

13 - Oil baffle

14 - 10 Nm

  1. Different lengths

15 - 10 Nm

  1. Fasten diagonally in steps

16 - Seal

  1. Replace

17 - Oil drain plug, 50 Nm

18 - 10 Nm

19 - Oil Level Thermal Sensor G266

  1. Removing and installing --> «Oil Level Thermal Sensor G266 , removing and installing»(ref-289202-S21376439762008062700000)

20 - Seal

  1. Replace

Draining

Note. Before raising the vehicle on a hoist (wheels off the ground), first activate the vehicle jack mode --> 43 - SELF LEVELING SUSPENSION . Drained coolant must be stored in a clean container for disposal or reuse.

CAUTIONCover cap of expansion tank with rag and open carefully, as hot steam i.e. hot coolant may escape when opening.
  1. Open cap of coolant expansion tank.

For vehicles with parking/auxiliary heater

  1. Remove bolts - arrows - for exhaust pipe of parking heater/auxiliary heater on noise insulation.

All

  1. Loosen mounting parts - 1 - and remove noise insulation.
  2. Place drip tray VAS 6208 under engine.

Scheme 61

Scheme 61
  1. Disconnect coolant hose - 1 - to drain coolant.
  2. Open drain plug - 2 - at oil filter bracket and drain coolant from engine at right.
  1. Open drain plug - arrows - and drain coolant from engine at left.
