Maintenance: Diagnosis Audi A8 D2 facelift

Procedures 24 illustrations ~1314 words

Connecting VAG1551 Scan Tool

  1. Apply parking brake and move selector lever into position "P" or "N."
  2. Connect VAG1551 (VAG1552) Scan Tool to 16-pin Data Link Connector (DLC) to left of steering column, using adapter cable VAG1551/3.

Checking DTC memory

  1. Start engine and run at idle speed.
  2. Depress brake pedal once, briefly.
  3. Press "Print" button to turn printer on.
  4. Press button -1- to select "Rapid data transfer" operating mode 1.
  5. Press button -0- twice to insert "Automatic Test Sequence" address word 00.
  6. Press -Q- button to confirm input (VAG1551 Scan Tool sends all known address words one after the other).

If a control module answers with its identification, the number of stored DTCs or "No DTC recognized" is displayed. Any DTCs stored are then displayed and printed out one after the other. The VAG1551 Scan Tool then sends the next address word.

Indicated on display 1) (automatic test sequence is ended)

1) Two operating modes are displayed alternately.

  1. Switch ignition off.

If DTCs are stored, appropriate repairs must then be carried out. The printed log must be retained by the Service Department.

Note. The VAG1551 Scan Tool must remain connected for adapting SRI displays and for performing any required emissions test.

Scheme 5

Scheme 5
Scheme 5

Connecting VAG1551 Scan Tool, adapting SRI displays

  1. Apply parking brake and move selector lever into position "P" or "N."
  2. Connect VAG1551 (VAG1552) Scan Tool to 16-pin Data Link Connector (DLC) to left of steering column, using adapter cable VAG1551/3.
  3. Switch ignition on.
  4. Press button -1- to select "Rapid data transfer" operating mode 1.
  5. Press buttons -1- and -7- to insert "Instrument Cluster" address word 17.
  6. Press -Q- button to confirm input.
  7. Advance through program sequence using --> button.
  8. Press buttons -1- and -0- to select "Adaptation" function 10.
  9. Press -Q- button to confirm input.

Scheme 6

Scheme 6: Adapting SRI Oil service display, channel 05
Scheme 6: Adapting SRI Oil service display, channel 05

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10
  1. Press buttons -0- and -5- to select channel 05.
  2. Press -Q- button to confirm input. Indicated on display (distance remaining until "Oil service" is displayed). Example: 1 (00001) corresponds to 1000 km (620 mi.).
  3. Advance through program sequence using --> button. Indicated on display
  4. Input 5 digit adaptation value 00012, corresponding to 12,000 km (7,500 mi.) until next oil change service.
  5. Press -Q- button to confirm input. NOTE: If an incorrect entry is made, the "Adaptation" function is ended and must be initiated again. Indicated on display
  6. Press -Q- button to confirm input. Indicated on display
  7. Press -Q- button to confirm. Indicated on display
  8. Press => button to end coding. Indicated on display. Adaptation of channel 05 is ended.

Scheme 11

Scheme 11: Adapting SRI Inspection 1 display, channel 06 (distance)
Scheme 11: Adapting SRI Inspection 1 display, channel 06 (distance)

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16
  1. Press buttons -0- and -6- to select channel 06.
  2. Press -Q- button to confirm input. Indicated on display (distance remaining until "In 1" is displayed). Example: 1 (00001) corresponds to 1000 km (620 mi.).
  3. Advance through program sequence using --> button. Indicated on display
  4. Input 5 digit adaptation value 00024, corresponding to 24,000 km (15,000 mi.) until next Inspection 1.
  5. Press -Q- button to confirm input. NOTE: If an incorrect entry is made, the "Adaptation" function is ended and must be initiated again. Indicated on display
  6. Press -Q- button to confirm input. Indicated on display
  7. Press -Q- button to confirm. Indicated on display
  8. Press => button to end coding. Indicated on display. Adaptation of channel 06 is ended.

Scheme 17

Scheme 17: Adapting SRI Inspection 1 display, channel 07 (time)
Scheme 17: Adapting SRI Inspection 1 display, channel 07 (time)

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22
  1. Press buttons -0- and -7- to select channel 07.
  2. Press -Q- button to confirm input. Indicated on display (number of days remaining until "In 1" is displayed). Example: 1 (00001) corresponds to 10 days.
  3. Advance through program sequence using --> button. Indicated on display
  4. Input 5 digit adaptation value 00036, corresponding to 365 days until next Inspection 1.
  5. Press -Q- button to confirm input. NOTE: If an incorrect entry is made, the "Adaptation" function is ended and must be initiated again. Indicated on display
  6. Press -Q- button to confirm input. Indicated on display
  7. Press -Q- button to confirm. Indicated on display
  8. Press => button to end coding. Indicated on display. Adaptation of channel 07 is ended.

