Air Conditioning: Component Locations Audi A8 D2 facelift

Special tools and equipment

1. Hose clamps 3093 or 3094
2. VAG1306 drip tray
3. Compressed air gun, standard

See PASSENGER-SIDE HEATER CORE, REMOVING AND INSTALLING .

See DRIVER-SIDE HEATER CORE, REMOVING AND INSTALLING .

Making special tool

1. Bend wire (3 mm diameter) as shown. Size x = 6 mm (0.24)

Note. For removing the instrument panel air outlet.

Scheme 13

Scheme 14

1. Remove glove box or shelf on driver side, respectively See «INTERIOR TRIM»(ref-196887) .
2. Remove screw -A-.
3. Use special tool to pull air outlet out of instrument panel.

Scheme 15

1. Remove lower air outlet in right or left of instrument panel.
2. Loosen screw -A-.
3. Pull the outlet out of the instrument panel.
