Air Conditioning: Wiring Audi A8 D2 facelift

Air distribution, schematic diagram

Note. For locations of individual components, see AUTOMATIC CLIMATE CONTROL COMPONENTS IN ENGINE COMPARTMENT, SERVICING .

Note. The following lists refers to items in see scheme 119.

1. Engine compartment (plenum)
2. Passenger compartment
3. Air conditioner

1. Dust and pollen filter Installed in front flap
2. Fresh air blower -V2
3. Evaporator

1. D1 - Left heater core (driver side)
2. D2 - Right heater core (passenger side)
3. E1 - Left mixing chamber
4. E2 - Right mixing chamber
5. F - Air guide to center air outlet at rear
6. G1 - To left footwell air outlets Driver and rear footwell
7. G2 - To right footwell air outlets Passenger and rear footwell
8. H1 - To left instrument panel air outlet and to B-pillar left air outlet
9. H2 - To right instrument panel air outlet and to B-pillar right air outlet
10. J - To defroster outlets
11. K - To center instrument panel air outlet
12. L - Air intake duct for recirculating air mode

1. Air flow flap motor -V71- Flap closes completely in recirculating air and ACF mode and also partially at higher speeds (program controlled)
2. Recirculation flap motor -V113- Flap opens in recirculating air mode
3. Center vent adjusting motor -V102- Flap can be opened or closed by adjusting potentiometer in center air outlet -G142 (program-controlled) If flap is open, cold air is blended with air flowing out of center instrument panel outlets
4. Temperature regulator flap motor -V68- Flap can be opened or closed by adjusting center vent position sensor -G142- (program-controlled) If flap is closed, only cold air flows out of center instrument panel air outlets (see item 3)
5. Defroster flap motor - V107
6. Left footwell flap motor - V108
7. Right footwell flap motor -V109
8. Left center vent motor -V110
9. Right center vent motor -V111
10. Rear footwell vent motor -V112
11. ACF flap motor -V114- In preparation
12. Left vent temperature sensor -G150
13. Left vent temperature sensor -G150

Scheme 12
