Engine Coolant Temperature Sensor, Connector Assignment Audi A8 D3 рестайлинг

Engine Coolant Temperature Sensor, Connector Assignment

Special tools, testers and auxiliary items required

Scheme 92

1. Assembly tool T10118

Procedure

1. Disconnect electrical connector at Engine Coolant Temperature (ECT) Sensor G62

1. Vehicles with 4.2L MPI engine --> «Coolant Temperature Sensor Electrical Connector, 4.2L MPI, Disconnecting»(/audi/a8/d3-2005-2007/remont/cruise-control-systems/#electrical-equipment) .
2. Vehicles with 4.2l FSI engine --> «Coolant Temperature Sensor Electrical Connector, 4.2L FSI, Disconnecting»(/audi/a8/d3-2005-2007/remont/cruise-control-systems/#electrical-equipment__coolant-temperature-sensor-electrical-connector-42l) .
3. Vehicles with 5.2l FSI engine --> «Coolant Temperature Sensor Electrical Connector, 5.2L FSI, Disconnecting»(/audi/a8/d3-2005-2007/remont/cruise-control-systems/#electrical-equipment) .
4. Vehicles with 6.0l MPI engine --> «Coolant Temperature Sensor Electrical Connector, 6.0L MPI, Disconnecting»(/audi/a8/d3-2005-2007/remont/cruise-control-systems/#electrical-equipment__coolant-temperature-sensor-electrical-connector-60l) .

Terminal assignment of the 2-pin harness connector at Engine Coolant Temperature (ECT) Sensor G62

Scheme 93

1. Sensor ground (GND)
2. Wire connection from Engine Coolant Temperature (ECT) Sensor G62 to engine control module

> Coolant Temperature Sensor Electrical Connector, 4.2L MPI, Disconnecting

> Coolant Temperature Sensor Electrical Connector, 4.2L FSI, Disconnecting

> Coolant Temperature Sensor Electrical Connector, 5.2L FSI, Disconnecting

> Coolant Temperature Sensor Electrical Connector, 6.0L MPI, Disconnecting

Scheme 94

Procedure

1. Remove rear engine cover - arrows -.

Scheme 95

1. Disconnect electrical connector on Engine Coolant Temperature (ECT) Sensor G62 - arrow - with Assembly Tool T10118.

Note. For the clarity, depicted without engine.

Install in reverse order.