Scheme 23

Scheme 23: Adapting SRI Inspection 2 display, channel 08 (time)
Scheme 23: Adapting SRI Inspection 2 display, channel 08 (time)

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28
  1. Press buttons -0- and -8- to select channel 08.
  2. Press -Q- button to confirm input. Indicated on display (number of days remaining until "In 2" is displayed). Example: 37 (00037) corresponds to 370 days.
  3. Advance through program sequence using --> button. Indicated on display
  4. Input 5 digit adaptation value 00073, corresponding to 730 days until next Inspection 2.
  5. Press -Q- button to confirm input. NOTE: If an incorrect entry is made, the "Adaptation" function is ended and must be initiated again. Indicated on display
  6. Press -Q- button to confirm input. Indicated on display
  7. Press -Q- button to confirm. Indicated on display
  8. Press => button to end coding. Indicated on display. Adaptation of channel 08 is ended.

Testing

  1. Measure voltage between pole terminals using digital multimeter. If multimeter indicates 12.5 volts or more, battery is OK If voltage is below 12.5 volts, cause must be determined

Engine and engine compartment, visual inspection

  1. Inspect engine and engine compartment for leaks and damage.
  2. Inspect lines, hoses and connections of fuel, brake, cooling and heating systems for leaks, chafing, porosity and deterioration.

Brake system, visual inspection

  1. Inspect brake master cylinder, brake servo unit, hydraulic unit, and brake calipers for leaks and damage.
  2. Make sure that brake hoses are not twisted.
  3. Make sure that brake hoses do not make contact with any parts of car when steering is at full lock.
  4. Inspect brake hoses for porosity, deterioration, and chafing.
  5. Make sure that brake line connections and attachments are correctly seated and free of leaks and corrosion.
CAUTIONRepair any malfunctions found.

Underbody sealant, visual inspection

  1. During inspection, pay attention to underside of floor, wheel arches and sills.

Any damage to the underbody sealant must be repaired.

Inspection service

  1. Check tires for scuffing, increased tread wear on one side, porous side walls, cuts and fractures and advise customer of any problems found.

Front tire tread wear patterns indicate the following problems

  1. Feathering on tread: incorrect toe setting
  2. Increased tread wear on one side: incorrect camber setting

If wear of this nature is noticed, the cause should be determined by checking the wheel alignment.

  1. The brake fluid level should always be assessed relative to brake pad wear. A slight drop in the fluid level occurs as a result of wear and automatic adjustment of the brake pads.
  2. If the fluid level is at the MIN marking or slightly above, it is not necessary to add fluid if the brake pad wear limit has nearly been reached.
  3. If the brake pads are new or far from being at their wear limit, the fluid level should be between the MIN and MAX markings.
  4. If the fluid level has dropped below the MIN marking, it is necessary to inspect the brake system before topping off the brake fluid.

Road test

The following checks should be carried out in accordance with the vehicle equipment and the road conditions available (i.e. urban or rural) during the road test.

Inspection

  1. Inspect RAPGARD(R) for damage or peeling.

If RAPGARD(R) is disturbed (dented, scratched, etc.)

  1. You must note the damage on the Carrier Delivery Receipt, including damage type, extent and location. Failure to note damage on the Carrier Delivery Receipt will result in nonpayment of the repair.

Note. RAPGARD(R) must be removed from the vehicle no later than six months after application. See sticker (location on vehicle body varies) for detailed information.

Within 72 Hours prior to delivery to the Customer

  1. Remove RAPGARD(R) from vehicle.
  2. Wash vehicle exterior.
  3. Inspect paint surfaces, moldings and glass.
  4. Protect the paint surface of all new vehicles by applying 3M Perfect-It(tm) Paste Wax (3M Part No. 39526) or equivalent.

RAPGARD(R), paint inspection after removal

  1. Inspect painted surfaces under one of the following lighting conditions
  1. Indoors under fluorescent lighting.
  2. Outdoors under bright sunlight.
