Component locations

Note. The following list refers to items in (Scheme 296).

1. Right front air strut
2. Operating unit
3. Right rear air strut
4. Right rear level control system sensor -G77
5. Control module Removing, see «LEVEL CONTROL SYSTEM CONTROL MODULE -J197- (ALLROAD)»(/audi/a6/c5-2001-2004/remont/electronic-suspension/#self-leveling-suspension) Installing, see «LEVEL CONTROL SYSTEM CONTROL MODULE -J197- (ALLROAD), INSTALLING»(/audi/a6/c5-2001-2004/remont/electronic-suspension/#self-leveling-suspension)
6. Pressure reservoir Assembly overview, see «PRESSURE RESERVOIR, ASSEMBLY OVERVIEW»(/audi/a6/c5-2001-2004/remont/electronic-suspension/#self-leveling-suspension__pressure-reservoir-assembly-overview)
7. Left rear level control system sensor -G76
8. Left rear air strut
9. Air supply unit with: Compressor Solenoid for level control system -N111- Lateral check-valves Level Control Pump Temperature Sensor -G290- Level Control Pressure Sensor-G291- Auxiliary noise insulation Component overview, see «COMPRESSOR (ALLROAD)»(/audi/a6/c5-2001-2004/remont/electronic-suspension/#self-leveling-suspension)
10. Electric/pneumatic lines
11. Left front air strut
12. Left front level control system sensor -G78
13. Right front level control system sensor -G289

Scheme 295
