Component Layout Audi A8 D3

Mechanical 1 illustration ~148 words
CAUTIONDO NOT overfill oil past the MAX mark on the oil dipstick. Damage to the Three Way Catalytic Converter (TWC) could result.

Note. Always replace gaskets and seals.

Note. The following list refers to items in see scheme 189.

  1. Oil pan - lower section
  2. 10 Nm (7ft lb)
  3. Oil pan - upper section
  4. 10 Nm (7 ft lb)
  5. Grid section
  6. Circlip
  7. Rubber tube
  8. Strainer
  9. Oil pump Removing, see «REMOVING»(ref-196865-S33364345952005100900000) If faulty, always replace whole pump
  10. 25 Nm (18 ft lb)
  11. Baffle plate
  12. Oil level sensor
  13. 35 Nm (26 ft lb)
  14. 25 Nm (18 ft lb)
  15. 10 Nm (7 ft lb)
  16. 25 Nm (18 ft lb)
  17. 60 Nm (44 - ft lb) + additional 90° Apply sealant D 454 300 02 before inserting ALWAYS REPLACE
  18. Plate
  19. Drive plate When assembling, make sure that dowel for ignition timing is correctly inserted in drive plate. Dowel should project 20 to 22mm (0.78 to 0.86 in.) from drive plate
  20. 10 Nm (7 ft lb)
  21. Rear sealing flange with oil seal

Scheme 171
