LOCKING CABLE Audi A6 C5 рестайлинг

Servicing - A/t (01l, Awd) 4 illustrations ~331 words

LOCKING CABLE

WARNINGVehicle is equipped with Supplemental Inflatable Restraint (SIR) system. When servicing vehicle, use care to avoid accidental air bag deployment. SIR system-related components are located in various locations throughout interior and exterior of vehicle, depending on application. Do not use electrical test equipment on or near these circuits. If necessary, deactivate SIR system before servicing components. See appropriate AIR BAG DEACTIVATION PROCEDURES article in GENERAL INFORMATION.
CAUTIONOn vehicles equipped with Audi Telematics by OnStar(R), switch-off emergency (back-up) battery for Telematic/Telephone Control Module prior to disconnecting vehicle battery.
CAUTIONObtain anti-theft radio security code prior to disconnecting battery.

Note. Locking cable must always be adjusted in installation position.

Scheme 82

Scheme 82: 01L Transaxle
Scheme 82: 01L Transaxle
  1. Remove selector lever handle. See «SELECTOR LEVER HANDLE»(/audi/a6/c5-2001-2004/remont/automatic-trans/#servicing-at-01l-awd).
  2. Shift selector lever to "P" position. Loosen bolt (6). (Scheme 85) Clamp (3) must be movable by hand in direction of arrow (5).
  3. Move steering column to lowest position. Insert gage (3352 A) between lever for lock cable and lock cable eye. Pull lock cable in direction of arrow (5), and tighten bolt (6) with 89 INCH lbs (10 N.m). Remove adjustment gage (4). Check ignition key removal lock after every adjustment of lock cable. See «IGNITION KEY REMOVAL LOCK»(/audi/a6/c5-2001-2004/remont/automatic-trans/#servicing-at-01l-awd__ignition-key-removal-lock) under INSPECTION.
  4. Reinstall all components. See «SELECTOR LEVER HANDLE»(/audi/a6/c5-2001-2004/remont/automatic-trans/#servicing-at-01l-awd). Tighten all nuts and bolts to specification. See «TORQUE SPECIFICATIONS»(/audi/a6/c5-2001-2004/remont/automatic-trans/#servicing-at-01l-awd__torque-specifications).

Scheme 83

Scheme 83: 01L Transaxle (Checking & Adjusting)
Scheme 83: 01L Transaxle (Checking & Adjusting)

Scheme 84

Scheme 84
Scheme 84

Scheme 85

Scheme 85
Scheme 85
  1. Shift selector lever to "P" position. Raise and support vehicle. Remove heat shield at selector lever cable. Pry off selector lever cable using lever (80-200) from lever and selector shaft (arrow). (Scheme 86)
  2. Move selector lever from "P" to "2" position. Shift mechanism and selector lever cable must move easily. If necessary, replace selector lever cable or repair shift mechanism. Shift selector lever to "P" position. When moving shift lever and selector shaft to "P" position, parking lock must engage. Both front wheels must not turn in one direction. If selector lever cable is not able to attach selector lever cable to selector shaft, adjust selector lever cable.
  3. Remove selector lever cable from lever/selector shaft. Shift selector lever to "P" position. When selector lever and selector shaft are moved to "P" position, parking lock must be engaged and front wheels must not turn in one direction. Loosen bracket nuts (arrows) on transmission. (Scheme 87)
  4. Attach selector lever cable on lever/selector shaft. Straighten selector lever cable at bracket (B). (Scheme 88) Install heat shield (A). Tighten bolts (2 and 3) at bracket. Check shift mechanism. See «SHIFT MECHANISM»(/audi/a6/c5-2001-2004/remont/automatic-trans/#servicing-at-01l-awd__shift-mechanism) under INSPECTION. Install all components. Tighten all nuts and bolts to specification. See «TORQUE SPECIFICATIONS»(/audi/a6/c5-2001-2004/remont/automatic-trans/#servicing-at-01l-awd__torque-specifications).
